10W隔离升降压型DC-DC电源 DM41-10W1212B1技术手册

产品特性—————————————————◆ 额定输出功率：10W ； ◆ 转换效率高达82%； ◆ 输入电压：56～700VDC ； ◆ 工作温度：-40℃～+85℃； ◆ Enable (EN)控制功能 ； ◆ 隔离电压：4000VAC ；◆ 可持续短路并自恢复、输入过压和输出过流保护。

PD2IHBXXD-10W产品说明—————————————————PD2IHBXXD-10W 系列电力电源模块是针对最新《国家电网标准》设计，应用在公变终端、专变终端、大客户终端、变电站终端的专用电力电源模块.可在56-700VDC 超宽输入电压下工作，符合额定电压：380/220VAC(三相四线)、任接2根线工作的供电要求。

在供电系统发生故障时产生的输入电压高达500VAC 的情况下仍可连续工作，使用该电源模块可以很容易满足《国家电网标准》。

注：（1）输入电压不能超过所规定范围值，否则可能会造成永久性不可恢复的损坏；（2）如无特殊说明，本手册中的参数均为25℃，湿度<75%，310VDC标称输入和CC模式满载输出下测得；（3）输出纹波噪声采用靠接测试法，靠接测试两端点的间距小于5mm；（4）EN引脚悬空模块默认有输出，关闭电平是指使模块停止输出时EN脚的引脚电平；（5）额定电流是指模块长期稳定工作的输出电流，最大输出电流是指模块短时间内可稳定输出的峰值电流，但不可长时间持续工作，以免引起模块内部重要器件加速老化。

产品特性曲线注：以上所得数据均为应用电路图1所示电路以及使用AC 电源测得，元件参数均为推荐值。

注：尺寸单位：mm(inches)端子直径公差：±0.10mm(±0.004inches)未标注之公差：±0.50mm(±0.020inches)包装说明包装纸盒大小：L ×W ×H=269×254×127mm每个纸盒包装数量：60PCS电路设计与应用图1 单相电源典型应用电路（全波整流）图2 三相三线典型应用电路（全波整流） 图3 三相四线典型应用电路（全波整流）图 4单相电高规EMC 应用电路（全波整流）该模块为超宽压DC 输入电力电源，故应用在AC 输入的条件下需参考图1~图4所示电路对输入电压进行整流滤波以及外围防护，必要时可加入防雷管、TVS 管等保证输入电压峰值小于800VDC 和初级干扰对次级的影响，为了防止模块失效对电网造成影响和产生安全隐患，应该在电路中加入保险丝，同时模块需要外接输出电容才可正常工作，故输出滤波电路推荐如图1所示的π型滤波，由于每个型号对输出电容要求不同，滤波元件参数请参考下图表1所示。
