PC3H3 Series
PC3H3 Series
∗
4-channel package type is also available. (model No. PC3Q63)
Mini-flat Half Pitch Package, High CMR, AC Input Photocoupler
PC3H3 Series
Model No.
Please contact a local SHARP sales representative to inquire about production status and Lead-Free options.
Sheet No.: D2-A01301EN
■ Outline Dimensions
Rank mark SHARP mark "S" Primary side mark 1.27±0.25
1
(Unit : mm)
Date code
4
2.6±0.3
3H3
4.4±0.2 0.4±0.1
2 3
5.3±0.3 (1.7) 0.2±0.05 0.1±0.1 2.0±0.2 Epoxy resin
0.4 0.5+ −0.2 0.2 7.0+ −0.7
*( ) : Reference dimensions
Product mass : approx. 0.05g
Sheet No.: D2-A01301EN
2
元器件交易网
Date code (2 digit)
1st digit Year of production A.D Mark 2002 A 2003 B 2004 C 2005 D 2006 E 2007 F 2008 H 2009 J 2010 K 2011 L 2012 M · · N · 2nd digit Month of production Month Mark January 1 February 2 March 3 April 4 May 5 June 6 July 7 August 8 September 9 October O November N December D
5
元器件交易网
Fig.1 Test Circuit for Common Mode Rejection Voltage
PC3H3 Series
(dV/dt)
VCM RL VO VCC VCM : High wave pulse RL=470Ω VCC=9V VO (Vcp Nearly = dV/dt×Cf×RL) 1) Vcp : Voltage which is generated by displacement current in floating capacitance between primary and secondary side. 1) Vo Vnp
Conditions IF=±20mA V=0, f=1kHz VCE=50V, IF=0 IC=0.1mA, IF=0 IE=10µA, IF=0 IF=±1mA, VCE=5V IF=±20mA, IC=1mA DC500V, 40 to 60%RH V=0, f=1MHz
Output
Output
Notice The content of data sheet is subject to change without prior notice. In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
VCM
Fig.2 Forward Current vs. Ambient Temperature
50
Fig.3 Diode Power Dissipation vs. Ambient Temperature
100 Diode power dissipation P (mW)
Forward current IF (mA)
Transfer characteristics
VCE=2V, IC=2mA, RL=100Ω Ta=25˚C, RL=470Ω, VCM=1.5kV(peak), IF=0, VCC=9V, Vnp=100mV
MIN. − − − *5 80 6 0.2 − 5×1010 − − − 10
TYP. 1.2 30 − − − − 0.1 1×1011 0.6 4 3 −
■ Description
PC3H3 Series contains a IRED optically coupled to a phototransistor. It is packaged in a 4-pin Mini-flat, Half pitch type. Input-output isolation voltage(rms) is 2.5kV. Collector-emitter voltage is 80V(∗) and CMR is MIN. 10kV/µs.
Sheet No.: D2-A01301EN
4
元器件交易网
■ Model Line-up
Package Taping 3 000pcs/reel PC3H3 PC3H3A PC3H3B Rank mark with or without A B IC [mA] (IF=±1mA, VCE=5V, Ta=25˚C) 0.2 to 4.0 0.5 to 1.5 1.0 to 2.5
(*) Up to Date code "P9" (September 2002) VCEO : 35V. From the production Date code "J5" (May 1997) to "P9" (September 2002), however the products were screened by BVCEO≥70V.
1
Sheet No.: D2-A01301EN Date Sep. 30. 2003 © SHARP Corporation
元器件交易网
■ Internal Connection Diagram
1
1 4
PC3H3 Series
2 3
2
3
4
Anode / Cathode Cathode / Anode Emitter Collector
Japan
Rank mark
Refer to the Model Line-up table
Sheet No.: D2-A01301EN
3
元器件交易网
■ Absolute Maximum Ratings
Parameter Symbol IF Forward current *1 Peak forward current IFM P Power dissipation Collector-emitter voltage VCEO Emitter-collector voltage VECO IC Collector current Collector power dissipation PC Ptot Total power dissipation Topr Operating temperature Tstg Storage temperature *2 Isolation voltage Viso (rms) *3 Soldering temperature Tsol Rating ±50 ±1 70 *4 80 6 50 150 170 −30 to +100 −40 to +125 2.5 260 Input (Ta=25˚C) Unit mA A mW V V mA mW mW ˚C ˚C kV ˚C
