机械毕业设计英文外文翻译436手动变速器 (2)

附录How Manual Transmissions WorkIf you drive a stick-shift car, then you may have several questions floating in your head.How does the funny "H" pattern that I am moving this shift knob through have any relation to the gears inside the transmission? What is moving inside the transmission when I move the shifter?When I mess up and hear that horrible grinding sound, what is actually grinding? What would happen if I were to accidentally shift into reverse while I am speeding down the freeway? Would the entire transmission explode?In this article, we'll answer all of these questions and more as we explore the interior of a manual transmission.Cars need transmissions because of the physics of the gasoline engine. First, any engine has a redline --a maximum rpm value above which the engine cannot go without exploding. Second, if you have read How Horsepower Works, then you know that engines have narrow rpm ranges where horsepower and torque are at their maximum. For example, an engine might produce its maximum horsepower at 5,500 rpm. The transmission allows the gear ratio between the engine and the drive wheels to change as the car speeds up and slows down. You shift gears so the engine can stay below the redline and near the rpm band of its best performance.Ideally, the transmission would be so flexible in its ratios that the engine could always run at its single, best-performance rpm value. That is the idea behind the continuously variable transmission (CVT).A CVT has a nearly infinite range of gear ratios. In the past, CVTs could not compete with four-speed and five-speed transmissions in terms of cost, size and reliability, so you didn't see them in production automobiles. These days, improvements in design have made CVTs more common. The Toyota Prius is a hybrid car that uses a CVT.The transmission is connected to the engine through the clutch. The input shaft of the transmission therefore turns at the same rpm as the engine.A five-speed transmission applies one of five different gear ratios to the input shaft toproduce a different rpm value at the output shaft.A Very Simple TransmissionTo understand the basic idea behind a standard transmission, the diagram below shows a very simple two-speed transmission in neutral:Let's look at each of the parts in this diagram to understand how they fit together:The green shaft comes from the engine through the clutch. The green shaft and green gear are connected as a single unit. (The clutch is a device that lets you connect and disconnect the engine and the transmission. When you push in the clutch pedal, the engine and the transmission are disconnected so the engine can run even if the car is standing still. When you release the clutch pedal, the engine and the green shaft are directly connected to one another. The green shaft and gear turn at the same rpm as the engine.) The red shaft and gears are called the layshaft. These are also connected as a single piece, so all of the gears on the layshaft and the layshaft itself spin as one unit. The green shaft and the red shaft are directly connected through their meshed gears so that if the green shaft is spinning, so is the red shaft. In this way, the layshaft receives its power directly from the engine whenever the clutch is engaged.The yellow shaft is a splined shaft that connects directly to the drive shaft through the differential to the drive wheels of the car. If the wheels are spinning, the yellow shaft is spinning.The blue gears ride on bearings, so they spin on the yellow shaft. If the engine is offbut the car is coasting, the yellow shaft can turn inside the blue gears while the blue gears and the layshaft are motionless.Now, let's see what happens when you shift into first gear.First GearIn this picture, the green shaft from the engine turns the layshaft, which turns the blue gear on the right. This gear transmits its energy through the collar to drive the yellow drive shaft. Meanwhile, the blue gear on the left is turning, but it is freewheeling on its bearing so it has no effect on the yellow shaft.When the collar is between the two gears (as shown in the first figure), the transmission is in neutral. Both of the blue gears freewheel on the yellow shaft at the different rates controlled by their ratios to the layshaft.From this discussion, you can answer several questions:When you make a mistake while shifting and hear a horrible grinding sound, you are not hearing the sound of gear teeth mis-meshing. As you can see in these diagrams, all gear teeth are all fully meshed at all times. The grinding is the sound of the dog teeth trying unsuccessfully to engage the holes in the side of a blue gear.The transmission shown here does not have "synchros" (discussed later in the article), so if you were using this transmission you would have to double-clutch it. Double-clutching was common in older cars and is still common in some modern race cars. In double-clutching, you first push the clutch pedal in once to disengage the engine from the transmission. This takes the pressure off the dog teeth so you can move the collar into neutral. Then you release the clutch pedal and rev the engine to the "right speed." The right speed is the rpm value at which the engine should be running in the next gear. The idea is to get the blue gear of the next gear and the collar rotating at the same speed so that the dog teeth can engage. Then you push the clutch pedal in again and lock the collar into the new gear. At every gear change you have to press and release the clutch twice, hence the name "double-clutching."You can also see how a small linear motion in the gear shift knob allows you to change gears. The gear shift knob moves a rod connected to the fork. The fork slides the collar on the yellow shaft to engage one of two gears.In the next section, we'll take a look at a real transmission.A Real TransmissionThere are three forks controlled by three rods that are engaged by the shift lever. Looking at the shift rods from the top, they look like this in reverse, first and second gear: Keep in mind that the shift lever has a rotation point in the middle. When you push the knob forward to engage first gear, you are actually pulling the rod and fork for first gear back.You can see that as you move the shifter left and right you are engaging different forks (and therefore different collars). Moving the knob forward and backward moves the collar to engage one of the gears。

MANUAL GEARBOXESMANUAL GEARBOX CLASSIFICATIONGearboxes are normally classified according to the number of toothed wheel couples (stages) involved in the transmission of motion at a given speed; in the case of manual vehicle transmissions, the number to be taken into account isthat of the forward speeds only, without consideration of the final gear, even if included in the gearbox.Therefore there are:• Single stage gearboxes• Dual stage or countershaft gearboxes• Multi stage gearboxesFigure shows the three configurations for a four speed gearbox.It is useful to comment on the generally adopted rules of these schemes.Each wheel is represented by a segment whose length is proportional to the pitch diameter of the gear; the segment is ended by horizontal strokes, representing the tooth width. If the segment is interrupted where crossing the shaft, the gear wheel is idle; the opposite occurs if the segment crosses the line of theshaft without interruption. Then the wheel rotates with the shaft. Hubs arerepresented according to the same rules, while sleeves are represented with apair of horizontal strokes. Arrows show the input and output shafts.Single stage gearboxes are primarily applied to front wheel driven vehicles,because in these it is useful that the input and the output shaft are offset; inG. Genta and L. Morello, The Automotive Chassis, Volume 1: Components Design, 425 Mechanical Engineering Series,c Springer Science+Business Media . 2009426 9. MANUAL GEARBOXESFIGURE . Schemes for a four speed gearbox shown in three different configurations:a: single stage, b: double stage and c: triple stage.conventional vehicles, on the other hand, it is better that input and output shaftsare aligned.This is why rear wheel driven vehicles usually adopt a double stage gearbox.The multi-stage configuration is sometime adopted on front wheel drivenvehicles with transversal engine, because the transversal length of the gearboxcan be shortened; it is used when the number of speeds or the width of the gearsdo not allow a single stage transmission to be used.It should be noted that on a front wheel driven vehicle with transversalengine, having decided on the value of the front track and the size of the tire,the length of the gearbox has a direct impact on the maximum steering angle ofthe wheel and therefore on the minimum turning radius.The positive result on the transversal dimension of multi-stage gearboxes isoffset by higher mechanical losses, due to the increased number of engaged gearwheels.It should be noted that in triple stage gearboxes, shown in the picture, theaxes of the three shafts do not lie in the same plane, as the scheme seems toshow. In a lateral view, the outline of the three shafts should be represented asthe vertices of a triangle; this lay-out reduces the transversal dimension of thegearbox. In this case and others, as we will show later, the drawing is representedby turning the plane of the input shaft and of the counter shaft on the plane ofthe counter shaft and of the output shaft.Gear trains used in reverse speed are classified separately. The inversion ofspeed is achieved by using an additional gear. As a matter of fact, in a train ofthree gears, the output speed has the same direction as the input speed, whilethe other trains of two gears only have an output speed in the opposite direction;the added gear is usually called idler.The main configurations are reported in Fig. .In scheme a, an added countershaft shows a sliding idler, which can matchtwo close gears that are not in contact, as, for example, the input gear of thefirst speed and the output gear of the second speed. It should be noted that, inthis scheme, the drawing does not preserve the actual dimension of the Manual gearbox classification 427FIGURE . Schemes used for reverse speed; such schemes fit every type of gearboxlay-out.Scheme b shows instead two sliding idlers, rotating together; this arrange-ment offers additional freedom in obtaining a given transmission ratio. The coun-tershaft is offset from the drawing plane; arrows show the gear wheels that matchwhen the reverse speed is engaged.Scheme c is similar to a in relation to the idler; it pairs an added specificwheel on the output shaft with a gear wheel cut on the shifting sleeve of the firstand second speed, when it is in idle position.Configuration d shows a dedicated pair of gears, with a fixed idler and ashifting sleeve.The following are the advantages and disadvantages of the configurationsshown in the figure.•Schemes a, b and c are simpler, but preclude the application of synchro-nizers (because couples are not always engaged), nor do they allow the useof helical gears (because wheels must be shifted by sliding).•Scheme d is more complex but can include a synchronizer and can adopthelical gears.•Schemes a, b and c do not increase gearbox 9. MANUAL GEARBOXESMECHANICAL EFFICIENCYThe mechanical efficiency of an automotive gear wheel transmission is high com-pared to other mechanisms performing the same function; indeed, the value ofthis efficiency should not be neglected when calculating dynamic performanceand fuel consumption. The continuous effort of to limit fuel consumption justi-fies the care of transmission designers in reducing mechanical losses.Total transmission losses are conveyed up by terms that are both dependentand independent of the processed power; the primary terms are:•Gearing losses; these are generated by friction between engaging teeth(power dependent) and by the friction of wheels rotating in air and oil(power independent).•Bearing losses; these are generated by the extension of the contact area ofrolling bodies and by their deformation (partly dependent on and partlyindependent of power) and by their rotation in the air and oil (powerindependent).•Sealing losses; they are generated by friction between seals and rotatingshafts and are power independent.•Lubrication losses; these are generated by the lubrication pump, if present,and are power independent.All these losses depend on the rotational speed of parts in contact and,therefore, on engine speed and selected transmission ratio.Table reports the values of mechanical efficiency to be adopted in calcu-lations considering wide open throttle conditions; these values consider a pair ofgearing wheels or a complete transmission with splash lubrication; in the sametable we can see also the efficiency of a complete powershift epicycloidal auto-matic transmission and a steel belt continuously variable transmission. For thetwo last transmissions, the torque converter must be considered as locked-up.TABLE . Mechanical efficiency of different transmission mechanisms.Mechanism type Efficiency (%)Complete manual gearboxwith splash lubrication 92–97Complete automatic transmission(ep. gears) 90–95Complete automatic gearbox(steel belt; without press. contr.) 70–80Complete automatic gearbox(steel belt; with press. contr.) 80–86Pair of cyl. gears –Pair of bevel gears 90– Mechanical efficiency 429FIGURE . Contributions to total friction loss of a single stage gearbox designed for300 Nm as function of input speed.It is more correct to reference power loss measurement as a function ofrotational input speed rather than efficiency. Figure shows the example ofa double stage transmission, in fourth speed, at maximum power; the differentcontributions to the total are shown.This kind of measurement is made by disassembling the gearbox step bystep, thus eliminating the related loss.In the first step all synchronizer rings are removed, leaving the synchronizerhubs only; mechanical losses of non-engaged synchronizers are, therefore, mea-surable. The loss is due to the relative speed of non-engaged lubricated conicalsurfaces; the value of this loss depends, obviously, on speed and the selectedtransmission ratio.In the second step all rotating seals are removed.In the third step the lubrication oil is removed, and therefore, the bulk ofthe lubrication losses is eliminated; some oil must remain in order to leave thecontact between teeth unaffected.By removing those gear wheels not involved in power transmission, theirmechanical losses are now measurable.The rest of the loss is due to bearings; the previous removal of parts canaffect this value.A more exhaustive approach consists in measuring the complete efficiencymap; the efficiency can be represented as the third coordinate of a surface, wherethe other two coordinates are input speed and engine torque. Efficiency calcu-lations can be made by comparing input and output torque of a working trans-mission.Such map can show how efficiency reaches an almost constant value at amodest value of the input torque; it must not be forgotten that standard fuelconsumption evaluation cycles involve quite modest values of torque and there-fore imply values of transmission efficiency that are changing with torque.Figure shows a qualitative cross section of the aforesaid map, cut atconstant engine speed. It should be noted that efficiency is also zero at input430 9. MANUAL GEARBOXESFIGURE . Mechanical efficiency map, as a function of input torque at constantengine speed; the dotted line represents a reasonable approximation of this curve, to beused on mathematical models for the prediction of performance and fuel consumption.torque values slightly greater than zero; as a matter of fact, friction implies acertain minimum value of input torque, below which motion is impossible.A good approximation to represent mechanical efficiency can be made usingthe dotted broken line as an interpolation of the real curve.MANUAL AUTOMOBILE GEARBOXES9.3.1 Adopted schemesIn manual gearboxes, changing speed and engaging and disengaging the clutchare performed by driver force only.This kind of gearbox is made with helical gears and each speed has a syn-chronizer; some gearboxes do not use show the synchronizer for reverse speed,particularly those in economy minicars.We previously discussed a first classification; additional information is thespeed number, usually between four and six.Single stage gearboxes are used in trans-axles; they are applied, with someexceptions, to front wheel driven cars with front engine and rear driven cars withrear engine; this is true with longitudinal and transversal engines.In all these situations the final drive is included in the gearbox, which istherefore also called transmission.Countershaft double stage gearboxes are used in conventionally driven cars,where the engine is mounted longitudinally in the front and the driving axle isthe rear axle. If the gearbox is mounted on the rear axle, in order to improve theweight distribution, the final drive could be included in the Manual automobile gearboxes 431 By multi-stage transmissions, some gear wheels could be used for differentspeeds. The number of gearing wheels could increase at some speeds; this nor-mally occurs at low speeds, because the less frequent use of these speeds reducesthe penalty of lower mechanical efficiency on fuel consumption.Cost and weight increases are justified by transmission length reduction,sometimes necessary on transversal engines with large displacement and morethan four cylinders.In all these gearboxes synchronizers are coupled to adjacent speeds .:first with second, third with fourth, etc.) in order to reduce overall length andto shift the two gears with the same selector rod.We define as the selection plane of a shift stick (almost parallel to the xzcoordinate body reference system plane for shift lever on vehicle floor) the planeon which the lever knob must move in order to select two close speed pairs. Forinstance, for a manual gearbox following many existing schemes, first, second,third, fourth and fifth speed are organized on three different selection planes; thereverse speed can have a dedicated plane or share its plane with the fifth speed.Figure shows a typica l example of a five speed single stage gearbox. Thefirst speed wheels are close to a bearing, in order to limit shaft deflection.In this gearbox the total number of tooth wheels pairs is the same as forthe double stage transmission shown in Fig. .While in the first gearbox there are only two gearing wheels for each speed,in the second there are three gearing wheels for the first four speeds and noneFIGURE . Scheme for a five speed single stage transmission, suitable for front wheeldrive with transversal 9. MANUAL GEARBOXESFIGURE . Scheme of an on-line double stage gearbox for a conventional lay-out.for the fifth. This property is produced by the presence of the so called constantgear wheels (the first gear pair at the left) that move the input wheels of t hefirst four speeds; the fifth speed is a direct drive because the two parts of theupper shaft are joined together.The single stage gearbox in Fig. shows the fifth speed wheel pair posi-tioned beyond the bearing, witness to the upgrading of an existing four speed transmission; in this case the fifth speed has a dedicated selection plane.The double stage gearbox in Fig. is organized in a completely differentway but also shows the first speed pair of wheels close to the bearing. The directdrive is dedicat ed to the highest speed; the fifth speed shows a dedicated selectionplane.Six speed double stage gearboxes do not show conceptual changes in com-parison with the previous examples; synchronizers are organized to leave firstand second, third and fourth, fifth and sixth speeds on the same selection plane.As already seen, the multistage configuration shown in Fig. allows areasonable reduction of the length of the gearbox. In this scheme, only first andsecond speeds benefit from the second countershaft; power enters the counter-shaft through a constant gear pair of wheels and flows to the output shaft at areduced speed. Third, fourth and fifth speed have a single stage arrangement.Reverse speed is obtained with a conventional idling wheel.9.3.2 Practical examplesFour speed gearboxes represented the most widely distributed solution in Europeuntil the 1970s, with some economy cars having only three Manual automobile gearboxes 433 FIGURE . Scheme of a triple stage five speed gearbox, suitable for front wheel drivencar with transversal engine.With the increase in installed power, the improvement in aerodynamic per-formance and increasing attention to fuel consumption, it became necessary toincrease the transmission ratio of the last speed, having the first s peed remain atthe same values; as a matter of fact car weight continued to increase and engineminimum speed did not change significantly.To achieve satisfactory performance all manufacturers developed five speedgearboxes; this solution is now standard, but many examples of six speed gear-boxes are available on the market, not limited to sports cars.Figure shows an example of a six speed double stage transmission withthe fifth in direct drive; here the first and second pair of wheels are close to thebearing.This rule is not generally accepted; on one hand having the most stressedpairs of wheels close to the bearing allows a shaft weight containment. On theother hand, having the most frequently used pairs of wheels close to the bearingreduces the n oise due to shaft deflection.Synchronizers of fourth and third speed are mounted on the countershaft;this lay-out reduces the work of synchronization, improving shifting quality by anamount proportional to the dimension of the synchronizing rings. Synchronizersof first and second gear on the output shaft are, because of their diameter, larger434 9. MANUAL GEARBOXESFIGURE . Double stage six speed gearbox (GETRAG).than those of the corresponding gear; the penalty of the synchronization work ispaid by the adoption of a double ring synchronizer.Synchronizers on the countershaft offer a further advantage: In idle positionthe gears are stopped and produce no rattle; this subject will be studied later Manual automobile gearboxes 435Figure introduces the example of a single stage gearbox for a frontlongitudinal engine. The input upper shaft must jump over the differential, whichis set between the engine and the wheels. The increased length of the shaftssuggested adopting a hollow section. Because of this length the box is dividedinto two sections; on the joint between the two sections of the box additionalbearings are provided to reduce the shaft deflection.The input shaft features a ball bearing close to the engine and three otherneedle bearings that manage solely the radial loads. The output shaft has twotapered roller bearings on the differential side and a roller bearing on the oppositeside. This choice is justified by the relevant axial thrust emerging from the bevelgears.The first and second speed synchronizers are on the output shaft and featurea double ring.The reverse speed gears are placed immediately after the joint (the idlergear is not visible) and have a synchronized shift. Remaining synchronizers areset in the second section of the box on the input shaft. The output shaft endswith the bevel pinion, a part of the final ratio.It should be noted that the gears of the first, second and reverse speeds aredirectly cut on the input shaft, in order to reduce overall dimensions.Most contemporary cars use a front wheel drive with transversal engine; thenumber of gearboxes with integral helical final ratio is, therefore, dominant.In these gearboxes geared pairs are mounted from the first to the last speed,starting from the engine side. An example of this architecture is given in Fig. .Like many other transmissions created with only four speeds, it shows thefifth speed segregated outside of the aluminium box and enclosed by a thin steelsheet cover; this placement is to limit the transverse dimension of the powertrain, in the area where there is potential interference with the left wheel in thecompletely steered position.This solution is questionable as far as the total length is concerned but showssome advantage in the reduction of the span between the bearings. Each bearingis of the ball type; on the side opposite to the engine the external ring of thebearing can move axially, to compensate for thermal differential displacements.One of the toothed wheels of the reverse speed is cut on the fir st and secondshifting sleeve.The casing is open on both sides; one of these is the rest of one of thebearings of the final drive. A large cover closes the casing on the engine side and,in the meantime, provides installation for the second bearing of the final driveand the space for the clutch mechanism; it is also used to join the gearbox tothe engine.In this gearbox synchronizers are placed partly on the input shaft and partlyon the output shaft.Figure shows a drawing of a more modern six speed gearbox, in whichit was possible to install all the gears in a conventional single stage arrangement,thanks to the moderate value of the rated 9. MANUAL GEARBOXESFIGURE . Single stage six speed gearbox for longitudinal front engine (Audi). Manual gearboxes for industrial vehicles 437FIGURE . Five speed transmission for a transversal front engine (FIAT).Gears are arranged from the first to the sixth, starting from the engineside; as we have already said this arrangement is demanded by the objectiveof minimizing shaft deflection. Only the synchronizers of first and second speedfound no place on the input shaft; they are of the double ring type, as for thefirst speed.The reverse speed is synchronized and benefits of a countershaft not shownin this drawing.MANUAL GEARBOXES FOR INDUSTRIALVEHICLES9.4.1 Lay-out schemesThe gearboxes we are going to examine in this section are suitable for vehicles ofmore than about 4 t of total weight; lighter vehicles, usually called commercialvehicles, adopt gearboxes that are derived from automobile production, as notedin the previous 9. MANUAL GEARBOXESFIGURE . Six speed transmission for a transversal front engine (FIAT).Gearboxes used in industrial vehicles also feature synchronizers; they can beshifted directly, as in a conventional manual transmission, or indirectly with theassistance of servomechanisms. Non-synchronized gearboxes are sometimes usedon long haul trucks, because of their robustness. Assisted shifting mechanismsare widespread because of the easy availability of power media. Automatic orsemi-automatic transmissions are also used, the first type especially in buses.For gearboxes with four up to six speeds, the double stage countershaftarchitecture represents a standard; the scheme is the same as seen before.The constant gear couple is used for all speeds but the highest. Also notableis that the lowest speed wheels are close to the bearings.As shown in the drawings of Fig. , the highest speed can be obtainedeither in direct drive (scheme b) or with a pair of gears (scheme a); in this lastcase the direct drive is used for the speed before the last: these architectures arecalled direct drive and overdrive.In the figure, only the last and the first before the last speed are represented.The cho ice between the two alternatives can be justified by the differentvehicle mission; virtually the same gearbox can be used on different vehicleswith different frequently used speeds (a truck and a bus for example). Manual gearboxes for industrial vehicles 439FIGURE . Alternative constant gear schemes with last or first before the last speedin direct drive.Sometime the constant gear is set on the output shaft, after the differentspeed gears; this configuration offers the following advantages:•Reduction of the work of synchronization, because of the smaller gear di-mension at the same torque and total transmission ratio•Less stress on the input shaft and countershaftOn the other hand, the following disadvantages emerge:•Bearings rotate faster.•Constant gear wheels are more highly stressed.This applies for single range transmissions.Multiple range transmissions feature, in addition to the main gearbox, othergearboxes that multiply the number of speeds of the main gearbox by the numberof their speeds. With this architecture the total number of gear pairs might bereduced, for a given number of speeds, and, sometime the use of the gearshiftlever can be simpler.This arrangement is used when more than six speeds are necessary. A multi-ple range transmission is therefore made out of a combination of different coun-tershaft gearboxes, single range gearboxes or epicycloidal gearboxes.Each added element is called a range changer if it is conceived as beingcapable of using the main gearbox speeds in sequence, in two completely non-overlapping series of vehicle speeds; for example, if the main gearbox has fourspeeds, the first speed in the high range is faster than the fourth speed in thelow range.The element is called a splitter if it is intended to create speeds that areintermediate to those of the main gearbox; in this case, for example the third440 9. MANUAL GEARBOXESFIGURE . Scheme of a 16 speed gearbox for industrial vehicles; it is made with afour gear main gearbox, a double speed splitter and a double speed range changer withdirect drive.speed in the high range is faster than the third speed in the low range, but slowerthan the fourth speed in the low range.We call the gearbox with the highest number of speeds the main gearbox;the splitter and the range changer will be set in series before and after the maingearbox.Figure shows the scheme of a gearbox featuring a splitter and a rangechanger. The splitter is made out of a pair of wheels that work as two differentconstant gears for the main gearbox. The countershaft can therefore be movedat two different speeds, according to the position of the splitter unit. Becausethe main gearbox has four speeds, this splitter unit can create a total of eightspeeds, one of them being in direct drive.At the output shaft of this assembly, there is a range changer unit madeas a two speed double stage gearbox with direct drive; this unit multiplies by two the total number of obtainable speeds. The range changer is qualified by the significant difference between the two obtainable speeds.The range changer can be made with a countershaft gearbox or an epicy- cloidal gearbox with direct drive; the advantage in the latter case is the possi- bility of an easier automatic actuation, by braking some of the elements of the epicycloidal Manual gearboxes for industrial vehicles 441FIGURE . Transmission ratios obtained with the scheme of transmission shown in Fig. ; speed identification shows the main gearbox speed with the number, the splitter position with the first letter, the range changer position with the second; L stands for low, H stands for high.It is also possible to place the range changer before the main gearbox andthe splitter unit after the main gearbox.A different way of defining the functions of r ange change units is to say thatthe splitter is a gearbox that compresses the gear sequence, because it reduces the gap between speeds, while the range changer is a gearbox that expands the gear sequence, because it increases the total range of the transmission.Figure explains the concept of compression; the bars represent the ratios obtained in all shifting lever positions. Ratios obtained with the splitter unit in the L position (the first letter in the speed identification, L stands for lower ratio) are interspersed with the ratios obtained with the splitter unit in the H position (H stands for higher ratio, in this case 1:1) and reduce the amplitude of the gear steps of the main gearbox.The same figure also explains the concept of expansion, showing on thesame graph the ratio obtained with the range changer in the H position (second identification letter) and the L position; the gear step between the first in low gear and the first in high gear is as big as the range of the main gearbox, andthe total transmission range is widened.The range changer is therefore seldom used, when driving conditions change suddenly, as, for example, when leaving a normal road for a country road that must be driven more slowly, or when encountering a strong slope with a fully loaded vehicle. The splitter allows the dynamic performance of the vehicle to be improved, making the optimum transmission ratio available to obtain the desired power. The splitter is therefore used frequently. In a fully loaded vehicle, for example, all split ratios can be used in sequence during full throttle acceleration from a 9. MANUAL GEARBOXESThe range changer and splitter are usually made as modular units that canbe mounted at both ends of the main gearbox, or changed with simple covers,in order to satisfy all application needs with limited total production costs. Generalizing these concepts could suggest building transmissions using ad- ditional range changing units arranged in series. These could be conceived as being made only of splitter units with direct drive.In such a case, with n pairs of tooth wheels it is possible to obtain a totalof z transmission ratios, given by the formula:z =2n−1.The formula expresses the number of possible states that can be obtainedfrom n − 1 pairs of gears; one unit is subtracted because one pair must be a constant gear to move the countershaft.With four pairs of gears, for example, four speeds can be obtained in adouble stage gearbox; while using a cascade of splitters eight different speeds could be obtained. The goal of good shift manoeuvrability and the implications for mechanical losses must not be forgotten, while defining the best architecture. Figure shows the scheme of the 16 speed transmission with splitter and。

Manual transmissionManual transmission is the most basic of transmission of a type, its effect is changing, and provide the transmission reverse and neutral. Usually, the pilot on the clutch pedal through manipulation and in any HuanDangGan can choose between gear. There are a few manual transmission, such as motorcycles, cars, some transmission shift transmission allows only sequence, the transmission is called sequence shift transmission. In recent years, along with the electronic control components durability, computerized automatic switching clutch automatic shift of transmission in Europe since the start line are more and more popular, car V olkswagen and ford are sold in the city on the double clutch provide updated generation, transmission from the start with two clutches, every shift automatically switch to another group of clutch engagement, need not as quick as traditional in manual have only one group separated again clutch engagement, shifting speed is faster, more small change gear vibration.Internal structure: shaftDecorate a form of transmission shaft type usually have two and three shaft type two kinds. Usually a rear wheel drive car will adopt three axis type, i.e. input shaft transmission, the output shaft and oart. Input shaft front associated with engine, borrow clutch output shaft back-end through the flange and universal transmission device connected.Input shaft and the output shaft in the same horizontal line, with their oart parallel arrangement. From the input shaft power through the gears to preach to the output shaft oart again. In many input and output shaft transmission shaft could engage in together, so to power, then the gear oart called directly. Direct files through uniaxial transmission, the ratio of 1:1, the highest transmission efficiency. Even in the transmission directly, cannot offer the input shaft, and the output shaft is decorated in a straight line to reduce work needed to inherit the torque transmission.Reversing deviceGenerally speaking, the reverse gear reducer than can alsosynchronizerIn synchronized meshing gears have type synchronizer Settings, can make two gear engagement in the first, before the speed reached synchronizer in all of this manual geartransmission of the car has been usedClutch,The clutch is can make two gear with a separate with mechanical parts, two gear transmission power can be combined, but when to speed, so will depend on the first two gear clutch, change gear ratio, the two gear transmission power, continue again Control：GearIn simple terms, the high speed, low speed ShengDang when the time cameEvery car high speedCompared with automatic transmissionThis refers to the automatic transmission of traditional hydraulic transmission, namely through hydraulic torque converter and planetary gear transmission power automatic transmission.Advantages：transmission efficiency than automatic gearboxes for high, of course, theoretically can compare economical.maintenance will be cheaper than transmission.If you want to higher cost, can begin from both the row of convenience and high power手动变速器手动变速器是汽车变速器中最基本的一种类型，其作用是改变传动比，并提供倒档和空档。

附录外文文献Manual transmission is the most basic of transmission of a type, its effect is changing, and provide the transmission reverse and neutral. Usually, the pilot on the clutch pedal through manipulation and in any HuanDangGan can choose between gear. There are a few manual transmission, such as motorcycles, cars, some transmission shift transmission allows only sequence, the transmission is called sequence shift transmission. In recent years, along with the electronic control components durability, computerized automatic switching clutch automatic shift of transmission in Europe since the start line are more and more popular, car Volkswagen and ford are sold in the city on the double clutch provide updated generation, transmission from the start with two clutches, every shift automatically switch to another group of clutch engagement, need not as quick as traditional in manual have only one group separated again clutch engagement, shifting speed is faster, more small change gear vibration.Internal structure: shaftDecorate a form of transmission shaft type usually have two and three shaft type two kinds. Usually a rear wheel drive car will adopt three axis type, i.e. input shaft transmission, the output shaft and oart. Input shaft front associated with engine, borrow clutch output shaft back-end through the flange and universal transmission device connected.Input shaft and the output shaft in the same horizontal line, with their oart parallel arrangement. From the input shaft power through the gears to preach to the output shaft oart again. In many input and output shaft transmission shaft could engage in together, so to power, then the gear oart called directly. Direct files through uniaxial transmission, the ratio of 1:1, the highest transmission efficiency. Even in the transmission directly, cannot offer the input shaft, and the output shaft is decorated in a straight line to reduce work needed to inherit the torque transmission.Reversing deviceGenerally speaking, the reverse gear reducer than can alsosynchronizerIn synchronized meshing gears have type synchronizer Settings, can make two gear engagement in the first, before the speed reached synchronizer in all of this manual gear transmission of the car has been usedClutch,The clutch is can make two gear with a separate with mechanical parts, two gear transmission power can be combined, but when to speed, so will depend on the first two gear clutch, change gear ratio, the two gear transmission power, continue againControl：GearIn simple terms, the high speed, low speed ShengDang when the time came Every car high speedCompared with automatic transmissionThis refers to the automatic transmission of traditional hydraulic transmission, namely through hydraulic torque converter and planetary gear transmission power automatic transmission.Advantages： transmission efficiency than automatic gearboxes for high, of course, theoretically can compare economical.maintenance will be cheaper than transmission.If you want to higher cost, can begin from both the row of convenience and high power附录外文文献的中文翻译手动变速器是汽车变速器中最基本的一种类型，其作用是改变传动比，并提供倒档和空档。

英文原文Stepless speed technologyStepless spee d tee 加ology USES belt and the work of the Lord diameters driven pulley, cooperated with the power to deliver, can realize the TRANSMISSION ratio of the continuous change, and get the TRANSMISSION and engine condition the best match between. Common step-l ess transmission have hydraulic mech 皿cal step-less transmission and belt type step-less transmission, the current domestic market of the vehicles already more and more. Editor this section step-less transmission and the origin of the automatic transmissionAutomatic transmission i s easy to operate, reduce fatigue driving, born of the gear drive system, the control method, it can be divided into the hydraulic controlled hydraulic and electric automatic transmission hydraulic automatic transmission; According to the change of the transmission way and can be divided into have levels o f automatic transmission and no levels of automatic transmission. Ther efore, step-less transmission is actually a kind of automatic transmission, but it than common automatic transmission is much more complex, more advanced tec 血ol ogi es. Step-less transmission and common hydraulic automatic transmission of the biggest differences is on the structure, the latter is by hydraulic control gear 如ve system structure, still have the gears, it can be realized in betwe en the two block is continuously variable transmission, and is two groups plate and a belt speed o f than traditional automatic transmission, simple structure, smaller. In addition, it is free to change gear ratios, so as to realize the full speed stepless speed change, make more smoothly, without the traditional transmission shift at the'"'feeling. Editor this section step-l ess transmission classificationTo realize stepless speed, 如ving mode can be adopted according to the liquid transmission, power transmission and mech皿cal drive three ways.Liquid transmissionLiquid transmission is divided into two kinds: one kind is hydraulic, mainly is composed by the pump and motor or the valve and pump v缸able speed of transmission device, apply to small and medium-sized power transmission. Another kind is hydraulic type, adopts hydraulic coupler or hydraulic torque of variable speed drive, used in high power(kw)To hundreds of thousands of Th e main characteristics of liquid transmission is: spee d range, can absorb the impact and big to prevent transmission efficiency high, overload, long life, easy to realize automation: manufacturing precision demand is high, the price is more expensive, output characteristics for constant torque, sliding rate is bigger, running vulnerable to leak.Po wer transmissionPo wer transmission basically is divided into three categories: one kind is electromagnetic sliding type, it is in the asynchronous motor installed in electromagnetic clutch, sliding by changing i ts exciter current to speed, this belongs to a kind of relatively bac kwardspeed adjustment way. T hecharacteristics of simple structure, low cost, convenient operation and maintenance, sliding, low efficiency, biggest fever, not suitable for long-term serious load operation, the general used only for small power transmission. Second is the dc motor type, changes in the magnetic flux or change the armature voltage realize the speed. Its characteristic is speed range, high precision, large and comp l ex, high cost but equipment, maintenance difficu l ties, are used for medium power range (dozens to hundreds of kw), has gradually been ac motor type instead. T hree kinds of ac motor type is, through the change pole, pressure control and frequency conversion for the speed. The most practical application for variable frequency speed regulation, namely deserve using a horns, and then get l uffing power drive motor variable speed. Its characteristic is the speed performance is good, range, high efficiency, it can automatic control, small volume, it is suitable for a wide range of power: mechanical properties in single reducing speed constant torque, low efficiency and low speed running smooth enough, the price is higher, maintenance should be professional. In recent years, frequency converter as an advanced, excellent variab l e speed device rapid development of machinery, step-less transmission produced a certain impactMechanical transmissionThe main characteristic of the mechanical transmission is stable, rotate speed sliding rate, reliable, and has small constant power mechanical properties, the transmission efficiency is high, and simp l e structure, convenient maintenance, the price is relatively cheap; B ut parts processing and lubrication to demand higher bearing capacity, low resistance, resistance to 皿pact overload and poor, so general suitable for medium and small power transmission.1, MTThe manual transmission(MT: Manua l Transmission) gearset, because the number of teeth of each gear is fixed, each gear ratio is a fixed value (that is, the so-called "level"). For example, a block ratio of 3.455, the second gear is 2.056 to the five-speed 0.85, these figures are multiplied by the main reduction ratio is the total transmission ratio of the power train, 5-speed transmission 5 value (ie 5 level), so it is a step-variable transmission. The manual transmission is the most common transmission, composed of relatively AT and CVT, its structure is simple, the main axis of the input shaft, output shaft and the intermediate shaft, the shaft bearings, each gear, the synchronizer, the shift operating mechanism. Manual transmission failure rate is relatively low, the use of lower cost.2,ATAutomatic transmission (A T: Automatic Transmission) automatic upshifts and downs皿s lifting gear control, computer based primarily on speed and load (throttle pedal stroke), but also refer to a variety of signal transmission oil temperature, shift mode. The same point of the AT and MT both step-variable transmission, only that the A T has a continuous speed ratio variation in the respective gear, and the speed according to the vehicle speed automatically to achieve a gear change for hand can be eliminated block cars "frustrated" variable block feeling. (1) AT structure: Compared with manual wave, hydraulic automatic transmission (AT) are very different in structure and use.Manually waves mainly composed of gears and shafts, v 印able speed torque generated by different gear combinations; AT by the torque converter, a planetary gear and the hydraulic steering system, to achieve a v印able speed hydraulic transmission and gear combination moment. Wherein the torque converter is the most characteristic parts of the A T, it is composed by the pump impeller, turbine and guide wheel member, directly enter the engine power transmitting torque and clutch effect. (2) A T advantages and disadvantages: AT without a clutch shift, gear changes less stable connection, so the operation is easy, both to car, bring comfort to the car. B ut the disadvantage is also one of the speed changes in response to slow, there is no manual transmission is sensitive, so many play car owners like to open a manual transmission car; Second, the economic cost of oil, the transmission efficiency is lo w variable torque range is limited, in recent years, the introduction of electronic control tec 血ology improve 伽s problem; institutional comp l ex, difficult to repair. High-Speed circula血g within the to rque converter hydraulic oil 邓11 generate heat, so as to use the specified high temper ature hydraulic oil. In addition, if the car can not be started due to battery power shortage, you can not start with a truck or trailer bed. Hauling fault car, pay attention to the drive wheels off the ground to protect the Automatic gear from damage. (3) AMT AMT transformation, major changes in the mechanical transmission (manual transmission) based on the original manual shift control section. In the case o f the overall transmission structure constant through the installation o f computer-contro ll ed robotic systems to achieve the automation of the shift. AMT is actually a robo t system to complete the two movements opera 血g the clutch and the gear selector. AMT is the production of manual wave based on the transformation, production inheritance, investment responsibility with lower production plant. AMT's core tec 加ology is computer-controlled, electronic tec 血ology and quality 呻directly detennine the quality of the performance and operation of the AMT3, the CVTThe continuously variable transmission (CVT: Continuous Variable T ransmission) with a step-type main difference in that: it is the speed ratio is not interrupted, but a series o f 山screte values, for example, has been changing from 3.455 to 0.85. CV T structure is simpler than conventional automatic transmission, smaller, neither many manual transmission gear pair, there is no automatic transmission complex planetary gear set, i t depends mainly on the main driven w heel and metal band or wheel dial to achieve the speed ratio stepless change. Its principle is as several sets of gear sizes watched under the control of an aggregate with a common gearbox, and a d 市erent speed ratio, like a bic ycle pedal driven by the size of the wheel and the chain wheels to rotate at different speeds. Also changes due to the different strength of the thrust generated by each group gear sizes, resul血g in the transmission output speed, in order to achieve the brad ycardia rotation, regardless of grade. CVT be l ts and variable-width ratchet power transmission, i.e., w hen the ratchet wheel changes the groove width of the elbow, corresponding to the shift change the contact radius of the drive wheel and the driven w heel on the driving belt, a bel t ships with a rubber band, metal band and meta l chain. CVT is truly stepless, i t is light we igh t, small size, fewer parts, and AT has a highoperating efficiency, lower fue l consumption. CV T disadvantage is obvious, is the transmission belt can be easily damaged, can not withstand a greater load, low power and low torque vehicles can only be restricte d to about 1 liter o扭splacement,so the share of the automatic transmiss i on 4. A代er the major car companies vigorously research in recent years, the situation has improved CVT will be the d evelopment direction of the automatic transmission. D omestic vehicle models equ i pped w ith the CV T, such as the Nissan T eana, Sylphy, X-T rail full range of models, FAW-Volkswagen, Audi, the Guangqi Honda F it, South F iat Siena, P a B aclofen, Chery Cowin The main structure and working principle of the CVT (1) stee l belt CV TThe CVT is a combination of pulleys and a steel strip, power is transmitted to rep l ace the conventional gear device. The main components of the basic member of the inclu 血g capstan group, a driven wheel set, a metal band, and a hydraulic pump, etc.. Meta l band by the two beams of metal rings and hundreds of sheet metal. Capstan group and a driven wheel set by the movable disc and the fixed rent, close to one side of the pulley and the cylinder can slide on the shaft, the other side is fixed. Movable plate and the fixed plate cone structure, the cone forming a V-groove to engage with the V-shaped metal transmission belt. The power output of the engine output shaft is first passed to the capstan of the CVT, and then is transmitted to the driven wheel through aV-type power transmission belt, and finally via the gear unit, the differential is transmitted to the wheels to drive the car. Through the capstan and the driven whee l when the movable disc for axial movement to change the working radius of the capstan and the tapered surface of the driven pulley with a V-type drive belt engaging, thereby changing the transmission ratio. T he amount of axial movement of the movable p l aten is needed by the driver through the control system to adjust the capstan, the follower wheel cylinder of the hydraulic pump pressure to achieve. Continuously adjusted in order to achieve a continuously variab l e transmission can be achieved due to the working radius of drive pulley and driven pulley. In the the CV T hydraulic system, the role of the slave cylinder to control the tension of the metal band, in order to ensure the efficient and reliable delivery of power from the engine. Active cylinder to control the position of the driving bevel wheel moves axially along the V-groove move in the the capstan group metal band, due to the constant length of the metal strip, a group of the driven wheel in the opposite direction on the metal strip along the V-groove changes. Change the radius of gyration of the metal strip in the the capstan group and a driven wheel set on the continuous variation of the speed ratio. When the car is started, the small working radius of the driving wheel, the transmission can get a l arger gear ratio, thus ensuring the drive axle to have enough torque to ensure the car has a higher acceleration As the speed increases, the capstan working radius is gradually reduced, the working radius of the driven wheel increases according l y, and the CV T transmission is decreased so that the car can travel at higher speeds.(2) wheel rotary C VTCan be used to deliver more power and torque applicable in a larger displacement automobiles加s CVT combination of turntable and roller transfer drive torque and change the transmission ratio. I t is changed by moving the power roller transmission ratio, input clial to the power roller force is applied in a timely manner, so that CV T gear ratio change of the reaction faster than the strip-type CV T, in order to achieve the 如ver's accelerator input of the transmission ratio changes linearly. In addition, similar to the strip-drive CV T, the continuous change of the transmiss i on ratio so that the driver can enjoy seamless smooth shifting, without any shi:ftshock.E ngine power trans皿tted to an input dial input 知al to the rotational movement of the trans皿tting power to the wheel, and then passed through the rollers to the output of the turntable. B y continuously changing the inc 血ation ang l e of the power roller, CV T performs a smooth and continuous gear ratio changes. The size of the contact circle between the points of contact between the input wheel and the power roller circle size and the output of the 如al and the power roller is changed accor 恤g to the change of the inclination ang l e of the power roller. The size ratio of the circle correspon 血g to the input the turntable and output rotational speed ratio of the turntable, the rotational speed ratio is equal to the drive ratio. When the the output dial circle is l arger, the rotation of the output clial slower than the input dial, which is equivalent to the traclitional low-endof the trans 皿ssion. Conversely, output 中al circle small, the rotation of the output 山al faster than the input clial, which is equivalent to the high-end of the traditional transmission.The momentum wheel is supported on the truimion connected above and below the assembly and the hydraulic servo piston can move up and down.P ower roller, this configuration allows each roller rotating around the trunnion.When the power roller axis through the wheel center, does not produce the force of the tilt of the wheel. Accordingly, since the wheel tilt remains unchanged, it is no change in the trans血ssion ratio.Since the high-speed rotation of the turntable, as long as the wheel moves up or down. 0.1mm to 1.0mm, can be tilted. This immediate response to a gear ratio change instruction, the EXT R O ID CVT cause p血cularly rapid transmission ratio change.The inclination angle of the power roller hydraulic mechanism for manipulation. D espite the transmission ratio is changed by tilting the power roller, but not directly to the whee l afterburner. Instead, the force generated using the turntable so that the inclined roller when the vertical movement of the wheel from the center axis, the turntable on the roller ti l t. As the high-speed rotary dial, 如1 the forces generated by the wheel movement and force the hours imme小ate l y tilt, so we can quickly feel the transmission ratio changes significantly. When the driver's accelerator input, and the linear acceleration and deceleration.中文译文无级变速器无级变速技术，它采用传动带和工作直径可变的主、从动轮相配合来传递动力，可以实现传动比的连续改变，从而得到传动系与发动机工况的最佳匹配。

汽车变速器的设计外文文献翻译、中英文翻译、外文翻译A manual n。

also known as a standard n。

XXX。

It consistsof gears。

synchros。

roller bearings。

shafts。

and gear selectors。

The main clutch assembly is used to engage and disengage the engine from XXX gears are used to select the desired。

and the sector fork moves gears from one to another using the gearshift knob。

Synchros are used to slow the gear to a。

before it is XXX。

The counter shaft holds the gears in place and against the main input and output shaft。

Unlike automatic ns。

XXX。

as there isno XXX。

Note: XXX "n Shifter" was deleted as it had no XXX.)XXX have four to six forward gears and one reverse gear。

However。

some cars may have up to eight forward gears。

while semi trucks XXX by the number of forward gears。

such as a 5-speed standard n.The n of a standard n includes three shafts: the input shaft。

本科毕业设计（论文）英文资料翻译*****指导教师：孙飞豹（副教授）学科、专业：车辆工程沈阳理工大学应用技术学院2011年12月20日transmission used in automobilesA standard transmission or manual transmission is the traditional type of transmission used in automobiles. The manual or standard transmission consists of a series of gears, synchros, roller bearings, shafts and gear selectors. The main clutch assembly is used to engage and disengage the engine from the transmission. Heliacal cut gears are used to select the ratio desired the sector fork move gears from one to another by using the gearshift knob. Synchros are used to slow the gear to a stop before it is engaged to avoid gear grinding, the counter shaft hold the gears in place and against the main input and output shaft. A stick shift transmission has no torque converter so there is no need for a transmission cooler. A stick shift transmission needs a simple fluid change for proper service. (there is no transmission filter in a stick shift transmission).Transmission ShifterMost manual transmissions have one reverse gear and four to six forward gears. Some cars also have eight forward gears while thirteen to twenty-four gears are present in semi trucks. To differentiate among the available standard transmissions, they are addressed by the number of forward gears. For example, if the standard transmission has five gears, it will be referred to as 5-speed standard transmission or 5-speed standard.Typical Standard Transmission ConfigurationInside the transmission shafts contain all forward and reverse gears. Most transmissions contain three shafts: input shaft, output shaft and counter or lay shaft. Other than standard transmission, there are other transmissions like continuously variable transmission, automatic transmission and semi-automatic transmission. In the manual transmission, a pair of gears inside the transmission selects the gear ratios. Whereas, in an automatic transmission, combination of brake bands and clutch packs control the planetary gear which selects the gear ratio.If there is a provision to select a gear ratio manually in automatic transmissions, the system is called a semi-automatic transmission. The driver can select from any of the gears at any pointof time. In some automobiles like racing cars and motorcycles that have standard transmissions, the driver can select the preceding or the following gear ratio with no clutch operation needed. This type of standard transmission is known as sequential transmission. In this transmission the clutch is still used for initial take off.Clutch and Flywheel AssemblyThe main clutch plays the role of a coupling device which separates the transmission and the engine. If the clutch is absent and the car comes to a stop the engine will stall. In automobiles, the clutch can be operated with the help of a pedal located on the floor of the vehicle. In an automatic transmission instead of a clutch, a torque converter is used to separate the transmission and engine.Typical Stick Shift PatternsA desired gear can be selected by a lever which is usually located on the floor in between the driver and passenger seat. This selector lever is called the gear lever or gear selector or gear shift or shifter. This gear stick can be made to move in right, left, forward and backward direction. When the gear is placed on the N position or neutral position, no gear will be selected. To move the car in the backward direction, the R gear or reverse gear should be selected.Standard transmissions are more efficient and less expensive to produce than automatic transmissions. A Standard transmission is about 15% more efficient compared to an automatic transmission. Standard transmissions are generally stronger than automatic transmissions and off road vehicles take advantage of a direct gear selection so they can withstand rough conditions. Less active cooling is also required in manual transmission system because less power is wasted.●Popular Problem ChecksCar will not go into gearClutch disc is broken completelyInternal transmission damageFailed clutch master cylinderSeized clutch slave cylinderBroken clutch fork pivotBroken clutch cableCar goes into gear but it fades out or is slippingClutch is worn out and needs replacementClutch is oil soaked from a external engine oil leakCar makes grinding noise while operating or shifting gearsOne of the roller or thrust bearings has failedThe gear synchro is worn out not forcing the gear stop before it is engaged causing a grinding gear.A counter or main shaft bearing has failed causing misalignment of the gears●Troubleshooting Noise and ProblemsIf the vehicle is running and a whirring sound is heard, then it goes away when the clutch is depressed, the transmission input bearing has failed.If the transmission is quiet in neutral but when you depress the clutch a squeaking noise is observed, a clutch throw out bearing has failed.Tips:Never let little noises go unattended; a small noise can cause a large noise and transmission operation failure. Never overload a vehicle or tow beyond the capacity this can cause premature transmission failure.汽车变速器汽车传统变速器是那种标准的手动变速器。

TRANSMISSIONManual transmission is one of the most common transmission, referredto as MT. Its basic structure in a single sentence is a central axis, twoinput shaft, namely, the axial and axial oart, they constituted the transmission of the subject, and, of course, a reverse axis. Manual transmission gear transmission and manual, contain can in axial sliding gears, through different meshing gears to change gear of torsional purpose.The typical structure and principle of the manual transmission.Input shaft also says, it's in front of the spline shaft directly withclutch platen, thus the spline set by the engine relay of torque. The firstshaft gear meshing gears, often with oart as input shaft, and the gear on oart will turn. Also called shaft, because even more solid shaft of gear. The output shaft, and the second shaft position have the drive shaftgear, may at any time and under the influence of the control devices and the corresponding oart gear, thus changing the speed and torque itself. The output shaft is associated with tail spline shaft torque transmissionshaft, through to drive to gear reducer.Predictably, transmission gear drive forward path is: input shaftgear - oart gnaws gnaws gear - because the second shaft gear - corresponding corresponding gear. Pour on the axle gear can also controldevice, by moving axis in the strike, and the output shaft gear and oart gear, in the opposite direction.Most cars have five forward and reverse gear, each one has certain ratio,the majority of gear transmission more than 1, 4 gears transmission is 1, called directly, and ratio is less than 1 of article 5 gear shift accelerated called. The output axis gear in the mesh position, can acceptpower transmission.Due to the gearbox output shaft to input shaft and the speed of theirgear rotating, transform an "synchronization problem". Two rotating speeddifferent meshing gears forcibly inevitable impact and collision damage gear. Therefore, the old transmission shift to use "two feet clutch" method, ShengDang in neutral position shift to stay for a while, in the space location on the door, in order to reduce gear speed. But this operation is more complex, difficult to grasp accurately. Thereforedesigners to create "synchronizer", through the synchronizer will makethe meshing gears reach speed and smooth.Currently the synchronous transmission adopts is inertial synchronizer, it mainly consists of joints, synchronizer lock ring etc,it is characteristic of the friction effect on achieving synchronization.Mating, synchronizer and mating locking ring gear tooth circle have chamfering (locking horns), the synchronizer lock ring inside surface ofgear engagement ring and the friction surface contact. The lock horns with cone when designing the proper choice, has been made to the surface friction of meshing gears with gear synchronous, also can rapid producesa locking function, prevent the synchronous before meshing gears. When synchronous lock ring of gear engagement with surface contact surface, the outer circle in friction torque under the action of gear speed rapiddecrease (increase) or to synchronous speed equal, both locking ring spunconcurrent, relative to lock ring gear synchronous speed is zero, thus inertia moment also disappear, then in force, driven by the junction of unimpeded with synchronous lock ring gear engagement, and further to engagement with the engagement ring gear tooth and complete shift process.functional (1) change ratio, meet different driving conditions for tractionengine, the need to work in the favorable conditions and meet the speed may request. In a wide range of vehicle speed changing the size and automobile driving wheel on the size of the torque. Due to the differentdemands, automobile driving conditions of vehicle speed and torque can drive in a broad range of change. For example, in high speed can be reachedon 100km/h, while in the urban district, speed in 50km/h. In the empty flat roads, road, very little resistanceWhen When carrying carrying carrying uphill, uphill, uphill, driving driving driving resistance resistance resistance was was was great. great. great. And And And the thecharacteristics of automobile engine speed range is lesser, and torque changes more cannot meet the actual conditions range. (2) drive backward, to satisfy the need to drive car backwards. Realizing the backing, engine crankshaft are generally only to a direction,and sometimes need to back, so, often used in the transmission of reverseto realize the car drive backward.(3) in power, interruption, idle running engine starting, auto shift or need to stop the dynamic output, interrupted to transfer the power ofthe drive wheels.(4), when the clutch engagement realize gap, gearbox can not power output. For example, can ensure drivers in engine flameout loosen the clutch when leaving drivers seat.constituteBy continuously variable transmission gearbox and speed control twoparts. The main function of the variable transmission torque and speed is the change of numerical and direction, The main function of theoperation is controlled transmission mechanism, realize thetransformation of transmission ratio, shift to speed torque. Principle,Mechanical transmission main application of the principle of geartransmission velocity. Say simply, there are a number of differenttransmission gearbox group of gear pair of vehicle, and behavior, is alsoshifting gears trunk by manipulating institutions make different gearpair work. As in low-speed, ratio of gear pair work, and in high-speed, let ratio of small gear pair work.Classification,1, according to the change of transmission, transmission way, there can be divided into grade level and synthetical three.(a) : several levels of transmission ratio, can choose the fixed by gear. And can be divided into: gear axis of ordinary gear transmission and fixed gear planetary gear (part) of planetary gear transmission axisof rotation.b) stepless type transmission: ratio can be continuous variation within a certain range, commonly, mechanical and electric hydraulic typeetc.(c) comprehensive type transmission by a class type, transmission andstepless type transmission, the ratio of the maximum and minimum values can be in between the scope for several section stepless change.2, press control can be divided into compulsory manipulation, transmission, automatic control and semi-automatic control 3 kinds.(a) mandatory manipulation of transmission by direct manipulation, change gear shift lever drivers.(b) automatic control type transmission ratio of choice and change: the shift is automatic. Drivers simply manipulate accelerated pedal, transmission can according to the engine speed and load control signal signal actuator, realize the transformation of gear.(c) semi-automatic control type transmission can be divided into twokinds: one kind is part of gear, automatic shift gears, manual (mandatory)shift, Another kind is selected by button in mining under gear clutch pedalor accelerated release pedal, the executing agency to shift. Transmission of maintenance1 transmission gears maintenanceTransmission gears are always changing speed, load, gear toothsurface by bluntThe impact of load, which struck gear tooth surface (especially) damage. Common injuries are:(1) gear transmission is worn gear under normal working conditions, shows the wear uniform angled tooth gear, long wear along the directionTooth thickness shouldof the tooth should not exceed 30 percent longer,not exceed usd, Gear tooth surface area of not less than two-thirds, Running gear mesh clearance shall be commonly used, 0.15-0.26 mm to 0.8 mm limit, Gear engagement between 0.10-0.15 mm, should use limit for 0.60mm. Available batches or soft metal rivalries. If more than clearance method for measuring the pairs, should be replaced.due to fail togear clearance is mainly(2) gear teeth,broken toothmeet the requirements, gear meshing parts or work under great impact load.If you are not greater than 2mm edge of gear oil can smile ShiXiuafter-grinding continue to use, If the scope or have more than three pairs,should smile.(3) often mesh surface of the helical gear often wear face due. 10-0.30mm, in order to ensure that the axial clearance, if tooth gear good operation within the wear, can repair tank, but the amount of grinding grinding should not exceed. 50.(4) often meshing gears shaft neck, needle roller bearing and wear into seat hole hole meshing gears seat with needle bearings and shaft neckwith clearance should be 0.01 - three 0.08 mm, otherwise must be changed.2 the overhaul. Transmission shellGearbox shell is transmissions, to ensure the basis of each part of the transmission is correct position, work under load. Common injuries are:(1) the abrasion of shell bearing hole hole wear will destroy its bearing assembly relation with the bearing, the direct impact of input, output shaft transmission position relative to the hole. Bearing seat with0-0.03 mm clearance shall be used for the maximum limit, should be replacedor 0.10 mm) shell or pile hole repair.(2) shell threaded holes repair note oil ROM plug hole, dumping screwhole threads connecting bolts damage and between shellThreaded hole, can take damage with screw repair.3 transmission shaft of maintenanceTransmission in the process of operation, each bearing the torsionalmoment of change, and bending moment, JianChi part is under pressure, impact and sliding friction etc. Various axial load of common injuries are:(1) the shaft neck and neck too worn wear axis gear axis will not onlyoffset, and can bring the change gear clearance, when making noisetransmission shaft neck. Also make coordination relationship with bearingdamage, may cause ablation. So roller bearings in a place with no more than 0.02 axis wear mm needle bearing shaft neck wear with place, otherwisethan 0.07 mm landscape change or chrome.side of thein stress and more seriouswear JianChi wear(2) JianChispline. JianChi with check, when more than 0.25 or and wear with more thanusd keyway apprentice, gear engagement mm, combining with the gear with JianChi weeks, according to the mm apprentice woodruff key and shaft neckkeyways apprentice to JianChi 0.08 mm over there when the keyway weeks, or should be repaired or replaced shaft.(3) transmission shaft bending thimble resist transmission shaft withmaintenance on both ends of the roof, using pinhole batches of shaft radial micrometers, check the deviation should be less than 0.10 mm) pressure correction repair.4 synchronizer overhaulA. lock ring type inertial synchronizer ring maintenance: lock hornscone a about six degrees - 7 degrees, in use, cone Angle deformation ofrapid synchronous, and not be change in time. B. B. locking locking locking pin pin pin type type type inertial inertial inertial synchronizer: synchronizer: synchronizer: locking locking locking pin pin pin type type synchronizer major damage for cone rim wear, when, cone-disk cone rim on the thread of groove depth 0.40 mm wear to 010mm deep, should be replaced.If the cone rim are scratching, face to face, but two turning machining, must not be more than 1mm should be replaced.变速器手动变速器是最常见的变速器，简称MT MT。

外文原文：TransmissionsTransmissions have to compromise on either ride comfort or efficiency, but a new approach to the dog engagement gearbox could improve both.With tightening emissions regulations, carmakers are not just confining their efforts to improving combustion and after-treatment. Many are finding that modern engines are so advanced that the benefits of some engine technologies are small compared to the huge development costs involved.It's important to look at the whole vehicle in order to improve emissions. As the second most expensive piece of kit in the car, the transmission is the logical next place to look.Of all transmission technologies, the manual gearbox is the most efficient; around 96percent of the energy that is put in comes out of the other end. But not everyone can drive one or wants to. Because you have to dip the clutch pedal, it's less comfortable to drive in heavy traffic. It makes the driver tired and the torque interruptions' head-nod effect on passengers can be wearing.The driver's clutch control and corresponding torque interruptions are also the manual's weak point. When accelerating up through the gearbox, each up-shift requires the driver to cut the torque momentarily by lifting the gas pedal and dipping the clutch. It may just take a second to complete the operation, but during this time the vehicle is losing speed and acceleration.At the opposite and of the spectrum is the traditional automatic. Its shift quality is good thanks to its torque converter, but efficiency is relatively poor despite recent advances. Because of this ,a lot of the current research is trying to find an efficient alternative to the conventional automatic.The main technologies are continuously variable transmissions (CVTs); dual clutch transmissions(DCTs) and automated manual transmissions(AMTs).They all offer different benefits over the conventional planetary automatic.The CVT uses a belt chain or toroidal shaped dish drive to vary an infinite number of gear ratios. It has improved efficiency and cost when compared to conventional automatics.Its advantage comes from its simplicitu. It consists of very few components; usually a rubber or metal-link belt; a hydraulically operated driving pulley, a mechanical torque-sensing driving pulley, microprocessors and some sensors.The transmissions works by varying the distance between the faces of the two main pulleys.The pulleys have V-shaped grooves in which the connecting belt rides. One side of the pulley is fixed axially; the other side moves, actuated by hydraulics.When actuatec, the cylinder can increase or reduce the amount of space between the two sides of the pulley. This allows the belt to ride lower or higher along the walls ofthe pulley, depending on driving conditions. This changes the gear ratio. A torodial-type design works in a similar way but runs on discs and power-rollers.The "stepless" nature of its design is CVT's biggest draw for automotive engineers. Because of this, a CVT can work to keep the engine in its optimum power range, thereby increasing efficiency and mileage. A CVT can convert every point on the engine's operating curve to a corresponding point on its own operating curve.The transmission is most popular with Japanese carmakers and Japanese supplier JATCO is a major producer. But in the US and Europe driving styles are different. Uptake has been slow despite Audi and other manufacturers having offered CVT otions on their ranges.The DCT is, in effect, two manual gearboxes coupled together. Gear shifts are made by switching from one clutch on one gearbox to another clutch on the other. The shift quality is equal to a conventional automatic, but slip, fluid drag and lydraulic losses in the system result in only slightly improved efficiency and acceleration over the conventional planetary automatic. Developing the control strategy is costly too."Recent advances in conventional automatic technology have weakened the argument to develop and set up production for CVT or DCT." says Bill Martin, managing director of transmission firm zeroshift. "Some carmakers have cancelled DCT projects because of the cost."The cheapest way to build an automatic is with an AMT. AMTs use actuators to replace the clutch pedal and gear stick of a conventional manual. They keep the high efficiency and acceleration of a manual gearbox, but the shift quality on some models is lacking. Torque interruptions and the head-nod effect are the most common complaint.so what is the alternative? There are always new ideas in transmissions, but Zeroshift says that its technology has efficiency benefits over a manual, delivering fuel economy improvements to city driving. Shift quality can also be equal to that of a refined automatic.Zeroshift's approach is an upgrade to the AMT. The synchromesh is replaced with an advanced dog enqaqement system.Dog engagement has been used for many years in motor sport to allow fast shifts. Conventional dog boxes are unsuitable for road use as the large spaces between the drive lugs or "dogs" create backlash, an uncomfortable shunt caused by the sudden change in torque direction.Zeroshift's technology solves this problem by adding a second set of drive dogs. It has also made each of the two sets of dogs only capable of transmitting torque in one or other opposing directions. "By controlling the engagement and disengagement of the two sets you can shift into the new gear befor disengaging the previous gear, "says Martin. "The shift quality is smoother than a typical modern six-speed automatic luxury car."The shift is instant and the torque is not interrupted.This philosophy is used for both up and down shifts."In conventional AMT there is an emissions spike during a shift due to the need to back off and reintroduce throttle, this is eliminated by going seamless, "says Martin. "This also reduces fuel consumption."It is a relative newcomer to the transmission sector, but the firm says that it is already attracting the attention of major European and US carmakers. The big draw is as a low-cost alternative to DCT, says Martin.Because the manual gearbox architecture is largely maintained, production costs and complexity are not greater than for a conventional AMT. Development of the controls side is also considerably cheaper. Music to the ears of engineers trying to cut emissions and costs."Most of the carmakers have seen the system at least once," says Martion. "Some signed us immediately. Some have said not yet. None have said no. "That may be the clearest sign yet that when it comes to powertrain developments, carmakers are starting to focus on the transmission.HOW ZWROSHIFT WORKSThe hardware consists of two sets of bullets. mounted and actuated on two independent bullet rings. both sets of bullets run on the common hub, which is attached to the shaft with splines.Each bullet has a special profile. On one side they have an angled face for engagement. These are diagonally opposed, allowing the bullet to have a drive function for one gear and an overrun function for the other gear. The engagement faces taper backwards slightly to ensure the bullet latches onto the engaged gear under load.the opposite corners have a ramp, which pushes the bullet out of the previous gear once the new gear has been engaged.In neutral both bullet rings are positioned midway between the ratios. To select first gear, the bullets are moved into mesh with the engagement dogs.The bullets are actuated via shift forks conected to the shift actuators.The driving bullets lock first gear to the output shaft and transfer torque from the gearwheel onto the output shaft. The first gear overrun bullets are also moved into gear to lock the wheel to the output shaft in the opposite direction. This transfrs torque from the gearwheel onto the output shaft when the throttle closes and the engine overruns. This eliminates the backlash you'd expect from a dog engagement gearbox.To shift up with an open throttle, first gear's overrun bullets are unloaded and move in to engage second gear. This is followed by the previous driving ring which becomes unloaded when second gear is taken up.If the bullet is stopped from engaging fully-dog-face to dog-face-the second gear wheel opens an engagement window due to the relative speed difference. With the bullet pushed against the engagement dog compliance between the fork and actuator allows the stored energyto fire the bullet into the window.The first gear overrun bullets have now become the second gear drive bullets. As second gear takes over, the load is removed from the first gear drive bullets. These bullets are now no longer held by their retention angie and can be either moved out ofgear by actuators or pushed out of gear by contact with the ramp face of the bullet.The first gear drive bullets then move across into engagement with second gear. In second gear, the roles of the bullets are reversed.Audi RoadjetAudi plans to add comfort, luxury and practicality without increasing emissions The Roadjet concept, first shown at Detroit in January 2006,indicates a number of technical directions that Audi going to take in the coming year. The firm is focusing on interior design, powertrain, chassis, electronics and safety innovations.These new directions will help Audi strengthen its position in the sub-luxury market that it previously had to itself. Audi has two main tactics to attract new customers in the US. It is breaking into the sports utility vehicle(SUV)and compact utility vehicle(CUV)markets.It also introduces new luxury and lifestyle features to strengthen its position in the US; sales there still lag behind those of BMW, Lexus and Mercedes-Benz. The recently launched Q7 off-road luxury vehicle is a late bid to capitalise on the SUV boom.In Europe, the carmaker's technical innovations such as aluminium construction, four-wheel-drive, and novel powertrain technologies have been successful. But if Audi wants to increase its US market share, it needs to innovate in those areas valued by American customers: comfort, luxury and practicality.Audi's designers have focused on this in the interior. They have devised a new wrap-around instrument panel shape to replace the more functional design in existing models. They have expanded the vehicle's multi-media interface (MMI)control system, used for cruise control, suspension, climate and entertainment separate controls. Combined with an upgraded climate system, occupants can set their own individual climate settings.Soft, warm, earthy colours are used in the Roadjet to create a feeling of well-being. The concept uses high quality functional materials: the upholstery is fine leather; the floor is neoprene. The space between the rear seats can house a range of optional equipment: the show car featured an espresso coffee machine. Storage boxes and baby carriers are more realistic alternatives.To enhance practicality, the rear seats slide backwards and forwards diagonally to increase shoulder and leg-room or rear load space. When the rear seats are in their most forward position, an oblique-facing child seat can be used behind the seats.Roadjet's load bay features an eletrically extending load floor to ease loading, offering unmerous lashing points to secure luggage items. The sliding seats and extending load floor are very likely to enter production on Audi's Q5 and A4 models.To heighten the sense of luxury, the concept uses a costly 1,000W Bang & Olufsen sound system with 14-speakers.This incorporates a "digital voice support" function that uses microphones and the car's speakers to pick up and amplify passengers' voices to ensure clear conversation even at high speeds.In a bid to improve road safety, convenience and traffic management, carmakers are working to common standards to develop a new in-car system to talk to other cars androadside wireless olcal area networks. In traffic jams, bad weather or accident situations, cars send information to emergency services, other cars and traffic computers. The Roadjet concept featres previews such a system.The weight of all the new electronics and luxury equipment in this segment, combined with customers' growing demand for power is having a negative effect on exhaust emissions and fuel consumption. Audi is looking at sophisticated technical solutions to balance the equation.Roadjet's 3.2-litre gasoline direct injection engine is based on an existing engine but features a new fixed intake manifold with an integral vacuum reservoir to increase its output. This is combined with a two-stage cam operated variable valve lit technology to increase output.Despite the sports car performance, the Roadjet's overall fuel consumption is slightly lower than the current A4 Quattro 3.2FSI.The valve train technology, due to enter production later in 2006,lets the engine perform economically and smoothly during normal driving, switching automatically to more responsive, more powerful characteristics when the driver demands.Roadjet also has the first Audi application of speeddependent variable ratio dynamic steering for a stable highspeed motorway ride but with enhanced control on twisty country roads. Electronically-controlled variable rate dampers automatically adjust from soft and comfortable to firm and sporty to enhance safety and handling.Audi's engineers have electronically linked all of these systems to create three driver-selectable programmes: dynamic, comfort and sport. Each programme adjusts the dampers, steering, gearbox and engine eletronics to give different driving experiences.Roadjet's body styling marks a new direction for the carmaker.At 1.55m high with a wheelbase 4.7m long and 2.85m wide, the concept is roomy. The firm has used a combination of sharp feature lines and careully-sculpted concave-section doors to disguise the height. While the trademark LED tail lights are likely to enter production unchanged, steerable xenon gas discharge lights will replace the LEDs in the headlamps.Around the end of 2007 Audi will launch the Q5 CUV, based on the next A4 platform. Smaller and lighter than the Q7,it will be well placed to compete in the profitable CUV segment in the US. The Roadjet previews elements of the interior and exterior styling of this model.The Q5 will need to be more rugged to match the outdoor lifestyle image of the CUVsegment. At the same time, for the European market, the Roadjet's sharp style previews the next A4 model range, which may produce a new hatchback body in 2007 to join the conventional saloon and Avant estate. The dashboard and other new interior refinements are likely to spread across the rest of the Audi range over the next 24 months.中文译文：变速器变速箱通常不得不在舒适性和效率之间做出选择，但一种新型的“犬牙啮合式”变速箱可以同时改善这两种性能。

附录附录A英文科技文献Transmission OverviewTransmission gearbox's function the engine's output rotational speed is high, the maximum work rate and the maximum torque appears in certain rotational speed area. In order to display engine's optimum performance, must have a set of variable speed gear, is coordinated the engine the rotational speed and wheel's actual moving velocity. The transmission gearbox may in the automobile travel process, has the different gear ratio between the engine and the wheel, through shifts gears may cause the engine work under its best power performance condition. Transmission gearbox's trend of development is more and more complex, the automaticity is also getting higher and higher, the automatic transmission will be future mainstream.Automotive Transmission's mission is to transfer power, and in the process of dynamic change in the transmission gear ratio in order to adjust or change the characteristics of the engine, at the same time through the transmission to adapt to different driving requirements. This shows that the transmission lines in the automotive transmission plays a crucial role. With the rapid development of science and technology, people's car is getting higher and higher performance requirements, vehicle performance, life, energyconsumption, such as vibration and noise transmission depends largely on the performance, it is necessary to attach importance to the study of transmission.Transmission gearbox's pattern the automobile automatic transmission common to have three patterns: Respectively is hydraulic automatic transmission gearbox (AT), machinery stepless automatic transmission (CVT), electrically controlled machinery automatic transmission (AMT). At present what applies is most widespread is, AT becomes automatic transmission's pronoun nearly.AT is by the fluid strength torque converter, the planet gear and the hydraulic control system is composed, combines the way through the fluid strength transmission and the gear to realize the speed change bending moment. And the fluid strength torque converter is the most important part, it by components and so on pump pulley, turbine wheel and guide pulley is composed, has at the same time the transmission torque and the meeting and parting function.And AT compare, CVT has omitted complex and the unwieldy gear combination variable transmission, but is two groups of band pulleys carries on the variable transmission. Through changes the driving gear and the driven wheel transmission belt's contact radius carries on the speed change. Because has cancelled the gear drive,therefore its velocity ratio may change at will, the speed change is smoother, has not shifted gears kicks the feeling.AMT and the hydraulic automatic transmission gearbox (AT) is the having steps automatic transmission equally. It in the ordinary manual transmission gearbox's foundation, through installs the electrically operated installment which the microcomputer controls, the substitution originally coupling's separation which, the joint and the transmission gearbox completes by the manual control elects to keep off, to shift gears the movement, realizes fluid drive.Manual transmission gear mainly uses the principle of deceleration. Transmission within the group have different transmission ratio gear pair, and the car at the time of shift work, that is, through the manipulation of institutions so that the different transmission gear pair work. Manual transmission, also known as manual gear transmission, with axial sliding in the gears, the meshing gears through different speed to achieve the purpose of torque variation. Manual shift transmission can operate in full compliance with the will of the driver, and the simple structure, the failure rate is relatively low, value for money.Automatic transmission is based on speed and load (throttle pedal travel) for two-parameter control gear in accordance with the above two parameters to automatically take-off and landing.Automatic transmission and manual transmission in common, that is, there are two-stage transmission, automatic transmission can only speed the pace to automatically shift, manual transmission can be eliminated, "setback" of the shift feel.Automatic transmission is a torque converter, planetary gears and hydraulic manipulation of bodies, through the hydraulic transmission and gear combination to achieve the purpose of variable-speed torque variation.Also known as CVT-type continuously variable CVT. This transmission and automatic transmission gear generally the biggest difference is that it eliminates the need of complex and cumbersome combination of variable-speed gear transmission, and only two groups to carry out variable-speed drive pulley.CVT transmission than the traditional structure of simple, smaller and it is not the number of manual gear transmission, no automatic transmission planetary gear complex group, mainly rely on the driving wheel, the driven wheel and the transmission ratio brought about by the realization of non-class change.Widely used in automotive internal combustion engine as a power source, the torque and speed range is very small, and complex conditions require the use of motor vehicles and the speed of the driving force in the considerable changes in the scope. Toresolve this contradiction, in the transmission system to set up the transmission to change transmission ratio, the expansion of the driving wheel torque and speed range in order to adapt to constantly changing traffic conditions, such as start, acceleration, climbing and so on, while the engine in the most favorable conditions to work under the scope; in the same direction of rotation of the engine under the premise of the automobile can be driven back; the use of neutral, interruption of power transmission, in order to be able to start the engine, idle speed, and ease of transmission or power shift . Transmission is designed to meet the above requirements, so that the conditions in a particular vehicle stability.In addition to transmission can be used to meet certain requirements, but also to ensure that it and the car can have a good match, and can improve the car's power and economy to ensure that the engine in a favorable condition to increase the scope of the work of the use of motor vehicles life, reduce energy consumption, reduce noise, such as the use of motor vehicles.Today the world's major car companies CVT are very active in the study. The near future, with electronic control technology to further improve, electronically controlled Continuously VariableTransmission-type is expected to be a wide range of development and application.附录B文献翻译变速器概述发动机的输出转速非常高，最大功率及最大扭矩在一定的转速区出现。

Motors and gearboxesAs the world energy crisis, and the war and the energy consumption of oil -- and are full of energy, in one day, someday it will disappear without a trace. Oil is not in resources. So in oil consumption must be clean before finding a replacement. With the development of science and technology the progress of the society, people invented the electric car. Electric cars will become the most ideal of transportation.In the development of world each aspect is fruitful, especially with the automobile electronic technology and computer and rapid development of the information age. The electronic control technology in the car on a wide range of applications, the application of the electronic device, cars, and electronic technology not only to improve and enhance the quality and the traditional automobile electrical performance, but also improve the automobile fuel economy, performance, reliability and emissions purification. Widely used in automobile electronic products not only reduces the cost and reduce the complexity of the maintenance. From the fuel injection engine ignition devices, air control and emission control and fault diagnosis to the body auxiliary devices are generally used in electronic control technology, auto development mainly electromechanical integration. Widely used in automotive electronic control ignition system mainly electronic control fuel injection system, electronic control ignition system, electronic control automatic transmission, electronic control (ABS/ASR) control system, electronic control suspension system, electronic control power steering system, vehicle dynamic control system, the airbag systems, active belt system, electronic control system and the automatic air-conditioning and GPS navigation system etc. With the system response, the use function of quick car, high reliability, guarantees of engine power and reduce fuel consumptionand emission regulations meet standards.The car is essential to modern traffic tools. And electric cars bring us infinite joy will give us the physical and mental relaxation. Take for example, automatic transmission in road, can not on the clutch, can achieve automatic shift and engine flameout, not so effective improve the driving convenience lighten the fatigue strength. Automatic transmission consists mainly of hydraulic torque converter, gear transmission, pump, hydraulic control system, electronic control system and oil cooling system, etc. The electronic control of suspension is mainly used to cushion the impact of the body and the road to reduce vibration that car getting smooth-going and stability. When the vehicle in the car when the road uneven road can according to automatically adjust the height. When the car ratio of height, low set to gas or oil cylinder filling or oil. If is opposite, gas or diarrhea. To ensure and improve the level of driving cars driving stability. Variable force power steering system can significantly change the driver for the work efficiency and the state, so widely used in electric cars. VDC to vehicle performance has important function it can according to the need of active braking to change the wheels of the car, car motions of state and optimum control performance, and increased automobile adhesion, controlling and stability. Besides these, appear beyond 4WS 4WD electric cars can greatly improve the performance of the value and ascending simultaneously. ABS braking distance is reduced and can keep turning skills effectively improve the stability of the directions simultaneously reduce tyre wear. The airbag appear in large programs protected the driver and passenger's safety, and greatly reduce automobile in collision of drivers and passengers in the buffer, to protect the safety of life.Intelligent electronic technology in the bus to promote safe driving and that the other functions. The realization of automatic driving through various sensors. Except some smart cars equipped withmultiple outside sensors can fully perception of information and traffic facilities and to judge whether the vehicles and drivers in danger, has the independent pathfinding, navigation, avoid bump, no parking fees etc. Function. Effectively improve the safe transport of manipulation, reduce the pilot fatigue, improve passenger comfort. Of course battery electric vehicle is the key, the electric car battery mainly has: the use of lead-acid batteries, nickel cadmium battery, the battery, sodium sulfide sodium sulfide lithium battery, the battery, the battery, the flywheel zinc - air fuel cell and solar battery, the battery. In many kind of cells, the fuel cell is by far the most want to solve the problem of energy shortage car. Fuel cells have high pollution characteristics, different from other battery, the battery, need not only external constantly supply of fuel and electricity can continuously steadily. Fuel cell vehicles (FCEV) can be matched with the car engine performance and fuel economy and emission in the aspects of superior internal-combustion vehicles.Along with the computer and electronic product constantly upgrading electric car, open class in mature technology and perfected, that drive more safe, convenient and flexible, comfortable. Now, the electric car from ordinary consumers distance is still very far away, only a few people in bandwagon. Electric cars with traditional to compete in the market, the car will was electric cars and intelligent car replaced. This is the question that day after timing will come. ABS, GPS, and various new 4WD 4WS, electronic products and the modern era, excellent performance auto tacit understanding is tie-in, bring us unparalleled precision driving comfort and safety of driving.The role of transmissionThe output of the engine speed is very high, maximum power and maximum torque at a certain speed area. Engine in order to exert the best performance, it is necessary to have a variable-speed devices, to coordinate the engine speed and the actual wheel speed. Transmissionprocess in the car, in between the engine and the wheels have a different gear ratio, by shifting the engine can work at their best performance of state power. Transmissions are the development trend of more and more complex, increasingly high degree of automation, automatic transmission will be the mainstream of the future. Transmission typeAutomotive automatic transmission has three common forms: namely, Automatic Transmission (AT), mechanical stepless automatic transmission (CVT), electric-controlled mechanical automatic transmission (AMT). At present, the most widely used is the AT, AT almost become synonymous with automatic transmission.AT Torque by Torque, and planetary gear and hydraulic control system components, through the hydraulic transmission and gear portfolio approach to achieve variable-speed torque variation. One of Hydraulic Torque is the most important parts, which pump wheels, turbines and components, such as guide pulley of the transmission of both torque and the role of clutch.AT compared with, CVT save the complex and cumbersome combination of variable-speed gear transmission, but the two groups to carry out variable-speed drive pulley. By changing the driving wheel and driven wheel contact belt speed radius. Canceled because of gear, so the transmission ratio can change speed more smoothly, without shifting sense of the sudden jump.AMT and Automatic Transmission (AT) are the same class has automatic transmission. It is in general based on the manual transmission, through the installation of microcomputer-controlled electric device to replace the original finish by the manual operation of the clutch of separation, joint, and block transmission of the election, motion shift, automatic shift implementation.The general structure of automobile transmission1. Easy transmission of the basic structure: the shell, transmissionand manipulation of some parts.(1) Shell: Shell is the basic pieces of support for the installation of transmission and storage of all parts lubricants. Has installed its bearing on the precision boring. Transmission under varying load, so the stiffness of the shell should be enough, there is to strengthen the wall, the shape of the complex, as many castings (gray cast iron materials, commonly used HT200).In order to facilitate the installation, transmission and manipulation of some Split parts are frequently made, cover with the housing connected by bolts and reliable positioning. Shell has come on up, I put the oil, check oil foot mouth, should also be taken into heat dissipation.(2) Transmission parts: is the gear, shaft, bearings and other transmission parts. Geometry axis through strength, stiffness calculation. Mainly due to decide on the stiffness, while the carbon steel and alloy steel elastic modulus almost equal, so the general use of carbon steel (commonly used 45 steel). Only one gear with the shaft or axle load made serious only by steel. Shaft and gear for many spline connection (for neutral good, reliable transmission of power, a small compressive stress, etc.). Spline shaft bearing parts and let the surface hardening treatment by the Department. Shaft with rolling bearing supports many, easy lubrication, high efficiency, small radial clearance, axial positioning should be reliable. Many ways to use splash lubrication (υ> 25m / s, as long as the appropria te viscosity apparently succumbed to the wall).(3) to manipulate parts: the main components located inside the transmission cover.2. The composition of the structural characteristics of transmission: there is easy and efficient transmission, the advantagesof simple easy-to-use-Jun mine but a few files, i changed the scope of small (traction, speed small), file number should be taken only atcertain limited Cut used. If the increase in the scope of i, then increase the size so that transmission, axle span increase, both in order to increase the file-axis span of a few do not make too large, transmission can be formed. The composition of the so-called transmission, usually from both a combination of easy transmission, one of a few more files as the main transmission, less transmission known as the deputy. Transmission component of advantages:(1) can reduce the number of gears, and a few more files to reduce the number of gear the more obvious advantages. Easy compared with the transmission, it can shorten the length of shaft to reduce the transmission of the external size and weight, and can easily be more than one reverse. Into the file so the current number of files more than six hours, almost all transmission components.(2) transmiss ion: the rate of change of Ω than large: if the main transmission gear ratio change rate Ωzu = 3, Vice transmission Ωfu = 4 is Ω = 12; easy transmission arrangement Ω = 12, the structure is often difficult to reasonable.Composed of transmission of disadvantage:(1) file groups have correspondence between the transmission ratio, so that each file is not 2, (the speed and traction) are ideal.(2) manipulation of trouble shifting, and sometimes both want to manipulate some speed, if not for the flower arrangement will shift memory.In order to reduce the control action, it is best to shift the order. Calling attention to the grade for this presentation ten out files so that the first group of transmission ratio is greater than all of the first file group 11 to the majority of phase transformation from the stall speed of just fixing the main purpose of this is the only way most convenient. GM Hydra-MaticGeneral can be regarded as the founder of automotive automatic transmission has been. The world's first automatic transmission is usedin the United States in 1940 Oldsmobile automobile on a common, and it is a tandem structure of planetary gear transmission fluid control. Applies to the Cadillac STS-V's latest six-speed Hydra-Matic automatic transmission 6L80, may be regarded as the world's most advanced Automatic Transmission (AT) has been.Automatic Transmission For example, it has an internal gear is also divided, but the abolition of the clutch. The more gear, then shift, the better the ride comfort. At present, common automatic transmission are generally four-speed, that is, block has four forward. 6L80 has six forward gear, the number of teeth than the one block are separately 2.36,3 block 4.03,2 block 0.85,6 block 1.15,5 block 1.53,4 block 0.67. Obviously, it is more than 4-speed automatic transmission with a greater ratio and smaller ratio of the difference, it is more smooth when speed.Outside the block a few more besides, 6L80 also has a lot of unique special skills:Driver shift control system (DSC) - through its driver into a vehicle without the clutch from the automatic five-speed, high-performance手动挡. Drivers under the food stalls to the DSC on the location, the light touch can be specified at the scope of the neat, smooth implementation block addition and subtraction. The driver to switch control mode, the transmission control module monitors the vehicle speed, engine torque and gear used to decide whether to automatically add block to avoid damage to the powertrain. Each have a sliding gear on the clutch, can be carried out on all five gear engine braking.Performance computing systems down block (PAL) - in a row after a high-speed, stop升挡maintain engine braking. Transmission control module based on driving behavior to decide whether to activate the device. If the system found in the vehicle slowed down before turning, transmission may be even lower in order to avoid stall twoblock.Performance computing shift system (PAS) - turn off the accelerator in high-speed automatic adjustment of the level of acceleration gear, re-open at throttle-down power to elevate. Once the transmission control module to detect high levels of command, this function immediately.This transmission also reduced in the rugged mountain road "Shift Search," the stability of the shift functions, with the lower block BrakeAssist monitoring function, electronically controlled engine braking, as well as to adapt to these high-power, high torque engines are the new need a new dual-chip torque converter. In addition, SRX is also equipped with high-performance downhill Downgrade Detection Brake Assist.Chinese car market gearboxChina's auto market is in a transmission period of rapid development. 2007 Chinese sales of 8,791,500 motor vehicles, motor vehicle production in 2008 will exceed nine million sales, car sales in 2010 will reach 12.63 million. Size of the market in the automotive industry's rapid growth, China is faced with a major transmission industry opportunities. In 2006 the market scale of China's automobile transmission up to 300 billion yuan and more than 20% annual growth is expected in 2010 is expected to reach 60 billion yuan.汽车与变速箱随着世界能源危机的持续，以及战争和能源-----石油的消耗及汽车饱有量的增加，能源在一天一天下降，终有一天它会消失的无影无踪。

机械专业外文翻译（中英文翻译）第1页Among the methods of material conveying employed，belt conveyorsplaya very important part in the reliable carrying of material over longdistances at competitive cost．Conveyor systems have become larger and morecomplex and drive systems have also been going through a process of evolutionand will continue to do so．Nowadays，bigger belts require more power and havebrought the need for larger individual drives as well as multiple drives suchas 3 drives of 750 kW for one belt(this is the case for the conveyor drivesin Chengzhuang Mine)．The ability to control drive acceleration torque iscritical to belt conveyors’ performance．An efficient drive system should beable to provide smooth，soft starts while maintaining belt tensions withinthe specified safe limits．For load sharing on multiple drives．torque andspeed control are also important considerations in the drive system’s design.Due to the advances in conveyor drive control technology，at present many morereliable．Cost-effective and performance-driven conveyor drive systems[1]covering a wide range of power are available for customers’ choices. Full-voltage starters．With a full-voltage starter design，the conveyor head shaft is direct-coupled to the motor through the gear drive．Direct full-voltage startersare adequate for relatively low-power, simple-profile conveyors．With direct fu11-voltage starters．no control is provided for various conveyor loadsand．depending on the ratio between fu11- and no-1oad power requirements，empty starting times can be three or four times faster than full load．The maintenance-free starting system is simple，low-cost and very reliable．However, they cannot control starting torque and maximum stall torque；therefore．they are第2页 limited to the low-power, simple-profile conveyor belt drives．Reduced-voltage starters．As conveyor power requirements increase，controlling the applied motor torque during the acceleration period becomes increasinglyimportant．Because motor torque 1s a function of voltage，motor voltage must be controlled．This can be achieved through reduced-voltage starters by employinga silicon controlled rectifier(SCR)．A common starting method with SCRreduced-voltage starters is to apply low voltage initially to takeup conveyorbelt slack．and then to apply a timed linear ramp up to full voltage and beltspeed．However, this starting method will not produce constant conveyor beltacceleration．When acceleration is complete．the SCRs, which control the applied voltage to the electric motor． are locked in full conduction, providing fu11-linevoltage to the motor．Motors with higher torque and pull—uptorque，can provide better starting torque when combined with the SCR starters, which are availablein sizes up to 750 KW．Wound rotor induction motors．Wound rotor induction motors are connecteddirectly to the drive system reducer and are a modifiedconfiguration of a standardAC induction motor．By inserting resistance in series with the motor’s rotor windings．the modified motor control system controlsmotor torque．For conveyor starting，resistance is placed in series with the rotor for low initial torque．As the conveyor accelerates，the resistance is reduced slowly to maintain a constantacceleration torque．On multiple-drive systems．an external slip resistor may beleft in series with the rotor windings to aid in load sharing．The motor systems have a relatively simple design．However, the control systems for these can behighly complex，because they are based on computer control of the resistanceswitching．Today，the majority of control systems are custom designed to meet aconveyor system’s particular specifications．Wound rotor motors are appropriatefor systems requiring more than 400 kW ．DC motor．DC motors．available from a fraction of thousands of kW ，are designed to deliver constant torque below base speed and constant kW above base speed tothe maximum allowable revolutions per minute(r/min)．with the majority of conveyordrives, a DC shunt wound motor is used．Wherein the motor’srotating armature is第3页 connected externally．The most common technology for controlling DC drives is aSCR device． which allows for continual variable-speed operation．The DC drive system is mechanically simple, but can include complex custom-designed electronicsto monitor and control the complete system．This system option is expensive incomparison to other soft-start systems．but it is a reliable, cost-effective drivein applications in which torque,1oad sharing and variable speed are primaryconsiderations．DC motors generally are used with higher-power conveyors，including complex profile conveyors with multiple-drive systems，booster tripper systems needing belt tension control and conveyors requiring a wide variable-speed range．Hydrokinetic couplings，commonly referred to as fluid couplings．are composed of three basic elements; the driven impeller, which acts as a centrifugal pump；the driving hydraulic turbine known as the runner and a casing that encloses thetwo power components．Hydraulic fluid is pumped from the driven impeller to thedriving runner, producing torque at the driven shaft．Because circulating hydraulicfluid produces the torque and speed，no mechanical connection is required betweenthe driving and driven shafts．The power produced by this coupling is based onthe circulated fluid’s amount and density and the torque in proportion to inputspeed．Because the pumping action within the fluid coupling depends on centrifugalforces．the output speed is less than the input speed．Referred to as slip．this normally is between l% and 3%．Basic hydrokinetic couplings are available inconfigurations from fractional to several thousand kW ．Fixed-fill fluid couplings．Fixed-fill fluid couplings are the most commonlyused soft-start devices for conveyors with simpler belt profiles and limitedconvex/concave sections．They are relativelysimple,1ow-cost,reliable,maintenance free devices that provide excellent softstarting results to the majority of belt conveyors in use today．Variable-fill drain couplings．Drainable-fluid couplings work on the sameprinciple as fixed-fill couplings．The coupling’s impellers are mounted on the ACmotor and the runners on the driven reducer high-speed shaft．Housing mounted to the drive base encloses the working circuit．The coupling’s rotating casing contains第4页 bleed-off orifices that continually allow fluid to exit the working circuit intoa separate hydraulic reservoir．Oil from the reservoir is pumped through a heatexchanger to a solenoid-operated hydraulic valve that controls the filling of thefluid coupling．To control the starting torque of a single-drive conveyor system，the AC motor current must be monitored to provide feedback to the solenoid controlvalve．Variable fill drain couplings are used in medium to high-kW conveyor systemsand are available in sizes up to thousands of kW ．The drives can be mechanicallycomplex and depending on the control parameters．the system can be electronicallyintricate．The drive system cost is medium to high, depending upon size specified．Hydrokinetic scoop control drive．The scoop control fluid coupling consistsof the three standard fluid coupling components：a driven impeller, a driving runnerand a casing that encloses the working circuit．The casing is fitted with fixedorifices that bleed a predetermined amount of fluid into a reservoir．When the scoop tube is fully extended into the reservoir, the coupling is l00 percentfilled．The scoop tube, extending outside the fluid coupling，is positioned using an electric actuator to engage the tube from the fully retracted to the fullyengaged position．This control provides reasonably smooth acceleration rates．to but the computer-based control system is very complex．Scoop control couplings are applied on conveyors requiring single or multiple drives from l50 kW to 750kW.Variable frequency control is also one of the direct drive methods．The emphasizing discussion about it here is because that it has so uniquecharacteristic and so good performance compared with other driving methods forbelt conveyor． VFC devices Provide variable frequency and voltageto the inductionmotor, resulting in an excellent starting torque and acceleration rate for beltconveyor drives．VFC drives．available from fractional to several thousand(kW ),are electronic controllers that rectify AC line power to DC and，through an inverter, convert DC back to AC with frequency and voltage contro1．VFC drives adopt vector control or direct torquecontrol(DTC)technology，and can adopt different operating speeds according to different loads．VFC drives can make starting or stalling第5页 according to any given S-curves．realizing the automatic track for starting orstalling curves．VFC drives provide excellent speed and torque control for startingconveyor belts．and can also be designed to provide load sharing for multipledrives．easily VFC controllers are frequently installed on lower-powered conveyordrives，but when used at the range of medium-high voltage in the past．the structure of VFC controllers becomes very complicated due to the limitation of voltage ratingof power semiconductor devices，the combination of medium-high voltage drives andvariable speed is often solved with low-voltage inverters usingstep-uptransformer at the output，or with multiple low-voltage inverters connected inseries．Three-level voltage-fed PWM converter systems are recently showingincreasing popularity for multi-megawatt industrial driveapplications becauseof easy voltage sharing between the series devices and improved harmonic qualityat the output compared to two-level converter systems With simple series connectionof devices．This kind of VFC system with three 750 kW /2．3kV inverters has been successfully installed in ChengZhuang Mine for one 2．7-km long belt conveyordriving system in following the principle of three-level inverterwill be discussedin detail．Three-level voltage-fed inverters have recently become more and more popularfor higher power drive applications because of their easy voltage sharingfeatures．1ower dv/dt per switching for each of the devices，and superior harmonic quality at the output．The availability of HV-IGBTs has led to the design of anew range of medium-high voltage inverter using three-level NPC topology．This kind of inverter can realize a whole range with a voltagerating from 2．3 kV to 4．1 6 kV Series connection of HV-IGBT modules is used in the 3．3 kV and 4．1[2,3]6 kV devices．The 2．3 kV inverters need only one HV-IGBT per switch.To meet the demands for medium voltage applications．a three-level neutral point clamped inverter realizes the power section．In comparison to a two-levelinverter．the NPC inverter offers the benefit that three voltage levels can besupplied to the output terminals，so for the same output current quality，only第6页1/4 of the switching frequency is necessary．Moreover the voltage ratings of theswitches in NPC inverter topology will be reduced to 1/2．and the additional transient voltage stress on the motor can also be reduced to 1/2 compared to thatof a two-level inverter．The switching states of a three-level inverter are summarized in Table 1．U．V and W denote each of the three phases respectively；P N and O are the dc bus points．The phase U，for example，is in stateP(positive bus voltage)when theswitches S and S are closed，whereas it is in state N (negative bus voltage) 1u2uwhen the switches S and S are closed．At neutral point clamping，the phase is 3u4uin O state when either Sor S conducts depending on positive or negative phase 2u 3ucurrent polarity，respectively．For neutral point voltage balancing，the average current injected at O should be zero．For standard applications．a l2-pulse diode rectifier feeds the divided DC-linkcapacitor．This topology introduces low harmonics on the line side．For even higher requirements a 24-pulse diode rectifier can be used as an input converter．For more advanced applications where regeneration capability is necessary, an activefront．end converter can replace the diode rectifier, using the same structureas the inverter．Motor Contro1．Motor control of induction machines is realized by using a rotorflux．oriented vector controller．Fig．2 shows the block diagram of indirect vector controlled drive thatincorporates both constant torque and high speed field-weakening regions wherethe PW M modulator was used．In this figure，the command flux is generated as function of speed．The feedback speed is added with the feed forward slip commandsignal . the resulting frequency signal is integrated and then the unit vectorsignals(cos and sin )are generated．The vector rotator generates the voltageand angle commands for the PW M as shown．PWM Modulator．The demanded voltage vector is generated using an elaborate第7页 PWM modulator．The modulator extends the concepts of space-vector modulation tothe three-level inverter．The operation can be explained by starting from aregularly sampled sine-triangle comparison from two-level inverter．Instead of using one set of reference waveforms and one triangle defining the switchingfrequency， the three-level modulator uses two sets of reference waveforms U and r1U and just one triangle．Thus, each switching transition is used in an optimal r2way so that several objectives are reached at the same time．Very low harmonics are generated．The switching frequency is low and thusswitching losses are minimized．As in a two-level inverter, a zero-sequencecomponent can be added to each set of reference waveform s in order to maximizethe fundamental voltage component．As an additional degree of freedom，the position of the reference waveform s within the triangle can be changed．This can be used for current balance in the two halves of the DC-1ink．After Successful installation of three 750 kW /2．3 kV three-level invertersfor one 2．7 km long belt conveyor driving system in Chengzhuang Mine．The performance of the whole VFC system was tested．Fig．3 is taken from the test，which shows the excellent characteristic of the belt conveyor driving system withVFC controller．Fig．3 includes four curves．The curve 1 shows the belt tension．From the curve it can be find that the fluctuation range of the belt tension is very smal1．Curve 2 and curve 3 indicate current and torque separately．Curve 4 shows the velocityof the controlled belt．The belt velocity have the“s”shape characteristic．A1l the results of the test show a very satisfied characteristic for belt drivingsystem．Advances in conveyor drive control technology in recent years have resultedin many more reliable．Cost-effective and performance-driven conveyor drive systemchoices for users．Among these choices，the Variable frequency control (VFC) methodshows promising use in the future for long distance belt conveyor drives due toits excellent performances．The NPC three-level inverter using high voltage IGBTs第8页 make the Variable frequency control in medium voltage applications become muchmore simple because the inverter itself can provide the medium voltage needed atthe motor terminals，thus eliminating the step-up transformer in most applicationsin the past．The testing results taken from the VFC control system with NPC three．1evel inverters used in a 2．7 km long belt conveyor drives in Chengzhuang Mine indicatesthat the performance of NPC three-level inverter using HV-IGBTs together with thecontrol strategy of rotor field-oriented vector control for induction motor driveis excellent for belt conveyor driving system．第9页在运送大量的物料时，带式输送机在长距离的运输中起到了非常重要的竞争作用。

附录外文文献Manual transmission is the most basic of transmission of a type, its effect is changing, and provide the transmission reverse and neutral. Usually, the pilot on the clutch pedal through manipulation and in any HuanDangGan can choose between gear. There are a few manual transmission, such as motorcycles, cars, some transmission shift transmission allows only sequence, the transmission is called sequence shift transmission. In recent years, along with the electronic control components durability, computerized automatic switching clutch automatic shift of transmission in Europe since the start line are more and more popular, car Volkswagen and ford are sold in the city on the double clutch provide updated generation, transmission from the start with two clutches, every shift automatically switch to another group of clutch engagement, need not as quick as traditional in manual have only one group separated again clutch engagement, shifting speed is faster, more small change gear vibration.Internal structure: shaftDecorate a form of transmission shaft type usually have two and three shaft type two kinds. Usually a rear wheel drive car will adopt three axis type, i.e. input shaft transmission, the output shaft and oart. Input shaft front associated with engine, borrow clutch output shaft back-end through the flange and universal transmission device connected.Input shaft and the output shaft in the same horizontal line, with their oart parallel arrangement. From the input shaft power through the gears to preach to the output shaft oart again. In many input and output shaft transmission shaft could engage in together, so to power, then the gear oart called directly. Direct files through uniaxial transmission, the ratio of 1:1, the highest transmission efficiency. Even in the transmission directly, cannot offer the input shaft, and the output shaft is decorated in a straight line to reduce work needed to inherit the torque transmission.Reversing deviceGenerally speaking, the reverse gear reducer than can alsosynchronizerIn synchronized meshing gears have type synchronizer Settings, can make two gear engagement in the first, before the speed reached synchronizer in all of this manual gear transmission of the car has been usedClutch,The clutch is can make two gear with a separate with mechanical parts, two gear transmission power can be combined, but when to speed, so will depend on the first two gear clutch, change gear ratio, the two gear transmission power, continue again Control：GearIn simple terms, the high speed, low speed ShengDang when the time cameEvery car high speedCompared with automatic transmissionThis refers to the automatic transmission of traditional hydraulic transmission, namely through hydraulic torque converter and planetary gear transmission power automatic transmission.Advantages： transmission efficiency than automatic gearboxes for high, of course, theoretically can compare economical.maintenance will be cheaper than transmission.If you want to higher cost, can begin from both the row of convenience and high power附录外文文献的中文翻译手动变速器是汽车变速器中最基本的一种类型，其作用是改变传动比，并提供倒档和空档。

毕业设计（论文）外文文献翻译文献、资料中文题目：汽车变速器设计文献、资料英文题目：Transmission design文献、资料来源：文献、资料发表（出版）日期：院（部）：专业：机械设计制造及其自动化班级：姓名：学号：指导教师：翻译日期： 2017.02.14毕业论文（设计）外文文献翻译汽车变速器设计我们知道，汽车发动机在一定的转速下能够达到最好的状态，此时发出的功率比较大，燃油经济性也比较好。

因此，我们希望发动机总是在最好的状态下工作。

但是，汽车在使用的时候需要有不同的速度，这样就产生了矛盾。

这个矛盾要通过变速器来解决。

汽车变速器的作用用一句话概括，就叫做变速变扭，即增速减扭或减速增扭。

为什么减速可以增扭，而增速又要减扭矩呢？设发动机输出的功率不变，功率可以表示为N=wT，其中w是转动的角速度，T是扭矩。

当N固定的时候，w与T是成反比的。

所以增速必减扭矩，减速必增扭矩。

汽车变速器齿轮传动就根据变速变扭的原理，分成各个档位对应不同的传动比，以适应不同的运行状况。

一般的手动变速器内设置输入轴、中间轴和输出轴，又称三轴式，另外还有倒档轴。

三轴式是变速器的主体结构，输入轴的转速也就是发动机的转速，输出轴转速则是中间轴与输出轴之间不同齿轮啮合所产生的转速。

不同的齿轮啮合就有不同的传动比，也就有了不同的转速。

例如郑州日产ZN6481W2G型SUV车手动变速器，它的传动比分别是：1档3.704:1；2档2.202:1；3档1.414:1；4档1:1；5档（超速档）0.802:1。

当汽车启动司机选择1档时，拨叉将1/2档同步器向后接合1档齿轮并将它锁定输出轴上，动力经输入轴、中间轴和输出轴上的1档齿轮，1档齿轮带动输出轴，输出轴将动力传递到传动轴上（红色箭头）。

典型1档变速齿轮传动比是3:1,也就是说输入轴转3圈，输出轴转1圈。

当汽车增速司机选择2档时，拨叉将1/2档同步器与1档分离后接合2档齿轮并锁定输出轴上，动力传递路线相似，所不同的是输出轴上的1档齿轮换成2档齿轮带动输出轴。

TRANSMISSIONEngine output speed is very high, the power and the maximum torque in certain areas of the speed. In order to exert the engine, you must have the best performance, to coordinate the speed of the engine and the actual speeds. Transmission in automobile driving process between the engine and wheels, in different ratios, through the shift in the engine can work under the condition of the best performance. The development trend of the transmission is more complex, more and more is also high automation degree, automatic transmission is the mainstream of the future.Car engines in certain speed can reach the best state, the output power of the bigger, fuel economy and better. Therefore, we hope in the best condition engine always work. But, in the use of the car to have different speed, the contradictions. This contradiction through the transmission to solve.Auto transmission function in a single sentence, is called the speed change, which reduced growth slowing or thickening twist. Why can increase twist, and slowing growth and to reduce twist? Put the power output unchanged, the engine power can be expressed as N = wT, w is turning, T is the angular torque. When N fixed, w and T is inversely proportional to the. So the growth will be reduced, slow increase twist. Auto transmission gear transmission is based on the principle of variable twist, each corresponding to different into gear transmission, in order to adapt to the different operating conditions.General manual transmission shaft set the input and output shaft, and say, another three axis reverse axis. Three main transmission shaft type is the speed of the input shaft structure, the speed of the engine, is also the output shaft speed is presented. By output shaft gear generated between different speeds. The gear is different with different ratio, also have different speed. Such as Zhen Zhou Nissan ZN6481W2G type SUV driver’s dynamic transmission, it is respectively: 1 ratio of 1:3.704 gears, 2.202 2:1, 3:1; 1.414 4 gears, - 5 (1): overdrive dependent.When the car started when the driver choose 1 files, dial 1 1/2 shift fork synchronizer backward joints and 1 shift gear lock on the output shaft, and the power input shaft, and the output shaft shift gears, 1 shift gear drive output shaft, output shaft will power to transmission (red arrows). The typical one shift gear ratio is 3:1, i.e. input shaft turn 3 laps, output shaft turn 1 lap.When the car growth drivers choose 2 files, dial 1 1/2 shift fork synchronizer and 1 separateness from 2 after mating locking output shaft gear and power transmission line, which is similar to the output shaft gear with 2, 1 files output shaft gear. The typical 2 shift gear ratio is 2.2:1, input, output shaft turning 2.2 pivot, 1-1 RPMincreases, torque shift.When gas growth drivers choose 3, dial 1 1/2 shift fork to synchronizer, and back to space three/four file synchronizer will move until 3 gear lock in the output shaft, make the power from the first shaft -- -- on the output shaft transmission gears, 3 through the output shaft gear shifting speed. The typical 3 ratio was 1.7:1, the input shaft turning circle, the output shaft 1.7 turn 1 ring, is further growth.When gas growth drivers choose 4 gears, fork will 3/4 file synchronizer from 3 gear directly with the input shaft driving gear engagement, power transmission directly from the input shaft to the output shaft, and the output shaft is 1:1 ratio and the input shaft speed. Due to the force, and the direct oart shift, the gear transmission efficiency ratio. Cars run most time in order to achieve the best directly file fuel economy.Shift to go into space, transmission in the transmission gears have locked in the output shaft, they cannot drive the output shaft rotation, no power output.General car manual transmission ratio main points above 1-4, usually designers to first identify the lowest (1) and (4) transmission, the ratio between after general distribution according to form. In addition, there is a reverse and overdrive, overdrive called 5 files.When the car to accelerate whether isolated car drivers choose more than 5, 5 gear transmission is typical 0.87:1, namely with big gear drive pinion gear turns, when active 0.87 lap, passive gear has turned over one lap.When the reverse in the opposite direction to the output shaft rotation. If a gear when reverse rotation, plus a gear will become a positive spin. Using this principle, will add a reverse gear do "medium", the direction of rotation axis, so has reversed a reverse axis. Reverse transmission shaft independent in housing, and parallel axis, when oart in gear and gear and oart output shaft gear, output shaft to will instead.Usually the reverse synchronizer is controlled by the jointing, so May 5 files and reverse position is in the same side. Due to the middle, reverse gear transmission is generally greater than 1 gear transmission ratio, twist, some cars met with forward instead of steep open up in reverse.From driving gear transmission is smooth; more is better, more adjacent gear shift between the transmission ratio, shift easy and smooth. But the gear transmission fault is more complex structure, big volume and light auto transmission is now commonly 4-5. At the same time, the transmission ratio is not an integer, but with the decimal point, this is not the whole number of meshing gears, two gear ratio is the euploid number will lead to two gear surface non-uniform wear, tooth surface quality of differences.Manual transmission and synchronizerManual transmission is one of the most common transmissions, referred to as MT. Its basic structure in a single sentence is a central axis, two input shaft, namely, the axial and axial oart, they constituted the transmission of the subject, and, of course, a reverse axis. Manual transmission gear transmission and manual, contain can in axial sliding gears, through different meshing gears to change gear of torsional purpose. The typical structure and principle of the manual transmission.Input shaft also says, it's in front of the spline shaft directly with clutch platen, thus the spline set by the engine relay of torque. The first shaft gear meshing gears, often with oart as input shaft, and the gear on oart will turn. Also called shaft, because even more solid shaft of gear. The output shaft, and the second shaft position have the drive shaft gear, may at any time and under the influence of the control devices and the corresponding oart gear, thus changing the speed and torque itself. The output shaft is associated with tail spline shaft torque transmission shaft, through to drive to gear reducer.Predictably, transmission gear drive forward path is: input shaft gear - oart gnaws gear - because the second shaft gear - corresponding gear. Pour on the axle gear can also control device, by moving axis in the strike, and the output shaft gear and oart gear, in the opposite direction.Most cars have five forward and reverse gear, each one has certain ratio, the majority of gear transmission more than 1, 4 gears transmission is 1, called directly, and ratio is less than 1 of article 5 gear shift accelerated called. The output axis gear in the mesh position, can accept power transmission.Due to the gearbox output shaft to input shaft and the speed of their gear rotating, transform a "synchronization problem". Two rotating speed different meshing gears forcibly inevitable impact and collision damage gear. Therefore, the old transmission shift to use "two feet on-off" method, accelerate in neutral position shift to stay for a while, in the space location on the door, in order to reduce gear speed. But this operation is more complex, difficult to grasp accurately. Therefore designers to create "synchronizer", through the synchronizer will make the meshing gears reach speed and smooth.Currently the synchronous transmission adopts is inertial synchronizer, it mainly consists of joints, synchronizer lock ring etc, it is characteristic of the friction effect on achieving synchronization. Mating, synchronizer and mating locking ring gear tooth circle have chamfering (locking horns), the synchronizer lock ring inside surface of gear engagement ring and the friction surface contact. The lock horns with cone when designing the proper choice, has been made to the surface friction of meshinggears with gear synchronous, also can rapid produces a locking function, prevent the synchronous before meshing gears. When synchronous lock ring of gear engagement with surface contact surface, the outer circle in friction torque under the action of gear speed rapid decrease (increase) or to synchronous speed equal, both locking ring spun concurrent, relative to lock ring gear synchronous speed is zero, thus inertia moment also disappear, then in force, driven by the junction of unimpeded with synchronous lock ring gear engagement, and further to engagement with the engagement ring gear tooth and complete shift process变速器发动机的输出转速非常高，最大功率及最大扭矩在一定的转速区出现。
