PAR30产品规格书

PAR30智能风扇控制电源
简介：PAR灯智能风扇控制电源，顾名思义就是在PAR灯工作中，通过电源对风扇电流的监控，当风扇电流出现故障的时候及时反馈回电源的控制电路，调整输出电流，最大限度的保护灯珠。

电源详细介绍：PAR30通常指一款直径为95mm高度为120mm的射灯，把LED行业前沿技术恰如其分地运用到了商业室内照明范畴，实现了体积小功率大的技术难题，其技术要点主要包括：灯体内置风扇散热、采用超高亮度LED芯片、与电源线路板采用世界顶级电子元器件等。

伴随着电子技术的的发展，对电源的要求也是逐渐提高。

由于PAR灯在使用的环境主要是人流量比较大的商业环境中，灰尘、纤维、粉尘等颗粒较多，在使用一段时间以后，风扇的扇叶会吸附灰尘，轴承会缠绕纤维等影响风扇转速的物质，并最终导致灯珠产生的热量不能靠结构件来自我散热，影响灯珠的光衰甚至灯珠和电源的损坏。

针对风扇的转速问题，众多电源厂家和方案商都在想办法来解决风扇故障后带来的问题，并且提出诸多解决方案，包括使用温敏电阻，在铝基板上安装保险丝，减小灯珠整体功率，改变灯体结构等，但是最终的结果始终不如人意，或多或少的存在一些缺陷：温度控制不精确，灯体结构不能确保散热，烧毁灯珠的事情时候发生。

针对这种情况，深圳市久嘉电源推出了新的解决方案--致力于解决风扇转速的问题：智能风扇控制电源。

当PAR30灯在使用一段时间以后，风扇转速变化时，电源智能控制系统能感知风扇电流的异常，并作出反馈：将整灯的功率降到3-6W，在保证照明的同时，最大限度的保证灯珠的完好，从而减少损失和隐患。

白炽灯- PAR38 节能型,节能省电:同普通PAR38相比,节能20%;80W PAR38的亮度相当于普通100W PAR38 有红、黄、蓝、绿四种色彩,鲜艳亮丽,营造特殊气氛户内户外都能使用(户外使用必须配备防水灯具) 适用于商场陈列、酒店旅馆、公园、博物馆、展示会、舞台等...本文所指的PAR灯仅指采用大功率LED（单颗1W、3W、5W等）光源的灯具而需要PA R灯专用的PAR灯透镜；一，PAR灯的分类PAR灯系列：PAR22、PAR30、PAR38、PAR64等二，PAR灯透镜的规格（外型及尺寸）1．PAR灯系列中透镜使用数量有区别，如PAR22采用3个透镜，PAR30或PAR38采用5个或7个透镜；无论是PAR30、PAR38等，其使用的LED透镜的外型规格都是相同的，最大直径一般为19.8mm左右，卡口（台阶）直径为17.8mm左右；2．PAR灯透镜的高度一般有两种（与灯杯的内部结构有联系）10.5mm或12mm;3．PAR灯透镜的安装方式除了利用灯杯前部面板卡口固定外，透镜的小内口与LED 的接触的方式也有两种：3．1．透镜顶住LED，此种透镜小内口直径一般为6.0mm至7.0mm，透镜高度为10. 5mm；3．2．透镜套住LED，此种秀镜小内口直径一般为8.0（配流明或仿流明规格）；也有小内口直径为6.8mm（CREE专用透镜）；4．PAR透镜可选用平型面或凹型面，可选用镜面、磨砂面、矩阵面等；三，PAR灯透镜的角度及光斑要求：1．PAR灯透镜角度角度范围比较宽：可选用15、25、38、45、60度等规格，2．PAR灯透镜以38度为最多选用；3．PAR灯透镜给合使用时，要求中心区光斑均匀，多个透镜的聚光光斑能较好的重叠（光形圆正、亮度显著提高）；4．因为不同场情需要可选用不同表面处理工艺的如镜面磨砂面或矩阵面等而获得不同光斑效果如（圆形光斑、漫射光斑等）；室内灯产品的相关名词1.PAR38 (paraboloid aluminium reflector) :PAR是表示抛物面反射形,38表示最大外径尺寸,即: (1/8)*38*25.4≈120.0mmPAR: echo shape of paraboloid; 38:max outer diameter: (1/8)*38*25.4≈120.0mm2.MR16 (Multifaceted （Mirror）Reflector ) :MR是表示由多个反射面组合成的反射器,16表示最大外径尺寸,即:(1/8)*16*25.4≈50.0mm. MR:max outer diameter3.T8(T10)日光灯:T: (Tube),8 表示外径尺寸outer diameter,即: (1/8)*8*25.4≈25.0mm10 表示外径尺寸outer diameter,即: (1/8)*10*25.4≈30.0mm4 .GU10灯头:G表示灯头类型是插入式，U表示灯头部分呈现U字形，后面数字表示灯脚孔中心距10mm.请问PAR光源有什么特点？PAR38和PAR20有什么区别？PAR38直径也就是38/8″，约为120mm；PAR20直径也就是20/8″，约为64mm；其实灯泡叫PARxx，Rxx，MRxx等都是为xx/8″的直径；不信试测量MR16灯泡的直径；--全心全意为人民币服务--38/8″表示38/8寸＝25.4＊38/8=120mm 一寸为25.4mm 是这样的。

产品规格书SPECIFICATION产品名称PAR20射灯产品型号S-PAR20(产品描述) PAR20射灯/主动散热/PAR20 射灯LED PAR20光源是一款紧凑型LED射灯，可以发出类似卤素灯/白炽灯一样的重点光束，是酒店业、商场、服装等行业聚光照明和一般照明理想的改型解决方案，特别适合于重点照明区域及公共照明区域。

产品能节省大量电能，较传统光源大幅降低维护成本，使业主能最快获得投资回报。

这些LED光源作为卤素灯或白炽灯的改性替代方案而设计，能与传统大多数灯具兼容。

一：产品特性>> 低维护成本>> 与卤素灯或白炽灯相比节能50%~80%>> 精致的外形设计>> 无紫外线辐射，不含铅、汞有害物质>> 主动散热技术，延长使用寿命的同时增加功率密度>> 多种光束角可选>> 应用OSRAM系列低光衰、高显色光源，光线光照质量高>> 传统光源替代设计，可应用于大部分传统卤素白炽灯灯具二：应用场合>>服装店、珠宝店、化妆品专卖店>>家私卖场、酒店、咖啡厅等照明场所>>其他传统PAR20卤素灯应用场合>>其他重点照明或基础照明场合三：产品主要规格产品/型号 直径 D (mm) 长度 L (mm)S-PAR20-02563.590产品型号 额定功率 色温 发光角度 流明值 显色指数 S-PAR20-025-BC 25W 2800-3200K 25° / 45° 1400 83 S-PAR20-025-BN 25W 3800-4200K 25° / 45° 1600 73 S-PAR20-025-BW 25W 5500-6500K 25° / 45° 1800 70 S-PAR20-025-WC 25W 2800-3200K 25° / 45° 1400 83 S-PAR20-025-WN 25W 3800-4200K 25° / 45° 1600 73 S-PAR20-025-WW25W5500-6500K25° / 45°180070PAR20射灯型号S-PAR20-025 输入电压 DC30-32V 输入电流 恒流730mA 光源数量 Osram LED ×9pcs防护等级 IP30 防触电等级CLASS III 亮度可调性 不可调 LED 寿命 >30000H工作环境温湿度 -20～+40℃ / 0-90% (RH) 储存温湿度 -20～+75℃ / 0-90% (RH)机械接口 E27 净重 0.093Kg 搭配适配器型号S-027-730型号代码说明：外观颜色：B (黑色)W (白色)色温代码：W (2800K-3200K) N (3800K-4200K) C (5500K-6500K) 投射角度：8 （25度） 4 （45度）PAR20电源适配器型号S-027-730输入电压AC100-240V 50/60Hz转换效率88%总谐波<15%输出功率27W max输出电压DC21-41V输出电流CC730mA保护功能短路、过载、开路、过温工作环境温度-20～+50℃ / 0-95% (RH)储存温度-20～+80℃ / 0-950% (RH)外形尺寸123*47*33mm净重0.166Kg四：光特性1、光谱分析系统测试报告2、配光曲线25度45度1m2m3m4m5m3、照度图五：光源及风扇寿命测试1、光源的衰减参数OSRAM 灯珠的寿命测试OSRAM 灯珠在铝基板温度85℃情况下，长期工作10000小时后光衰在8%左右光束角 距离 25度 45度 中心照度 光斑大小 中心照度 光斑大小1m10700 lx 33cm 3898 lx 75cm 2m 2675 lx 65cm 975 lx 150cm 3m 1189 lx 98cm 433 lx 224cm 4m669 lx 130cm 244 lx 299cm 5m 428 lx163cm156 lx374cm光束角 距离 25度 45度 中心照度 光斑大小 中心照度 光斑大小1m 7663 lx 33cm 2801 lx 75cm 2m1916 lx 65cm 700 lx 150cm 3m 852 lx 98cm 311 lx 224cm 4m 479 lx 130cm 175 lx 299cm 5m307 lx163cm112 lx374cm正白(6000K ）暖白(3000K)2、散热风扇寿命测试风扇在环境温度70℃的条件下测试寿命为27943小时。

深圳市天电光电科技有限公司LIGHTNING OPTOELECTRONIC TECHNOLOGY (SZ) CO.,LTDPAR 30 拆解分析报告一：整灯基本特性1.1光谱图1.2光通量测试以及衰减1.3光分布曲线和空间光照度曲线上图测试得到该PAR灯光束角度为77.6°（检测时没有安装透镜）深圳市天电光电科技有限公司LIGHTNING OPTOELECTRONIC TECHNOLOGY (SZ) CO.,LTD 二：灯具内部结构组成2.1 灯头和灯身如下图示，灯头采用E27螺旋样式灯头，符合国家通用标准。

灯身主要材料是塑料结构，可以起到防止漏电，增加散热以及缩小成本的作用。

周身很多规律长孔，很大程度上与外界接触，增加散热。

2.2 电源驱动、散热器和PCB灯板左图是电源驱动模块，内部含有整流电桥和变压器，能把输入220V，165MA 电压和电流转变成灯板工作所需的52V，60MA。

后面会继续介绍。

右图是散热器和PCB灯板，散热器整体全部由铝合金材料构成，最有效的将PCB灯板热量散出。

PCB板是通过螺丝和导热胶固定在散热器上，灯板厚度1.2mm 符合国家通用标准。

2.3 固定支架、风扇和反光杯下图红色部分是固定支架的一个脚，卡在驱动电源上，风扇装置在支架内部，深圳市天电光电科技有限公司 LIGHTNING OPTOELECTRONIC TECHNOLOGY (SZ) CO.,LTD 这样使整个灯具内部结构更加稳定。

风扇品牌型号：SUNON ME30101V3-E01C-A99 DC12V 0.52W 。

反光杯右图所示，三：测试项目3.1 输入输出测试根据测试得到，输入端：电压 220V ，电流160MA ，功率34.8W 。

输出端：电压 52V ，电流600MA ，功率31.38W 。

3.2 温升测试 测试项目 整流电桥Q1 电解电容C5 变压器T1 LED 测试数据（℃） 32.3 42.9 33.567.9深圳市天电光电科技有限公司LIGHTNING OPTOELECTRONIC TECHNOLOGY (SZ) CO.,LTD四：总结根据以上拆解分析、光电测试、温升测试、特性材料对比和光通量等各项要求均可以达到原有需求标准，所以我们可以认为天电光电的LED3030完全可以取代原用飞利浦3030作为该PAR30的灯珠，可以达到一致的使用效果。

通道功能 数值 描述1 总调光 0-255 总调光0-100%2 红 0-255 红0-100%3 绿 0-255 绿0-100%4 蓝 0-255 蓝0-100% 5 频闪 0-255 频闪，由慢到快 6预设程序1 0-127 闭光128-255 淡进淡出程序：用通道6调节速度 7预设程序20-127闭光128-191 颜色追逐效果：用通道6调节速度 192-255 颜色追逐效果：用通道6调节速度 8 宏功能0-007 闭光168-175 红100% 绿100% 蓝100% 008-015 红100% 绿20% 蓝 176-183 红100% 绿100% 蓝25% 016-023 红100% 绿40% 蓝 184-191 红100% 绿100% 蓝50% 024-031 红100% 绿60% 蓝 192-199 红100% 绿100% 蓝75% 032-039 红100% 绿80% 蓝 200-207 红100% 绿100% 蓝100% 040-047 红100% 绿100% 蓝 208-215 红20% 绿100% 蓝100% 048-055 红 绿100% 蓝 216-223 红40% 绿100% 蓝100% 056-063 红 绿100% 蓝20% 224-231 红60% 绿100% 蓝100% 064-071红 绿100% 蓝40% 232-239 红80% 绿100% 蓝100% 072-079 红 绿100% 蓝60% 240-247 红20% 绿100% 蓝100% 080-087 红 绿100% 蓝80% 248-255 红50% 绿50% 蓝50% 088-103 红 绿 蓝100% 104-111 红20% 绿 蓝100% 112-119 红40% 绿 蓝100% 120-127 红60% 绿 蓝100% 128-135 红80% 绿 蓝100% 136-143 红100% 绿 蓝100% 144-151 红100% 绿25% 蓝100% 152-159 红100% 绿50% 蓝100% 160-167红100% 绿75% 蓝100%LED-PAR36X3W-RGB 说明书在使用本产品前,请务必仔细阅读此说明书!安装,操作及维护本产品的工作人员须满足以下要求: - 经验足够- 遵循此说明书的每个事项.- 将此说明书视为本产品的重要组成部分. - 保存好此说明书.- 将此说明书提供给本产品的购买者或使用者. - 留意此说明的更新补充内容.开机前请确保本产品在运输过程中 不被损坏. 如果有任何损坏, 谨记不要使用本产品,并联系本产品的供应商!安全事项注意！操作本产品前请务必谨慎。
