BAV99BRW-7-F;中文规格书,Datasheet资料
- 格式:pdf
- 大小:113.78 KB
- 文档页数:6
Features∙ Fast Switching Speed∙ Surface Mount Package Ideally Suited for Automated Insertion ∙ For General Purpose Switching Applications∙ Two Diode Elements Connected in a Common Anode Configuration∙ Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2) ∙ Halogen and Antimony Free. “Green” Device (Note 3) ∙ Qualified to AEC-Q101 Standards for High ReliabilityMechanical Data∙ Case: SOT23∙ Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0∙ Moisture Sensitivity: Level 1 per J-STD-020∙ Terminals: Matte Tin Finish annealed over Alloy 42 Leadframe (Lead Free Plating). Solderable per MIL-STD-202, Method 208 ∙ Polarity: See Diagram∙Weight: 0.008 grams (Approximate)Ordering Information (Note 4)2. See https:///quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen - and Antimony-free, "Green" and Lead-free.3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and <1000ppm antimony compounds.4. For packaging details, go to our website at /products/packages.html.Marking InformationTop ViewSOT23Top ViewInternal SchematicK = SAT (Shanghai Assembly / Test site) JD = Product Type Marking Code YM = Date Code Marking Y = Year (ex: F = 2018)M = Month (ex: 9 = September) C = CAT (Chengdu Assembly / Test site)JD = Product Type Marking Code= Date Code Marking for Chengdu = Year (ex: F = 2018) M = Month (ex: 9 = September)CJDY MKJD Y MYMY(@T = +25°C, unless otherwise specified.)Thermal CharacteristicsNotes: 5. Part mounted on FR-4 substrate PC board with 1inch squared, 2oz copper pad layout.6. Short duration pulse test used to minimize self-heating effect.400T , AMBIENT TEMPERATURE, (°C)Fig. 1 Power Derating Curve, Total Package A P P O W E R D I S S I P A T I O N (m W )D ,1000.110.010.001I , I N S T A N T A N E O U S F O R W A R D C U R R E N T (A )F V , INSTANTANEOUS FORWARD VOLTAGE (V)Fig. 2 Typical Forward Characteristics, Per Element F0.11101001,00010,000V , INSTANTANEOUS REVERSE VOLTAGE (V)Fig. 3 Typical Reverse Characteristics, Per Element R I , I N S T A N T A N E O U S R E V E R S E C U R R E N T (n A )R 0.00.20.40.60.81.81.61.41.21.02.0010204030C , T O T A L C A P A C I T A N C E (p F )T V , DC REVERSE VOLTAGE (V)Fig. 4 Total Capacitance vs. Reverse Voltage, Per Element RPackage Outline DimensionsPlease see /package-outlines.html for the latest version.Suggested Pad LayoutPlease see /package-outlines.html for the latest version.SOT23。
QUAD SURFACE MOUNT SWITCHING DIODE ARRAYFeatures• Fast Switching Speed• Low Forward Voltage: Maximum of 0.715V at 1mA • Fast Reverse Recovery: Maximum of 4ns • Low Capacitance: Maximum of 2pF • Small Surface Mount Package• For General Purpose Switching Applications • Two “BAV99” Circuits In One Package • Easily Connected As Full-Wave Bridge• Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2) • Halogen and Antimony Free. “Green” Device (Note 3)Mechanical Data• Case: SOT-363 • Case Material: Molded Plastic, “Green” Molding Compound. ULFlammability Classification Rating 94V-0 • Moisture Sensitivity: Level 1 per J-STD-020D • Terminals: Solderable per MIL-STD-202, Method 208 • Lead Free Plating (Matte Tin Finish annealed over Alloy 42leadframe).• Polarity: See Diagram •Weight: 0.006 grams (approximate)Ordering Information (Note 4)Part Number Case Packaging BAV99BRW-7-FSOT-363 3000/Tape & ReelNotes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.2. See for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and <1000ppm antimony compounds.4. For packaging details, go to our website at /datasheets/ap02007.pdf.Marking InformationDate Code KeyYear 2001 2002 2003 ….. ….. 2012 2013 2014 2015 2016 2017 2018 CodeM N P ….. ….. Z A B C D E FMonth JanFebMarAprMayJunJulAugSepOctNovDecCode1 2 3 4 5 6 7 8 9 O N De3TOP VIEWSOT-363TOP VIEW Internal SchematicAC 1AC2C 1A 1C 2A 2KGJ = Product Type Marking Code YM = Date Code Marking Y = Year ex: Z = 2012M = Month ex: 9 = SeptemberKGJY MMaximum Ratings(@T A = +25°C, unless otherwise specified.)Characteristic Symbol Value Unit Non-Repetitive Peak Reverse Voltage V RM100 VPeak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage V RRMV RWMV R75 VRMS Reverse Voltage V R(RMS)53 V Forward Continuous Current (Note 5) I FM300 mA Average Rectified Output Current (Note 5) I O150 mANon-Repetitive Peak Forward Surge Current @ t = 1.0µs@ t = 1.0s I FSM2.01.0AThermal CharacteristicsCharacteristic Symbol Value Unit Power Dissipation (Note 5) P D200 mW Thermal Resistance Junction to Ambient Air (Note 5) RθJA625 °C/W Operating and Storage Temperature Range T J , T STG-65 to +150 °CElectrical Characteristics(@T A = +25°C, unless otherwise specified.)Characteristic Symbol Min Max Unit Test Condition Reverse Breakdown Voltage (Note 6) V(BR)R75 ⎯V I R = 2.5µAForward Voltage V F⎯0.7150.8551.01.25VI F = 1.0mAI F = 10mAI F = 50mAI F = 150mAReverse Current (Note 6) I R⎯2.5503025µAµAµAnAV R = 75VV R = 75V, T J = +150°CV R = 25V, T J = +150°CV R = 20VTotal Capacitance C T⎯ 2.0 pF V R = 0, f = 1.0MHzReverse Recovery Time t rr⎯ 4.0 ns I F = I R = 10mA,I rr = 0.1 x I R, R L = 100ΩNotes: 5. Device mounted on FR-4 PC board with recommended pad layout, which can be found on our website at /datasheets/ap02001.pdf.6. Short duration pulse test used to minimize self-heating effect.501001502002502505075100125150P , P O W E R D I S S I P A T I O N (m W )D T , AMBIENT TEMPERATURE (°C)A Figure 1 Power Derating Curve, Total Package300Note 50.10.01I , I N S T A N T A N E O U S F O R W A R D C U R R E N T (A )F V , INSTANTANEOUS FORWARD VOLTAGE (V)Figure 2 Typical Forward Characteristics, Per Element F1001,00010,000V , INSTANTANEOUS REVERSE VOLTAGE (V)Figure 3 Typical Reverse Characteristics, Per ElementR I , I N S T A N T A N E O U S R E V E R S E C U R R E N T (n A )R 0.00.20.40.60.81.81.61.41.21.02.020C , T O T A L C A P A C I T A N C E (p F )T V , DC REVERSE VOLTAGE (V)Figure 4 Total Capacitance vs. Reverse Voltage, Per ElementRPackage Outline DimensionsSuggested Pad LayoutSOT363Dim Min Max Typ A 0.100.30 0.25 B 1.15 1.35 1.30 C 2.00 2.20 2.10 D 0.65 TypF 0.400.45 0.425 H 1.80 2.20 2.15 J 0 0.10 0.05 K 0.90 1.00 1.00 L 0.250.40 0.30 M 0.100.22 0.11α0° 8° -All Dimensions in mmDimensions Value (in mm)Z 2.5 G 1.3 X 0.42 Y 0.6 C1 1.9 C2 0.65XZYC1C2C2GIMPORTANT NOTICEDIODES INCORPORATED MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARDS TO THIS DOCUMENT, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION).Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes without further notice to this document and any product described herein. Diodes Incorporated does not assume any liability arising out of the application or use of this document or any product described herein; neither does Diodes Incorporated convey any license under its patent or trademark rights, nor the rights of others. Any Customer or user of this document or products described herein in such applications shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on Diodes Incorporated website, harmless against all damages.Diodes Incorporated does not warrant or accept any liability whatsoever in respect of any products purchased through unauthorized sales channel. Should Customers purchase or use Diodes Incorporated products for any unintended or unauthorized application, Customers shall indemnify and hold Diodes Incorporated and its representatives harmless against all claims, damages, expenses, and attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized application.Products described herein may be covered by one or more United States, international or foreign patents pending. Product names and markings noted herein may also be covered by one or more United States, international or foreign trademarks.LIFE SUPPORTDiodes Incorporated products are specifically not authorized for use as critical components in life support devices or systems without the express written approval of the Chief Executive Officer of Diodes Incorporated. As used herein:A. Life support devices or systems are devices or systems which:1. are intended to implant into the body, or2. support or sustain life and whose failure to perform when properly used in accordance with instructions for use provided in thelabeling can be reasonably expected to result in significant injury to the user.B. A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause thefailure of the life support device or to affect its safety or effectiveness.Customers represent that they have all necessary expertise in the safety and regulatory ramifications of their life support devices or systems, and acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any use of Diodes Incorporated products in such safety-critical, life support devices or systems, notwithstanding any devices- or systems-related information or support that may be provided by Diodes Incorporated. Further, Customers must fully indemnify Diodes Incorporated and its representatives against any damages arising out of the use of Diodes Incorporated products in such safety-critical, life support devices or systems.Copyright © 2012, Diodes Incorporated分销商库存信息: DIODESBAV99BRW-7-F。
各式贴片二极管基本参数TYPE Io(A) VR(V) VF(V) IR(μA) PD(mW) Package 1N4148W 150mA 75 1.25 1.0 350 SOD-123 1N4448W 250mA 75 1.25 2.5 350 SOD-123 BAV16W 150mA 75 1.25 1.0 400 SOD-123 BAV19W 200mA 100 1.25 0.1 250 SOD-123 BAV20W 200mA 150 1.25 0.1 250 SOD-123 BAV21W 200mA 200 1.25 0.1 250 SOD-123 1N4148WS 150mA 75 1.25 1.0 350 SOD-323 1N4448WS 250mA 75 1.25 2.5 350 SOD-323 BAV16WS 150mA 75 1.25 1.0 400 SOD-323 BAV19WS 200mA 100 1.25 0.1 250 SOD-323 BAV20WS 200mA 150 1.25 0.1 250 SOD-323 BAV21WS 200mA 200 1.25 0.1 250 SOD-323 1SS387 100mA 80 1.2 0.5 150 SOD-523 1SS388 100mA 40 0.6 5.0 150 SOD-523 1SS400 100mA 90 1.2 0.1 150 SOD-523 1SS422 150mA 85 1.2 0.1 150 SOD-523 BAS16X 150mA 75 1.25 1.0 150 SOD-523 BAS516 200mA 75 1.25 1.0 200 SOD-523 1SS400G 100mA 90 1.2 0.1 100 SOD-723 TYPE Io(A) VR(V) VF(V) IR(μA) Trr(nS) Package BAT42W - 30 0.65 0.2 - SOD-123 BAT43W - 30 0.45 0.2 - SOD-123 BAT46W - 30 0.45 0.2 - SOD-123 SD101AW - 60 1.0 0.2 - SOD-123 SD101BW - 50 0.95 0.2 - SOD-123 SD101CW - 40 0.9 0.2 - SOD-123 1N5711W - 70 1.0 0.2 - SOD-123 1N6263W - 60 1.0 0.2 - SOD-123 B0520W 0.5 20 0.385 250 - SOD-123 B0530W 0.5 30 0.43 130 - SOD-123 B0540W 0.5 40 0.62 20 - SOD-123 B5817W 1.0 20 0.75 1000 - SOD-123 B5819W 1.0 40 0.9 1000 - SOD-123 FM120-M-FM1100-M 1.0 20-100 0.5-0.85 1000 - SOD-123 FM220-M-FM2100-M 2.0 20-100 0.5-0.85 1000 - SOD-123 BAT42WS - 30 0.65 0.5 - SOD-323 BAT43WS - 30 0.45 0.5 - SOD-323 BAT54WS - 30 1.0 2.0 - SOD-323BAS40WS - 40 1.0 0.2 - SOD-323 BAS70WS - 70 1.0 0.1 - SOD-323 SD101AWS - 60 1.0 0.2 - SOD-323 SD101BWS - 50 0.95 0.2 - SOD-323 SD101CWS - 40 0.9 0.2 - SOD-323 SD103AWS - 40 0.37 5.0 - SOD-323 SD103BWS - 30 0.6 5.0 - SOD-323 SD103CWS - 20 0.6 5.0 - SOD-323 MBR0520WS - 20 0.31 0.1 - SOD-323 MBR0530WS - 30 0.36 0.03 - SOD-323 MBR0540WS - 40 0.36 0.03 - SOD-323 1N5711WS - 70 1.0 0.2 - SOD-323 BAT54X 200mA 30 0.8 2.0 - SOD-523 RB520S-30 200mA 30 0.45 0.5 - SOD-523 RB521S-30 200mA 30 0.35 10 - SOD-523 RB751S-40 30mA 40 0.37 0.5 - SOD-523 RB520G-30 100mA 30 0.345 0.5 - SOD-723 RB521G-30 100mA 30 0.35 10 - SOD-723 RB751G-40 30mA 40 0.37 0.5 - SOD-723 FM4001-M-FM4007-M 1.0 50-1000 1.10 5.0 - SOD-123 FFM-101-M-FFM107-M 1.0 50-1000 1.3 5.0 150-500 SOD-123 MURX0505-MURX0560 0.5 50-600 1.35 5.0 75 SOD-123 HFM101-M-HFM107-M 1.0 50-1000 1.0-1.7 5.0 50-75 SOD-123 BB910 a a a a a SOD-123 BZT52C2V4-BZT52C51 1/2W a a a a SOD-123 BZT52C2V0S-BZT52C39S 1/4W a a a a SOD-323 TYPE Io(A) VR(V) VF(V) IR(μA) PD(mW) Package 1SS181 - 80 1.2 0.5 150 SOT-23 1SS184 - 80 1.2 0.5 150 SOT-23 1SS187 - 80 1.2 0.5 150 SOT-23 1SS190 - 80 1.2 0.5 150 SOT-23 1SS193 - 80 1.2 0.5 150 SOT-23 1SS196 - 80 1.2 0.5 150 SOT-23 1SS226 - 80 1.2 0.5 150 SOT-23 BAL99LT1 - 70 1.25 2.5 350 SOT-23 BAS116LT1 - 75 1.25 5.0 300 SOT-23 BAS16LT1 - 75 1.25 1.0 225 SOT-23 BAS19LT1 - 120 1.25 0.1 225 SOT-23 BAS21LT1 - 250 1.25 1.0 225 SOT-23 BAV70LT1 - 70 1.0 5.0 350 SOT-23BAW56LT1 - 70 1.0 2.5 350 SOT-23 BAV74LT1 - 50 1.0 0.1 225 SOT-23 BAV99LT1 - 70 1.25 2.5 225 SOT-23 DAN202K - 70 1.25 2.5 225 SOT-23 DAP202K - 70 1.25 2.5 225 SOT-23 MA147 - 80 1.2 100 - SOT-23 MA153 - 40 1.2 0.1 - SOT-23 MA153A - 80 1.2 0.1 - SOT-23 MA157A - 80 1.2 0.1 - SOT-23 MMBD914LT1 - 75 1.25 2.5 225 SOT-23 MMBD2836LT1 - 75 1.0 0.1 225 SOT-23 MMBD2838LT1 - 75 1.2 0.1 225 SOT-23 MMBD6050LT1 - 70 1.1 0.1 225 SOT-23 MMBD7000LT1 - 100 1.1 5.0 225 SOT-23 SDS7000 - 100 1.1 5.0 225 SOT-23 BAS16W - 75 1.25 1.0 200 SOT-323 BAS19W - 100 1.25 0.1 200 SOT-323 BAS20W - 150 1.25 0.1 200 SOT-323 BAS21W - 200 1.25 0.1 200 SOT-323 BAV70W - 75 1.25 2.5 200 SOT-323 BAV99W - 75 1.25 2.5 200 SOT-323 BAW56W - 75 1.25 2.5 200 SOT-323 MMBD4148W - 75 1.25 1.0 200 SOT-323 MMBD4448W - 75 1.25 2.5 200 SOT-323 BAS16T - 85 1.25 2.0 150 SOT-523 BAW56T - 85 1.25 2.0 150 SOT-523 BAV70T - 85 1.25 2.0 150 SOT-523 BAV99T - 85 1.0 2.0 150 SOT-523 DAN222 - 80 1.2 0.1 100 SOT-523 DAP222 - 80 1.2 0.1 100 SOT-523 BAV70DW - 75 1.25 2.5 200 SOT-363 BAV756DW - 75 1.25 2.5 200 SOT-363 BAV99BRW - 75 1.25 2.5 200 SOT-363 BAV99DW - 75 1.25 2.5 200 SOT-363 BAW56DW - 75 1.25 2.5 200 SOT-363 MMBD4148TW - 75 1.25 1.0 200 SOT-363 BAS16TW - 75 1.25 1.0 200 SOT-363 MMBD4448HADW-HTW - 80 1.25 0.1 200 SOT-363 TYPE Io(A) VR(V) VF(V) IR(μA) Trr(nS) Package BAS40LT1 - 40 1.0 100 - SOT-23BAS70LT1 - 30 0.45 100 - SOT-23BAS70LT1-04 - 70 1.0 100 - SOT-23BAS70LT1-05 - 70 1.0 100 - SOT-23BAS70LT1-06 - 70 1.0 100 - SOT-23 BAT54A - 30 1.0 2.0 - SOT-23BAT54C - 30 1.0 2.0 - SOT-23BAT54S - 30 1.0 2.0 - SOT-231N5817 - 20 0.75 1.0 - SOT-23-3L1N5819 - 40 0.9 1.0 - SOT-23-3LRB400D - 40 0.55 0.5 - SOT-23-3LRB420D - 40 0.45 0.01 - SOT-23-3LRB421D - 40 0.34 0.01 - SOT-23-3LRB425D - 40 0.34 0.01 - SOT-23-3LRB491D - 25 0.45 1.0 - SOT-23-3LRB495D - 25 0.5 0.2 - SOT-23-3LBAS40W - 40 1.0 0.2 - SOT-323BAS40W-04 - 40 1.0 0.2 - SOT-323BAS40W-05 - 40 1.0 0.2 - SOT-323BAS40W-06 - 40 1.0 0.2 - SOT-323BAS70W - 70 1.0 0.1 - SOT-323BAS70W-04 - 30 1.0 0.1 - SOT-323BAS70W-05 - 30 1.0 0.1 - SOT-323BAS70W-06 - 30 1.0 0.1 - SOT-323BAT54W - 30 1.0 2.0 - SOT-323BAT54AW - 30 1.0 2.0 - SOT-323BAT54CW - 30 1.0 2.0 - SOT-323BAT54SW - 30 1.0 2.0 - SOT-323RB706F-40 - 30 1.0 1.0 - SOT-323RB715F - 30 1.0 1.0 - SOT-323RB715W - 40 0.37 1.0 - SOT-523 BAT54TW-SDW - 30 1.0 2.0 - SOT-363 BZX84C2V4-BZX84C75 a a a a a SOT-23 AZ23C2V7-C51 aaaaaa a a a a SOT-23 BZX84C2V4W-BZX84C39W a a a a a SOT-323 TYPE Io(A) VR(V) VF(V) IR(μA) Trr Package DL4001-DL4007 1.0 50-1000 1.1 5.0 - MELF DL120-DL160 1.0 20-60 0.55-0.70 1000 - MELF DL5817-DL5819 1.0 20-40 0.45-0.60 100 - MELF DLF101-DLF106 1.0 50-800 1.3 5.0 150-500 MELF DL4933-DL4937 1.0 50-600 1.3 5.0 200 MELF。
FLEXO® F6Flexible, Semi-RigidWrappable Split Braided TubeF6’s unique split, semi-rigid braided constructionmakes it the ideal solution for situations whereease of installation is of primary importance.The lateral split allows the tube to open upto accommodate a wide variety of bundlingrequirements, and the semi-rigid braidconfiguration simply closes around the entireinstallation without the need for any additionalfasteners (velcro, tape, etc.)edge overlap (at nominal diameter) allows coveragearound inline plugs, connectors and splices.F6 will bend to a tight radius without distortingor splitting open and, unlike full rigid tubing, willnot impair or affect the flexibility of harnesses.Colors Available:Black (BK), Orange (OR), Platinum Gray (PG)& Clear/White (CW).E asy, Cost And LaborEffective InstallationM ore Flexible Than SplitConvoluted Or Spiral Wrap25% Edge OverlapS oft And Quiet In HighVibration UsesC ut And Abrasion ResistantC hemically InertH aloge FreePolyethylene TerepthalateMaterialF6NGrade.008” - .015”Monofilament DiameterTF001F6-WDDrawing NumberHot KnifeCut Cleanly800.323.5140 • 973.300.9242 • fax: 973.300.940929 Brookfield Dr • Sparta, NJ 07871Braided Sleeving ProductsColors Available:4= BK, OR, PG, CW.Nominal DiameterThe large overlap allows easyinstallation over splices andincline connectors withoutexposing wires and cables.NominalSizePart#WallThicknessMonofilamentDiameterBulkBoxBoxABoxBAvailableColorsLbs/100’1/8”F6N0.13.024”.008”10,000’400’100’40.201/4”F6N0.25.025”.010”3,000’200’100’40.603/8”F6N0.38.025”.010”1,000’150’75’4 1.201/2”F6N0.50.025”.010”1,200’150’75’4 1.403/4”F6N0.75.025”.010”500’100’50’4 1.601”F6N1.00.038”.015”400’100’50’4 2.001 1/4”F6N1.25.038”.015”250’75’25’4 2.401 1/2”F6N1.50.038”.015”200’75’25’4 2.702”F6N2.00.038”.015”150’50’25’4 3.60Put-Ups芯天下--/FLEXO® F6Abrasion ResistanceMediumAbrasion Test MachineTaber 5150Abrasion Test WheelCalibrase H-18Abrasion Test Load 500gRoom Temperature 80°FHumidity74%Some Scuffing Visible500 Test CyclesSignificant Wear Is Visible With Several Braid Filaments Broken1,200 Test CyclesMaterial Destroyed 1,950 Test CyclesPre-Test Weight5,365.1 mgPost-Test Weight 4,850 mgTest End Loss Of Mass Point Of Destruction515.1 mg1=No Effect 4=More Affected 2=Little Effect 5=Severely Affected 3=AffectedAromatic Solvents ______________2Aliphatic Solvents ______________1Chlorinated Solvents ____________3Weak Bases __________________1Salts _________________________1Strong Bases___________________2Salt Water 0-S-1926 ____________1Hydraulic Fluid MIL-H-5606 _______1Lube Oil MIL-L-7808 ____________1De-Icing Fluid MIL-A-8243 ________1Strong Acids __________________3Strong Oxidants ________________2Esters/Keytones _______________1UV Light ______________________1Petroleum ____________________1Fungus ASTM G-21 _____________1Halogen Free ________________Yes RoHS ______________________Yes SVHC _____________________NoneRating ___________UL94VOMonofilament Diameter__.008-.015 ASTM D-204Flammability Rating________UL94Recommended Cutting___Hot Knife Colors______________________4 Wall Thickness_________.024-.038Tensile Strength (Yarn)_______6-10ASTM D-2256 LbsSpecific Gravity ASTM D-792__1.38Moisture Absorption_________.1-.2 % ASTM D-570Hard Vacuum Data ASTM E-595TML_______________________19CVCM_____________________.00WVR______________________.16Smoke D-Max _______________56 ASTM E-662Outgassing________________Med Oxygen Index________________21ASTM D-2863© 2011 Techflex, Inc. - Any unauthorized reproduction, in whole or part, in any medium whatsoever, without the express written permission of Techflex, Inc. is strictly forbidden.T echflex product names and logos are registered trademarks of T echflex, Inc., unless otherwise attributed. The contents and illustrations contained herein are believed to be reliable. T echflex makes no warranties as to their accuracy or completeness and disclaims any liability in connection with their use. T echflex’s only obligations are those in standard terms ofsale for these products and T echflex will not be liable for any consequential or other damages arising due to misuse of these products or typographical errors or omissions.Users should make their own evaluation to determine the suitability of these products for their unique and specific applications.09-11Melt Point ASTM D-2117482°F (250°C)Maximum ContinuousMil-I-23053257°F (125°C)Minimum Continuous-94°F (-70°C)芯天下--/。
QUAD SURFACE MOUNT SWITCHING DIODE ARRAYFeatures• Fast Switching Speed• Low Forward Voltage: Maximum of 0.715V at 1mA • Fast Reverse Recovery: Maximum of 4ns • Low Capacitance: Maximum of 2pF • Small Surface Mount Package• For General Purpose Switching Applications • Two “BAV99” Circuits In One Package • Easily Connected As Full-Wave Bridge• Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2) • Halogen and Antimony Free. “Green” Device (Note 3)Mechanical Data• Case: SOT-363 • Case Material: Molded Plastic, “Green” Molding Compound. ULFlammability Classification Rating 94V-0 • Moisture Sensitivity: Level 1 per J-STD-020D • Terminals: Solderable per MIL-STD-202, Method 208 • Lead Free Plating (Matte Tin Finish annealed over Alloy 42leadframe).• Polarity: See Diagram •Weight: 0.006 grams (approximate)Ordering Information (Note 4)Part Number Case Packaging BAV99BRW-7-FSOT-363 3000/Tape & ReelNotes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.2. See for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and <1000ppm antimony compounds.4. For packaging details, go to our website at /datasheets/ap02007.pdf.Marking InformationDate Code KeyYear 2001 2002 2003 ….. ….. 2012 2013 2014 2015 2016 2017 2018 CodeM N P ….. ….. Z A B C D E FMonth JanFebMarAprMayJunJulAugSepOctNovDecCode1 2 3 4 5 6 7 8 9 O N De3TOP VIEWSOT-363TOP VIEW Internal SchematicAC 1AC2C 1A 1C 2A 2KGJ = Product Type Marking Code YM = Date Code Marking Y = Year ex: Z = 2012M = Month ex: 9 = SeptemberKGJY MMaximum Ratings(@T A = +25°C, unless otherwise specified.)Characteristic Symbol Value Unit Non-Repetitive Peak Reverse Voltage V RM100 VPeak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage V RRMV RWMV R75 VRMS Reverse Voltage V R(RMS)53 V Forward Continuous Current (Note 5) I FM300 mA Average Rectified Output Current (Note 5) I O150 mANon-Repetitive Peak Forward Surge Current @ t = 1.0µs@ t = 1.0s I FSM2.01.0AThermal CharacteristicsCharacteristic Symbol Value Unit Power Dissipation (Note 5) P D200 mW Thermal Resistance Junction to Ambient Air (Note 5) RθJA625 °C/W Operating and Storage Temperature Range T J , T STG-65 to +150 °CElectrical Characteristics(@T A = +25°C, unless otherwise specified.)Characteristic Symbol Min Max Unit Test Condition Reverse Breakdown Voltage (Note 6) V(BR)R75 ⎯V I R = 2.5µAForward Voltage V F⎯0.7150.8551.01.25VI F = 1.0mAI F = 10mAI F = 50mAI F = 150mAReverse Current (Note 6) I R⎯2.5503025µAµAµAnAV R = 75VV R = 75V, T J = +150°CV R = 25V, T J = +150°CV R = 20VTotal Capacitance C T⎯ 2.0 pF V R = 0, f = 1.0MHzReverse Recovery Time t rr⎯ 4.0 ns I F = I R = 10mA,I rr = 0.1 x I R, R L = 100ΩNotes: 5. Device mounted on FR-4 PC board with recommended pad layout, which can be found on our website at /datasheets/ap02001.pdf.6. Short duration pulse test used to minimize self-heating effect.501001502002502505075100125150P , P O W E R D I S S I P A T I O N (m W )D T , AMBIENT TEMPERATURE (°C)A Figure 1 Power Derating Curve, Total Package300Note 50.10.01I , I N S T A N T A N E O U S F O R W A R D C U R R E N T (A )F V , INSTANTANEOUS FORWARD VOLTAGE (V)Figure 2 Typical Forward Characteristics, Per Element F1001,00010,000V , INSTANTANEOUS REVERSE VOLTAGE (V)Figure 3 Typical Reverse Characteristics, Per ElementR I , I N S T A N T A N E O U S R E V E R S E C U R R E N T (n A )R 0.00.20.40.60.81.81.61.41.21.02.020C , T O T A L C A P A C I T A N C E (p F )T V , DC REVERSE VOLTAGE (V)Figure 4 Total Capacitance vs. Reverse Voltage, Per ElementRPackage Outline DimensionsSuggested Pad LayoutSOT363Dim Min Max Typ A 0.100.30 0.25 B 1.15 1.35 1.30 C 2.00 2.20 2.10 D 0.65 TypF 0.400.45 0.425 H 1.80 2.20 2.15 J 0 0.10 0.05 K 0.90 1.00 1.00 L 0.250.40 0.30 M 0.100.22 0.11α0° 8° -All Dimensions in mmDimensions Value (in mm)Z 2.5 G 1.3 X 0.42 Y 0.6 C1 1.9 C2 0.65XZYC1C2C2GIMPORTANT NOTICEDIODES INCORPORATED MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARDS TO THIS DOCUMENT, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION).Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes without further notice to this document and any product described herein. Diodes Incorporated does not assume any liability arising out of the application or use of this document or any product described herein; neither does Diodes Incorporated convey any license under its patent or trademark rights, nor the rights of others. Any Customer or user of this document or products described herein in such applications shall assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on Diodes Incorporated website, harmless against all damages.Diodes Incorporated does not warrant or accept any liability whatsoever in respect of any products purchased through unauthorized sales channel. Should Customers purchase or use Diodes Incorporated products for any unintended or unauthorized application, Customers shall indemnify and hold Diodes Incorporated and its representatives harmless against all claims, damages, expenses, and attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized application.Products described herein may be covered by one or more United States, international or foreign patents pending. Product names and markings noted herein may also be covered by one or more United States, international or foreign trademarks.LIFE SUPPORTDiodes Incorporated products are specifically not authorized for use as critical components in life support devices or systems without the express written approval of the Chief Executive Officer of Diodes Incorporated. As used herein:A. Life support devices or systems are devices or systems which:1. are intended to implant into the body, or2. support or sustain life and whose failure to perform when properly used in accordance with instructions for use provided in thelabeling can be reasonably expected to result in significant injury to the user.B. A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause thefailure of the life support device or to affect its safety or effectiveness.Customers represent that they have all necessary expertise in the safety and regulatory ramifications of their life support devices or systems, and acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any use of Diodes Incorporated products in such safety-critical, life support devices or systems, notwithstanding any devices- or systems-related information or support that may be provided by Diodes Incorporated. Further, Customers must fully indemnify Diodes Incorporated and its representatives against any damages arising out of the use of Diodes Incorporated products in such safety-critical, life support devices or systems.Copyright © 2012, Diodes Incorporated分销商库存信息: DIODESBAV99BRW-7-F。
