Ver 2.1目录Ver 2.0 (2)第1章仪器简介与开箱安装 (8)1.1仪器简介 (8)1.2开箱检查 (8)1.3电源连接 (8)1.4保险丝 (8)1.5环境 (8)1.6使用测试夹具 (9)1.7预热 (9)1.8仪器的其它特性 (9)第2章前面板说明及入门操作 (10)2.1前面板说明 (10)2.2后面板说明 (11)2.3显示区域的定义 (12)2.4按键及其相应的显示页面 (13)2.4.1测量主菜单按键【DISP】 (13)2.4.2系统设置主菜单按键【SETUP】 (13)2.5基本操作 (13)2.6开机 (14)第3章基本操作 (15)3.1<测量显示>页面 (15)3.1.1测试功能 (15)3.1.2测试量程 (16)3.1.3测试速度 (17)3.1.4文件管理 (17)3.1.5其他工具 (17)3.2<比较显示>页面 (18)3.2.1文件管理 (19)3.2.2工具 (19)3.2.3比较 (19)3.2.4比较模式和上下限、百分比误差设置 (19)3.3<档显示>页面 (19)3.4<统计显示>页面 (21)3.4.1边界模式和其相应值的设定 (21)3.4.2统计状态 (21)3.4.3统计分析参数说明 (21)3.4.4工具 (22)3.4.5文件 (22)3.5<测量设置>页面 (22)3.6<TC/Δt设置>页面 (24)3.6.1温度校正(Temperature Correction 简称TC) (25)3.6.2温度转换(temperature conversion 简称t ) (25)3.6.3温度传感器的类型 (26)3.6.4参数设定 (27)3.6.5文件 (27)3.7<档设置>页面 (27)3.7.1文件 (29)3.7.2工具 (29)第4章系统设置和文件管理 (30)4.1系统设置 (30)4.1.1触摸音 (30)4.1.2语言 (30)4.1.3口令 (31)4.1.4总线模式 (31)4.1.5波特率 (32)4.1.6总线地址 (32)4.1.7EOC信号 (32)4.1.8Err.OUT信号 (33)4.1.9电源频率 (34)4.1.10时间和日期设定 (34)4.2<文件管理>功能页面 (34)4.2.1存储/调用功能简介 (34)4.2.2U盘上的文件夹/文件结构 (35)4.2.3DHCP (39)4.2.4IP地址 (40)4.2.5子网掩码 (40)4.2.6网关 (40)4.2.7首选DNS、备用DNS (40)第5章性能指标 (41)5.1测量功能 (41)5.1.1测量参数及符号 (41)5.1.2测量组合 (41)5.1.3等效方式 (41)5.1.4量程 (41)5.1.5触发 (41)5.1.6测试端方式 (41)5.1.7测量中的各种时间的开销 (41)5.1.8平均 (42)5.1.9显示的位数 (42)5.2测试信号 (42)5.2.1量程电流 (42)5.2.2开路输出电压 (42)5.2.3测量显示最大范围 (42)5.3测量准确度 (43)5.3.2温度测量的准确度(Pt500) (44)5.3.3温度测量的准确度(模拟输入) (45)5.3.4温度修正系数K (45)第6章远程控制 (46)6.1RS232C接口说明 (46)6.2GPIB接口说明(选购件) (47)6.2.1GPIB接口功能 (49)6.2.2GPIB 地址 (49)6.2.3GPIB总线功能 (49)6.2.4可编程仪器命令标准(SCPI) (50)6.3LAN远程控制系统 (50)6.3.1通过浏览器访问TH2515 (52)6.3.2通过上位机软件访问TH2515 (52)6.4USBTMC远程控制系统 (53)6.4.1系统配置 (53)6.4.2安装驱动 (53)6.5USBVCOM虚拟串口 (54)6.5.1系统配置 (54)6.5.2安装驱动 (54)第7章RS232命令参考 (55)7.1SCPI系统命令 (55)7.1.1DISPlay子系统命令集 (55)7.1.2FUNCtion 子系统命令集 (56)7.1.3APERture子系统命令集 (61)7.1.4TRIGer子系统命令集 (61)7.1.5FETCh?子系统命令集 (63)7.1.6TEMPerature子系统命令集 (64)7.1.7COMParator子系统命令集 (66)7.1.8BIN子系统命令集 (69)7.1.9STA Tistics子系统命令集 (73)7.1.10IO子系统命令集 (76)7.1.11MEMory子系统命令集 (77)7.1.12SYSTem 子系统命令集 (78)7.1.13SCPI公用命令 (81)7.2MODBUS系统命令 (83)7.2.1MODBUS协议说明 (84)7.2.2公用指令操作说明 (85)7.2.3DISP指令操作说明 (86)7.2.4FUNC指令操作说明 (86)7.2.5APER指令操作说明 (87)7.2.6TRIG指令操作说明 (87)7.2.7FETC指令操作说明 (88)7.2.8TEMP指令操作说明 (88)7.2.10BIN指令操作说明 (90)7.2.11STA T指令操作说明 (93)7.2.12IO指令操作说明 (94)7.2.13SYST指令操作说明 (94)第8章Handler接口使用说明及程序升级方法 (99)第9章包装及保修 (103)9.1标志 (103)9.2包装 (103)9.3运输 (103)9.4贮存 (103)9.5保修 (103)本说明书所描述的可能并非仪器所有内容，同惠公司有权对本产品的性能、功能、内部结构、外观、附件、包装物等进行改进和提高而不作另行说明！由此引起的说明书与仪器不一致的困惑，可通过封面的地址与我公司进行联系。
RVN4126 3.59100-386-9100-386/T DEVICERVN41772-CD2-3.5MCS/MTSRVN41821-CD2-3.5XTS3000/SABER PORTABLE YES RKN4046KHVN9085 3.51-20 R NO HLN9359 PROG. STAND RVN4057 3.532 X 8 CODEPLUG NO3080385B23 & 5880385B30 MDVN4965 3.59100-WS/T CONFIG KITRVN4053 3.5ASTRO DIGITAL INTERFACE NO3080385B23RVN41842-CD RKN4046A (Portable) 2-3.5ASTRO PORTABLE /MOBILE YES3080369B73 or0180300B10 (Mobile) RVN41831-CD3080369B732-3.5ASTRO SPECTRA MOBILE YES(Low / Mid Power)0180300B10 (High Power) RVN4185CD ASTRO SPECTRA PLUS MOBILE NO MANY OPTIONS; SEESERVICE BRIEF#SB-MO-0101RVN4186CD ASTRO SPECTRA PLUS MANY OPTIONS;MOBILE/PORTABLE COMB SEE SERVICE BRIEF#SB-MO-0101RVN4154 3.5ASTROTAC 3000 COMPAR.3080385B23RVN5003 3.5ASTROTAC COMPARATORS NO3080399E31 Adpt.5880385B34RVN4083 3.5BSC II NO FKN5836ARVN4171 3.5C200RVN4029 3.5CENTRACOM SERIES II NO VARIOUS-SEE MANUAL6881121E49RVN4112 3.5COMMAND PLUS NORVN4149 3.5COMTEGRA YES3082056X02HVN6053CD CT250, 450, 450LS YES AAPMKN4004RVN4079 3.5DESKTRAC CONVENTIONAL YES3080070N01RVN4093 3.5DESKTRAC TRUNKED YES3080070N01RVN4091 3.5DGT 9000 DESKSET YES0180358A22RVN4114 3.5GLOBAL POSITIONING SYS.NO RKN4021AHVN8177 3.5GM/GR300/GR500/GR400M10/M120/130YES3080070N01RVN4159 3.5GP60 SERIES YES PMLN4074AHVN9128 3.5GP300 & GP350RVN4152 3.5GP350 AVSRVN4150 3.5GTX YES HKN9857 (Portable)3080070N01(Mobile) HVN9025CD HT CDM/MTX/EX SERIES YES AARKN4083/AARKN4081RiblessAARKN4075RIBLESS NON-USA RKN4074RVN4098H 3.5HT1000/JT1000-VISAR YES3080371E46(VISAR CONV)RVN4151 3.5HT1000 AVSRVN4098 3.5HT1000/ VISAR CONV’L.YES RKN4035B (HT1000) HVN9084 3.5i750YES HLN-9102ARVN4156 3.5LCS/LTS 2000YES HKN9857(Portable)3080070N01(Mobile) RVN4087 3.5LORAN C LOC. RECV’R.NO RKN4021ARVN4135 3.5M100/M200,M110,M400,R100 includesHVN9173,9177,9646,9774YES3080070N01RVN4023 3.5MARATRAC YES3080070N01RVN4019 3.5MAXTRAC CONVENTIONAL YES3080070N01RVN4139 3.5MAXTRAC LS YES3080070N01RVN4043 3.5MAXTRAC TRK DUPLEX YES3080070N01RVN4178CD MC SERIES, MC2000/2500DDN6124AW/DB25 CONNECTORDDN6367AW/DB9 CONNECTOR RVN41751-CD Rib to MIC connector 1-3.5MCS2000 RKN4062BRVN41131-3.5MCS2000RVN4011 3.5MCX1000YES3000056M01RVN4063 3.5MCX1000 MARINE YES3000056M01RVN4117 3.5MDC/RDLAP DEVICESRVN4105 3.5MOBILE PROG. TOOLRVN4119 3.5MOBITEX DEVICESRVN4128 3.5MPT1327-1200 SERIES YES SEE MANUALRVN4025 3.5MSF5000/PURC/ANALOG YES0180355A30RVN4077 3.5MSF5000/10000FLD YES0180355A30RVN4017K 3.5MT 1000YES RTK4205CRVN4148 3.5MTR 2000YES3082056X02RVN4140 3.5MTRI 2000NORVN41761-CD MTS2000, MT2000*, MTX8000, MTX90001-3.5*programmed by DOS which is included in the RVN4176RVN4131 3.5MTVA CODE PLUG FIXRVN4142 3.5MTVA DOCTOR YES3080070N01RVN4131 3.5MTVA3.EXERVN4013 3.5MTX800 & MTX800S YES RTK4205CRVN4097 1-CD MTX8000/MTX9000,MTS2000,MT2000*,* programmed by DOS which is included in the RVN4176HVN9067CD MTX850/MTX8250MTX950,MTX925RVN4138 3.5MTX-LS YES RKN4035DRVN4035 3.5MX 1000YES RTK4203CRVN4073 3.5MX 800YES RKN4006BHVN9395 P100, P200 LB, P50+, P210, P500, PR3000RVN4134 3.5P100 (HVN9175)P200 LB (HVN9794)P50+ (HVN9395)P210 (HVN9763)P500 (HVN9941)PR3000 (HVN9586)YES RTK4205HVN9852 3.5P110YES HKN9755A/REX1143 HVN9262 3.5P200 UHF/VHF YES RTK4205RVN4129 3.5PDT220YVN4051 3.5PORTABLE REPEATER Portable rptr.P1820/P1821AXRVN4061C 3.5PP 1000/500NO3080385B23 & 5880385B30 RVN5002 3.5QUANTAR/QUANTRO NO3O80369E31RVN4135 3.5R100 (HVN9177)M100/M200/M110/M400YES0180358A52RVN4146 3.5RPM500/660RVN4002 3.5SABER YES RTK4203CRVN4131 3.5SETTLET.EXEHVN9007 3.5SM50 & SM120YESRVN4039 3.5SMART STATUS YES FKN5825AHVN9054 3.5SOFTWARE R03.2 P1225YES3080070N01HVN9001 3.5SOFTWARE R05.00.00 1225LS YES HLN9359AHVN9012 3.5SP50RVN4001N 3.5SPECTRA YES3080369B73 (STANDARD)0180300B10 (HIGH POWER) RVN4099 3.5SPECTRA RAILROAD YES3080369B73RVN4110 3.5STATION ACCESS MODULE NO3080369E31RVN4089A 3.5STX TRANSIT YES0180357A54RVN4051 3.5SYSTEMS SABER YES RTK4203BRVN4075 3.5T5600/T5620 SERIES NO3080385B23HVN9060CD TC3000, TS3000, TR3000RVN4123 3.5VISAR PRIVACY PLUS YES3080371E46FVN4333 3.5VRM 100 TOOLBOX FKN4486A CABLE &ADAPTORRVN4133 3.5VRM 500/600/650/850NORVN4181CD XTS 2500/5000 PORTABLES RKN4105A/RKN4106A RVN41002- 3.5XTS3000 ASTRO PORTABLE/MOBILERVN4170 3.5XTS3500YES RKN4035DRIB SET UPRLN4008E RADIO INTERFACE BOX (RIB)0180357A57RIB AC POWER PACK 120V0180358A56RIB AC POWER PACK 220V3080369B71IBM TO RIB CABLE (25 PIN) (USE WITH XT & PS2)3080369B72IBM TO RIB CABLE (9 PIN)RLN443825 PIN (F) TO 9 PIN (M) ADAPTOR (USE W/3080369B72 FOR AT APPLICATION) 5880385B308 PIN MODULAR TO 25 PIN ”D” ADAPTOR (FOR T5600 ONLY)0180359A29DUPLEX ADAPTOR (MOSTAR/TRAXAR TRNK’D ONLY)Item Disk Radio RIB Cable Number Size Product Required Number Item Disk Radio RIB Cable Number Size Product Required NumberUtilizing your personal computer, Radio Service Software (RSS)/Customer Programming Software (CPS)/CustomerConfiguration Software (CCS) enables you to add or reprogram features/parameters as your requirements change. RSS/CPS/CCS is compatible with IBM XT, AT, PS/2 models 30, 50, 60 and 80.Requires 640K RAM. DOS 3.1 or later. Consult the RSS users guide for the computer configuration and DOS requirements. (ForHT1000, MT/MTS2000, MTX838/8000/9000, Visar and some newer products —IBM model 386, 4 MEG RAM and DOS 5.0 or higher are recommended.) A Radio Interface Box (RIB) may be required as well as the appropriate cables. The RIB and cables must be ordered separately.Licensing:A license is required before a software (RVN) order is placed. The software license is site specific (customer number and ultimate destination tag). All sites/locations must purchase their own software.Be sure to place subsequent orders using the original customer number and ship-to-tag or other licensed sites; ordering software without a licensed customer number and ultimate tag may result in unnecessary delays. To obtain a no charge license agreement kit, order RPX4719. To place an order in the U.S. call 1-800-422-4210. Outside the U.S., FAX 847-576-3023.Subscription Program:The purchase of Radio ServiceSoftware/Customer Programming/Customer ConfigurationSoftware (RVN & HVN kits) entitles the buyer/subscriber to three years of free upgrades. At the end of these three years, the sub-scriber must purchase the same Radio Service Software kit to receive an additional three years of free upgrades. If the sub-scriber does not elect to purchase the same Radio Service Software kit, no upgrades will be sent. Annually a subscription status report is mailed to inform subscribers of the RSS/CPS/CCS items on our database and their expiration dates.Notes:1)A subscription service is offered on “RVN”-Radio Service Software/Customer Programming/Customer Configuration Software kits only.2)“RVN” software must only be procured through Radio Products and Services Division (RPSD). Software not procured through the RPSD will not be recorded on the subscription database; upgrades will not be mailed.3)Upgrades are mailed to the original buyer (customer number & ultimate tag).4)SP software is available through the radio product groups.The Motorola General Radio Service Software Agreement is now available on Motorola Online. If you need assistance please feel free to submit a “Contact Us” or call 800-422-4210.SMART RIB SET UPRLN1015D SMART RIB0180302E27 AC POWER PACK 120V 2580373E86 AC POWER PACK 220V3080390B49SMARTRIB CABLE (9 PIN (F) TO 9 PIN (M) (USE WITH AT)3080390B48SMARTRIB CABLE (25 PIN (F) TO 9 PIN (M) (USE WITH XT)RLN4488ASMART RIB BATTERY PACKWIRELESS DATA GROUP PRODUTS SOFTWARERVN4126 3.59100-386/9100T DEVICES MDVN4965 3.59100-WS/T CONFIG’TN RVN41173.5MDC/RDLAP DEVICESPAGING PRODUCTS MANUALS6881011B54 3.5ADVISOR6881029B90 3.5ADVISOR ELITE 6881023B20 3.5ADVISOR GOLD 6881020B35 3.5ADVISOR PRO FLX 6881032B30 3.5BR8506881032B30 3.5LS3506881032B30 3.5LS5506881032B30 3.5LS7506881033B10 3.5LS9506881035B20 3.5MINITOR III8262947A15 3.5PAGEWRITER 20008262947A15 3.5PAGEWRITER 2000X 6881028B10 3.5TALKABOUT T3406881029B35 3.5TIMEPORT P7308262947A15 3.5TIMEPORT P930NLN3548BUNIVERSAL INTERFACE KITItem Disk Radio NumberSize Product。
电感专业制造商 CMNR系列磁胶屏蔽功率电感器●EXTERNAL DIMENSIONS UNIT：mm（外形尺寸）Fig 1Fig 2Fig 3● PART NUMBERING SYSTEM（品名系统）CMNR3015-4R7M T123451、SERIES NAME 品名 C代C.RD.，M指贴片端银系列，NR代表点磁胶屏蔽2、DIMENSIONS 尺寸 外围*高度3、INDUCTANCE 电感值 前两位为有效数字，第三位表示零的个数4、TOLERANCE CODE 公差 J：±5%，K：±10%，L：±15%，M：±20%，P：±25%，N：±30%5、PACKING CODE 包装方式 T：Tape&Reel(卷装) B：In Bulk● FEATURES（特性）Various high power inductors are superior to be high saturation for surface mounting.具有高功率、高饱和电流，低阻抗、小型化之特点● Operating Temp（操作温度）工作环境温度 -40℃～125℃● APPLICATIONS（用途）LED,VR,AR,Notebooks, desktop computers, servers, graphic cards cards，Telecomm base stationsPortable gaming devices, personal navigation systems, personal multimedia devicesFlat-screen TVs, blue-ray disc recorders, set top box, movie cameras,smart phone************************************************************************************ Design As Customers Requested Specifications可根据客户需求设计电感专业制造商 CMNR系列磁胶屏蔽功率电感器CMNR4020 TYPECMNR4030 TYPECMNR5040 TYPECMNR6028 TYPE※1: All test data is referenced to 20°C ambient;※2: Rated current: Isat or Irms, whichever is smaller;※3: Isat: DC current at which the inductance drops approximate 30% from its value without current;※4: Irms: DC current that causes the temperature rise (△T =40°C) from 20°C ambient.TYPICAL ELECTRICAL CHARACTERISTICS CMNR252012 SeriesTemperature vs. DC Current Characteristics Inductance vs. DC Current CharacteristicsTYPICAL ELECTRICAL CHARACTERISTICSCMNR3012 SeriesTemperature vs. DC Current Characteristics Inductance vs. DC Current CharacteristicsCMNR3015 SeriesTemperature vs. DC Current Characteristics Inductance vs. DC Current CharacteristicsCMNR4012 SeriesTemperature vs. DC Current Characteristics Inductance vs. DC Current CharacteristicsTYPICAL ELECTRICAL CHARACTERISTICSCMNR4020 SeriesTemperature vs. DC Current Characteristics Inductance vs. DC Current CharacteristicsCMNR4030 SeriesTemperature vs. DC Current Characteristics Inductance vs. DC Current CharacteristicsCMNR5020 SeriesTemperature vs. DC Current Characteristics Inductance vs. DC Current CharacteristicsCMNR6020 SeriesTemperature vs. DC Current Characteristics Inductance vs. DC Current CharacteristicsCMNR6028 SeriesTemperature vs. DC Current Characteristics Inductance vs. DC Current CharacteristicsCMNR8040 SeriesTemperature vs. DC Current Characteristics Inductance vs. DC Current Characteristics。
CT-2525CH, CT-2550CH and CT-2570CHPA25383A01 Rev. 07 1-2019CRIMPING HEADS USED WITH THE CT-2500, CT-2500/E; orCT-2500/L, CT-2500/LE TOOLS© Panduit Corp. 2019CT-2525CH CT-2550CH CT-2570CHCT-2525CH Crimping head for installing the following Panduit products:#26 – #22 AWG (0,14 – 0,5 mm2)insulated terminals and splices,#22 – #10 AWG (0,5 – 6,0 mm2) fully insulated disconnects, insulated parallel splices;and specific #22 – #14 AWG (0,5 – 2,5 mm2) barrel insulated disconnects.CT-2550CH Crimping head for installing the following Panduit products:#22 – #10 AWG (0,5 – 6,0 mm2) insulated terminals and splices;and specific insulated disconnects.Reduced crimp effort advantage for #12 – #10 AWG (4,0 – 6,0mm2) terminations.CT-2570CH Crimping head for installing most of the following Panduit products:#22 – #10 AWG (0,5 – 6,0 mm2) non-insulated terminals, disconnects; and specificnon-insulated splices.CRIMPING HEAD INSTALLATION(See Page 2)Monthly Maintenance1. Thoroughly clean all surfaces.2. Oil the locating pins.NOTE: In the interest of higher quality and value, we are constantly improving and updating our products. Consequently, pictures in this manual may sometimes vary from the productenclosed.E-mail:EU Website:/emeaEU Email:emeatoolservicecenter@Technical Support:1-800-777-3300Panduit EuropeEMEA Service CenterAlmelo, NetherlandsTel: +31-546-580-452Fax: +31-546-580-441© Panduit Corp. 2019INSTALLATION INSTRUCTIONS CT-2525CH, CT-2550CHand CT-2570CHCRIMPING HEAD INSTALLATION1. Rotate crimping head adapter fully --clockwise (see Figure 1).2. Press retract slide to lower pistoncompletely.3. Pull out the pins for mounting adifferent crimping head on theadapter.4. Before installing a different crimpinghead, slide the crimp dies to the fullopen position. Lock the head withthe locating pins (see Figure 2),paying attention that the pins arelocked securely before starting.5. The crimping cycle is terminatedwhen the dies are completely closedand the maximum crimping force isreached, which is indicated by theauto retraction of the piston.Refer to the CT-2500, CT-2500/E(PA25346A01); or CT-2500/L,CT-2500/LE (PA28113A01) OperationManual for complete tool and crimpinghead instructions.ATTENTION: The crimping process can be interrupted at any time by releasing the trigger.After having terminated the crimping process and prior to changing the heads, remove battery to avoid unintended starts.DIE CLOSURE GO / NO GO GAGE MEMBERS – CT-2525CHCRIMP POCKET ENGLISH GO / NO GO GAGE MEMBERS METRIC GO / NO GO GAGE MEMBERS AWG / mm2“G” Dia. (GO) “NG” Dia. (NO GO) “G” Dia. (GO) “NG” Dia. (NO GO) Pocket “A” .0835” .091” 2,12 mm 2,31 mm22 – 14 / 0,5 – 2,5 .0765” .084” 1,94 mm 2,13 mm12 – 10 / 4,0 – 6,0 .1005” .108” 2,55 mm 2,74 mmDIE CLOSURE GO / NO GO GAGE MEMBERS – CT-2550CHCRIMP POCKET ENGLISH GO / NO GO GAGE MEMBERS METRIC GO / NO GO GAGE MEMBERS AWG / mm2“G” Dia. (GO) “NG” Dia. (NO GO) “G” Dia. (GO) “NG” Dia. (NO GO) 22 – 14 / 0,5 – 2,5 .1015” .108” 2,57 mm 2,74 mm12 – 10 / 4,0 – 6,0 .1475” .154” 3,74 mm 3,91 mmDIE CLOSURE GO / NO GO GAGE MEMBERS – CT-2570CHCRIMP POCKET ENGLISH GO / NO GO GAGE MEMBERS METRIC GO / NO GO GAGE MEMBERS AWG / mm2“G” Dia. (GO) “NG” Dia. (NO GO) “G” Dia. (GO) “NG” Dia. (NO GO) 22 – 18 / 0,5 – 1,5 .0515” .060” 1,31 mm 1,53 mm16 – 14 / 1,5 – 2,5 .0735” .082” 1,87 mm 2,09 mm12 – 10 / 4,0 – 6,0 .0995” .108” 2,53 mm 2,75 mm。
