DS-3E1326P-SISmart Managed 24-Port 100 Mbps PoE SwitchSmart managed switches are developed by Hikvision,featuring in easy management and maintenance. You caneasily deploy, monitor and expand your surveillance systemanytime and anywhere with our software platforms. Youcan view the network topology, monitor the health of thenetwork and receive device alarms in real time, whichgreatly reduces the cost of network operation andmaintenance.Key Feature• 24 × 100 Mbps PoE RJ45 port, 2 × gigabit combo.• IEEE 802.3at/af standard for PoE ports.• Network topology management, alarm push, network health monitor.• 6 KV surge protection for PoE ports.• AF/AT camera can reach up to 300 m in extend mode.SpecificationModel DS-3E1326P-SINetwork Parameters Port Number 24 × 100 Mbps PoE RJ45 port, and 2 × gigabit comboPort Type RJ45 port, full duplex, MDI/MDI-X adaptiveStandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE802.3zHigh Priority Ports Ports 1 to 8Forwarding Mode Store-and-forward switchingWorking ModeStandard mode (default)Extend modeMAC Address Table 16 KSwitching Capacity 8.8 GbpsPacket ForwardingRate6.5472 MppsInternal Cache 4 MbitsPoE Power Supply PoE Standard IEEE 802.3af, IEEE 802.3atPoE Power PinEnd-span: 1/2(-), 3/6(+)Mid-span: 4/5(+), 7/8(-)8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) PoE Port Ports 1 to 24Max. Port Power 30 WPoE Power Budget 370 WSoftware Function Device MaintenanceRemote upgrade, default parameters recovery, logs viewing,basic network parameters configuration, import and exportconfiguration, time syncPort Configuration Port rate configuration, slow control, and ports enabling Long Range Up to 300 m transmissionPoE ConfigurationPoE watchdog: Ports 1 to 24 auto detect and restart thecameras that do not respond.PoE enabling: SupportPort Rate-Limiting Rate-limiting for ingress and egress portsStorm Control Storm control of unknown unicast, multicast and broadcast Port Mirroring SupportLink Aggregation Static link aggregation supported for G1 and G2 portPort Isolation Ports in isolation group cannot communicate with each other. QoS WRR and SP scheduling and port priorityVLAN 4094 VLANsSTP STP and RSTP protocolsSNMPSNMPv1 and SNMPv2c supported for obtaining nodeinformation of the system and interfacesLLDPLLDP protocol supported for port configuration, globalconfiguration and neighbour discoveryGeneral Shell Metal material Net Weight 2.83 kg (6.24 lb)Gross Weight 3.33 kg (7.34 lb) Dimension (W × H × D)440 mm × 44 mm × 221 mm (17.32” × 1.73” × 8.70”) OperatingTemperature-10°C to 55°C (14°F to 131°F) Storage Temperature-40°C to 85°C (-40°F to 185°F) Operating Humidity5% to 95% (no condensation) Relative Humidity5% to 95% (no condensation) Power Supply100 VAC~240 VAC, 50/60 Hz, Max. 6.5 A Max. PowerConsumption400 W Power Consumption inIdle 5 WApprovalEMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, ENIEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN50130-4: 2011 +A1: 2014, EN 55035: 2017); IC (ICES-003: Issue 6); RCM (AS/NZS CISPR 32: 2015)Safety UL (UL 60950-1); CB (IEC 60950-1:2005, AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition); CE-LVD (EN60950-1: 2006 + A11: 2009 +A1: 2010+A12: 2011+A2: 2013, EN 62368-1: 2014+A11: 2017)ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No.1907/2006)⏹Typical Application⏹ Available ModelDS-3E1326P-SI⏹Physical Interface⏹Dimension (Unit: mm)。
DS-2DF8C825IXS-AEL(T5)8 MP 25× Network IR Speed DomeHikvision DS-2DF8C825IXS-AELW(T5) 8MP 25× Network IR Speed Dome adopts 1/1.2" progressive scan CMOS chip. With the 25× optical zoom lens, the camera offers more details over expansive areas. This series of cameras can be widely used for wide ranges of high-definition, such as the rivers, forests, roads, railways, airports, ports, squares, parks, scenic spots, stations and large venues, etc.⏹1/1.2" progressive scan CMOS⏹High quality imaging with 8 MP resolution⏹Excellent low-light performance with DarkFighter technology⏹25× optical zoom and 16× digital zoom provide close up views over expansive areas⏹Expansive night view with up to 500 m IR distance⏹Water and dust resistant (IP67) and vandal resistant (IK10) excluding glass window⏹Supports face capture to detect, capture, grade, and select faces in motion⏹Supports road traffic to detect vehicles⏹DORIThe DORI (detect, observe, recognize, identify) distance gives the general idea of the camera ability to distinguish persons or objects within its field of view.It is calculated based on the camera sensor specification and the criteria given by EN 62676-4: 2015.DORI Detect Observe Recognize IdentifyDefinition25 px/m63 px/m125 px/m250 px/m Distance (Tele) 3750 m (12303.1 ft.) 1488.1 m (4882.2 ft.) 750 m (2460.6 ft.) 375 m (1230.3 ft.)⏹SpecificationCameraImage Sensor 1/1.2" progressive scan CMOSMin. Illumination Color: 0.002 Lux @(F1.6, AGC ON), B/W: 0.0002 Lux @(F1.6, AGC ON), 0 Lux with IR Shutter Speed 1/1 s to 1/30,000 sSlow Shutter YesDay & Night IR cut filterZoom 25x optical, 16x digitalMax. Resolution 3840 × 2160LensFocus Auto, semi-auto, manual, rapid focusFocal Length 7.5mm to 187.5mmZoom Speed Approx. 6.8 sFOV Horizontal field of view: 60.4° to 3.7° (wide-tele), Vertical field of view: 36.2° to 2.1° (wide-tele), Diagonal field of view: 67.8° to 4.3° (wide-tele)Aperture Max. F1.6IlluminatorSupplement Light Type IRSupplement Light Range Up to 500 mSmart Supplement Light YesPTZMovement Range (Pan) 360°Movement Range (Tilt) -20° to 90° (auto flip)Pan Speed Pan speed: configurable from 0.1° to 210°/s; preset speed: 280°/s Tilt Speed Tilt speed: configurable from 0.1° to 150°/s, preset speed 250°/s Proportional Pan YesPresets 300Patrol Scan 8 patrols, up to 32 presets for each patrolPattern Scan 4 pattern scans, record time over 10 minutes for each scan Power-off Memory YesPark Action Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan3D Positioning Yes PTZ Status Display Yes Preset Freezing YesScheduled Task Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux outputVideoMain Stream 50 Hz: 25 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);60 Hz: 24 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)Sub-Stream 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 24 fps (704 × 480, 640 × 480, 352 × 240)Third Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 24 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)Video Compression Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEGThird stream: H.265/H.264/MJPEGVideo Bit Rate 32 Kbps to 16384 KbpsH.264 Type Baseline Profile/Main Profile/High ProfileH.265 Type Main ProfileScalable Video Coding (SVC) H.264 and H.265 encodingRegion of Interest (ROI) 8 fixed regions for each streamAudioAudio Compression G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCMAudio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2) NetworkNetwork Storage NAS (NFS, SMB/ CIFS), ANRProtocols IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, BonjourAPI ISUP, ISAPI, Hikvision SDK, Open Network Video Interface (Profile S, Profile G, Profile T) Simultaneous Live View Up to 20 channelsUser/Host Up to 32 users 3 user levels: administrator, operator, and userSecurity Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address)Client HikCentral, iVMS-4200, Hik-ConnectWeb Browser IE11, Chrome 57.0+, Firefox 52.0+, Safari 11+ ImageDay/Night Switch Day, night, auto, scheduled-switchImage Enhancement BLC, HLC, 3D DNRWide Dynamic Range (WDR) 140 dBDefog Optical defogImage Stabilization EIS (Built-in gyroscope to improve EIS performance) Regional Exposure YesRegional Focus YesImage Settings Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browserImage Parameters Switch YesPrivacy Mask Up to 24 masks, mosaic mask, mask color configurable, rectangle regionSNR ≥ 52 dBInterfaceEthernet Interface 1 RJ45 10M/100M self-adaptive Ethernet portOn-board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC cards, up to 256 GBAlarm 7 inputs, 2 outputsAudio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 ΩVideo Output 1.0 V[p-p]/75 Ω, PAL, NTSC, BNC connectorRS-485 Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive EventBasic Event Audio exception, motion detection, video tampering alarm, alarm input, alarm output, exceptionSmart Event Line crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, vandal-proof alarm, audio exception detectionSmart Tracking Manual tracking, auto-trackingAlarm Linkage Preset, patrol scan, pattern scan, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, NAS video recordingDeep Learning FunctionFace Capture Support detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the faceFace Comparison YesPerimeter Protection Line crossing, intrusion, region entrance, region exitingSupport alarm triggering by specified target types (human and vehicle)Road Traffic and Vehicle DetectionRoad Traffic Support vehicle detection (license plate number, vehicle model, and vehicle color recognition)GeneralOperating Condition Temperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95%Language 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), UkrainianPower Consumption and Current 24 VAC (Max. 62 W, including max. 12 W for IR and max. 8 W for heater), PoE 802.3 bt (Max. 51 W, including max. 12 W for IR and max. 8 W for heater)Dimension Ø 267 mm × 430 mm (Ø 10.51" × 16.93") Weight Approx. 9.6 kg (21.16 lb.)ApprovalEMC FCC SDoC (47 CFR Part 15, Subpart B);CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014);RCM (AS/NZS CISPR 32: 2015);IC VoC (ICES-003: Issue 7);KC (KN 32: 2015, KN 35: 2015)SafetyUL (UL 62368-1)CB (IEC 62368-1:2014+A11);CE-LVD (EN 62368-1:2014+A11:2017), BIS (IS 13252(Part 1):2010/ IEC 60950-1: 2005); LOA (IEC/EN 60950-1)Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)ProtectionIP67 (IEC 60529-2013), IK10 (IEC 62262:2002), 6000V Lightning Protection, Surge Protection and Voltage Transient Protection⏹Typical ApplicationHikvision products are classified into three levels according to their anti-corrosion performance. Refer to the following description to choose for your using environment.This model has NO SPECIFIC PROTECTION.LevelDescriptionTop-level protectionHikvision products at this level are equipped for use in areas where professional anti-corrosion protection is a must. Typical application scenarios include coastlines, docks, chemical plants, and more.Moderate protectionHikvision products at this level are equipped for use in areas with moderate anti-corrosion demands. Typical application scenarios include coastal areas about 2 kilometers (1.24 miles) away from coastlines, as well as areas affected by acid rain.No specific protectionHikvision products at this level are equipped for use in areas where no specific anti-corrosion protection is needed.⏹Dimension⏹Available Model DS-2DF8C825IXS-AEL (T5)⏹Accessory ⏹OptionalDS-1603ZJ-P Wall Mount DS-1603ZJ-pole-PPole MountDS-1661ZJ-PPendant Mount。
经济型POE交换机产品简介DS-3E系列POE交换机支持5/8/16/24口百兆PoE电口，可通过网线直接供电，PoE自适应802.3af（15.4W）和802.3at（30W）标准，整机PoE最大输出功率为58/120/230/370W，通过普通的5类双绞线即可为AP、IP摄像头、IP电话等PoE受电设备同时传输电力和数据。
设备支持网络延长（EXTEND）模式，开启后，使用超五类及以上网线时，对应端口的数据传输和供电距离最远可达250米；PoE支持8芯供电技术，有效降低电源线路损耗；支持重要端口数据保障功能，对于重点区域的数据或视频，优先保证及传输；智能型支持VLAN、链路汇聚、QoS、STP防环、SNMP等智能管理功能，可减少项目施工难度和施工时间，最大程度的节省工程项目成本，保护用户投资。
整机全金属设计，结构坚固、使用方便，可靠性好，适用于园区、公安、楼宇等多种监控场景。
DS-3E0105P-EDS-3E0109P-E&DS-3E0109P-E(B)DS-3E0318P-EDS-3E0326P-EDS-3E1310P-EDS-3E1318P-EDS-3E1326P-E订货型号功能特性●支持802.3af/at PoE标准●支持PoE 8芯供电技术，降低网线电源损耗●支持重要端口数据保障●支持EXTEND模式，延长网线传输至250m●支持buffer优化，保证视频数据传输●支持VLAN配置(智能型支持)●支持端口汇聚(智能型支持)●支持STP、组播、端口镜像(智能型支持)●支持QoS(智能型支持)●支持SNMP网络管理(智能型支持)●支持WEB管理(智能型支持)●存储转发交换方式；●支持IEEE802.3、IEEE802.3u、IEEE802.3x网络标准●平均无故障时间MTBF≥10万小时；●全金属封闭结构；●桌面、机架式设计,安装简便技术参数非网管型硬件规格智能型硬件规格智能型软件规格组网应用DS-3E1318P-EDS-3E1318P-EDS-3E1318P-EDS-3E1318P-EDS-3E2528电视墙POE IPCPOE交换机汇聚交换机NVR客户端存储服务器监控组网示意图。
H3C S5500—EI 系列以太网交换机产品概述H3C S5500—EI系列交换机是H3C公司最新开发的增强型IPv6强三层万兆以太网交换机产品，具备业界盒式交换机最先进的硬件处理能力和最丰富的业务特性.支持最多4个万兆扩展接口，支持IPv4/IPv6硬件双栈及线速转发，使客户能够从容应对即将带来的IPv6时代;除此以外，其出色的安全性，可靠性和多业务支持能力使其成为大型企业网络和园区网的汇聚，中小企业网核心、以及城域网边缘设备的第一选择。
S5500—28C-EI/S5500-28C—PWR—EIS5500—52C—EI/ S5500—52C-PWR-EIS5500—28F-EIH3C S5500—EI系列以太网交换机目前包含如下型号：●S5500-28C-EI:24 个10/100/1000Base-T以太网端口，4 个复用的SFP 千兆端口（Combo），两个扩展槽位；●S5500-52C-EI：48 个10/100/1000Base—T以太网端口，4 个复用的SFP 千兆端口(Combo），两个扩展槽位；●S5500—28C—PWR-EI:24 个10/100/1000Base-T以太网（PoE)，4 个复用的SFP 千兆端口（Combo),两个扩展槽位；●S5500-52C-PWR—EI:48 个10/100/1000Base-T以太网（PoE),4 个复用的SFP 千兆端口（Combo)，两个扩展槽位；●S5500—28F—EI：24 个SFP千兆端口，8 个复用的10/100/1000Base-T以太网端口（Combo），两个扩展槽位；高扩展性保护投资随着用户端速度不断提高，用户最终会使集群千兆链路达到饱和，而能够拥有多条集群10GE链路将是我们的未来发展方向。
H3C S5500—EI系列交换机支持两个扩展槽位，每个槽位支持最大两端口的10GE扩展模块及两端口的CX4扩展模块，在实现千兆汇聚或接入时保留进一步支持10GE的扩展能力，尽力保护用户投资.IPv4到IPv6的演变是以太网发展的大势所趋，网络设备对于IPv6的支持不仅是简单的可用就行，而是需要达到商用的标准，S5500—EI已经通过了国际最权威的IPv6 Ready 第二阶段认证,而且通过了信息产业部严格的IPv6入网测试.这个系列产品是基于硬件的IPv4/IPv6双栈平台，支持丰富的IPv4和IPv6三层路由协议、组播协议和策略路由机制，实现IPv4到IPv6的平滑升级.智能弹性架构H3C S5500—EI系列交换机支持IRF2（第二代智能弹性架构）技术，就是把多台物理设备互相连接起来,使其虚拟为一台逻辑设备，也就是说，用户可以将这多台设备看成一台单一设备进行管理和使用。
“手机看店”终端设备说明书（海康威视）中国电信浙江公司政企客户部2013年9月终端设备说明书（海康威视）目录第1章CDX1 ................................................................................................................................- 1 -1.1 产品特性........................................................................................................................- 1 -1.2 外观介绍........................................................................................................................- 1 -1.3 技术参数........................................................................................................................- 2 -1.4 安装 ...............................................................................................................................- 4 - 第2章CDX1普通版 ...................................................................................................................- 5 -2.1 产品特性........................................................................................................................- 5 -2.2 外观介绍........................................................................................................................- 6 -2.3 技术参数........................................................................................................................- 7 -2.4 安装 ...............................................................................................................................- 8 - 第3章CDX2 ............................................................................................................................. - 10 -3.1 产品特性.................................................................................................................... - 10 -3.2 外观介绍.................................................................................................................... - 10 -3.3 安装注意事项............................................................................................................. - 11 -3.4 安装 ............................................................................................................................ - 12 -3.4.1吸顶式安装 ..................................................................................................... - 12 - 第4章CDX2普通版 ................................................................................................................ - 15 -4.1 产品特性.................................................................................................................... - 15 -4.2 外观介绍.................................................................................................................... - 15 -4.3安装注意事项 ............................................................................................................ - 16 -4.4 安装 .............................................................................................................................- 17 -4.4.1吸顶式安装 ......................................................................................................- 17 - 第5章DDX1 ............................................................................................................................. - 18 -5.1 面板按键及指示灯说明............................................................................................. - 18 -5.2 鼠标操作说明..............................................................................................................- 20 -5.3 输入法说明................................................................................................................. - 21 -5.4 菜单说明..................................................................................................................... - 21 -5.5 技术参数..................................................................................................................... - 21 -第1章CDX11.1 产品特性网络摄像机是集传统的模拟摄像机和网络视频服务器于一体的嵌入式数字监控产品。
渠道产品体系2014.01内容概要•DIS---渠道专用模拟摄像机•IPC---渠道专用网络摄像机•IPD---渠道专用球机•DVR---渠道专用硬盘录像机•NVR---渠道专用NVR2011年2012年2013年600TVL海康威视DIS摄像机720TVL750TVL580TVL950TVL2014年E系列摄像机非红外定焦半球红外定焦海螺红外防水定焦筒机点阵防水定焦筒机点阵防水定焦海螺红外防水变焦筒机红外防水变焦海螺红外防水定焦海螺DS-2 C E 1 6 C 2 P-IT3①②③④⑤⑥⑦⑧⑨经济型摄像机枪型/筒型摄像机半球型摄像机E ：1：5：第一代DIS 摄像机第二代DIS 摄像机5:6 :海康威视摄像机产品DS-2：彩色摄像机C ：580TVL 600TVL 700TVL 720TVL7：8：A ：C ：普通摄像机2：PAL 制P ：支持变焦镜头红外距离10-20米点阵红外30-40米点阵红外50-80米VF:IR:IT3:IT5:DIS 产品命名规则四大优势•PICADIS 系列采用的130万(1280x960)图像传感器的有效像素是960H(976x582)CCD 的2倍多，输出图像清晰度更高，可达750线750线超高清晰度•PICADIS 系列采用HDR(High dynamic range)Sensor 单元，动态范围相比600线DIS 提高了20dB ；在亮暗对比时，输出图像更明亮HDR 单元更高动态范围•PICADIS 系列ISP 处理单元采用ALTM(自适应局部亮度矫正技术),仿真人眼的图像处理特点, 对图像的每个像素自适应地进行校正ALTM 技术最优图像输出•PICADIS 系列图像处理系统最长的曝光时间达到40ms ，是现有模拟解决方案的两倍，使相同光照情况下的Sensor 感光度提高了一倍，从而获得更优秀的图像质量。
40ms 曝光出色超低照度清晰度高PICADIS系列摄像机清晰度高，可达750TVL，图像清晰细腻温度范围广◆普通CCD红外摄像机温度范围为“-10℃~60℃”◆DIS系列摄像机温度范围为“-40℃~60℃”，能适用于更严酷的环境红外ICR◆相同规格的红外摄像机无ICR机制，摄像机为感红外，白炽灯下会偏白◆海康威视采用ICR滤片式机制，白炽灯下色彩还原更真实◆海康威视DIS摄像机采用专利的ICR切换装置，能保证更长的使用寿命以及更高的稳定性。
OPTICAL MODULENETWORK CABLESRECOMMENDED OPTIONSWIRELESS BRIDGEAGGREGATION & CORE ETHERNET SWITCHINDUSTRIAL POE ETHERNET SWITCH≤ 100-ch IPCTypeModel Aggregation switchDS-3E0524TFAccess switch DS-3E01(3)xxP-E(B)Access switchDS-3E01(3)xxP-E/M(B)Access switch DS-3E05xxP-E Access switch DS-3E05xx-EOptical moduleHK-SFP-1.25G-1310-DF-MM100-ch < IPC ≤ 300-chTypeModel Aggregation switch DS-3E2528Access switch DS-3E13xxP-E Access switch DS-3E01(3)xxP-E(B)Access switch DS-3E05xxP-E Access switch DS-3E05xx-E Optical moduleHK-SFP-1.25G-20-1310HK-SFP-1.25G-20-1550300-ch < IPC ≤ 500-chType Model Core switch DS-3E3756TF Core switch DS-3E3740Aggregation switchDS-3E2528Access switch DS-3E23xxP-E Access switch DS-3E05xxP-E Access switch DS-3E01(3)xxP-E(B)Optical moduleHK-SFP-1.25G-20-1310HK-SFP-1.25G-20-1550ModelImageDescriptionHK-SFP-1.25G-20-1310TX 1310 nm/1.25G, RX 1550 nm/1.25G, LC, single mode and single fiber, 20 km, 0~70°C, SFPHK-SFP-1.25G-20-1550TX 1550 nm/1.25G, RX 1310 nm/1.25G, LC, single mode and single fiber, 20 km, 0~70°C, SFPHK-SFP-1.25G-1310-DF-MMTX 1310 nm/1.25G, RX 1310 nm/1.25G, LC, Multi mode and duplex fiber, 1 km, 0~70°C, SFPHK-SFP-1.25G-20-1310-DF TX 1310 nm/1.25G, RX 1310 nm/1.25G, LC, Single mode and duplex fiber, 20 km, 0~70°C, SFPHK-SFP+-10G-20-1270TX 1270 nm/10G, RX 1330 nm/10G, LC, single mode and single fiber, 20 km, 0~70°C, SFP+HK-SFP+-10G-20-1330TX 1330 nm/10G, RX 1270 nm/10G, LC, single mode and single fiber, 20 km, 0~70°C, SFP+Outdoor wireless bridgeElevator wireless bridgeModelDS-3WF01C-2N/ODS-3WF02C-5N/ODS-3WF03CDS-3WF0AC-2NTDS-3WF01C-2NDescriptionSupports point-to-point &point-to-multipoint;Range up to 3 km; 802.11 b/g/n, Built-in 12 dBiantenna up to 150 Mbps; Output power 27 dBm; Angle Horizontal: 60° Vertical: 30°; IP65;Supports point-to-point & point-to-multipoint; Range up to 5 km; 802.11 a/n, Built-in 10 dBi 2×2 MIMO antenna up to 300 Mbps; Output power 24 dBm; Angle Horizontal: 60° Vertical: 16°; IP65;Supports point-to-point & point-to-multipoint; Range up to 15 km; 802.11a/n, Built-in 15dBi 2×2 MIMO antenna with 300 Mbps; Output power 27 dBm; Angle Horizontal: 40° Vertical: 15°; IP65;Supports point-to-point, distance 100 m; IEEE 802.11b/g/n, Built-in 8dBi antenna; Output power 20 dBm; Angle Horizontal: 60° Vertical: 30°; Working temperature: -30 ~65°C; Plug and play, no initial setting;Supports point-to-point, distance 500 m; IEEE 802.11b/g/n, Built-in 6dBi antenna; Output power 27 dBm; Angle Horizontal: 65° Vertical: 60°; Working temperature: -30 ~65°C;Plug and play, no initial setting;ModelDS-1LN5E-SDS-1LN6-UUDS-1LN5E-E/EDS-1LN6-UE-WDescriptionUTP CAT 5E, 305 meters Core diameter: 0.5 mm Solid copper,CM,grayUTP CAT 6, 305 meters Core diameter: 0.565 mm Solid copper, CM, orangeUTP CAT 5E, 305 meters Core diameter: 0.45 mm Solid copper, CMX,grayUTP CAT 6, 305 meters, Core diameter: 0.53 mm Solid copper, CM,whiteModelDS-3E0524TFDS-3E2528DS-3E3740DS-3E3756TFManagement Unmanaged Full-managed Full-managed Full-managed Ports12 × Gigabit RJ45 ports 12 × Gigabit SFP ports24 × Gigabit RJ45 ports 4 × Gigabit SFP ports32 × Gigabit RJ45 ports 8 × 10G SFP+ ports24 × Gigabit RJ45 ports 24 × Gigabit SFP ports 8 × 10G SFP+ portsPacket Forwarding Rate 35.7 Mpps 42 Mpps 136 Mpps 136 Mpps Switching Capacity 48 Gbps 56 Gbps 224 Gbps 256 GbpsMAC Address Table 16 K 8 K64 K64 KManagement Mode -Console, Telnet, SSH2.0, Web, SNMP v1/v2/v3, TFTP, RMONOther Software Features-STP, VLAN, Mirroring, IGMP Snoopingand IGMP v1/v2, L2/L3/L4 ACL, LACP,EAPS, ERPSSTP, VLAN, Mirroring, IGMP Snooping and IGMP v1/v2, L2/L3/L4 ACL, LACP, EAPS,Operating Temperature -5°C~50°C0°C~45°C0°C~45°C0°C~45°C Dimension (440 × 186.5 × 44.5) mm (440 × 230 × 45) mm (442.5 × 315 × 44) mm (442.5 × 350 × 44) mmPower SupplyModelELG-150-48AImageOutput Voltage 48 VRated Current 3.13 ARated Power 150 WOperating Temperature-40~90°CIP Rating IP65AccessoryOptional accessory for industrial PoEswitchIndustrial switchModelDS-3T0306PDS-3T0310PManagement UnmanagedUnmanagedPorts 4 × 10/100 Mbps PoE RJ45 ports2 × Gigabit uplink SFP ports 8 × 10/100 Mbps PoE RJ45 ports 2 × Gigabit uplink SFP ports PoE Standards IEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atPoE Budget≤ 120 W ≤ 240 W Packet Forwarding Rate 3.6 Mpps 4.2 Mpps Switching Capacity 8.8 Gbps 8.8 Gbps MAC Address Table 4 K 4 K Surge Protection 2 KV 2 KV Operating Temperature -40°C~75°C -40°C~75°C Dimension(155 × 130 × 42) mm(170 × 156 × 42) mmUNMANAGED NON-POE ETHERNET SWITCHUNMANAGED POE ETHERNET SWITCHMANAGED POE ETHERNET SWITCHUNMANAGED SWITCHIEEE 802.3bt Standard Hi-PoE, Max. 90 W for One PortIEEE 802.3bt standard Hi-PoE port provides max. 90 W power supply for high power devices such as domes.Up to 300 m Long Range PoE TransmissionBased on all series of camera tests with Hikvisionnetwork cables, up to 300 m long range PoE transmission is provided.Intelligent PoE ManagementWhen the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.4/8-Core Adaptive Power Supply with Less Power Loss8-core power supply reduces the power loss on cables.6KV Surge Protection to Improve Reliability in Harsh EnvironmentThe built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.Design for Video TransmissionVIP port ensures important data transmission when network congestion occurs.Hi-PoE SwitchesModelDS-3E0106HP-EDS-3E0310HP-EPorts1 × 10/100 Mbps Hi-PoE port 3 × 10/100 Mbps PoE ports2 × 10/100 Mbps RJ45 ports 1 × 10/100 Mbps Hi-PoE port 7 × 10/100 Mbps PoE ports 2 × Gigabit RJ45 ports PoE Standards Port 1: IEEE 802.3af, IEEE 802.3at, IEEE802.3btPorts 2 to 4: IEEE 802.3af, IEEE 802.3atPort 1: IEEE 802.3af, IEEE 802.3at, IEEE802.3btPorts 2 to 8: IEEE 802.3af, IEEE 802.3atPoE Budget 60 W 110 W Max. port PoE power Port 1: 60 W Ports 2 to 4: 30 W Port 1: 90 W Ports 2 to 8: 30 W PoE Extend Mode Max. 300 m, Port 1-4Max. 300 m, Port 1-8Packet Forwarding Rate 0.893 Mpps 4.166 Mpps Switching Capacity 1.2 Gbps 5.6 Gbps MAC Address Table 2 K 16 K Surge Protection 6 KV 6 KV Operating Temperature-10°C~55°C -10°C~55°CDimension(145 × 25.6 × 68.45) mm(217.6 × 27.8 × 103.35) mm10/100 Mbps SwitchesModelDS-3E0105P-E/M(B)DS-3E0109P-E/M(B)DS-3E0318P-E/M(B)DS-3E0326P-E/M(B)DS-3E0105P-E(B)DS-3E0109P-E(C)DS-3E0318P-E(B)DS-3E0326P-E(B)Ports4 × 10/100 Mbps PoE RJ45 ports 1 × 10/100 Mbps uplink RJ45 port8 × 10/100 Mbps PoE RJ45 ports 1 × 10/100 Mbps uplink RJ45 port16 × 10/100 Mbps PoE RJ45 ports 1 × Gigabit uplink RJ45 port 1 × Gigabit uplink SFP port 24 × 10/100 Mbps PoE RJ45 ports1 × Gigabit uplink RJ45 port1 × Gigabit uplink SFP port4 × 10/100 Mbps PoE RJ45 ports1 × 10/100 Mbps uplink RJ45 port8 × 10/100 Mbps PoE RJ45 ports1 × 10/100 Mbps uplink RJ45 port16 × 10/100 Mbps PoE RJ45 ports 2 × Gigabit comb ports (2 RJ45 Ports and 2 SFP Ports)24 × 10/100 Mbps PoE RJ45 ports 2 × Gigabit comb ports (2 RJ45Ports and 2 SFP Ports)PoE Standards IEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atPoE Budget35 W60 W130 W230 W60 W115 W 230 W370 WPoE Extend Mode Max.300 m, Port 1-4Max. 300 m, Port 1-8Max. 300 m, Port 9-16Max. 300 m, Port 17-24Max 300 m, Port 1-4Max 300 m, Port 1-8Max. 300 m, Port 9-16Max. 300 m, Port 17-24Packet Forwarding Rate0.744 Mpps 1.34 Mpps 5.36 Mpps 6.55 Mpps 0.74 Mpps 1.34 Mpps 5.36 Mpps 6.55 Mpps Switching Capacity1 Gbps 1.8 Gbps 7.2 Gbps 8.8 Gbps 1 Gbps 1.8 Gbps 7.2 Gbps 8.8 Gbps MAC Address Table 1 K 2 K 4 K 4 K 1 K 2 K 4 K 4 K Surge Protection 6 KV 6 KV 6 KV 6 KV 6 KV 6 KV 6 KV 6 KV Operating Temperature-10°C~55°C -10°C~55°C -10°C~55°C -10°C~55°C -10°C~55°C -10°C~55°C -10°C~55°C -10°C~55°C Dimension(105 × 27.6 × 83.1)mm(170 × 27.6 × 93.1) mm(266 × 44.5 × 220.8) mm(335 × 44.5 × 226) mm(105 × 27.6 × 83.1) mm(170 × 27.6 × 93.1) mm(440 × 44 × 220.8) mm(440 × 44 × 220.8) mmGigabit SwitchesModel DS-3E0505P-EDS-3E0510P-EDS-3E0518P-EDS-3E0526P-EPorts4 × Gigabit PoE RJ45 ports1 × Gigabit RJ45 port 8 × Gigabit PoE RJ45 ports 1 × Gigabit RJ45 port 1 × Gigabit SFP port 16 × Gigabit PoE RJ45 ports 1 × Gigabit RJ45 port 1 × Gigabit SFP port 24 × Gigabit PoE RJ45 ports 1 × Gigabit RJ45 port 1 × Gigabit SFP port PoE Standards IEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atPoE Budget60 W 110 W 230 W 370 W Packet Forwarding Rate 7.44 Mpps 14.88 Mpps 26.784 Mpps 38.688 Mpps Switching Capacity 10 Gbps 20 Gbps 36 Gbps 52 Gbps MAC Address Table 2 K 4 K 8 K 8 K Surge Protection6 KV 6 KV 6 KV 6 KV Operating Temperature-10°C~55°C -10°C~55°C-10°C~55°C -10°C~55°C Dimension(105 × 27.6 × 83.1) mm(217.6 × 27.8 × 108.55) mm(440 × 44 × 220.8) mm(440 × 44 × 220.8) mmModel DS-3E0105D-EDS-3E0108D-EDS-3E0505D-EDS-3E0508D-EDS-3E0508-EDS-3E0516-EDS-3E0524-EPorts 5 × 10/100 Mbps RJ45 ports 8 × 10/100 Mbps RJ45 ports 5 × Gigabit RJ45 ports 8 × Gigabit RJ45 ports 8 × Gigabit RJ45 ports 16 × Gigabit RJ45 ports 24 × Gigabit RJ45 portsSwitching Capacity 1 Gbps 1.6 Gbps 10 Gbps 16 Gbps 16 Gbps 32 Gbps 48 GbpsPacket Forwarding Rate 0.744 Mpps 1.1904 Mpps 7.44 Mpps 11.904 Mpps 11.9 Mpps 23.8 Mpps 35.7 MppsMAC Address Table 1 K 1 K 2 K 4 K 4 K 8 K 8 KSurge Protection ---- 4 KV 4 KV 4 KVOperating Temperature 0°C~40°C 0°C~40°C 0°C~40°C 0°C~40°C 0°C~40°C 0°C~40°C 0°C~40°CDimension (82 × 52 × 22.4) mm (124 × 59 × 23.2) mm (92.8 × 65.8 × 22.8) mm (142 × 90 × 23) mm (186.7 × 106.7 × 33.3) mm (440 × 178.8 × 44) mm (440 × 178.8 × 44) mmModel DS-3E1310P-EDS-3E1318P-EDS-3E1326P-EDS-3E2310PDS-3E2318PDS-3E2326PDS-3E2510PDS-3E2528PManagement Web-managed Web-managed Web-managed Full-managed Full-managed Full-managed Full-managed Full-managed Ports 8 × 10/100 Mbps PoE RJ45 ports 2 × Gigabit comb ports (2 RJ45 Ports and 2 SFP Ports)16 × 10/100 Mbps PoE RJ45 ports 2 × Gigabit comb ports (2 RJ45 Ports and 2 SFP Ports)24 × 10/100 Mbps PoE RJ45 ports 2 × Gigabit comb ports (2 RJ45 Ports and 2 SFP Ports)8 × 10/100 Mbps PoE RJ45 ports 2 × Gigabit comb ports (2 RJ45 Ports and 2 SFP Ports)16 × 10/100 Mbps PoE RJ45 ports 2 × Gigabit comb ports (2 RJ45 Ports and 2 SFP Ports)24 × 10/100 Mbps PoE RJ45 ports 2 × Gigabit comb ports (2 RJ45Ports and 2 SFP Ports)8 × Gigabit PoE RJ45 ports 2 × Gigabit SFP ports 24 × Gigabit PoE RJ45 ports 4 × Gigabit SFP ports PoE Standards IEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atIEEE 802.3af, IEEE802.3atPoE Budget 123 W 230 W370 W125 W 300 W 380 W 125 W 380 W PoE Extend Mode Max. 250 m, Port 1-8Max. 250 m, Port 1-16Max. 250 m, Port 1-24-----Packet Forwarding Rate 1.34 Mpps 5.36 Mpps 6.55 Mpps 5.6 Mpps 8.4 Mpps 9.6 Mpps 15 Mpps 42 Mpps Switching Capacity5.4 Gbps 7.2 Gbps 8.8 Gbps 10 Gbps 21.2 Gbps 22.8 Gbps 20 Gbps 56 Gbps MAC Address Table 4 K4 K4 K8 K8 K8 K8 K8 KManagement Mode SNMP v1/v2, WEB managementConsole, Telnet, SSH2.0, Web, SNMP v1/v2/v3, TFTP, RMONOther Software Features STP, VLAN, Mirroring, IGMP Snooping and IGMP v1/v2STP, VLAN, Mirroring, IGMP Snooping and IGMP v1/v2, L2/L3/L4 ACL, LACP, EAPS, ERPSSurge Protection 4 KV 4 KV 4 KV 4 KV 4 KV 4 KV 4 KV 4 KV Operating Temperature 0°C~40°C 0°C~40°C 0°C~40°C 0°C~40°C 0°C~40°C 0°C~40°C 0°C~45°C 0°C~45°C Dimension(294 × 165.8 × 44) mm(440 × 285 × 43) mm(440 × 285 × 43) mm(280 × 179 × 45) mm(440 × 232 × 44) mm(440 × 232 × 44) mm(280 × 179 × 45) mm(440 × 232 × 45) mm。
后端产品手册2009.12.06目录DS-9000系列 (1)产品简介 (1)订货型号 (1)主要特性 (1)功能与性能 (2)物理接口 (4)典型应用 (5)技术规格表 (6)DS-9100系列 (8)产品简介 (8)订货型号 (8)主要特性 (8)功能与性能 (9)物理接口 (11)典型应用 (12)技术规格表 (13)DS-8100系列 (14)主要特性 (14)功能与性能 (14)典型应用 (16)DS-8100HF-S (18)产品简介 (18)订货型号 (18)特别说明 (18)物理接口 (18)技术规格表 (20)DS-8100HE-S (21)产品简介 (21)订货型号 (21)特别说明 (21)物理接口 (21)技术规格表 (23)DS-8100HC-S (24)产品简介 (24)订货型号 (24)特别说明 (24)物理接口 (24)技术规格表 (26)DS-8100HS-S (27)订货型号 (27)特别说明 (27)物理接口 (27)技术规格表 (29)DS-8100HL-S (30)产品简介 (30)订货型号 (30)特别说明 (30)物理接口 (30)技术规格表 (32)DS-7100系列 (33)DS-7100H-S (33)产品简介 (33)订货型号 (33)特别说明 (33)主要特性 (33)功能与性能 (34)物理接口 (36)典型应用 (37)技术规格表 (38)DS-7200系列（6467平台） (39)主要特性 (39)功能与性能 (39)典型应用 (41)DS-7208HV-S (42)产品简介 (42)订货型号 (42)特别说明 (42)物理接口 (42)技术规格表 (44)DS-7216HV-S (45)产品简介 (45)订货型号 (45)特别说明 (45)物理接口 (45)技术规格表 (47)DS-8000系列 (48)功能与性能 (48)典型应用 (50)DS-8000HF-S (51)产品简介 (51)订货型号 (51)特别说明 (51)技术规格表 (54)DS-8000HT-S (55)产品简介 (55)订货型号 (55)特别说明 (55)物理接口 (55)技术规格表 (57)DS-8000HE-S (58)产品简介 (58)订货型号 (58)特别说明 (58)物理接口 (58)技术规格表 (60)DS-8000HE-SL (61)产品简介 (61)订货型号 (61)特别说明 (61)物理接口 (61)技术规格表 (63)DS-8000HC-S (64)产品简介 (64)订货型号 (64)特别说明 (64)物理接口 (64)技术规格表 (66)DS-8000HC-SL (67)产品简介 (67)订货型号 (67)特别说明 (67)物理接口 (67)技术规格表 (69)DS-8000HS-S (70)产品简介 (70)订货型号 (70)特别说明 (70)物理接口 (70)技术规格表 (72)DS-8000HS-ST (73)产品简介 (73)订货型号 (73)特别说明 (73)物理接口 (73)技术规格表 (75)DS-7000系列 (76)DS-7000H-S (76)产品简介 (76)订货型号 (76)特别说明 (76)物理接口 (76)技术规格表 (79)DS-7200系列（6446平台） (80)DS-7204H-S (80)产品简介 (80)订货型号 (80)特别说明 (80)物理接口 (80)技术规格表 (81)DS-7208H-S (82)产品简介 (82)订货型号 (82)特别说明 (82)物理接口 (82)技术规格表 (83)DS-9000系列产品简介DS-9000系列网络硬盘录像机是海康威视自主研发的新一代混合型网络硬盘录像机它融合了多项专利技术，采用了多项IT高新技术，如视频编解码技术、嵌入式系统技术、存储技术、网络技术和智能技术等。
DS-3E0510P-E/M交换机快速指南法律声明版权所有©杭州海康威视数字技术股份有限公司2018。
保留一切权利。
本手册的任何部分，包括文字、图片、图形等均归属于本公司所有。
未经书面许可，任何单位和个人不得以任何方式摘录、复制、翻译、修改本手册的全部或部分。
除非另有约定，本公司不对本手册提供任何明示或默示的声明或保证。
关于本手册本手册描述的产品仅供中国大陆地区销售和使用。
本手册作为指导使用。
手册中所提供照片、图形、图表和插图等，仅用于解释和说明目的，与具体产品可能存在差异，请以实物为准。
因产品版本升级或其他需要，本公司可能对本手册进行更新，如您需要最新版手册，请登录公司官网查阅（）。
海康威视建议您在专业人员的指导下使用本手册。
商标声明为海康威视的注册商标。
本手册涉及的其他商标由其所有人各自拥有。
责任声明●在法律允许的最大范围内，本手册所描述的产品（含其硬件、软件、固件等）均“按照现状”提供，可能存在瑕疵、错误或故障，本公司不提供任何形式的明示或默示保证，包括但不限于适销性、质量满意度、适合特定目的、不侵犯第三方权利等保证；亦不对使用本手册或使用本公司产品导致的任何特殊、附带、偶然或间接的损害进行赔偿，包括但不限于商业利润损失、数据或文档丢失产生的损失。
●若您将产品接入互联网需自担风险，包括但不限于产品可能遭受网络攻击、黑客攻击、病毒感染等，本公司不对因此造成的产品工作异常、信息泄露等问题承担责任，但本公司将及时为您提供产品相关技术支持。
●使用本产品时，请您严格遵循适用的法律。
若本产品被用于侵犯第三方权利或其他不当用途，本公司概不承担任何责任。
●如本手册内容与适用的法律相冲突，则以法律规定为准。
前言本节内容的目的是确保用户通过本手册能够正确使用产品，以避免操作中的危险或财产损失。
在使用此产品之前，请认真阅读产品手册并妥善保存以备日后参考。
概述本手册适用于以下型号的交换机：DS-3E0510P-E/M系列。
H3C S1850 Gigabit WEB Managed Switch Series Product overviewH3C 1850 Switch Series consists of advanced smart-managed fixed-configuration Gigabit switches designed for small businesses in an easy-to-administer solution. By utilizing the latest design in silicon technology, this series is one of the most power efficient in the market.S1850 series has 4 models: three non-PoE models and one PoE+ model. All models are equipped with additional Gigabit SFP ports for fiber connectivity.The series is part of the portfolio of H3C small business networking products. These switches provide a great value, and includes features to satisfy even the most advanced small business networks. All models support rack mounting or desktop operation. Customizable features include basic Layer 2 features like VLANs and link aggregation, as well as advanced features such as Layer 3 static routing, IPv6, ACLs, and Spanning Tree Protocols.S1850-10P S1850-28PS1850-28P-PWRS1850-52PFeatures and benefitsManagementSimple Web managementAllows for easy management of the switch even by nontechnical users through an intuitive Web GUI, supports HTTP and HTTP Secure (HTTPS)Single IP managementEnables management of up to 32 H3C S1850 switches using a single Web interface, simplifies management of multiple devicesSNMPv1, v2c, and v3Facilitates management of the switch, as the device can be discovered and monitored from an SNMP management stationManagement SecurityRestricts access to critical configuration commands; offers multiple privilege levels with password protection;ACLs provide Telnet and SNMP access; local and remote syslog capabilities allow logging of all accessComplete session loggingProvides detailed information for problem identification and resolutionPort mirroringEnables traffic on a port to be simultaneously sent to a network analyzer for monitoringDual flash imagesProvides independent primary and secondary operating system files for backup while upgradingNetwork Time Protocol (NTP)Synchronizes timekeeping among distributed time servers and clients; keeps timekeeping consistent among all clock dependent devices within the network so that the devices can provide diverse applications based on the consistent timeLimited CLIEnables users to quickly deploy and troubleshoot devices in the networkDefault DHCP client modeAllows the switch to be directly connected to a network, enabling plug-and-play operation; in absence of a DHCP server on the network, the switch will fall back to a unique static address determined by the switch's MAC addressFTP, TFTP, and SFTP supportOffers different mechanisms for configuration updates; FTP allows bidirectional transfers over a TCP/IP network; trivial FTP (TFTP) is a simpler method using User Datagram Protocol (UDP); Secure File Transfer Protocol (SFTP) runs over an SSH tunnel to provide additional securityRemote monitoring (RMON)Uses standard SNMP to monitor essential network functions; supports events, alarm, history, and statistics group plus a private alarm extension groupQuality of Service (QoS)Traffic prioritizationProvides time-sensitive packets (like VoIP and video) with priority over other traffic based on DSCP or IEEE 802.1p classification; packets are mapped to eight hardware queues for more effective throughputIEEE 802.1p/QDelivers data to devices based on the priority and type of traffic; supports IEEE 802.1QClass of Service (CoS)Sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), Layer 3 protocol, TCP/UDP port number, source port, and DiffServBroadcast controlAllows limitation of broadcast traffic rate to cut down on unwanted network broadcast trafficAdvanced Classifier based QoSClassifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting priority level and rate limit to selected traffic on a per-port basisRate limitingSets per-port ingress enforced maximums and per-port, per-queue minimumsPowerful QoS featureSupports the following congestion actions: strict priority queuing (SP), weighted round robin (WRR) queuing, and SP+WRRConnectivityIPv6IPv6 hostEnables switches to be managed and deployed at the IPv6 network's edgeIPv6 routingSupports IPv6 static routesMLD snoopingForwards IPv6 multicast traffic to the appropriate interface, preventing traffic floodingIPv6 ACL/QoSSupports ACL and QoS for IPv6 network trafficIEEE 802.3X flow controlProvides a flow throttling mechanism propagated through the network to prevent packet loss at a congested nodeIEEE 802.3at Power over Ethernet (PoE+)Provides up to 30W per port, which allows support of the latest PoE+-capable devices such as IP phones, wireless access points, and security cameras, as well as any IEEE 802.3af-compliant end device; lowers the cost of additional electrical cabling and circuits that would otherwise be necessary in IP phone and WLAN deployments.Cable diagnosticsDetects cable issues remotely using a browser-based toolFlow controlProvides back pressure using standard IEEE 802.3x, reducing congestion in heavy traffic situationsAuto MDI/MDI-XAdjusts automatically for straight-through or crossover cables on all 10/100/1000 portsSecurityAdvanced access control lists (ACLs)Enables network traffic filtering and enhances network control using MAC- and IP-based ACLs; time-based ACLs allow for greater flexibility with managing network accessIEEE 802.1X and RADIUS network loginsControls port-based access for authentication and accountabilitySecure Socket Layer (SSL)Encrypts all HTTP traffic, allowing safe access to the browser-based management GUI in the switchPort IsolationThe port isolation feature isolates Layer 2 traffic for data privacy and security without using VLANs. This feature can also be used to isolate the hosts in a VLAN from one another.Port SecurityCombines and extends IEEE 802.1X and MAC authentication to provide MAC-based network access control ARP attack protectionThe ARP detection feature enables access devices to block ARP packets from unauthorized clients to prevent user spoofing and gateway spoofing attacks.Automatic VLAN assignmentAssigns users automatically to the appropriate VLAN based on their identity, location and time of daySTP BPDU port protectionBlocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacksSTP root guardProtects the root bridge from malicious attacks or configuration mistakesAutomatic denial-of-service protectionMonitors for malicious attacks and protects the network by blocking the attacksManagement passwordProvides security so that only authorized access to the Web browser interface is allowed PerformanceHalf- and full-duplex auto-negotiating capability on every portDoubles the throughput on every portSelectable queue configurationsAllows for increased performance by selecting the number of queues and associated memory buffering that best meet the requirements of the network applicationsIGMP snoopingImproves network performance through multicast filtering, instead of flooding traffic to all portsFiber uplinkProvides greater distance connectivity using Gigabit Ethernet fiber uplinksLayer 2 switchingSpanning Tree Protocol (STP)Supports standard IEEE 802.1D STP, IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) for faster convergence, and IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)BPDU filteringDrops BPDU packets when STP is enabled globally but disabled on a specific portJumbo frame supportSupports up to 10 kilobyte frame size to improve the performance of large data transfersVLAN support and taggingSupports IEEE 802.1Q with 4,094 simultaneous VLAN IDsLayer 3 switchingAddress Resolution Protocol (ARP)Determines the MAC address of another IP host in the same subnet; supports static ARPs; gratuitous ARP allows detection of duplicate IP addresses; proxy ARP allows normal ARP operation between subnets or when subnets are separated by a Layer 2 networkDHCP relaySimplifies management of DHCP addresses in networks with multiple subnetsLayer 3 routingStatic IPv4/IPv6 routingProvides basic routing (supporting up to 32 static routes and 8 virtual VLAN interfaces); allows manual routing configurationResiliency and high availabilityLink aggregationGroups together multiple ports up to a maximum of eight ports per trunk either automatically using LinkAggregation Control Protocol (LACP), or manually, to form an ultra-high-bandwidth connection to the network backbone; help prevent traffic bottlenecks. The 8 port models support 4 trunks, 16 and 24 port models support8 trunks, 48 port models support 16 trunks.ConvergenceLLDP-MED (Media Endpoint Discovery)Defines a standard extension of LLDP that stores values for parameters such as QoS and VLAN toautomatically configure network devices such as IP phonesPoE allocationsSupports multiple methods (automatic, IEEE 802.3af class, LLDP-MED, or user-specified) to allocate PoE power for more efficient energy savingsAuto voice VLANRecognizes IP phones and automatically assigns voice traffic to dedicated VLAN for IP phones Additional informationGreen initiative supportProvides support for RoHS and WEEE regulationsGreen IT and powerImproves energy efficiency through the use of the latest advances in silicon development; shuts off unused ports and utilizes variable-speed fans, reducing energy costsEnergy Efficient EthernetCompliant with IEEE 802.3az standard requirements to save energy during periods of low data activity. SpecificationsHardware SpecificationsD A T A S HE E T11Ordering Information:New H3C Technologies Co., LimitedBeijing base8 GuangShun South Street, Chaoyang District,BeijingZip: 100102Hangzhou base 466 Changhe Road, Binjiang District, Hangzhou, ZhejiangProvince 310052 P.R.ChinaZip: 310052Tel: +86-571-86760000 Fax: +86-571-86760001Copyright ©2018 New H3C Technologies Co., Limited Reserves all rights Disclaimer: Though H3C strives to provide accurate information in this document, we cannot guarantee that details do not contain any technical error or printing error. Therefore, H3C cannot accept responsibility for any inaccuracy in this document. H3C reserves the right for the modification of the contents herein without prior notification。
DS-3D08/3D58F/3D258F/3D248F8路光交换机用户手册杭州海康威视数字技术股份有限公司技术热线：400-700-5998UD.6L0103D0117A01非常感谢您购买我公司的产品，如果您有什么疑问或需要请随时联系我们。
本手册适用于光交换机本手册可能包含技术上不准确的地方、或与产品功能及操作不相符的地方、或印刷错误。
我公司将根据产品功能的增强而更新本手册的内容，并将定期改进或更新本手册中描述的产品或程序。
更新的内容将会在本手册的新版本中加入，恕不另行通知。
0100001030625安全使用注意事项此内容的目的是确保用户正确使用本产品，以避免危险或财产损失。
在使用此产品之前，请认真阅读此说明手册并妥善保存以备日后参考。
如下所示，预防措施分为“警告”和“注意”两部分：警告：无视警告事项，可能会导致死亡或严重伤害。
注意：无视注意事项，可能会导致伤害或财产损失。
警告⏹在本产品安装使用中，必须严格遵守国家和使用地区的各项电气安全规程。
⏹请使用正规厂家提供的电源适配器，供电电源要求为DC12V/1A。
⏹在接线、拆装等操作时请一定要将电源断开，切勿带电操作。
⏹如果设备工作不正常，请联系购买设备的商店或最近的服务中心，不要以任何方式拆卸或修改设备。
（对未经认可的修改或维修所导致的问题，本公司不承担责任）。
⏹光端机的光器件所产生的光源能对人的眼睛产生永久性伤害，切勿用眼睛直视光端机的光器件和通电状态下光端机的光纤接口。
⏹在光端机上插拔光纤时，切断电源。
注意⏹请不要使物体摔落到设备上或大力震动设备，并使设备远离存在磁场干扰的地点。
避免将设备安装到表面震动或容易受到冲击的地方。
（忽视此项可能会损坏设备）⏹请不要在高温（超过75℃）或低温（低于－30℃）或高湿度地点安装设备。
⏹提供良好的通风环境。
⏹请勿在潮湿环境下操作。
⏹请勿在易爆环境中操作。
⏹保持产品表面清洁和干燥。
⏹避免接触裸露电路。
产品加电时，请勿接触裸露的接点和部件。
