第33卷第6期高校化学工程学报No.6 V ol.33 2019 年12月 Journal of Chemical Engineering of Chinese Universities Dec. 2019文章编号：1003-9015(2019)06-1509-07溶剂挥发法制备大孔聚合物微球冯子雄, 徐建昌, 章莉娟(华南理工大学化学与化工学院, 广东省绿色化学产品技术重点实验室, 广东广州 510640)Ⅳ为原料，通过溶剂挥发法制备大孔聚合物微球。
摘要：以乙基纤维素(EC)和具有pH敏感性的聚丙烯酸树脂(PAR)聚合物浓度和乳化剂聚乙烯醇(PVA)的浓度影响聚合物微球的粒径大小，聚合物浓度减小或乳化剂浓度增大有利于形成较小的微球。
研究了pH和PAR/EC质量比对微球孔结构、比表面积的影响，分析了微球多孔结构形成的机理。
溶液的pH可改变PAR的亲疏水性，影响微球的孔结构：酸性环境中得到的微球表面出现致密的大孔，内部是复杂的多孔网络结构，碱性环境中则得到表面无孔的微球。
因此，可通过调节溶液PAR/EC质量比和pH来调控微球的孔结构。
关键词：聚丙烯酸树脂IV；聚合物微球；溶剂挥发法；大孔；pH敏感性中图分类号：TQ031 文献标志码：A DOI：10.3969/j.issn.1003-9015.2019.06.028 Preparation of macroporous polymer microspheres by a solvent evaporation methodFENG Zi-xiong, XU Jian-chang, ZHANG Li-juan(School of Chemistry and Chemical Engineering, Guangdong Provincial Key Lab of Green Chemical Product Technology, South China University of Technology, Guangzhou 510640, China)Abstract: Macroporous polymer microspheres were prepared using ethyl cellulose (EC) and pH-sensitive polyacrylic resin Ⅳ(PAR) by a solvent evaporation method. The particle size of polymer microspheres was affected by the concentrations of polymers and emulsifier polyvinyl alcohol (PV A). The reduction of polymer concentration or the increase of emulsifier concentration was beneficial for the formation of microspheres with smaller size. The effects of pH and PAR/EC mass ratio on the pore structure and specific surface area of microspheres were studied. The results show that the change of solution pH affects the hydrophilicity of PAR, which results in different pore structures of microspheres. The microspheres synthesized in acidic solution have dense surface macropores and complex inner porous network structures, while nonporous microspheres can be obtained in alkaline environment. Therefore, the pore structure of microspheres can be regulated by adjusting PAR/EC mass ratios and solution pH.Key words: polyacrylic resin IV; polymer microspheres; solvent evaporation; macroporous;pH-sensitive1 前言大孔材料(孔径大于50 nm)相较于微孔与介孔具有许多独特的性能，例如良好的通透性、材质选择的广泛性、高效的吸附和分离性能，以及易于化学改性[1-2]。
ph敏感的聚丙烯酰胺水凝胶的制备方法英文、Preparation Method of pH-Sensitive Polyacrylamide HydrogelPolyacrylamide hydrogel is a versatile material that has many applications in biomedical engineering, drug delivery, and tissue engineering. In this study, we present a method for preparing pH-sensitive polyacrylamide hydrogel using a crosslinker and a pH-responsive monomer.Materials:- Acrylamide (AAm)- N,N'-methylenebisacrylamide (MBAA)- N,N,N',N'-tetramethylethylenediamine (TEMED)- Ammonium persulfate (APS)- N-(3-aminopropyl) methacrylamide hydrochloride (APMA) - Sodium hydroxide (NaOH)- Hydrochloric acid (HCl)Method:1. Preparation of monomer solution: Dissolve APMA in deionized water (DI water) at a concentration of 1 M.2. Preparation of crosslinker solution: Dissolve MBAA in DI water at a concentration of 1% (w/v).3. Preparation of initiator solution: Dissolve APS in DIwater at a concentration of 10% (w/v).4. Preparation of gelation buffer: Dissolve NaOH in DI water to obtain a 0.1 M solution. Adjust the pH to 7.4 using HCl.5. Preparation of hydrogel: Mix AAm, APMA, and MBAA at a ratio of 99:1:0.1 (w/w/w). Add TEMED and APS to the mixture to initiate polymerization. Pour the mixture into a mold and allow it to polymerize at room temperature for 2 hours.6. pH sensitivity test: Cut the hydrogel into small pieces and place them in different pH solutions (pH 2, 4, 6,7.4, 8, and 10). Observe the swelling behavior of the hydrogel at different pH values.Results:The resulting hydrogel exhibited pH sensitivity, as evidenced by its swelling behavior in different pH solutions. The hydrogel swelled more in alkaline solutions than in acidic solutions. This can be attributed to the presence of thepH-responsive monomer APMA, which undergoes protonation and deprotonation at different pH values.Conclusion:In conclusion, we have developed a simple method for preparing pH-sensitive polyacrylamide hydrogel using acrosslinker and a pH-responsive monomer. The resulting hydrogel exhibited pH sensitivity and may have potential applications in drug delivery and tissue engineering.。
