机械图纸中常用词汇英语缩写 汇总

ANGLE 角度
NATURE R 自然R
ALL ROUND 周边，全周
NG 粗牙
BOT (BOTT) 底部
NF 细牙
CB 沉头孔
PART NO 料号
CL 中心线
PUNCH 冲头
C+0.02 单边放大0.02间隙PIERCE PUNCH 落料冲头chamfer(C) 倒角
PCS 个，块，件
CA(NCA) 清角（不清角）
Q'TY 数量
CENTER(CEN) 中心，园心REF 参考
DWG NO 图号
REV 版次
DEEP(DEP) 深度
RIGHT 右
EDGE 刀口
SYM 中心对齐
ECN NO 设变号码
SMALL 小端
EWL (newl) 清线头（不清线头）S落料斜度
FINISH 硬度
SCALE 比例
GAP 单边间隙
SECTION A-A 剖视A-A HEIGHT 高度
SHEET 表单，页次HATCHING 阴影线
SURFACE 表面
HEAT TREATMENT 热处理TAP 攻牙
INSERT 入块
TYP 相同，尺寸一致
LARGE 大端
THRU(THR) 贯穿
LEFT 左
TOP 顶部
MM 螺纹的规格
THICK 厚度
MARK 记号标记TAPPER 锥度斜度MATEL 材料材质
TAN 切点
MAX 最大值
TAP1/2NPT 1/2英制管牙MIN 最小值
UNIT 单位
NAME 名称
VIWE A 视图A
NEF 特别攻牙
SECA-A A-A剖视
NRT 新制管牙。
