PHOENIX CONTACT GmbH & Co. KGPage 1 / 3http://www.phoenixcontact.de
Feb 16, 2008Extract from the onlinecatalog HC-D 7-KML-61/M1PG11Order No.: 1773297http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1773297 Coupling housing, with single locking latch, height 61 mm, with screwconnection, 1x Pg11, material zinc Commercial dataEAN4017918122287Pack10 Pcs.Customs tariff76169910Weight/Piece0.09745 KGCatalog page informationPage 423 (PC-2007)Product notesWEEE/RoHS-compliant since:02/17/2006http://www.download.phoenixcontact.comPlease note that the data givenhere has been taken from theonline catalog. For comprehensiveinformation and data, please referto the user documentation. TheGeneral Terms and Conditions ofUse apply to Internet downloads.Technical dataGeneral dataNoteFor contact inserts HC-D7, D8, A3, A4DesignD7Height61 mmWidth26.5 mmLength26.5 mmHousing typeCoupling housingsLocking typeWith single locking latchType of the screw connection1x Pg11元器件交易网www.cecb2b.comHC-D 7-KML-61/M1PG11Order No.: 1773297http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1773297
PHOENIX CONTACT GmbH & Co. KGPage 2 / 3http://www.phoenixcontact.deFeb 16, 2008Pg screw connectionWithWrench size, union nut18 mmExternal cable diameter7.5 mm ... 12.5 mmDegree of protectionIP54 / IP65 with sealing screwAmbient temperature (operation)-40 °C ... 125 °CHousing materialsee aboveHousing surface materialPowder-coated, grayScrew connection materialNickel-plated brassCable seal materialNBRLocking latch materialSteel, galvanizedCertificates / ApprovalsApproval logorequested approbationsCertificationGOSTAccessoriesItemDesignationDescriptionAssembly1686229HC-D 7-DS-IP65Sealing screw, for IP65 protectionDrawingsDimensioned drawing元器件交易网www.cecb2b.comHC-D 7-KML-61/M1PG11Order No.: 1773297http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1773297
PHOENIX CONTACT GmbH & Co. KGPage 3 / 3http://www.phoenixcontact.deFeb 16, 2008AddressPHOENIX CONTACT GmbH & Co. KGFlachsmarktstr. 832825 Blomberg,GermanyPhone +49 5235 3 00Fax +49 5235 3 41200http://www.phoenixcontact.de© 2008 Phoenix ContactTechnical modifications reserved;元器件交易网www.cecb2b.com
