NE55345533/5534分别是双/单路高效低噪音运算放大器。

相比于那些如TL083的放大器而言，它们拥有更好的噪声性能，更高的外部驱动能力以及更加高的小信号输入和更高的功率带宽。

这使得它们特别适合应用于高质量和专业的音频设备以及仪器仪表，控制电路和电话信道功率放大器。

它的内部补偿大于或等于三，其频率响应可以在外部通过补偿电容针对不同的应用需求（单位增益放大器，电容负载性，转换速率，降低自激等等的要求）优化。

如果超低噪声是首要的要求，那么建议仔细阅读5533A/5534A类型的保证噪声特性的说明。

高性能运算放大器结合良好的直流和交流的特点。

一些特点包括很低噪音、高驱动输出能力,高单位增益和最大的输出摆动带宽和高,低失真,转换速率。

这些运算放大器的内部得到补偿等于或大于三个。

频率响应各种的优化使应用程序可以通过使用外部补偿电容器赔偿金之间能够被获得。

这些设备特征有输入保护二极管、输出保护短路,使用剩余和平衡来补偿电压无效的能力。

特性：·小信号的带宽：10MHZ·输出驱动能力：600 Ω，10VRMS at 在VS=±18V·输入噪声：4nV/HZ^2·直流电压增益：100000·交流电压增益：6000在频率为10KHZ·功率带宽：200KHZ·转换速率：每秒13V·大电源电压范围：从±3V到±20V引脚配置NE/SA/SE5534/5534A平衡1 8 平衡/补偿反相输入2 7 V+同相输入 3 6 输出V- 4 5 补偿绝对最大额定参数（额定值）电源电压 ±22V输入电压差分输入电压 ±0.5V功耗8N封装1150Mw10秒可承受的焊接温度300︒C备注：1．二极管起过流保护作用，因此，除非电路中有限流电阻，否则当差分输入超过0.6V时，将有大电流输入。

最大的电流应该控制在 ±10mA以内。
