SQUARE-D Class 9012.9016.9025 Industrial Pressure Switches
- 格式:pdf
- 大小:672.30 KB
- 文档页数:64
Industrial Pressure SwitchesCATALOG CONTENTSDescription . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page Class 9012 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16 Class 9016 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-18 Class 9025 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-20 Type XML, T ype XMLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-60Industrial Pressure SwitchesClass 9012, Type G–Description DESCRIPTIONThe Class 9012 T ype G pressure switches are UL Listed and CSA Certified as industrial control equipment. They are used to interface pneumatic or hydraulic systems with electrical control systems by opening or closing electrical contacts in response to pressure changes in the system. They have outstanding repeatability and drift performance. Their efficient design uses durable, low mass components for excellent performance under heavy duty vibration and shock conditions.The T ype G pressure switches includes diaphragm and piston actuated devices with a variety ofmodifications (see page 14).T ype G diaphragm switches range from 0.2-675 psi falling pressure. Buna-N diaphragms and zinc plated steel flanges are standard. Diaphragms of Viton™ and ethylene propylene are available as well as stainless steel flanges.T ype G piston actuated switches range from 20-9,000 psi falling pressure. They have sealed pistons and can be used on air, water, oil, or any media compatible with the actuator material. Piston actuated switches come standard with stainless steel pistons and housings, VITON® diaphragms and o-ring seals, and T eflon® retaining rings. Ethylene propylene diaphragms and o-ring seals are also available.Features for both diaphragm and piston actuated pressure switches include:•High shock resistance•Dual numerical range scale (psi and kPa)•High set point stability•SPDT or DPDT double break contacts•Adjustable or nonadjustable differential•Internal or external range adjustment•No drain line required•Single stage operation•Dual stage operation•Differential pressure operationT ype G industrial switches are available as open type or in NEMA Type 1 enclosures. The backplate is steel with a plastic cover. Open type devices in pressure ranges up to 250 psi are available with internal or external threaded pressure connectors making them ideally suited for panel mounting.T ype G machine tool switches have NEMA Type 4, 4X, or 13 (IEC IP66) cast aluminum enclosures. These devices are UL Listed and CSA Certified as industrial control equipment. They are UL Listed for use in Class II, Division 2, Group G and Class III hazardous locations. They are also UL Marine Listed for use on vessels greater than 65 feet long where ignition protection is not required.T ype G machine tool switches are also available in NEMA T ype 7 & 9 cast iron enclosures. These are UL Listed for use in Class I, Divisions 1 and 2, Groups C and D, and Class II, Divisions 1 and 2, Groups E, F, G hazardous locations.Industrial Pressure SwitchesClass 9012, Type G–Application and General InformationAPPLICATION AND GENERAL INFORMATIONPressure switches are used in a wide variety of applications such as:•compressors•HVAC equipment•chillers•pumping systems•machine tools•stamping presses•automatic grinders•welders•process equipment•molding machinesGenerally, Class 9012 pressure switches can be used in any application where electrical contacts mustopen or close in response to a system pressure change, within the electrical and pressure ratings of theswitch.T wo typical functions of a pressure switch are to:•Monitor the pressure in the system. The switch can be used as either an interlock that will sequence operations in an automatic system, or to give an audio or visual signal, typically an alarm of anundesired condition, at predetermined pressures.•Control the pressure in the system by starting and stopping a pump or a compressor atpredetermined pressures.Normally a switch with a nonadjustable differential is used in applications that monitor the pressure. Anadjustable differential switch is usually necessary in applications that require the switch to control thepressure.Bellows vs. DiaphragmThe three factors that affect bellows life are the compatibility of the pressure medium with the bellowsand bellows housing material, the amount of pressure change during each operating cycle, and thespeed of operation.On wide pressure change applications, the bellows is flexed over a wide portion of the range on eachoperating cycle causing the metal to fatigue faster than if it flexes over a small portion such as betweenthe operating points only. This will reduce life. The T ype G is offered with either diaphragm or pistonactuators only — for maximum versatility, speed of operation, and life.Diaphragm life, like bellows life, is affected by pressure medium compatibility. Standard diaphragms onClass 9012 T ype G devices are nitrile (Buna-N) in zinc plated steel flanges. Fluorocarbon (VITON®) andethylene propylene diaphragms as well as Type 316 stainless steel flanges are also available.The elastomer diaphragms used on Class 9012 switches are capable of withstanding high speed cyclingand wide pressure changes. Operating speeds up to 200 cycles per minute are not detrimental to thelife of the diaphragm.Surges which exceed the maximum range value may occasionally occur, especially on start-up of themachine (see section on surges). The switch will withstand these occasional surges if they are withinthe maximum allowable pressure rating of the switch. However, frequently applying this higher pressurewill greatly reduce the life of the switch.Although the diaphragm will withstand wide pressure changes on each operating cycle, the pressureapplied to the diaphragm during the normal operating cycle should never exceed the maximum valuelisted in the “Range” column in the catalog listing. Life will be considerably reduced if regularly cycledabove this pressure. If significant surges are common or if pressures are higher than listed in the“Range” column, consider the use of a piston device.Industrial Pressure SwitchesClass 9012, Type G–Application and General Information SurgesOne of the most destructive elements to a pressure switch is the hydraulic surge. A surge is a high rate of rise in pressure, normally of short duration, caused by starting a pump or opening and closing a valve. Extremely high rates of rise in pressure can be damaging even though they are within the limits of the maximum allowable pressure.T o limit the effect of surges, the switch should be mounted as close to an accumulator and as far from the pump or quick acting valve as possible. Type G piston actuated switches are supplied with a 0.020" pressure orifice to help reduce the effects of minor surges. T ype G diaphragm actuated switches are supplied with a 0.060" pressure orifice. A restrictor with a small orifice placed in the line between the switch and pump or valve will further help to protect the switch. Using a surge snubber such as the Class 9049 T ypes A26 or A26S will also protect the switch.VibrationAmong other things, excessive vibration can cause contact bounce, chatter or premature contact transfer especially when system pressure is near the operating point of the switch. Remote mounting of the switch is the best way to avoid problems.Use On SteamSwitches should not be applied directly on steam exceeding 15 psig. However, with the installation of a Class 9049 T ype A7A steam capillary tubing kit between the pressure connection and the switch, steam pressure up to 250 psig may be applied provided this does not exceed the maximum allowable pressure rating of the switch or the maximum temperature rating at the actuator.Piston vs. DiaphragmSelecting between piston and diaphragm devices depends on several criteria: 1) maximum allowable pressure, 2) range and differential, 3) surges and 4) media, whether hydraulic or pneumatic.Maximum allowable pressures for piston devices are much higher than for diaphragm devices. Most diaphragm devices have a maximum allowable pressure of 850 psi or less, where all piston devices have a maximum allowable pressure of 10,000 psi or more.Range and differential for diaphragm devices are lower than for piston devices. Many applications call for a low differential, ie: 20 psi, which may exclude piston devices which have a minimum differential of 60 psi or more.Surges are a part of every hydraulic system, and while many are small and have only a small effect on the switch, some are significant and can potentially destroy a pressure switch. Diaphragm devices are the most sensitive to surges and will be damaged most easily. Piston devices are more tolerant of surges and will last longer in the same application.Hydraulic systems, which typically use oil based media, are more demanding on a system because they are usually at higher pressures, have wider pressure variations and produce more surges since the media does not compress. Pneumatic systems, which are typically air, are less demanding on a system since they are usually at lower pressures and the medium can compress itself to cushion the effects of surges.As a guide, follow these basic steps:High maximum allowable pressures:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . piston Lower maximum allowable pressures: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . diaphragm Low differentials or pressures:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . diaphragm High pressures: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . piston Minimal surges: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . diaphragm or piston Constant surges: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . piston Hydraulic systems:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . piston Pneumatic systems: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . diaphragmIndustrial Pressure SwitchesClass 9012, Type G–Application and General InformationPiston LifeFor long piston life, the pressure medium should be filtered to keep foreign matter such as dirt and chips out of the piston assembly. Type G sealed piston devices are not recommended for use on dry gas media since there could be some leakage past the seal. The amount of leakage will depend on the gas, media pressure and rate of operation. It is possible the switch would be inoperative. Dual Stage Pressure SwitchesThe T ype G is available with dual stage switches and provide two distinct levels of control from one device. These switches are most commonly used where dual functions are required or in sequencing applications such as alarm-shutdowns. Differential Pressure SwitchesThe T ype G is also available as a differential switch. These devices are used to monitor the change in the difference between two pressures. They are unidirectional devices and used in applications to signal that a predetermined pressure difference has been reached as a result of a widening or increasing difference between the pressures. They can also be used in applications to signal that a predetermined difference has been reached as a result of a narrowing or decreasing pressure difference between the two pressures. SummaryWhile a pressure switch may perform satisfactorily in one application, it may prove to be unsatisfactory in a different application. Therefore, the deciding factor in the selection of a pressure switch should be based on the requirements of the application being considered.When specifying a pressure switch, note the following:•T o ensure repeatability and minimize setting drift, pressure settings should fall within the middle 80% of the pressure range. When the pressure settings approach 10% of the minimum or maximum end of the pressure range, select a switch with a lower or higher pressure range, respectively.•When switches are required to be factory set and only one setting is identified, specify whether this setting is on increasing or decreasing pressure.•The pressure applied to a diaphragm actuated switch during a normal cycle should never exceed the maximum range value listed for the switch. The life of the switch will be reduced if the switch is regularly cycled above the maximum range value.•Ensure the switch is rated to withstand any pressure surges that may occur at the switch location in the system. Any anticipated pressure surges should be less than the maximum allowable pressure listed for the switch.•Ensure the wetted parts of the switch are compatible with the system fluid.•If system response time is critical, select a switch with a volumetric displacement that is compatible with the overall system. See table 1. Table 1:Volumetric Displacement of Class 9012 Type Pressure SwitchesClass 9012 TypeVolumetric Displacement (1)(in 3 )Volumetric Displacement (1)(cm 3 )GAR, GAW, GDR, GDW-1& 210.20774 3.40422GAR, GAW, GDR, GDW-2 & 220.07040 1.15385GAR, GAW, GDR, GDW-4 & 240.043200.70805GAR, GAW, GDR, GDW-5 & 250.021440.35140GAR, GAW, GDR, GDW-6 & 260.013760.22553GBR, GBW, GER, GEW-1 & 210.002000.13112GBR, GBW, GER, GEW-2 & 220.005120.08392GCR, GCW, GFR, GFW-1 & 210.003200.05245GCR, GCW, GFR, GFW-2 & 220.001170.01922GCR, GCW, GFR, GFW-3 & 230.000600.00924GCR, GCW, GFR, GFW-4 & 240.000370.00612(1)Figures shown are total displacement. When switch is operated between settings only, displacement will be 1/3 of values shown.Industrial Pressure SwitchesClass 9012, Type G–Technical Overview TECHNICAL OVERVIEWOperating Points (Settings)Every pressure switch has two operating points; one on rising pressure and one of falling pressure. The operating point on rising pressure is referred to as the TRIP POINT and the operating point on falling pressure is referred to as the RESET POINT. These operating points are called the SETTINGS of the switch.—TRIP POINT (rising pressure)—RESET POINT (falling pressure)DifferentialThe differential is the difference in pressure between the trip point and the reset point. It can be adjustable or nonadjustable (fixed).RangeThe range is the pressure limits within which the operating points (settings) can be adjusted. The range of the Class 9012 pressure switch is referenced to the operating point on falling pressure (reset point). The differential adds to the reset point setting and determines the operating point on rising pressure (trip point).T o determine the operating range on rising pressure for a nonadjustable (fixed) differential type switch, the differential is added to both the low end of the range and the high end of the range.For example, to determine the range on rising pressure for a Class 9012 Type GDW5:1.Range on falling pressure = 3 to 150 psi2.Nonadjustable differential = 6.0 ± 0.8 psi3.Range on rising pressure = 9 ± 0.8 to 156 ± 0.8 psiIndustrial Pressure SwitchesClass 9012, Type G–Technical OverviewFor adjustable differential type switches, add the minimum differential to the low end of the range andthe maximum differential to the high end of the range.For example, to determine the range on rising pressure for a Class 9012 T ype GAW5:1.Range on falling pressure = 3 to 150 psi2.Adjustable differential = 6.0 to 30 psi3.Range on rising pressure = 9 to 180During the normal operating cycle, system pressure should never exceed the upper limit of the rangewhen using a diaphragm actuated switch. This will greatly reduce the life of the diaphragm.Maximum Allowable PressureMaximum allowable pressure is the pressure to which a switch can be subjected without causing achange in operating characteristics, shift in settings, or damage to the device.Pressure surges may occur in a system during the start up of a machine or from valve operation. Surgesare not normally detrimental to the life of a switch if the surge is within the maximum allowable pressurerating of the switch. Diaphragm actuated switches should not be subjected to more than 10 surges perday. More frequent surges will greatly reduce the life of the diaphragm.Industrial Pressure SwitchesClass 9012, Type G–SpecificationsSPECIFICATIONSContact ArrangementSnap switch contains two (2) double break contact elements (1 N.O. – and 1 N.C.) that must be used on circuits of same polarity.contains two double break contact elements (1 N.O. and 1 N.C.) that must be used on circuits of same polarity.electrically separate and can not be used on opposite polarities.Circuit Ratingsa 600 volt DC rating does not apply.Acceptable Wire Sizes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .#12-22 AWG Recommended T erminal Clamp Torque. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 in-lbs Temperature RatingsType G Machine Tool, Temperature & Vacuum (except GVG)Type G IndustrialContactsAC – 50 or 60 Hz DCAC or DCVoltsInductive35% Power FactorResistive 75% Power Factor VoltsInductive and ResistiveContinuous Carrying AmperesMake BreakMake and Break AmperesMake and BreakAmperes Amps.VAAmps.VASingle ThrowDouble ThrowSPDT120607200672061250.550.2210240307200372032500.270.1110480157200 1.5720 1.5600 a 0.10. . . .10600127200 1.2720 1.2. . . .. . . .. . . .. . . .DPDT120607200672061250.220.2210240307200372032500.110.1110480157200 1.5720 1.5600. . . .. . . .106001272001.27201.2. . . .. . . .. . . .. . . .ActuatorMinimumMaximumAmbient All -23 ° C (-10 ˚F)+85 ° C (+185 ° F)MediaDiaphragm -40 ° C (-40 ˚F)+120 ° C (+250 ° F)Piston-26 ° C (-15 ˚F) All with Forms Q4 and Q14-26 °C (-15 ˚F)Industrial Pressure SwitchesClass 9012, Type G–DimensionsDIMENSIONSTypes GNG, GPG, GQG, GRG, GSG, and GTG Industrial Pressure SwitchesTypes GAW, GBW, GCW, GDW, GEW, GFW, GKW, GLW, and GMW Machine Tool SwitchesTypeA Dimension, in(mm)GNG, GRG - 3, 4, 5, 6 1.41 (36)GPG, GSG - 1, 2, 3 1.31 (33)GQG, GTG - 1, 2, 3, 42.24 (57)TypeA Dimension, in(mm)GAW, GDW, GKW - 2, 4, 5, 622, 24, 25, 26 2.33 (59)GBW, GEW, GLW -1, 2, 212.23 (57)GCW, GFW, GMW - 1, 2, 3, 421, 22, 23, 243.15 (80)Industrial Pressure SwitchesClass 9012, Type G–Selection and ModificationsSELECTION & MODIFICATIONSType G Machine Tool SwitchesClass 9012 single stage pressure switches are control circuit rated devices. These switches are used in pneumatic or hydraulic systems on a wide variety of machine and process applications to protect the equipment. They either control or monitor the system pressure. h For metric threads, add M after the W on all types.c UL Marine Listed for use on ships/vessels greater than 65 feet long where ignition protection is not required. Also UL Listed for use in Class II , Division 2, Group G and Class III hazardous locations.a UL Marine Listed for use on vessels greater than 65 feet long where ignition protection is required. q Differential adds to range setting and determines operating point on rising pressure.NOTE: When switches are required to be factory set and only one setting is identified, specify whether this setting is on increasing or decreasing pressure.Nonadjustable Differential hNEMA Type 4, 4X, 13 EnclosureUL Listed And CSA Certified As Industrial Control EquipmentcRange On DecreasingPressure PSIGq Approximate Differential AtMid Range — PSIG Maximum Allowable Pressure PSIGSingle Pole Double ThrowDouble Pole Double ThrowTypeTypeDiaphragm Actuated – Nitrile (Buna-N) Diaphragm, Zinc Plated Steel Housing.2-10.6 ± .1100GDW1GDW211-40 1.6 ± .4100GDW2GDW221.5-75 3.0 ± .5240GDW4GDW243-150 6.0 ± .8475GDW5GDW255-25010.0 ± 1.5750GDW6GDW2613-42516 ± 3.5850GEW1GEW2120-67527 ± 52000GEW2GEW22Piston Actuated – #440 Stainless Steel Piston.#303 Stainless Steel Housing, Fluorocarbon (VITON ® ) Diaphragm and O-ring, TEFLON ® Retaining Ring20-100059 ± 910000GFW1GFW2190-2900170 ± 1515000GFW2GFW22170-5600289 ± 5520000GFW3GFW23270-9000495 ± 7025000GFW4GFW24Nonadjustable DifferentialNEMA Type 7 & 9 EnclosureClass I & II , Division 1 & 2, Groups C, D, E, F, G UL Listed As Industrial Control Equipment aRange On DecreasingPressure PSIGq Approximate Differential AtMid Range - PSIG Maximum Allowable Pressure PSIGSingle Pole Double ThrowDouble Pole Double ThrowTypeTypeDiaphragm Actuated – Nitrile (Buna-N) Diaphragm, Zinc Plated Steel Housing.2 - 10 1.0 ± .1100GDR1GDR211 - 40 2.4 ± .8100GDR2GDR221.5 - 75 4.5 ± 1240GDR4GDR243 - 1509 ± 1.5475GDR5GDR255 - 25015 ± 3750GDR6GDR2613 - 42525 ± 7850GER1GER2120 - 67541 ± 102000GER2GER22Piston Actuated – #440 Stainless Steel Piston.#303 Stainless Steel Housing, Fluorocarbon (VITON ® ) Diaphragm and O-ring, TEFLON ® Retaining Ring20-100089 ± 1810000GFR1GFR2190-2900255 ± 3015000GFR2GFR22170-5600578 ± 11020000GFR3GFR23270-9000788 ± 14025000GFR4GFR24MarkingComplies with IEC 957.5.1, 5C8.3.4 when protected with a Bussman Class CC KTK-R-10 fuse.Industrial Pressure SwitchesClass 9012, Type G–Selection and Modificationsh For metric threads, add M after the W on all types.cUL Marine Listed for use on ships/vessels greater than 65 feet long where ignition protection is not required. Also UL Listed for usein ClassII, Division 2, Group G and ClassIIIhazardous locations.aUL Marine Listed for use on vessels greater than 65 feet long where ignition protection is required.q Differential adds to range setting and determines operating point on rising pressure.NOTE: When switches are required to be factory set and only one setting is identified, specify whether this setting is on increasing or decreasing pressure.Adjustable Differential hNEMA Type 4, 4X, 13 EnclosureUL Listed And CSA Certified As Industrial Control Equipment cRange On DecreasingPressure PSIGq Adjustable Differential Approximate at Mid Range Maximum Allowable Pressure PSIGSingle Pole Double ThrowDouble Pole Double ThrowTypeTypeDiaphragm Actuated - Nitrile (Buna-N) Diaphragm, Zinc Plated Steel Housing.2 - 10.6 - 2100GAW1GAW211 - 40 1.6 - 8100GAW2GAW221.5 - 75 3.5 - 15240GAW4GAW243 - 150 6.0 - 30475GAW5GAW255 - 25010.0 - 49750GAW6GAW2613 - 42516 - 90850GBW1GBW2120 - 67527 - 1302000GBW2GBW22Piston Actuated – #440 Stainless Steel Piston.#303 Stainless Steel Housing, Fluorocarbon (VITON ®) Diaphragm and O-ring, TEFLON ® Retaining Ring20 - 100059 - 20010000GCW1GCW2190 - 2900170 - 56015000GCW2GCW22170 - 5600289 - 126020000GCW3GCW23270 - 9000495 - 190025000GCW4GCW24Adjustable DifferentialNEMA Type 7 & 9 EnclosureClass I & II , Division 1 & 2, Groups C, D, E, F, G UL Listed As Industrial Control Equipment aRange On DecreasingPressure PSIGq Adjustable Differential Approximate at Mid Range Maximum Allowable Pressure PSIGSingle Pole Double ThrowDouble Pole Double ThrowTypeTypeDiaphragm Actuated – Nitrile (Buna-N) Diaphragm, Zinc Plated Steel Housing.2 - 10 1.0 - 2100GAR1GAR211 - 40 2.4 - 8100GAR2GAR221.5 - 75 4.5 - 15240GAR4GAR243 - 1509 - 35475GAR5GAR255 - 25015 - 49750GAR6GAR2613 - 42525 - 90850GBR1GBR2120 - 67541 - 1302000GBR2GBR22Piston Actuated – #440 Stainless Steel Piston.#303 Stainless Steel Housing, Fluorocarbon (VITON ®) Diaphragm and O-ring, TEFLON ® Retaining Ring20 -100089 - 20010000GCR1GCR2190 - 2900255 - 56015000GCR2GCR22170 - 5600578 - 126020000GCR3GCR23270 - 9000788 - 190025000GCR4GCR24Industrial Pressure SwitchesClass 9012, Type G–Selection and ModificationsDifferential Pressure SwitchDifferential pressure switches are used to monitor the change in the difference between two pressures. T ype G differential pressure switches are unidirectional devices and are used in applications to signal that a predetermined pressure difference has been reached as a result of a widening or increasing difference between the two pressures. They can also be used in applications to signal that a predetermined pressure difference has been reached as a result of a narrowing or decreasing difference between the two pressures.c UL Listed for use in Class II , Division 2, Group G and Class III hazardous locations. Also, UL Marine Listed for use on vesselsgreater than 65 feet long where ignition protection is not required.Dual Stage Pressure SwitchClass 9012 T ype G dual stage pressure switches are designed for use in applications where twoseparate pressure operations must be controlled by a single pressure monitoring device. These controls are most commonly used where dual functions are required or in sequencing applications such as alarm shutdowns.c UL Listed for use in Class II, Division 2, Group G and Class III hazardous locations. Also UL Marine Listed for use on vesselsgreater than 65 feet long where ignition protection is not required.NEMA Type 4, 4X, 13 EnclosuresUL Listed And CSA Certified As Industrial Control Equipment cWorking PressureRange on DecreasingX (upper) ActuatorAdjustable Difference on Decreasing Pressure (adds to working pressure) Y (lower) ActuatorAdjustable DifferentialActuates on IncreasingPressure (adds toadjustable difference)Maximum Allowable PressureSingle Pole Double Throw Double Pole Double ThrowTypeTypeDiaphragm Actuated – Nitrile (Buna-N) Diaphragm, Zinc Plated Steel Housing0 - 75.25 - 10.8 - 2100GGW1GGW210 - 175.5 - 36 5 - 15240GGW4GGW240 - 5003 - 17522 - 90850GHW1GHW21Piston Actuated – #440 Stainless Steel Piston.#303 Stainless Steel Housing, Fluorocarbon (VITON ®) Diaphragm and O-ring, TEFLON ® Retaining Ring 0 - 500015 - 82580-2007500GJW1GJW21Dual Stage Pressure Switch NEMA Type 4, 4X, 13 EnclosureUL Listed And CSA Certified As Industrial Control Equipment cRange Setting Limits of Pressure Between Which Stage 1 can be Adjusted to Operate on Decreasing Pressure Adjustable Spread Adds toRange Setting to ObtainDecreasing Operating Pointof Stage 2Fixed Differential — Add to Low(decreasing) Operating Point to Obtain Approximate High (rising) Operating Point of Each Stage MaximumAllowablePressureSPDTeach Stage Stage 1Stage 2TypeDiaphragm Actuated – Nitrile (Buna-N) Diaphragm, Zinc Plated Steel Housing.2 - 10 1 - 5 1.0 ± 0.2 1.5 ± 0.4100GKW11 - 40 4 - 20 4.0 ± 1.0 6.0 ± 1.5100GKW21.5 - 75 6 - 30 5.0 ± 1.58.0 ± 2.0240GKW43 - 15012 - 758.0 ± 2.012 ± 3475GKW55 - 25022 - 11014 ± 321 ± 5750GKW613 - 42540 - 18020 ± 430 ± 7.5850GLW120 - 67545 - 25030 ± 645 ± 112000GLW2Piston Actuated – #440 Stainless Steel Piston.#303 Stainless Steel Housing, Fluorocarbon (VITON ®) Diaphragm and O-ring, TEFLON ® Retaining Ring20 - 100050 - 30050 ± 1075 ± 1910000GMW190 - 2900140 - 800140 ± 30210 ± 5215000GMW2170 - 5600300 - 1700275 ± 60400 ± 10020000GMW3270 - 9000500 - 2500400 ± 80800 ± 15025000GMW4。
