AL-7480B升级版用户指南

AL-2010S操作说明1.1 第一步点击“获取序列号”文件进入以下界面点击“获取”就会生成的一组数字，请将该组数字回馈给我公司，将会给一个软件启动的序列号。

1.2第二步点击“” ，出现以下界面输入序列号就可以进入软件。

（第一次使用时才需要）1.3 第三步点击“” ，运行程序该程序。

进入以下界面：输入系统管理员初始名称：ADMIN系统管理员初始密码：ADMIN初始安装的系统中拥有系统管理员用户，具有所有权限，其他用户的增加及权限设置有系统管理员管理注意：第一次进入后应更改此口令。

2.1 软件用户界面用户界面主要包括主显示界面、系统菜单、工具栏。

主显示界面主要显示报警板，用户/防区地图，用户防区资料，报警历史记录等数据，但这些内容不能同时显示。

弹出式窗口主要显示报警处理界面，主机参数设置，系统参数设置等内容，允许同时弹出多个窗口，这些窗口覆盖主显示界面。

AL-2010S所有功能全部在系统菜单中有相应选项，常用功能在工具栏中列出。

2.2 基本操作AL-2010S所有功能可以通过系统菜单实现，系统菜单如下：3.1 进入参数设置进入主菜单“配置中心”—“参数设置”，对用户本身的基本信息和其他系统参数进行设置。

参数设置主界面3.2 通过串口或TCP/IP连接的中心设备3.2.1修改中心设备编号进入“参数设置”—“全局配置”串口连接:修改中心设备编号为“1-10”，“1-10”号中心设备可通过串口连接多台报警主机和通讯机（AL-7480B、AL-3280等报警主机系列）；1-10分别代表的电脑上的每个串口。

TCP/IP连接:修改中心设备编号为“11”，“11”号中心设备可通过网络连接多台报警主机和通讯机注：1、在首次设置时出现“Warning”提示，可直接确定2、在已经设置好相应中心设备下的相关参数后，修改该编号，将会删除原来该中心设备下的所有信息。

3.2.2 通讯参数设置进入以下界面：此UDP端口（也就是本机端口）必须与网络（TCP/IP）主机的UDP端口一致。
