设备布置及管道布置中英文对照修订版

●弯头 elbow异径弯头 reducing elbow带支座弯头base elbow长半径弯头(标准1。

5倍弯曲半径—--1.5D）long radius elbow●三通 tee异径三通 reducing tee等径三通 straighttee带侧向口的三通（右向或左向) side outlet tee（right hand or 1eft hand)异径三通（分支口为异径） reducing tee (reducing on outlet）异径三通(一个直通口为异径)reducing tee (reducing on one run）带支座三通 base tee异径三通（一个直通口及分支口为异径） reducing tee (reducing on one run and outlet）异径三通（两个直通口为异径，双头式）reducing tee （reducing on both runs， bullhead）45°斜三通 45° lateral45°斜三通(支管为异径） 45° lateral （reducing on branch)45°斜三通（一个直通口为异径） 45° lateral（reducing on one run)45°斜三通(一个直通口及支管为异径） 45° lateral（reducing on one run and branch）Y型三通（俗称裤衩）true “Y”四通 cross等径四通straight cross异径四通 reducing cross异径四通(一个分支口为异径）reducing cross （reducing onone outlet)异径四通(一个直通口及分支口为异径）reducing cross （reducing on one run andoutlet）异径四通(两个分支口为异径) reducing cross （reducing on both outlet)异径四通(一个直通口及两个分支口为异径） reducing cross （reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentricreducer锻制异径管 reducing swage螺纹支管台threadolet焊接支管台weldolet承插支管台sockolet 弯头支管台elbolet斜接支管台latrolet镶入式支管嘴sweepolet短管支管台nipolet支管台，插入式支管台boss●螺纹支管台Threadolet●弯头支管台elbolet●焊接支管台weldolet；on weld●短管支管台nipolet●承插支管台sockolet●烧焊支管台weldolet●斜接支管台latrolet●承插焊支管台Sockolet●支管台，插入式支管台boss管接头 coupling， fullcoupling半管接头 half coupling异径管接头reducing coupling活接头 union内外螺纹缩接（俗称补芯） bushing管帽 cap （C）堵头 plug短节nipple异径短节 reducing nipple； swage nipple 管道英文缩写A Anchor 固定ABS ＊Absolute 绝对的AISI ＊American Iron andSteelInstitute 美国钢铁学会ANSI ＊American National Standards Institute 美国国家标准学会API ＊American Petroleum Institute 美国石油学会APPROX *Approximate 大约，近似的ASB Asbestos 石棉ASME ＊American Society Of Mechanical Engineers美国机械工程师协会ASSY ＊Assembly 装配，组装ASTM ＊American Society Of Testing Material 美国材料实验协会ATM ＊Atmosphere 大气压AWG ＊American Wire Gage 美国线规AWS *American Wel*＊** Society 美国焊接协会AWWA ＊American Water WorksAssociation 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B-B Beveled End-Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆B。

管道工程施工质量管理工作细则PIPING CONSTRUCTION QUALITY MANAGEMENT DETAIL RULES目录Content1.0 编制目的及适用范围Purpose for Preparation and Scope of Application2.0 编制原则Principles for Preparation3.0执行标准及有关规定Applicable Standards and Relevant Regulations3.1 中国政府的相关法规和政策Relevant laws, regulations and policies issued by Chinese government: 3.2 SECCO项目IPMT质量体系有关文件Documentation related to IPMT quality system of SECCO project: 3.3 SECCO项目IPMT规定和要求IPMT regulations and requirements of SECCO project:3.4 施工验收标准及规范Standards and codes for construction acceptance:4.0 冲突和协调Conflict and Coordination5.0 专业技术经理与专业工程师Specialist Technical Manager and Specialist Engineer5.1专业技术经理Specialist technical manager5.2 专业工程师Specialist engineer6.0 HSE7.0 施工过程中工程施工质量的控制Quality Control in the Process of Construction7.1 主要依据Main basis7.2 熟悉现场管理体系、建立工作接口Acquaintance with site management system and establishment ofworking interface7.3 技术准备Technical Preparations7.4 组织设计交底Organization Design Briefing7.5 图纸与设计文件会审Joint Check-up of Drawings and Design Documents7.6 审查施工组织设计和施工方案Check-up of Construction Organization Design and Construction Plan 7.7 施工过程的质量控制点的制定和检查程序Procedures for the Establishment and Inspection of Quality ControlPoints in the Construction Process7.8 施工过程中的质量控制Quality Control During the Construction Process7.8.1 原材料的检查与验收原则Principles for the Inspection and Verification of Raw Materials7.8.2 管子抽检的内容和比例Contents and Percentage of Pipe Spot-check7.8.3 其他管道组成件抽检的内容和比例Spot-check Contents and Percentage of Other Pipe Components7.8.4 阀门的检验与试验（包括管道视镜、过滤器及阻火器检验）Valve Inspection and Experiment (Including the inspection of pipe signtglass, strainer and flame arrestor)7.8.5 采用的主要管道器材标准（规范）Major Piping Specifications Standards (or codes)7.8.5.1 材料标准Material Standards7.8.5.1.1 无缝钢管Seamless Steel Pipe7.8.5.1.2 焊接钢管Welded Steel Pipe7.8.5.1.3 管件Pipe fittings7.8.5.1.4 联接件Pipe joints7.8.5.1.5 阀门Valves7.8.5.2 应用规范Application specification7.8.5.2.1 管子Pipe7.8.5.2.2 管件Pipe fittings7.8.5.2.3 联接件Pipe joints7.8.5.2.4 阀门Valves7.8.6 管道防腐Pipingcorrosion prevention7.8.7 管道的预制加工工艺Pre-fabrication process for pipe7.8.8 碳素钢管道焊接、热处理及质量检查Welding, heat treatment and quality inspection for carbon steel pipe 7.8.9 阀门安装Valve installation7.8.10 低温材料检验及安装Cryogenic material inspection and installation7.8.11 静电接地安装Static grounding erection7.8.12 管道系统试验、吹除与清洗Test, purging and cleaning for piping system7.8.13 工程中间交接Engineering intermediate takeover7.8.14 竣工验收Completion acceptance7.9 专业工程师应保存的资料Documents to be retained by specialist engineer附录1: 管道安装工程质量控制点Appendix 1 Quality Control Points for Piping Installation Project附录2：工业管道施工管理台帐Appendix 2 I ndustrial Piping Construction Management Record Book1.0编制目的及适用范围：Purpose for Preparation and Scope of Application1.1 本规定适用于上海SECCO 90x104t/a乙烯项目（以下简称SECCO项目）的现场施工质量管理工作。

●1。

2 管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头（右向或左向) side outlet elbow （right hand or left hand)双支管弯头(形） double branchelbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通（右向或左向） side outlet tee (right hand or 1eft hand)异径三通(分支口为异径)reducing tee （reducing on outlet)异径三通（一个直通口为异径）reducing tee （reducing on one run)带支座三通 base tee异径三通（一个直通口及分支口为异径） reducing tee (reducing on one run and outlet）异径三通（两个直通口为异径，双头式） reducing tee (reducing on both runs, bull head)45°斜三通 45° lateral45°斜三通（支管为异径） 45° lateral （reducing on branch)45°斜三通（一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral （reducing on one run andbranch)Y型三通（俗称裤衩）true “Y”四通 cross等径四通 straight cross异径四通reducing cross异径四通（一个分支口为异径）reducing cross (reducing on one outlet)异径四通(一个直通口及分支口为异径) reducing cross （reducing on one run and outlet）异径四通（两个分支口为异径） reducing cross （reducing on both outlet）异径四通（一个直通口及两个分支口为异径） reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管reducing swage螺纹支管台 threadolet焊接支管台weldolet承插支管台sockolet弯头支管台 elbolet斜接支管台latrolet镶入式支管嘴sweepolet短管支管台 nipolet支管台，插入式支管台 boss●螺纹支管台Threadolet●弯头支管台elbolet●焊接支管台weldolet；on weld●短管支管台nipolet●承插支管台sockolet●烧焊支管台weldolet●斜接支管台latrolet●承插焊支管台Sockolet●支管台，插入式支管台boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头union内外螺纹缩接(俗称补芯） bushing管帽 cap （C)堵头 plug短节 nipple异径短节 reducing nipple； swage nipple管道英文缩写A Anchor 固定ABS *Absolute 绝对的AISI ＊American Iron andSteelInstitute 美国钢铁学会ANSI ＊American National Standards Institute 美国国家标准学会API *American Petroleum Institute 美国石油学会APPROX *Approximate 大约，近似的ASB Asbestos 石棉ASME ＊American Society Of Mechanical Engineers美国机械工程师协会ASSY *Assembly 装配，组装ASTM ＊American Society Of Testing Material 美国材料实验协会ATM *Atmosphere 大气压AWG *American Wire Gage 美国线规AWS *American Wel＊＊＊＊ Society 美国焊接协会AWWA *American Water WorksAssociation 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B-B Beveled End—Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆B.C Bolted Cover(cap）螺栓连接的阀兰盖（帽）BE Beveled End (for wel*＊＊＊) 坡口(焊接用）B。

工艺管道施工各专业名词缩写中英文对照表P 管子PipeEL 弯头ElbowELL 长半径弯头Long radius elbowELS 短半径弯头Short radius elbowMEL 斜接弯头（虾米腰弯头）Mitre elbowREL 异径弯头Reducing elbowT 三通TeeLT 斜三通Lateral teeRT 异径三通Reducing teeR 异径管接头（大小头）ReducerCR 同心异径管接头（同心大小头）Concentric reducerER 偏心异径管接头（偏心大小头）Eccentric reducerCPL 管箍CouplingFCPL 双头管箍Full couplingHCPL 单头管箍Half couplingRCPL 异径管箍Reducing couplingBU 内外螺纹接头BushingUN 活接头UnionHC 软管接头Hose couplerSE 翻边短节Stub endNIP 短节Pipe nipple or straight nippleSNIP 异径短节Swaged nippleCP 管帽（封头）CapPL 管堵（丝堵）PlugBLK 盲板BlankSB 8字盲板Spectacle blind （blank）RP 补强板Reinforcing pad法兰缩写中文名称英文名称PLG 法兰FlangeWNF 对焊法兰Welding neck flangeSOF 平焊法兰Slip-on flangeSWF 承插焊法兰Socket-welding flangeT 螺纹法兰Threaded flangeLJ 松套法兰Lapped joint flangeREDF 异径法兰Reducing flangeBF 法兰盖（日法兰）Blind flangeFSF 法兰密封面Flange scaling faceFF 全平面Flat faceRF 凸台面Raised faceMFF 凹凸面Male ａnd female faceLF 凹面Female faceLM 凸面Male faceRJ 环连接面Ring joint faceTG 榫槽面Tongue ａnd groove faceTF 榫面Tongue faceGF 槽面Groove face垫片缩写中文名称英文名称G 垫片GasketNMG 非金属垫片Non-metallic gasketAG 石棉垫片Asbestos gasketRG 橡胶垫片Rubber gasketTEG 聚四氟乙烯包复垫片PTFE envelope gasket SMG 半金属垫片Semimetallic gasketMJG 金属包垫片Meta-jacket gasketSWG 缠绕式垫片Spiral wound gasketMG 金属垫片Metallic gasketFMG 金属平垫片Flat metallic gasketSMSG 齿形金属垫片Solid metal serrated gasket LER 透镜式金属环垫Lens ring gasketOCR 八角形金属环垫Octagonal ring gasket OVR 椭圆形金属环垫Oval ring gasketIR/OR 内外定位环Inner ring ａnd outer ring IR 内定位环Inner ringOR 外定位环Outer ring坚固件缩写中文名称英文名称B 螺栓BoltSB 螺柱Stud boltNU 螺母NutTB 花蓝螺母TurnbuckleWSR 垫圈WasherSWSR 弹簧垫圈Spring washer阀门缩写中文名称英文名称GV 闸阀Gate valveGLV 截止阀Globe valveCHV 止回阀Check valveBUV 蝶阀Butterfly valveBAV 球阀Ball valvePV 旋塞阀Plug valve （cock）CV 调节阀Control valveSV 安全阀Safety valveRV 减压阀Pressure reducing valveST 蒸汽疏水阀Steam trapPRV 泄压阀Pressure relief valveBV 呼吸阀Breather valveNV 针形阀Needle valveAV 角阀DV 隔膜阀TWV 三通阀SGV 插板阀管道上用的小型设备缩写中文名称英文名称SPR 气液分离器SeparatorFA 阻火器Flame arresterSR 过滤器StrainerSRY Y型过滤器Y-type strainerSRT T型过滤器T-type strainerSRB 桶式过滤器Bucket type strainerTSR 临时过滤器Temporary strainerSIL 消声器SilencerSG 视镜Slight glassSC 取样冷却器Sample coolerDF 排液漏斗Drain funnelLM 管道混合器Line mixerRO 限流孔板Restriction orificeMO 混合孔板Mixing orificeRD 爆破片（爆破膜）Rupture diskEJ 补偿器Expansion joint隔热、伴热中文名称英文名称INS 隔热Thermal insulationH 保温Hot insulationC 保冷Cold insulationP 防烫伤隔热Personnel protection insulation T&I 伴热Tracing ａnd insulation管道伴热（冷）TracingEST 蒸汽外伴热External steam tracingIST 蒸汽内伴热Internal steam tracingSJT 蒸汽夹套伴热Steam-jacket tracingET 电伴热Electric tracing配管材料和等级缩写中文名称英文名称M 金属材料Metallic materialCS 碳钢Carbon steelCAS 铸钢Cast steelFS 锻钢Forged steelAS 合金钢Alloy steelSS 不锈钢Stainless steelAUSTSS 奥氏体不锈钢Austenitic stainless-steelCI 铸铁Cast ironMI 可锻铸铁Malleable ironDI 球墨铸铁Ductile ironAL 铝AluminumBRS 黄铜BrassBRZ 青铜BronzeCU 紫铜CopperLAS 低合金钢Low alloy steelFLAS 低合金锻钢Forged low alloy steelCLAS 低合金铸钢Cast low alloy steelTHK 壁厚ThicknessSCH 表号Schedule numberSTD 标准StandardXS 加强Extra strongXXS 特强Double extra strong装置布置缩写中文名称英文名称CN 建北Construction northE 东EastW 西WestS 南SouthN 北NorthH 水平HorizontalV 竖直、铅直、直立VerticalGRD 地坪GroundUG 地下UndergroundBL 装置边界线Battery limit lineESEW 事故沐浴洗眼器Emergency shower ａnd eye washer HS 软管站Hose stationML 接续分界线Match linePS 管道支架（管架）Piping supportPR 管桥Pipe rackSTRU 构架（构筑物）StructureBLDG 建筑物BuildingPD 清扫设施Purge devicePT 池PitSHLT 棚ShelterCOFF 围堰CofferdamFL 楼板FloorPF 平台Platform尺寸标注缩写中文名称英文名称EL 标高ElevationBOP 管底Bottom of pipeCOP 管中心Center of pipeTOP 管顶Top of pipeFOB 底平Flat on bottomFOT 顶平Flat on topCL（屯）中心线Center lineTL 切线Tangent lineSYM 对称的SymmetricalBOS 支架底Bottom of supportTOS 支架顶Top of supportCL 净距（净空）ClearanceCTC 中心至中心Center to centerCTF 中心至面Center to faceCTE 中心至端部Center to endETE 端到端End to endFEF 法兰端面Flange and faceFTF 面到面Face to faceD 直径DiameterDN 公称直径Nominal diameterID 内径Inside diameterOD 外径Outside diameterDIM 尺寸DimensionMAX 最大MaximumMIN 最小MinimumAVG 平均AverageAPP 约、近似ApproximatePT.EL 点标高Point elevation图表缩写中文名称英文名称PFD 工艺流程图Process flow diagramPID 管道和仪表流程图Piping & instrument diagram COD 接续图Continued on drawingDTL 详图DetailSPDWG（ISODWG）管段图Spool drawing （each line isometric drawing）DWGNO 图号Drawing numberDWGI 所在图号Drawing identificationLOW 材料表List of materialMTO 汇料Material take-offAPPX 附录AppendixJOB. No. 工号Job NumberBEDD 基础工程设计数据Basic engineering design dataDEDD 详细工程设计数据Detail engineering design dataREV. No. 修改号Revision numberREFDWG 参考图Reference drawingSC 采样接口Sample connection操作方式及工作参数缩写中文名称英文名称AUT 自动AutomaticML 手动Manual controlCHOP 链条操作Chain operatedCSC 铅封关Car seal closeCSO 铅封开Car seal openLC 锁闭Lock closedLO 锁开Lock openNC 正常关Normally closeNO 正常开Normally openATM 大气压AtmospherePN 公称压力Nominal pressureA 绝压G 表压（T）温度Temperature（P）压力Pressure施工缩写中文名称英文名称W 焊接WeldingAW 电弧焊Arc weldingGSAW 气体保护电弧焊Gas shielded-acre weldingEFW 电熔焊Electric fusion weldingERW 电阻焊Electric Resistance weldingGW 气焊Gas weldingLW 搭接焊Lap weldingBW 对焊Butt weldingTW 定位焊Tack weldingSW 承插焊Socket weldingCW 连续焊Continuous weldingSEW 密封焊Seal weldingSFG 堆焊SurfacingFW 现场焊接Field weldingHT 热处理Heat treatmentPH 预热PreheatingSR 应力消除Stress reliefPWHT 焊后热处理Post weld heat treatmentEIT 检查、探伤和实验Examination, inspection & testingVE 外观检查Visual examinationUI （UT）超声探伤Ultrasonic inspection （test）RI （RT）射线探伤Radiographic inspection （test）MPI （MT）磁粉探伤Magnetic particle inspection （test）LPI （PT）液体渗透检验Liquid penetration inspection （test）HADT 硬度实验Hardness testingHYDT 水压实验Hydraulic testingPNET 气压实验Pneumatic testing焊条Covered electrodeWW 焊丝Welding wireASSY 装配、组合AssemblyF 现场FieldF/F 现场制造Field fabricatedSF 现场决定Suit in fieldCSP 冷紧Cold springBCT 螺栓冷紧Bolt cold tighteningBHY 螺栓热紧Bolt hot tighteningCO 清洗口Clean outANNY 退火AnnealedPE 平端面Plain endBE 坡口端Beveled endTHR 螺纹ThreadHB 布氏硬度Brinell hardnessRC 洛氏硬度其他缩写中文名称英文名称FDN 基础FoundationINF 信息（资料）InformationREF 参考ReferenceREV 修改RevisionSEQ 序号（顺序）SequenceW/E 设备带来With equipmentW/I 仪表带来With instrumentCM 色标Color markCA 腐蚀裕度Corrosion allowanceUTL 公用系统UtilityUC 公用工程接头Utility connectionQTY 数量QuantityWT 重量WeightMHR 工时Man hourBC 螺栓分布圆Bolt circleHP 高点High pointLP 低点Low pointSUC 吸入（口）SuctionDIS 排出（口）DischargeSO 蒸气吹扫（口）Steam outNPT 美国标准锥管螺纹National standard taper pipe thread NPS 美国标准直管螺纹National standard straight pipe thread DR 排液DrainVT 放气VentRTG （压力）等级RatingCL 等级ClassSMLS 无缝Seamless。

常用管件管道配件中英文对照常用管件管道配件中英文对照１.管件系列1.1>>P 管子Pipe1.2>> EL 弯头Elbow1.2.1> ELL 长半径弯头Long radius elbow1.2.2> ELS 短半径弯头Short radius elbow1.2.3>MEL 斜接弯头（虾米腰弯头）Mitre elbow1.2.4> REL 异径弯头Reducing elbow1.3>> T 三通Tee1.3.1> LT 斜三通Lateral tee1.3.2> RT 异径三通Reducing tee1.3.3> CROSS 四通1.4>>R 异径管接头（大小头）Reducer1.4.1> CR 同心异径管接头（同心大小头）Concentric reducer 1.4.2> ER 偏心异径管接头（偏心大小头）Eccentric reducer 1.5>> CPL 管箍Coupling1.5.1> FCPL 双头管箍Full coupling1.5.2> HCPL 单头管箍Half coupling1.5.3> RCPL 异径管箍Reducing coupling1.6>>BU 内外螺纹接头Bushing1.7>> UN 活接头Union1.8>> HC 软管接头Hose coupler1.9>> SE 翻边短节Stub end1.10>> NIP 短节Pipe nipple or straight nipple1.10.1>SNIP 异径短节Swaged nipple1.11>>CP 管帽（封头）Cap1.12>> PL 管堵（丝堵）Plug1.13>> BLK 盲板Blank1.13.1> SB 8字盲板Spectacle blind1.14>> PAD 补强板Reinforcing pad1.15>焊接支管台 WELDOLET1.16> 螺纹支管台 THREADOLET1.17> FO 限流孔板2 法兰2.1>> PLG 法兰Flange2.1.1> WNF 对焊法兰Welding neck flange2.1.2> SOF 平焊法兰Slip-on flange2.1.3> SWF 承插焊法兰Socket-welding flange2.1.4>T 螺纹法兰Threaded flange2.1.5> LJ 松套法兰Lapped joint flange2.1.6> REDF 异径法兰Reducing flange2.1.7> BF 法兰盖（盲法兰）Blind flange2.2>> FSF 法兰密封面Flange scaling face2.2.1> FF 全平面Flat face2.2.2>RF 凸台面Raised face2.2.3> MFF 凹凸面Male and female face2.2.4>LF 凹面Female face2.2.5> LM 凸面Male face2.2.6> RJ 环连接面Ring joint face2.2.7>TG 榫槽面Tongue and groove face2.2.8> TF 榫面Tongue face2.2.9> GF 槽面Groove face3 垫片3.1>> >G 垫片Gasket3.1.1>> NMG 非金属垫片Non-metallic gasket3.1.1.1> AG 石棉垫片Asbestos gasket3.1.1.2> RG 橡胶垫片Rubber gasket3.1.1.3> TEG 聚四氟乙烯包复垫片PTFE envelope gasket 3.1.2>> SMG 半金属垫片Semimetallic gasket3.1.2.1 >MJG 金属包垫片Meta-jacket gasket3.1.2.2> SWG 缠绕式垫片Spiral wound gasket3.1.3>> MG 金属垫片Metallic gasket3.1.3.1> FMG 金属平垫片Flat metallic gasket3.1.3.2> SMSG 齿形金属垫片Solid metal serrated gasket 3.1.3.3> LER 透镜式金属环垫Lens ring gasket3.1.3.4> OCR 八角形金属环垫Octagonal ring gasket3.1.3.5> OVR 椭圆形金属环垫Oval ring gakset3.1.3.6> IR/OR 内外定位环Inner ring and outer ring 3.1.3.7> IR 内定位环Inner ring3.1.3.8> OR 外定位环Outer ring4 坚固件4.1>> B 螺栓Bolt4.1.1> SB 螺柱Stud bolt4.2>> NU 螺母Nut4.3>> TB 花蓝螺母Turnbuckle4.4>> WSR 垫圈Washer4.4.1 >SWSR 弹簧垫圈Spring washer5 阀门5.1>> GV 闸阀Gate valve5.2>> GLV 截止阀Globe valve5.3>> CHV 止回阀Check valve5.4 >> BUV 蝶阀Butterfly valve5.5>> BAV 球阀Ball valve5.6>> PV 旋塞阀Plug valve (cock)5.7>> CV 调节阀Control valve5.8>> SV 安全阀Safety valve5.9>>RV 减压阀Pressure reducing valve 5.10>> ST 蒸汽疏水阀Steam trap5.11>> PRV 泄压阀Pressur relief valve5.12>> BV 呼吸阀Breather valve5.13>> NV 针形阀Needle valve5.14>> AV 角阀5.15>> DV 隔膜阀5.16>> TWV 三通阀5.17>> SGV 插板阀6 管道上用的小型设备6.1>> SPR 气液分离器Separator6.2 >>FA 阻火器Flame arrester6.3 >>SR 过滤器Strainer6.3.1> SRY Y型过滤器Y-type strainer6.3.2> SRT T型过滤器T-type strainer6.3.3> SRB 桶式过滤器Bucket type strainer 6.3.4> TSR 临时过滤器Temporary strainer 6.4.>> SIL 消声器Silencer6.5 >>SG 视镜Slight glass6.6 >>SC 取样冷却器Sample cooler6.7 >>DF 排液漏斗Drain funnel6.8>> LM 管道混合器Line mixer6.9>> RO 限流孔板Restriction orifice6.9.1> MO 混合孔板Mixing orifice6.1>>> RD 爆破片（爆破膜）Rupture disk6.11 >>EJ 补偿器Expansion joint7 隔热、伴热编号缩写中文名称英文名称7.1 >>INS 隔热Thermal insulation7.1.1> H 保温Hot insulation7.1.2> C 保冷Cold insulation7.1.3>> P 防烫伤隔热Personnel protection insulation7.2 >T&I 伴热Tracing and insulation7.3> T 管道伴热（冷）Tracing7.3.1> EST 蒸汽外伴热External steam tracing7.3.2> IST 蒸汽内伴热Internal steam tracing7.3.3 >SJT 蒸汽夹套伴热Steam-jacket tracing7.3.4 >ET 电伴热Electric tracing8、配管材料和等级8.1> M 金属材料Metallic material8.1.1> CS 碳钢Carbon steel8.1.2 >CAS 铸钢Cast steel8.1.3> FS 锻钢Forged steel8.1.4>> AS 合金钢Alloy steel8.1.5> SS 不锈钢Stainless steel8.1.6> AUST SS 奥氏体不锈钢Austenitic stainless-steel 8.1.7>> CI 铸铁Cast iron8.1.8> MI 可锻铸铁Malleable iron8.1.9> DI 球墨铸铁Ductile iron8.1.10> AL 铝Aluminum8.1.11> BRS 黄铜Brass8.1.12> BRZ 青铜Bronze8.1.13> CU 紫铜Copper8.1.14> LAS 低合金钢Low alloy steel8.1.15> FLAS 低合金锻钢Forged low alloy steel8.1.16> CLAS 低合金铸钢Cast low alloy steel8.2>> THK 壁厚Thickness8.2.1> SCH 表号Schedule number8.2.2> STD 标准Standard8.2.3 >>XS 加强Extra strong8.2.4>> XXS 特强Double extra strong9、装置布置9.1>> CN 建北Construction north9.2 >>E 东East9.3>> W 西West9.4>> S 南South9.5>> N 北North9.6>> H 水平Horizontal9.7>> V 竖直、铅直、直立Vertical9.8>> GRD 地坪Ground9.9>> UG 地下Underground9.10>> BL 装置边界线Battery limit line9.11>> ESEW 事故沐浴洗眼器Emergency shower and eye washer 9.12>> HS 软管站Hose station9.13 >>ML 接续分界线Match line9.14>> PS 管道支架（管架）Piping support9.15>> PR 管桥Pipe rack9.16>>STRU 构架（构筑物）Structure9.17>>BLDG 建筑物Building9.18>> PD 清扫设施Purge device9.19 >>PT 池Pit9.20 >>SHLT 棚Shelter9.21>> COFF 围堰Cofferdam9.22>> FL 楼板Floor9.23>> PF 平台Plateform10、尺寸标注10.1 >>>EL 标高Elevation10.2>> BOP 管底Bottom of pipe10.3>> COP 管中心Center of pipe10.4>> TOP 管顶Top of pipe10.5 >>FOB 底平Flat on bottom10.6>> FOT 顶平Flat on top10.7>> CL(屯) 中心线Center line10.8>> TL 切线Tangent line10.9>> SYM 对称的Symmetrical10.10>> BOS 支架底Bottom of support10.11 >>TOS 支架顶Top of support10.12>> CL 净距（净空）Clearance10.13>> CTC 中心至中心Center to center10.14>> CTF 中心至面Center to face10.15>> CTE 中心至端部Center to end10.16>> ETE 端到端End to end10.17>> FEF 法兰端面Flange and face10.18 >>FTF 面到面Face to face10.19 >>D 直径Diameter10.20>> DN 公称直径Nominal diameter10.21 >>ID 内径Inside diameter10.22>> OD 外径Outside diameter10.23>> DIM 尺寸Dimension10.24>> MAX 最大Maximum10.25 >>MIN 最小Minimum10.26>> AVG 平均Average10.27>> APP 约、近似Approximate10.28>> PT.EL 点标高Point elevation11 图表11.1>> PFD 工艺流程图Process flow diagram11.2>> PID 管道和仪表流程图Piping & instrument diagram11.3>> COD 接续图Continued on drawing11.4>> DTL 详图Datail11.5>> SPDWG 管段图Spool drawing (each line isometric drawing) 11.6>> DWGNO 图号Drawing number11.7>> DWGI 所在图号Drawing identification11.8>> LOW 材料表List of material11.9>> MTO 汇料Material take-off11.10>> APPX 附录Appendix11.11>> JOB. No. 工号Job Number11.12>> BEDD 基础工程设计数据Basic engineering design data 11.13>> DEDD 详细工程设计数据Detail engineering design data 11.14>> REV. No. 修改号Recision number11.15>> REF DWG 参考图Reference drawing11.16 >>SC 采样接口Sample connection12、操作方式及工作参数12.1>> AUT 自动Automatic12.2>> ML 手动Manual control12.3>> CHOP 链条操作Chain operated12.4 >>CSC 铅封关Car seal close12.5>> CSO 铅封开Car seal open12.6>> LC 锁闭Lock closed12.7>> LO 锁开Lock open12.8>> NC 正常关Normally close12.9>> NO 正常开Normally open12.10>> ATM 大气压Atmosphere12.11>> PN 公称压力Nominal pressure12.12>> A 绝压12.13>> G 表压12.14>> (T) 温度Temperature12.15>> (P) 压力Pressure13、施工13.1>> W 焊接Welding13.1.1> AW(SMAW) 电弧焊Arc welding13.1.2> GSAW 气体保护电弧焊Gas shielded-acr welding13.1.3> EFW 电熔焊Elecric fusion welding13.1.4 >ERW 电阻焊Electric Resistance welding13.1.5> GW 气焊Gas welding13.1.6> LW 搭接焊Lap welding13.1.7> BW 对焊Butt welding13.1.8 >TW 定位焊Tack welding13.1.9> SW 承插焊Socket welding13.1.10> CW 连续焊Continuous welding13.1.11> SEW 密封焊Seal welding13.1.12> SFG 堆焊Surfacing13.1.13> FW 现场焊接Field welding13.1.14 > TIG(GTAW) 钨极惰性气体保护焊(氩弧焊) Gas Tungsten Arc Weld13.2 >>HT 热处理Heat treatment13.2.1>> PH 预热Preheating13.2.2 >SR 应力消除Stress relief13.2.3> PWHT 焊后热处理Post weld heat treatment13.3> EIT 检查、探伤和实验Examination, inspection & testing13.3.1> VE 外观检查Visual examination13.3.2>> UI (UT) 超声探伤Ultrasonic inspection (test)13.3.3>> RI (RT) 射线探伤Radiographic inspection (test)13.3.4> MPI (MT) 磁粉探伤Magnetic particle inspection (test)13.3.5> LPI (PT) 液体渗透检验Liquid penterant inspection (test) 13.3.6> HADT 硬度实验Hardness testing13.3.7> HYDT 水压实验Hydraulic testing13.3.8> PNET 气压实验Pneumatic testing13.3.9> CE 焊条Covered electrode13.3.10> WW 焊丝Welding wire13.3.11> ASSY 装配、组合Assembly13.3.12 >F 现场Field13.3.13> F/F 现场制造Field faricated13.3.14> SF 现场决定Suit in field13.3.15> CSP 冷紧Cold spring13.3.16> BCT 螺栓冷紧Bolt cold tightening13.3.17> BHY 螺栓热紧Bolt hot tightening13.3.18> CO 清洗口Clean out13.3.19> ANNY 退火Annealed13.4 >PE 平端面Plain end13.5 >BE 坡口端Belelled end13.6> THR 螺纹Thread13.7 >HB 布氏硬度Brinnel hardness13.8> RC 洛氏硬度14、其他14.1> FDN 基础Foundation14.2> INF 信息（资料）Information14.3 >REF 参考Reference14.4 >REV 修改Revision14.5 >SEQ 序号（顺序）Sequence14.6> W/E 设备带来With equipment14.7> W/I 仪表带来With instrument14.8> CM 色标Colour mark14.9> CA 腐蚀裕度Corrosion allowance14.10> UTL 公用系统Utility14.11> UC 公用工程接头Utility connection14.12> QTY 数量Quantity14.13 >WT 重量Weight14.14> MHR 工时Man hour14.15> BC 螺栓分布圆Bolt circle14.16> HP 高点High point14.17> LP 低点Low point14.18> SUC 吸入（口）Suction14.19 DIS 排出（口）Discharge14.20> SO 蒸气吹扫（口）Steam out14.21> NPT 美国标准锥管螺纹National standard taper pipe thread 14.22> NPS 美国标准直管螺纹National standard straight pipe thread 14.23> DR 排液Drain14.24> VT 放气Vent14.25> RTG （压力）等级Rating14.26> CL 等级Class14.27 >SMLS 无缝Seamless14.28> 螺旋缝 Spiral seam。

工程管道英文缩写对照AA Anchor 固定ABS Absolute 绝对的AISI American Iron and Steel Institute 美国钢铁学会ANSI American National Standards Institute 美国国家标准学会API American Petroleum Institute 美国石油学会APPROX Approximate 大约，近似的ASB Asbestos 石棉ASME ＊American Society Of Testing Material 美国机械工程师协会ASSY *Assembly 装配，组装ASTM *American Society OfTesting Material 美国材料实验协会ATM *Atmosphere 大气压AWG ＊American Wire Gage 美国线规AWS ＊American Wel＊**＊Society 美国焊接协会AWWA ＊American Water WorksAssociation 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B—B Beveled End—Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆B。

C Bolted Cover（cap）螺栓连接的阀兰盖(帽）BE Beveled End (for wel＊*＊＊）坡口（焊接用）B。

E Bell End 承口BEP Both Ends Plain 两端平BET Both Ends Threaded 两端带螺纹BL Battery Limit 装置区边界BF Blind Flange 法兰盖BLD Blind 盲板BLDG *Buil**** 建筑物BM Bill Of Material 材料表BOP Bottom Of Pipe 管底B—P Beveled End —Plain End 坡口端。

●1。

2 管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头（右向或左向）side outlet elbow (right hand or left hand）双支管弯头（形) double branchelbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通（右向或左向) side outlet tee (right hand or 1eft hand)异径三通（分支口为异径）reducing tee (reducing on outlet)异径三通（一个直通口为异径）reducing tee（reducing on one run)带支座三通 base tee异径三通（一个直通口及分支口为异径） reducing tee (reducing on one run and outlet）异径三通(两个直通口为异径,双头式） reducing tee (reducing on both runs, bull head)45°斜三通 45° lateral45°斜三通(支管为异径） 45° lateral （reducing on branch)45°斜三通（一个直通口为异径） 45° lateral (reducing on one run)45°斜三通（一个直通口及支管为异径) 45° lateral (reducing on one run andbranch)Y型三通（俗称裤衩）true “Y"四通 cross等径四通 straight cross异径四通reducing cross异径四通（一个分支口为异径)reducing cross （reducing on one outlet)异径四通（一个直通口及分支口为异径) reducing cross （reducing on one run and outlet）异径四通（两个分支口为异径) reducing cross (reducing on both outlet）异径四通（一个直通口及两个分支口为异径） reducing cross （reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管reducing swage螺纹支管台 threadolet焊接支管台weldolet承插支管台sockolet弯头支管台 elbolet斜接支管台latrolet镶入式支管嘴sweepolet短管支管台 nipolet支管台，插入式支管台 boss●螺纹支管台Threadolet●弯头支管台elbolet●焊接支管台weldolet；on weld●短管支管台nipolet●承插支管台sockolet●烧焊支管台weldolet●斜接支管台latrolet●承插焊支管台Sockolet●支管台，插入式支管台boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头union内外螺纹缩接（俗称补芯） bushing管帽 cap （C）堵头 plug短节 nipple异径短节 reducing nipple； swage nipple管道英文缩写A Anchor 固定ABS ＊Absolute 绝对的AISI ＊American Iron andSteelInstitute 美国钢铁学会ANSI *American National Standards Institute 美国国家标准学会API ＊American Petroleum Institute 美国石油学会APPROX ＊Approximate 大约，近似的ASB Asbestos 石棉ASME ＊American Society Of Mechanical Engineers美国机械工程师协会ASSY ＊Assembly 装配，组装ASTM ＊American Society Of Testing Material 美国材料实验协会ATM *Atmosphere 大气压AWG *American Wire Gage 美国线规AWS *American Wel**** Society 美国焊接协会AWWA *American Water WorksAssociation 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B—B Beveled End-Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆B.C Bolted Cover（cap) 螺栓连接的阀兰盖（帽）BE Beveled End (for wel＊*＊＊) 坡口(焊接用）B.E Bell End 承口BEP Both Ends Plain 两端平BET Both Ends Threaded两端带螺纹BL Battery Limit 装置区边界BF Blind Flange 盲板法兰BLD Blind 盲板BLDG *Buil＊＊*＊建筑物BM Bill Of Material 材料表BOP Bottom Of Pipe 管底B—P Beveled End —Plain End 坡口端.平端BVButterfly valve 蝶阀BWG * Birmingham Wire Gage 伯明翰线规BWButt Weld对焊CC Cap 管帽C-C Center to Center 中至中C—E Center to End 中至端面C-F Center to Face 中至面CH—OP Chain Operated 链条操纵的CH.PL Checkered Plate 花纹钢管C.I ＊Cast Iron 铸铁CL ＊Class 英制压力等级,等级，种类CLEAR Clearance 间隙COD Continued on Drawing 接续图COL *Column 柱，塔CONC Concentric 同心的CONN Connection 连接，接口CONT ＊Continue 连续CONT。

1.2 管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头（右向或左向） side outlet elbow (right hand or left hand)双支管弯头（形） double branch elbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通（右向或左向） side outlet tee (right hand or 1eft hand)异径三通（分支口为异径） reducing tee (reducing on outlet)异径三通（一个直通口为异径）reducing tee (reducing on one run)带支座三通 base tee异径三通（一个直通口及分支口为异径） reducing tee (reducing on one run and outlet)异径三通（两个直通口为异径，双头式） reducing tee (reducing on both runs, bull head)45°斜三通 45° lateral45°斜三通（支管为异径） 45° lateral (reducing on branch)45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch) Y型三通（俗称裤衩）true “Y”四通 cross等径四通 straight cross异径四通 reducing cross异径四通（一个分支口为异径）reducing cross (reducing on one outlet)异径四通（一个直通口及分支口为异径） reducing cross (reducing on one run and outlet)异径四通（两个分支口为异径） reducing cross (reducing on both outlet)异径四通（一个直通口及两个分支口为异径） reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管 reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台 sockolet弯头支管台 elbolet斜接支管台 latrolet镶入式支管嘴 sweepolet短管支管台 nipolet支管台，插入式支管台 boss●螺纹支管台Threadolet●弯头支管台elbolet●焊接支管台weldolet；on weld●短管支管台nipolet●承插支管台sockolet●烧焊支管台weldolet●斜接支管台latrolet●承插焊支管台Sockolet●支管台，插入式支管台boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头 union内外螺纹缩接（俗称补芯） bushing管帽 cap (C)堵头 plug短节 nipple异径短节 reducing nipple; swage nipple管道英文缩写A Anchor 固定ABS * Absolute 绝对的AISI *American Iron and Steel Institute 美国钢铁学会ANSI * American National Standards Institute 美国国家标准学会API *American Petroleum Institute 美国石油学会APPROX *Approximate 大约，近似的ASB Asbestos 石棉ASME *American Society Of Mechanical Engineers美国机械工程师协会ASSY * Assembly 装配，组装ASTM * American Society Of Testing Material 美国材料实验协会ATM * Atmosphere 大气压AWG * American Wire Gage 美国线规AWS * American Wel**** Society 美国焊接协会AWWA * American Water Works Association 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B-B Beveled End-Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆B.C Bolted Cover(cap) 螺栓连接的阀兰盖（帽）BE Beveled End (for wel****) 坡口（焊接用）B.E Bell End 承口BEP Both Ends Plain 两端平BET Both Ends Threaded 两端带螺纹BL Battery Limit 装置区边界BF Blind Flange 盲板法兰BLD Blind 盲板BLDG *Buil**** 建筑物BM Bill Of Material 材料表BOP Bottom Of Pipe 管底B-P Beveled End —Plain End 坡口端.平端BV Butterfly valve 蝶阀BWG * Birmingham Wire Gage 伯明翰线规BW Butt Weld 对焊CC Cap 管帽C-C Center to Center 中至中C-E Center to End 中至端面C-F Center to Face 中至面CH-OP Chain Operated 链条操纵的CH.PL Checkered Plate 花纹钢管C.I *Cast Iron 铸铁CL *Class 英制压力等级，等级，种类CLEAR Clearance 间隙COD Continued on Drawing 接续图COL *Column 柱，塔CONC Concentric 同心的CONN Connection 连接，接口CONT *Continue 连续CONT.V. Control Valve 控制阀CPLG Coupling 管接头，连轴节CPLH Half Coupling 半管接头，连轴节C.R. Concentric Reducer 同心异径管C.S. *Carbon Steel 碳钢C.S. Cold Spring 冷紧C.S.C. Car Seal Close 在关闭状态下封住C.S.O. Car Seal Open 在开启状态下封住CUST Customer 客C.V Check Valve 止回阀DDEG *Degree 度DF Drain funnel 排液漏斗DIA *Diameter 直径DIM *Dimension 尺寸DISCH *Discharge 出口，排出Diaphragm VELVE 隔膜阀DMF Double Male And Female 双重凹凸DN Norminal Diameter公称直径DN Down 下DR Drain 排液DS Directional Stop 定向限为架DWG * Drawing 图EE *East 东EC External Coating 外面涂防腐层ECC Eccentric 偏心EFW Electric Fusion Welded 电容焊的EL(ELEV) *Elevation 标高；立面ELL Elbow 弯头EQIOP Equipment 设备，装置EQUIV Equivalent 相当的E.R. Eccentric Reducer 偏心异经管ERW Electric Resistance Welded 电阻焊的EW Eye Washer & Shower 洗眼器及淋浴器EXP.JT Expansion Joint 膨胀节FFDN Foundation 基础FF Flat Faced Or Full Faced 全平面；满平面F-F Face To Face 面至面FGW Fusion Gas Wel**** 气熔焊FIG *Figure 图FL Floor 楼面FLEX TUBE Flexible Tube 挠性管FLG Flange 法兰FLGD Flanged 法兰式的FLGF Flanged Face 法兰面FOB Flat On Bottom 底面平FOT Flat On Top 顶面平FP Fix Point 固定点FS Forged Steel 锻钢FTF Fitting To Fitting 管件直连FTG Fitting 管件FURND Furnished 提供的，装设的FW Field Weld 现伤焊GG Guide 导向GA * Gage 表，表压，规（线规）GALV *Galvanize 镀锌GL Ground Level 地面GLV Globe Valve 截止阀GEAR OP Gear Operated 齿轮传动的GMAW Gas Metal Arc Wel**** 金属极惰气体保护焊GSKT Gasket 垫片GTAW (Inert)Gas Tungsten Arc Wel**** 惰性气体保护钨极电弧焊GV Gate Valve 闸阀HH Hanger 吊架HC Hose Connection 软管接头H.CPLG Half Coupling 半节管接头HDR Header 总管HEX *Hexagon 六角形HF Hard Alloy Face on阀内件（阀心）为Valve Trim 硬质合金密封面HH Hand Hole 手孔HOR Horizontal 水平的H.P * High Pressure 高压HS Hose Station 软管IID * Inside Diameter 内径IN * Inch 英寸INS Insulation 隔热INST Instrument 仪表INV Invert (inside bottom of pipe) 管子内底IPS Iron Pipe size 铁管尺寸ISO Isometric Drawing 周测图（空视图）I.S.B.L Inside Battery Limit 装置边界内恻ISNS Inside screw & Non-rising Stem 内螺纹非升杆ISRS Inside screw & Rising stem 内螺纹升杆JJT Joint 接头JS Jack Screw 顶开（起）螺栓LLC Locked Closed 在关闭状态下锁定LEP Large end plain 大端为平的LET Large end Threaded 大端带螺纹LG Long 长LGF Lens Gasket Face 透镜垫连接面L.H. THD Left Hand Thread 左螺纹LIFT Lift Type 升降式LJ Lap Joint 搭接LJF Lap Joint Flange 松套法兰LO Locked Open 在开启状态下锁定L.P. Low Pressure 低压LR Long Radius 长半径LRE Long Radius Elbow 长半径弯头LTG Large Tongue & Groove 大椎槽MMATL Material 材料MAX Maximum 最大MB Machine Bolt 机器螺栓（单头）MF Male and Female 凸和凹MFG Manufacture 制造MF * Manufacture 制造厂MH Manhole 人孔MI Malleable Iron 可锻铸铁MIN *Minimum 最小MJ Mechanical Joint 机械接头M.L Match Line 连续线MSS * Manufacturers Standardization Society of the Valve and Fittings Industry, Inc. 美国阀门和管件制造商标准化协会MTO Material take-off 材料统计MW Minimum Wall 最小壁厚M.W. Mineral Wool 矿（物）棉NN * North 北NB Nominal Bore 公称孔径N.B. Non-Bonnet 无阀盖NC Normally Closed 常闭NIP Nipple 短管NO Normally Open; 常开*Number号；数量NO INS No Insulation 不隔热NOM Nominal 公称的；额定的NOZ Nozzle 管口NPS Nominal Pipe Size 公称管径NPSH Net Positive Suction Head 净正吸入压头NPT *American National Taper 美国锥管螺纹Pipe ThreadNS Nominal Size 公称直径NV Needle Valve 针形阀OOD *Outside Diameter 外径OET One end Threaded 一端带螺纹OR Outside Radius 外半径ORF Orifice 孔板ORIENT Orientation 方位OS & Y Outside Screw and Yoke 外螺纹阀杆和阀轭OSNB Outside Screw Non-Bonnet 外螺纹无阀盖PP Plug 堵头PAP Piping Arrangement Plan 管道布置平面图PB Pressure Seal Bonnet 压力密封的阀盖P-B Plain End –Bevel End 平端—坡口端PC Pressure Seal Cap 压力密封的阀帽P.C.D. Pitch Circle Diameter 节圆直径PE Plain End (not beveled) 平端（无坡口）PF Platform 平台PID Piping & Instrument Diagram管道及仪表流程图PN *Nominal Pressure 公称压力PN Plant North 工厂北向POS point of Support 支承点P-P Plain End—Plain End 两端为平端PREP Preparation 加工准备PSIA *Pounds Per Square Inch Absolute 磅/ PSIG Pounds Per Square Inch Gage 磅/PT Point 点PTFE *Polytetrafluoroethylene 聚四氟乙烯PT.NO Part No. 件号PV Plug Valve 旋塞阀PVC *Poly Vinyl Chloride 聚氯乙烯QQTY *Quantity 数量RR * Radius 半径RED Reducer 异径管REF Reference 参考REINF Reinforce 加强REQD Required 需要；申请REV *Revision 修改RF Raised Face 凸面RG Ring Gasket 环形垫片R.H.THD Right Hand Thread 右螺旋RJ Ring Joint 环垫接头RO Restriction Orifice 限流孔板RPM * Revolutions Per Minute 转/分RPS * Revolutions Per Second 转/秒RS Resting Support 支承架，滑动架RTJ Ring Type Joint（见RJ）RV Relief Valve 安全泄液阀SS *South 南S Spring 弹簧（管架用）SAW (Automatic)Submerged Arc Wel**** 自动埋弧焊SB Stud Bolt 双头螺栓SB Screwed Bonnet 螺纹阀盖SC Sample Cooler 取样冷却器SCH * Schedule 管壁厚系列号SCRD Screwed 螺纹SEP Small end Plain 小端为平的SET Small end Threaded 小端带螺纹SF Semi-Finished 半光SG Sight Glass 视镜SH Surface Hard Facing 硬质密封面SK Sketch 草图SMAW Shielded Metal Arc Wel**** 有保护的金属电弧焊SMLS Seamless 无缝SN Swaged Nipple 异径短管SO Slip – On 滑套SOF Slip – On Flange 滑套法兰SPEC * Specification 规定，说明SPL Sound Pressure Lever 升压水准SQ * Square 方的，平方SR Shout Radius 短半径SRE Short Radius Elbow 短半径弯头SS *Stainless Steel 不锈钢ST Steam Trap 蒸汽疏水阀STD *Standard 标准STG Small Tongue & Groove 小椎槽面STL *Steel 钢STM Steam 蒸汽STM.TR Steam Tracing 蒸汽拌热SUCT Suction 吸入口SV Safety Valve 安全泄气阀SW Socket Weld 承插焊SWG Swage 锻造，模锻SWMG Swing Type 旋启式SYM Symmetrical 对称的TT Tee 三通TE Threaded End 螺纹端TEMP *Temperature 温度TG Tongue & Groove 椎槽THD *Threaded 螺纹的THK *Thickness 厚度TL Tangent Line 切线TN True North 真实北向TOC Top of Concrete 混凝土北向TOP Top of pipe 管顶TOS Top of Support 支架顶面Top of Steel 钢结构顶面TY P Typical 典型的UUB Union Bonnet 带活接头的阀盖UC Union Cap 带活接头的阀帽UN Union 活接头VV Valve 阀VAC Vacuum 真空VAR Variable 可变的VERT Vertical 垂直的VOL *Volume 卷，册，容量，体积WW * West 西WB Weld Branch 焊接支管WC Weld Cap 焊接管帽WD Width 宽度WE Weld End 焊接端WL Wel**** Line 焊接线WN Wel**** Neck 对焊法兰（颈部）WNF Weld Neck Flange 对焊法兰WP Working Pressure 工作压力W.P. Working Point 工作点WT Wall Thickness 壁厚Weight 重量XXH Extra Heavy 加强的，加厚的XXH Double Extra Heavy 双倍加强（厚）的XS Extra Strong 加强的XXS Double Extra Strong 双倍加强的YYP Yield Point 屈服点1.2 管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头（右向或左向） side outlet elbow (right hand or left hand)双支管弯头（形） double branch elbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通（右向或左向） side outlet tee (right hand or 1eft hand)异径三通（分支口为异径） reducing tee (reducing on outlet)异径三通（一个直通口为异径） reducing tee (reducing on one run)带支座三通 base tee异径三通（一个直通口及分支口为异径） reducing tee (reducing on one run and outlet)异径三通（两个直通口为异径，双头式） reducing tee (reducing on both runs, bull head)45°斜三通 45° lateral45°斜三通（支管为异径） 45° lateral (reducing on branch)45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch)Y型三通（俗称裤衩）true “Y”四通 cross等径四通 straight cross异径四通 reducing cross异径四通（一个分支口为异径 reducing cross (reducing on one outlet)异径四通（一个直通口及分支口为异径） reducing cross (reducing on one run and outlet)异径四通（两个分支口为异径） reducing cross (reducing on both outlet)异径四通（一个直通口及两个分支口为异径） reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管 reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台 sockolet弯头支管台 elbolet斜接支管台 latrolet镶入式支管嘴 sweepolet短管支管台 nipolet支管台，插入式支管台 boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头 union内外螺纹缩接（俗称补芯） bushing管帽 cap (C)堵头 plug短节 nipple异径短节 reducing nipple; swage nipple1.3 弯管 Bend预制弯管 fabricated pipe bend跨越弯管（^ 形） cross-over bend偏置弯管（~ 形） offset bend90°弯管 quarter bend环形弯管 cirele bend单侧偏置90°弯管（? 形） single offset quarter bendS形弯管“S” bend单侧偏置U形膨胀弯管（| ?形）single offset “U” bendU形弯管“U” bend双偏置U膨胀弯管double offset expansion “U” bend斜接弯管 mitre bend三节斜接弯管 3-piece mitre bend折皱弯管 corrugated bend圆度 roundness1.4 法兰 Flange (FLG）整体管法兰 integral pipe flange钢管法兰 steel pipe flange螺纹法兰 threaded flange滑套法兰（包括平焊法兰） slip-on flange (SO); slip-on welding flange承插焊法兰 socket welding flange松套法兰 lap joint flange (LJF)对焊法兰 welding neck flange (WNF)法兰盖 blind flange, blind孔板法兰 orifice flange异径法兰 reducing flange盘座式法兰 pad type flange松套带颈法兰 loose hubbed flange焊接板式法兰 welding plate flange对焊环 welding neck collar （与stub end相似）平焊环 welding-on collar突缘短节 stub end, lap翻边端 lapped pipe end松套板式法兰 loose plate flange压力级 pressure rating, pressure rating class压力—温度等级 pressure-temperature rating法兰密封面，法兰面 flange facing突面 raised face (RF)凸面 male face (MF)凹面 female face (FMF)榫面 tongue face槽面 groove face环连接面 ring joint face全平面；满平面 flat face; full face (FF)光滑突面 smooth raised face (SRF)法兰面加工 facing finish粗糙度 roughness光滑的 smooth齿形 serrated均方根 root mean square (RMS)算术平均粗糙高度 arithmetical average roughness height (AARH) 配对法兰 companion-flange螺栓圆 bolt circle (B.C.)1.5 垫片 Gasket (GSKT)垫片的型式 type of gasket平垫片 flat gasket环形平垫片 flat ring gasket平金属垫片 flat metal gasket夹棉织物的橡胶 elastomer with cotton fabric insertion夹石棉织物的橡胶 elastomer with asbestos fabric insertion夹石棉织物及金属丝加强的橡胶 elastomer with asbestos fabric insertion and with wire reinforcement无石墨压缩白石棉垫片 non graphited compressed white asbestos gasket天然白橡胶垫片 natural white rubber gasket压缩石棉垫片 compressed asbestos class gasket浸聚四氟乙烯的石棉垫片 PTFE impregnated asbestos gasket夹石棉的缠绕金属垫片 spiral-wound metal gasket with asbestos filler内环 inner ring外环，外定位环 outer ring波纹金属垫片 corrugated metal gasket波纹金属包嵌石棉垫片 corrugated metal gasket with asbestos inserted双夹套波纹金属包石棉垫片 corrugated metal double jacketed asbestos filled gasket 双夹套垫片 double jacketed gasket金属包石棉平垫片 flat metal jacketed asbestos filled gasket整体金属齿形垫片 solid metal serrated gasket槽形金属垫片 grooved metal gasket环形连接金属垫片 ring joint metal gasket八角环形垫片 octagonal ring gasket椭圆环形垫片 oval ring gasket透镜式垫片 lens gasket非金属垫片 non-metallic gasketTOE是Threaded One End的缩写，意思是一端螺纹POE是Plain One End的缩写，意思是一端平口TBE是Threaded Both End的缩写，意思是两端螺纹PBE是Plain Both End的缩写，意思是两端平口TOE&POE就是一端平口，另一端螺纹连接TBE就是两头都是螺纹连接PBE就是两头都是平口（焊接）。

窗|Window吹出|Blow-off吹灰器|Soot blower吹扫|Purge垂直|Perpendicular垂直安装|Vertical installation垂直的|Vertical垂直管|Riser醇酸瓷漆|Alkyd enamel瓷漆|Enamel磁粉探伤|Magnetic particle test (MT)粗糙度|roughness粗滤器|Strainer粗牙螺纹|Coarse thread粗制的|Coarse醋酸丁酸纤维素|Cellulose acetate butyrate (CAB)催货|Expediting脆性|Brittleness淬火|Quenching萃取器|Extractor错边量|Alignment tolerance错位|Mismatch搭焊|Lap welding搭接|Lapped joint大端带螺纹|Large end thread (LET)大端为平的|Large end plain (LEP)大气腿|Barometric leg大气污染|Atmospheric pollution大气压|Atmosphere (ATM)大修|Over haul大约|Approximate (APPROX)代码|Code number带侧向口的三通|Side outlet tee (right hand or left hand)带侧向口的三通（右向或左向）|side outlet tee (right hand or left hand)带侧向口的弯头|Side outlet elbow (right hand or left hand)带侧向口的万头（右向或左向）|side outlet elbow (right hand or left hand) 带铬镍合金丝的石棉绳|Asbestos rope with inconel wire ;inconel wire asbestos 带环头拉杆|Eye rod带铰链膨胀节|Hinged expansion joint带接杆膨胀节|Tied expansion joint带孔销|Pin with hole带支座的三通|Base tee带支座三通|base tee带支座弯头|base elbow带状卡|Strap clamp待定|Hold单波|Single bellow单侧偏置90°弯管|single offset quarter bend单侧偏置90度弯管|Single offset quarter bend单侧偏置U形膨胀弯管|Single offse t ”U” bend单侧偏置U型膨胀弯管|single offset "U" bend单面U形坡口|Single U groove单体|Monomer单位|Unit单位制|System of units单向滑动填料函补偿器|Single action packed slip joint 弹簧垫圈|Spring washer弹簧吊架|Spring hanger弹簧钢|Spring steel弹簧恒力吊架|Spring constant hanger弹簧恒力托架|Resting type spring constant support 弹簧架|Spring support弹簧球式止回阀|Spring ball check valve弹簧托架|Resting type spring support弹簧系数|Spring constant弹簧支撑架|Spring bracing弹性极限|Elastic limit弹性模量|Modulus of elasticity淡色的|Light氮气|Nitrogen当量的|Equivalent导管|Conduit导热系数|Thermal conductivity factor导线管|Conduit tube导向板|Cleat导向架|Guide倒吊桶式疏水阀|Inverted bucket trap倒链|Chain block倒密封|Back seal道路|Road等级|Class (CL)等级分界|Material specification break等径孔道|Full bore; full port等径三通|straight tee等径四通|staight cross等离子焊|Plasma welding等温淬火|Isothermal quenching等温退火|Isothermal annealing低合金钢|Low alloy steel低碳钢|Low-carbon steel低温用阀|Cryogenic service valve低压|Low pressure (L.P.)低压蒸汽|Low pressure steam底板|Base plate底阀|Foot valve底平|Flat on bottom (FOB)底漆|Primary coat ; bottom coat地脚螺栓|Anchor bolt ; foundation bolt地漏|Floor drain地面|Ground level地上管道|Above ground piping地下槽|Slop tank地下管道|Under ground piping地震|Earthquake地震荷载|Seismic load ; earthquake load地震系数|Seismic coefficient ; seismic factor第一道阀|Primary valve点焊|Spot welding点蚀|Pitting电伴热|electrical tracing电磁阀|Solenoid valve ; solenoid operated valve 电动操纵器|Electric motor operator电动阀|Electrically operated valve ; electric-motor operated valve 电动葫芦|Motor hoist电动机|Motor电弧焊|Arc welding电弧焊钢板卷管|Electric-arc-welded steel-plate pipe电化腐蚀|Electro corrosion电话|Telephone电加热器|Electric heater电缆|Cable电缆槽架|Cable tray (channel);cable rack电缆沟|Cable trench电流|Current电气盘|Electrical panel电容|Capacitance电熔（弧）焊钢板卷管|electric-fusion(arc)-welded steel-plate pipe 电熔焊|Electric fusion welding (EFW)电熔焊钢板卷管|Electric-fusion-welded steel-plate pipe电线|Wire电压|Voltage电渣焊|Electroslag welding电阻|Resistance电阻焊|Electric resistance welding (ERW)电阻焊钢管|electric-resistance welded steel pipe垫板|Shim垫板焊|Backing weld垫环|Spacer垫片|gasket[GSKT]垫片的形式|Type of gasket垫片的型式|type of gasket垫圈|Washer吊耳|Lifting lug吊架|Hanger吊梁|Hoisting beam吊柱|Davit吊装孔|Erection opening调节阀|Regulating valve调制|Quenching and tempering蝶阀|Butterfly valve蝶式止回阀|Butterfly check valve蝶形螺母|Wing nut丁腈橡胶|Nitrile butadiene rubber顶板|Top plate顶开螺栓|Jack screw顶平|Flat on top (FOT)顶起螺栓|Jack screw订货单|Purchasing order定购单|Purchasing order定位|Location定位焊|Tack weld定位块|Preset pieces定位销|Dowel pin定向限位架|Directional stop定值限位架|Limit stop东|East (E)动力操纵器|Powered operator动力荷载|Dynamic load动态分析|Dynamic analysis堵头|plug度|Degree （）镀层|Plating镀铬的|Chromium-plated ;chrome-plated镀锌钢管|galvanized steel pipe镀锌铁皮|Galvanized (sheet) iron ; galvanized plain sheet 镀锌铁丝|Galvanized wire镀锌铁丝网|Galvanized wire mesh端部连接|End connection短半径180度弯头|short radius return短半径弯头|short radius elbow短代码|Short code短管支管台|nipolet短节|Nipple短型|short pattern断面收缩率|Reduction of area断面系数|Section modulus断续淬火|Slack quenching锻钢|Forged steel锻铁管|wrought-iron pipe锻造、型钢|Swage锻造的、锻造|Forging锻造阀|Forged valve锻制U形夹|Forged steel clevis锻制异径管|reducing swage堆焊|Build up welding堆焊( 阀) 座|deposited seat堆焊座|Deposited seat对称的|Symmetric对焊|Butt welding对焊的|Butt welded (BW)对焊端|Butt welded end对焊法兰|welded neck flange[WNF]对焊环|welding neck collar(与stub end相似) 对焊连接|Butt welded joint对夹式|Wafer type对流段|Convection section对面|Opposite对中心；找正|Alignment吨|Ton (t)多波|Multiple below多级压缩机|Multiple stages compressor多通路阀|Multiport valve耳轴|Trunnion二次应力|Secondary stress二维限位架|Two-axis stop发电机|Generator发泡|Foaming发毡|Hair felt阀轭|yoke阀轭套|yoke sleeve阀盖|bonnet阀盖衬套|bonnet bush阀盖垫片|bonnet gasket阀杆|stem阀杆环|stem ring阀杆填料|stem packing阀井|Valve pit阀盘|disc阀盘密封圈|disc seat阀体|body阀芯|Trim阀芯( 包括密封圈、杆等内件)|trim阀座|valve seat (seat)阀座环|seat ring阀座环、密封圈|Seat ring法兰|Flange (FLG)法兰端|Flanged end法兰盖|blind flange;\r\nblind法兰盖贴面|Protective disc法兰连接|Flanged joint法兰密封面|flange facing法兰密封面；法兰面|Flange facing法兰面|flange facing法兰面加工|facing finish法兰式的|Flanged (FLGD)翻边端|lapped pipe end反力|Reaction反应器|Reactor方垫圈|Square washer方钢|Square bar方螺母|Square nut方头螺栓|Square head bolt方位|Orientation方向|Direction防爆门|Explosion door防潮湿包装|Moisture-proof packing防冻|Winterizing防腐剂|Corrosion inhibitor防腐漆|Anti-corrosive paint;rush-proof paint 防火层|Fire-proofing防火门|Fire door防结露|Anti-sweat防水包装|Water-proof packing防脱出阀杆|Blowout proof stem防锈包装|Rust-proof packing防锈漆|Antirust paint放空|Vent放空阀|Vent valve放气阀|Air vent valve放气孔|Vent hole非金属材料|Non-metallic material非金属垫片|non-metallic gasket非铺砌区|Unpaved area非升杆式|Non-rising stem (NRS)非升杆式( 暗杆)|Non-rising stem [NRS]非铁合金|Nonferrous alloy非旋转式阀|Non-rotary valve废热锅炉|Waste heat boiler沸腾钢|Rimmed steel ; rimming steel ; open-steel 费托立克接头|Victaulic coupling分|Minute (min)分包商|Subcontractor分贝|Decibel分类形式|Block form分离器|Separator分区索引图|Key plan分析设计时间|Analytical engineering phase分析室|Analyzer room分子筛|Molecular sieve分组形式|Block form酚醛漆|Phenolic paint焚烧炉|Incinerator风荷载|Wind load风机|Fan风门挡板|Damper风速|Wind velocity封底焊|Back run welding峰值应力|Peak stress缝隙腐蚀|Crevice corrosion呋喃树脂|Furan resin伏特|Volt (V)氟塑料|Fluoroplastics浮动球阀|Floating ball type浮球式疏水阀|Float trap浮桶式疏水阀|Open bucket trap ; open top bucket trap符号|Symbol辐射段|Radiant section辅助锅炉|Auxiliary boiler腐蚀|Corrosion腐蚀试验|Corrosion test腐蚀裕量|Corrosion allowance附加位移|Appendant displacement ; externally imposed displacement 附件|Accessory附录|Appendix附属设备|Accessory复合钢|Clad steel复合管|clad pipe复式安全泄气阀|Twin type safety valve腹板|Web覆盖层|Coating盖阀|Flat valve干式气柜|Dry gas-holder干燥器|Dryer感应硬化|Induction hardening刚性的|Rigid刚性吊架|Rigid hanger钢板|Plate钢带|Strap steel钢管|steel pipe钢管法兰|steel pipe flange钢环|Steel ring钢结构|Steel structure钢结构顶面|Top of steel钢筋混凝土结构|Reinforced concrete construction钢索|Cable杠杆|Lever杠杆重锤式|Lever and weight type高度|Height高硅铸铁|High silicon cast iron高合金钢|High alloy steel高强度钢|High strength steel高碳钢|High-carbon steel高温淬火|Hot quenching高压|High pressure (H.P.)高压蒸汽|High pressure steam隔断阀|Isolating valve隔膜阀|Diaphragm valve隔墙|Partition wall隔热|Insulation隔热分界|Insulation break隔声|Sound insulation铬钢|Chromium steel铬钼钢|Chrome-molybdenum steel铬镍钢|Chromium-nickel steel ; chrome-nickel steel 铬镍铁合金|Inconel给水加热器|Feed water heater根部阀|Primary valve,Root valve根部间隙|Root gap根部裂纹|Root crack根部未焊透|Incomplete penetration更衣室|Locker room工厂|Plant工厂北向|Plant north工厂焊接|Shop weld工厂区界|Plant limit工程规定|Engineering specification工程手册|Engineering manual工程图|Engineering drawing工具钢|Tool steel工日|Man-day (M/D)工时|Man-hour (M/H)工业废水|Industrial waste water工艺空气|Process air工艺流程图|process flow diagram[PFD]工艺气体|Process gas工艺水|Process water工艺液体|Process liquid工字钢|I-beam工作程序|Working procedure工作点|Working point (W.P.)工作荷载|Working load工作温度|Operating temperature工作压力|Operating pressure ;working pressure公差|Tolerance公称压力|Nominal pressure (PN)公称直径|Nominal diameter (DN) ;nominal (pipe) size 公斤|Kilogram (kg)公用工程流程图|utility flow diagram[UFD]公用工程站|utility station公制螺纹|Metric thread功率因子|Power factor攻螺孔|Tapped ；tapping供应者|supplier共聚物|Copolymer共振|Resonance沟槽|Trough沟底|Bottom of trench构件|Member估价|Estimated price估算|Estimate鼓风机|Blower固定鞍座|Fixed saddle固定点|Fix point ; anchor point固定架|Anchor固有频率|Natural frequency固有振动型式|Natural frequency mode顾客|Client ; customer观察孔|Observation door ; peep door管部附着件|Pipe attachment管道泵|Inline pump管道表|Nomenclature管道布置|Piping layout管道布置平面|Piping arrangement plan (PAP)管道材料规定|Piping material specification管道等级|Piping class ; piping classification管道等级号|Class designation管道附件|Piping attachment管道及仪表流程图|piping and instrument flow diagram[PID] 管道跨距|Line span管道盲板阀|Line-blind valve管道柔性分析|Piping flexibility analysis管道设计|Piping design管道特殊组件|Piping special element管道询价表|Piping requisition sheet管道研究|Piping study管道组件|Piping element管道支吊架|Pipe supports and hangers管道支吊架图|Piping support drawing管道组成件|Piping component管底|Bottom of pipe (BOP)管顶|Top of pipe (TOP)管段|Spool piece ; spool管墩，低管架|Sleeper管沟|Piping trench管架零部件|Attachment of support管间距|Line spacing管件|fitting管件直接|Fitting to fitting (FTF)管接头|coupling;\r\nfull coupling管卡|Clamp管壳|Shell管口|Nozzle管口表|List of nozzles管口方位|Nozzle orientation管廊|Pipe rack管螺纹|Pipe thread管螺纹连接|Threaded joint ; pipe threaded joint管帽|cap[c]管托|Shoe管网|Network of pipes管系|Piping system管线表|Line list ;line schedule管线号|Line number管支架型式|Type of pipe support管子|Pipe;tube管子（按照配管标准规格制造的）|pipe管子（不按照配管标准规格制造的其他用管）|tube 管子内底|Invert (inside bottom of pipe)惯性矩|Moment of inertia盥洗室|Closet ; lavatory ; toilet灌浆|Grouting罐|Drum罐底排污阀|Flush-bottom tank valve罐区|Tank yard光滑的|smooth光滑突面|smooth raised face [SRF]规划布置阶段|Planning stage (phase)硅酸钙|Calcium silicate硅酸铝纤维|Aluminosilicate fiber硅藻土|Kieselguhr ; diatomite; diatomaceous earth滚动支架|Rolling support锅炉|Boiler锅炉给水|Boiler feed water锅炉给水泵|Boiler feed water pump过道|Walk way ; gangway ; access way过滤器|Filter过氯乙烯漆|Ethylene perchloride paint过热敏感性|Superheated susceptivity过热器|Super heater过热蒸汽|Superheated steam过氧树脂漆|Ethylene perchloride paint海拔|Altitude海平面标高|Over-sea mean level (OSL)焊穿|Burn through焊接|Welding焊接板式法兰|welding plate flange焊接端|Welding end焊接阀盖|Welded bonnet [WB]焊接符号|Symbol of weld焊接钢管|welded steel pipe焊接工艺评定试验|Welding procedure qualification test 焊接检验|Welding inspection焊接接头|Welded joint ; welding joint焊接裂纹|Weld crack焊接缺陷|Defects of welding焊接位置|Welding position焊接线|Welding line焊接形式|Type of welding焊接支管|Branch pipe welded directly to the run pipe焊接支管台|weldolet焊接种类|Varieties of welding焊瘤|Overlap焊丝|Welding wire焊条|Welding electrode (rod)焊药|Flux毫米|Millimeter (mm)合成塔|Synthesis tower合成橡胶|Synthetic rubber合金钢|Alloy steel合金钢管|alloy steel pipe合金结构钢|Structural alloy steel荷载|Load荷载工况|Load case褐色的|Brown黑色金属|Ferrous metal恒力吊架|Constant hanger恒温式疏水阀|Thermostatic trap桁架|Girder横向变形系数|Poisson ratio红色的|Red后冷却器|After cooler厚度|Thickness (THK)呼吸阀|Breather valve弧度|Radian (rad)弧坑|Pit ; crater华氏|Fahrenheit (F)滑动鞍座|Sliding saddle滑动吊板|Sliding traveler (for hanger)滑动阀杆|Sliding stem滑动架|Sliding support滑轮组|Tackle-block滑套法兰|Slip-on flange (SO); slip-on welding flange滑套法兰（包括平焊法兰）|slip-on flange[SO];\r\nslip-on welding flange 化粪池|Septic tank化学分析|Chemical analysis化学清洗|Chemical cleaning化学污水|Chemical sewage环垫接头|Ring joint (RJ)环箍|Circumferential band环境温度|Ambient temperature环连接面|ring joint face环头螺栓|Eye bolt环形连接金属垫片|ring joint metal gasket环形平垫片|flat ring gasket环形弯管|circle bend环氧树脂|Epoxy ; epoxy resin环氧树脂漆|Epoxy resin paint缓冲罐|Knock out drum缓冲筒|Dash pot换热器|Heat exchanger换向阀|Diverting valve ; reversing valve黄色的|Yellow黄铜|Brass灰色的|Grey (gray)灰铸铁|Grey cast iron回火脆性|Temper brittleness回热炉|Direct-fired heater回收|Recovery回水|Tempering回转半径|Radius of gyration回转窑|Rotary kiln汇总表|summary sheet会签|Inter-department check惠氏螺纹|Whitworth thread混合阀|mixing valve混合器|Mixer混凝土顶面|Top of concrete活荷载|Live load活接阀盖|Union bonnet活接阀盖( 帽)|union bonnet [cap]活接阀帽|Union cap活接头|union活塞式止回阀|Piston check valve火炬|Flare火炬气|Flare gas火焰表面淬火|Flame surface quenching机螺钉|Machine bolt机螺栓|Machine bolt机械式疏水阀|Mechanical trap机械振动|Mechanical vibration基层金属|Base metal基础|Foundation ;footing基础设计|Basic design激发|Excitation激振|Excitation极惯性矩|Polar moment of inertia极软退火|Dead-soft annealing极限强度|Ultimate strength急冷器|Quencher集水池|Catch basin集液包|Drip leg集液排放阀|Drip valve集中品质|Lumped mass挤压|Extruding挤压阀|Squeeze valve （用于泥浆及粉尘等）挤压机|Extruder计量泵|Metering pump计量槽|Measuring tank计算机辅助设计|Computer aided design （CAD）计算书|Calculation sheet技术说明|Technical specification加厚的|Extra heavy ; extra strong加料槽|Feed tank加强板|Stiffener加强的|Extra heavy ; extra strong加强圈|Reinforcing ring加热器|Heater夹板|Cleat夹紧式胶管阀|Pinch valve(用于泥浆、粉尘等)夹棉织物的橡胶|elastomer with cotton fabric insertion夹石棉的缠绕金属垫片|Spiral-wound metal gasket with asbestos filler夹石棉织物的橡胶|elastomer with asbestos fabric insertion夹石棉织物及金属丝加强的橡胶|elastomer with asbestos fabric insertion and with wire reinforcement夹套阀|Jacketed valve夹套管|Jacketed line ;jacketed piping夹渣|Slag inclusion甲烷化器|Methanator架顶面|Top of support ((TOS)间断焊|Intermittent welding间隔管|Spacer间隙|Clearance减温器|Desuperheater减压阀|Pressure reducing valve ; reducing valve减振器|Snubber减振装置|Damping device剪切应力|Shear stress检查孔|Inspection hole检验|Inspection碱性水|Brackish water件号|Part number建设|Construction建筑物|Building键|Key交变应力|Alternating stress交货单|Delivery order (D/O)交流|Alternating current胶粘剂|Adhesive焦耳|Joule (J)焦炭塔|coke drum\r\ncoke tower角板|Gusset角阀|Angle valve角钢|Angle steel角焊|Fillet welding角位移|Angular rotation搅拌器|Agitator接触腐蚀|Contact corrosion接地|Grounding ; earthing接地板|Earth lug界面|Spool piece ; spool接受槽|Receiver接线箱盒|Junction box接续图|Continue on drawing (COD)接续线|Match line (M.L.)节点|Node节点号|Node number节距|Pitch节流闪阀|Throttle valve结晶器|Crystallizer截止阀|Globe valve界区条件|Battery limit condition界外|Off site金相试验|Microscopic test金属包石棉平垫片|flat metal jacketed asbestos filled gasket金属保护层|Clad ; metal jacketing ; cladding metal金属极惰性气体保护电弧焊|Gas metal arc welding (GMAW)金属膨胀式蒸汽疏水阀|Metal expansion steam trap金属软管|Metal hose金属填料|Metallic stuffing筋|rib紧凑型|compact type进料|Feed浸聚四氟乙烯的石棉垫片|PTFE impregnated asbestos gasket 浸聚四氟乙烯的石棉填料|Teflon impregnated asbestos packing 晶间腐蚀|Intergranular corrosion精馏塔|Fractionating tower精制的|Finished ; fine井|Well净化器|Purifier净空|Head room净正吸入压头|Net positive suction head (NPSH)净重|Net weight静电|Static electricity静荷载|Dead load就地盘|Local panel局部退火|Spot annealing剧烈循环条件|Severe cyclic condition距离|Distance聚氨基甲酸酯|Polyurethane聚氨酯|Polyurethane聚氨酯漆|Polyurethane paint聚苯乙烯|Polystyrene (PS)聚丙烯|Polypropylene (PP)聚丁烯|Polybutylene (PB)聚合釜|Polymerizer聚合物|Polymer聚甲基丙烯酸甲酯|Polymethyl methacrylate (PMMA) 聚氯乙烯|Polyvinyl chloride (PVC)聚偏二氟乙烯|Polyvinylidene fluoride (PVDF)聚四氟乙烯|Polytetrafluoroethylene (PTFE)聚四氟乙烯滑动板|PTFE sliding plate聚碳酸酯|Polycarbonate (PC)聚烯烃|Polyolefin (PO)聚酰胺|Polyamide (PA)聚乙烯|Polyethylene (PE)聚酯树脂|Polyester resin聚酯纤维|Polyester fibers绝对标高|Absolute elevation均方根|root mean square [RMS]均聚物|Homopolymer竣工图|As built drawing开车|Start-up开工会议|Kick-off meeting ; launching meeting开口销|Cotter pin开口楔形闸板|split wedge抗拉强度|Tensile strength抗弯强度|Bending strength抗压强度|Compressive strength可程序设计控制器|programmable controller 可淬性|Hardenability可调夹板|Adjustable cleat可调支架|Adjustable support可锻铸铁|Malleable iron (MI)可更换的阀座环|renewable seat ring可燃的|Flammable可转动的阀盘|Swivel disc克|Gram (g)空分装置|Air separation facility空冷器|Air cooler空气|Air孔板|Orifice孔板法兰|orifce flange控制阀|Control valve控制室|control room苦咸水|Brackish water裤衩|True “Y”跨度|Span跨越弯管|Cross-over bend跨越弯管（︹形）|cross-over bend快闭阀|Quick closing valve快开阀|Quick opening valve快速操纵器|quick-acting operator快速接头|Quick coupling宽度|Width宽缘工字钢或H钢|Wide flanged beam矿棉|Mineral wool扩口试验|Flaring test拉伸试验|Tension test拉应力|Tension stress栏杆|Handrail蓝色的|Blue肋|rib类别|Class (CL)冷拔无缝钢管|cold-drawing seamless pipe 冷脆|Cold shortness冷冻机|Refrigerator冷冻剂|Refrigerant冷加工|Cold working冷拉|Cold spring冷流|Cold flow冷凝器|Condenser冷却水|Cooling冷却塔|Cooling tower冷态荷载|Cold load冷轧|Cold rolling离岸价格|Free on board (FOB)离心泵|Centrifugal pump离心分离机|Centrifugal separator离心过滤机|Centrifugal filter离心机|Centrifuger离心式压缩机|Centrifugal compressor力|Force力矩|Moment力偶|Couple of force立方米|Cubic meter (m3)立焊|Vertical welding立面|Elevation (EL)立式的|Vertical沥青|Asphalt沥青漆|Bituminous paint沥青毡|Asphalt felt连杆式蝶阀|Link butterfly valve连接板|Tile plate;Gusset连接杆|Tie rod;Connecting rod连接图|Hook up drawing联锁|Interlock链轮|chain wheel链条操纵的|chain operated梁|Beam梁顶面|Top of beam (TOB)两端带螺纹|Both end thread (BET)两端平|Both end plain (BEP)料仓|Silo ; bin料斗|Hopper裂化炉|Reformer临界点|Critical point临界温度|Critical temperature临界压力|Critical pressure临时粗滤器|Temporary strainer临时荷载|Temporary load磷青铜|Phosphor bronze流程图|Flow diagram流量计|Flow meter流体|Fluid流体特性|Fluid characteristics硫酸|Sulphuric acid六角钢|Hexagonal steel bar六角螺母|Hexagonal nut六角头螺栓|Hexagonal head bolt龙头|Bibb ; bib ; faucet笼式环|lantern ring楼面|Floor楼梯|Stair ;stair way漏斗|Funnel炉管|Furnace tube炉子|Furnace卤气泄漏试验|Halogen gas leak test路肩|Shoulder铝|Aluminum铝板|Aluminium sheet铝镁合金|Aluminum magnesium铝青铜|Aluminum bronze绿色的|Green氯丁橡胶|Neoprene氯化聚氯乙烯|Chlorinated polyvinyl chloride (CPVC) 氯化聚醚|Chlorinated polyether (CPE)罗茨鼓风机|Roots blower螺杆压缩机|Helical screw compressor螺距|Pitch of thread螺孔|Tap螺母|Nut螺栓|Bolt螺栓连接的阀盖|bolted bonnet [BB]螺栓连接的阀帽|bolted cap [BC]螺栓圆|bolt circle [B.C.]螺纹的|Threaded (THD)螺纹端|Threaded end (TE)螺纹阀盖|screw bonnet螺纹阀帽|screw cap螺纹法兰|threaded flange螺纹连接|Threaded joint ; pipe threaded joint螺纹支管台|threadolet螺旋板式换热器|Spiral plate heat exchanger螺旋焊接钢管|spiral welded steel pipe螺旋式气柜|Helical gas-holder螺柱|Stud bolt裸管|Bare line洛氏硬度|Rockwell hardness落球式止回阀|Ball check valve马丁钢|Martin steel马氏体不锈钢|Martensitic stainless steel玛帝脂保护层|Mastic weatherproof coating码头交货|Ex wharf ; Ex pier脉冲式蒸汽疏水阀|Impulse steam trap脉动|Pulsation脉动应力|Pulsating stress满平面|flat face;\r\nfull face [FF]毛重|Gross weight锚固件|Clip铆钉|Rivet美国标准锥管螺纹|American standard taper pipe thread (NPT) 美国线规|American wire gage (AWG)门|Door蒙乃尔|Monel锰青铜|Manganese bronze米|Meter (m)密度|Density密封圈|seat ring密封油|Sealing oil棉毡|Blanket面积；区域|Area面内|In-plane面漆|Finishing coat面外|Out-plane面至面|Face to face (F-F)秒|Second (s)灭火器|Fire extinguisher明杆|Rising stem (RS)命名表|Nomenclature模型|Model膜式控制阀|Diaphragm operated control valve母材|Base metal母液|Mother liquor木材|Wood木块|Wood block木箱|Wooden box目录|Index钼钢|Molybdenum steel内部审查版设备布置图|Internal approval plot plan (“B” issue) 内侧厚度切斜角|Bevel for inside thickness内环|inner ring内径|Inside diameter (ID)内力|Internal force内螺纹|inside screw[IS]内外侧厚度切斜角|Bevel for combined thickness内外螺纹缩接|Bushing内外螺纹缩接（俗称补芯）|bushing内压应力|Internal pressure stress耐火型|Fire safe type耐火砖|Fire brick耐碱漆|Alkali-proof paint耐热钢|Heat resisting steel耐热铬镍铁合金|Incoloy耐热漆|Heat-proof paint耐蚀耐热镍基合金|Hastelloy耐蚀性|Corrosion resistance耐酸漆|Acid-proof paint耐温漆|Thermo-paint耐震等级|Seismic class南|South (S)挠度|Deflection挠性管|flexible tube挠性整体楔形闹板|flexible solid wedge挠性整体楔形闸板|Flexible solid wedge尼龙塑料|Nylon plastic逆时针方向|Counter clock wise脲醛树脂|Urea resin镍钢|Nickel steel镍及铜合金|Monel镍铜合金|Nickel copper alloy凝固点|Freezing point牛顿|Newton (N)扭矩|Torque扭转应力|Torsional stress浓度|Concentration奥姆|Ohm排出阀|Discharge valve排出口|Exhaust排空|Evacuation排污|Blow down排污阀|Blowdown valve排污罐|Blow down tank排液|Drain排液阀|Drain valve排液环|Drip ring排液漏斗|Drain funnel盘|Panel盘座式法兰|pad type flange旁路|By pass旁路阀|By-pass valve泡沫玻璃|Foam glass ; cellular glass泡沫混凝土|Foamed concrete;cellular concrete泡沫聚苯乙烯|Cellular polystyrene ; foam polystyrene泡沫炮|Foam monitor泡沫栓|Foam hydrant泡沫消防|Foam fire-fighting泡沫站|Foam station配电盘|Switch board配电室|Substation ; switch room配对法兰|companion flange喷咀|Spray nozzle喷射泵|Jet pump喷射器|Ejector喷头|Sprayer棚|Shelter硼硅玻璃|Borosilicate glass膨胀节|Expansion joint膨胀螺栓|Expansion bolt批准用于规划布置|Approved for planning (AFP)批准用于设计|Approved for design (AFD)批准用于施工|Approved for construction (AFC)皮带输送机|Belt conveyor疲劳极限|Fatigue limit疲劳试验|Fatigue test偏心阀板蝶阀|Offset disc butterfly valve ; eccentric butterfly valve 偏心异径管|eccentric reducer偏置弯管|offset bend频率|Frequency平板式滑动闸阀|Slab type sliding gate valve平垫片|flat gasket平垫圈|Plain washer平端|Plain end (PE)平方毫米|Square millimeter (mm2)平方米|Square meter (m2)平焊|Flat welding平焊法兰|Slip-on flange (SO); slip-on welding flange平焊环|welding-on collar平金属垫片|flat metal gasket平炉钢|Martin steel平面|Plan平台|Platform (PF)平行|Parallel平行的|Parallel平行双闸板|double disc parallet seat评标|Evaluation坡度|Slope坡口|Groove坡口端|Beveled end (BE)破真空|Vacuum breaker破真空阀|Vacuum breaker铺砌区|Paving area普通低合金结构钢|General structure low-alloy steel 普通热处理|Conventional heat treatment普通碳素钢|General carbon steel谱分析|Spectrum analysis漆酚树脂漆|Urushiol resin paint起重机|Crane气动操纵器|pneumatic operator气动阀|Pneumatic operated valve气缸|Cylinder气缸( 或液压缸) 操纵的|cylinder operated气缸操纵的|Cylinder operated气柜|Gas-holder气焊|Gas welding ; flame welding气化器|Vaporizer气孔|Porosity ; blow hole气密试验|Air tightness test气熔焊|Fusion gas welding (FGW)气蚀|Cavitation erosion气体保护电弧焊|Gas-shielded arc welding气体分析|Gas analysis气相腐蚀|Gaseous corrosion气象色谱仪|Gas chromatograph气压试验|Pneumatic test汽包|Steam drum汽轮机|Steam turbine汽提塔|Stripper千磅|Kilopounds (Kip)千克|Kilogram (kg)千瓦|Kilowatts (kW)铅|Lead墙|Wall墙架|Support on wall桥式起重机|Bridge crane切断阀|Block valve ;shut-off valve;stop valve切断式止回阀|Stop check valve ; non-return valve切割使适合|Cut to suit切线|Tangent line青铜|Bronze氢脆|Hydrogen embrittlement氢气|Hydrogen轻的|Light清漆|Varnish清扫口|Clean out请购|Requisitioning球阀|Ball valve球罐|Spheroid ; spherical tank球化退火|Spheroids annealing球面垫圈|Spherical washer球墨铸铁|Nodular cast iron ; nodular graphite iron球心型阀盘|Globe type disc球形补偿器|Ball type expansion joint flexible ball joint 区界|Area limit区域边界|Zone limit屈服点|Yield point屈服极限|Yield limit取样阀|Sampling valve取样界面|Sampling connection取样冷却器|Sample cooler全夹套的|Full jacketed全平面|flat face;\r\nfull face [FF]全平面；满平面|Flat face ; full face (FF)确认版设备布置图|Confirm plot plan (“D” issue)裙座|Skirt燃料气|Fuel gas燃料油|Fuel oil燃气轮机|Gas turbine热处理|Heat treatment热电偶|Thermocouple热动力式疏水阀|Thermodynamic trap热固性塑料|Thermosetting plastics热加工|Hot working热膨胀阀|Thermo expansion valve热膨胀系数|Thermal expansion coefficient 热水|Hot water热水伴热|hot-water tracing热塑性塑料|Thermoplastic热循环|Thermal cycle热应力|Thermal stress热应力分析|Thermal stress analysis热影响区|Heat affected zone (HAZ)热轧|Hot rolling热轧无缝钢管|hot-rolling seamless pipe 人孔|Manhole (MH)人身保护|Personal protection人月|Man-month (M/M)韧性|Toughness容器|Vessel溶剂|Solvent溶剂胶接剂|Solvent cement溶液|Solution溶液贮罐|Solution storage tank融点|Melting point融解槽|Melter融热层|Insulation柔度特性|Flexibility characteristic柔性|Flexibility柔性系数|Flexibility factor柔性应力|Flexibility stress肉眼检验|Visual inspection蠕变断裂强度|Creep rupture strength蠕变极限|Creep limit入口|Inlet ; suction入口中心线|Center line of suction软管阀|Hose valve软管接头|Hose connection (HC)软管卷盘|Hose reel软管站|Hose station (HS)软化装置|Softener软木|Cork wood软钎焊连接|Soldered joint软水|Soft water润滑油|Lubricating oil洒水器|Sprinkler塞焊|Plug welding塞型阀盘|Plug type disc塞型闸阀|Plug gate valve三角架|Triangular support三节斜接弯管|3-piece mitre bend三通|tee三通阀|Three way valve三通球阀|3-way ball valve三通旋塞阀|Three-way plug valve伞齿轮传动|bevel gear operated散装材料|Bulk material砂眼|Blister闪点|Flash point闪蒸罐|Flash drum上|Up上升管|Riser尚海波|shb烧碱|Caustic soda烧咀|Burner设备|Apparatus设备表|Equipment list (schedule)设备布置及管道布置|Plot plan and piping layout ; equipment and piping arrangement设备名称|Equipment name设备位号|Equipment item number设计版设备布置图|Designing plot plan (“F” issue)设计规定汇总表|Design specification summary sheet (DSSS)设计基础数据|Basic engineering design data设计经理|Design manager设计深度|target depth设计手册|Engineering manual设计温度|Design temperature设计档|Design document设计响应谱|Design response spectrum 设计压力|Design pressure设计震度|Design seismic coefficient设计注释|Design note设施|Facilities射线检验|Radiographic test (RT)摄氏|Celsius (C)伸出长度|Extrusion深度|Depth深井泵|Deep well pump深冷器|Chiller深色的|Dark审定|Approval审核提纲|Check list渗氮|Nitridation渗铬|Chromizing渗铬钢，镀铬纲|Chromized steel渗滤井|Soak-away pit渗铝|Aluminizing渗碳|Carbonization升|Liter ; litre (L)升杆式|Rising stem (RS)升杆式( 明杆)|rising stem [RS]升降式止回阀|Lift check valve升压器|Booster生根件|Clip生活污水|Sanitary sewer生铁|Pig iron声强|Sound intensity声压值|Sound pressure level声源|Sound source省煤器|Economizer盛水试验|Full water test施工版设备布置图|Construction plot plan (“G” issue)湿度|Humidity湿式气柜|Wet gas-holder石棉安全密封|Asbestos emergency seal石棉板|Asbestos board石棉布|Asbestos cloth石棉绳|Asbestos rope ; asbestos cord石棉织品|Asbestos fabric石墨酚醛塑料|Graphite phenolic plastics石脑油|Naphtha时效处理|Ageing treatment事故切断阀|Emergency valve视镜|Sight glass试车|Commissioning ; running-in试验|Test手柄|hand lever (handle)手动阀|Hand-operated valve; manually operated valve手动葫芦|Chain block手工或自动惰性气体保护钨极电弧焊|Manual and automatic inert gas tungsten arc welding (GTAW)手孔|Handhole (HH)手轮|hand wheel手摇泵|Hand-pump ; wobble pump输送机|Conveyor熟铁，锻铁|Wrought iron树脂|Resin数据表|Data sheet数据库|Data base数量|Quantity (QTY)衰减系数|Decay factor ;decay coefficient ; attenuation constant双板对夹式止回阀|Dual plate wafer type check valve双倍加厚的|Double extra heavy ; double extra strong双倍加强的|Double extra heavy ; double extra strong双波|Double bellow双夹套波纹金属包石棉垫片|corrugated metal double jacketed asbestos filled gasket双夹套垫片|double jacket gasket双金属膨胀式蒸汽疏水阀|Bimetallic expansion steam trap。

● 1.2 管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头（右向或左向）side outlet elbow (right hand or left hand）双支管弯头（形） double branchelbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通（右向或左向） side outlet tee （right hand or 1eft hand）异径三通（分支口为异径)reducing tee （reducing on outlet)异径三通（一个直通口为异径）reducing tee (reducing on one run）带支座三通 base tee异径三通（一个直通口及分支口为异径） reducing tee （reducing on one run and outlet）异径三通(两个直通口为异径，双头式） reducing tee (reducing on both runs, bull head)45°斜三通 45° lateral45°斜三通(支管为异径） 45° lateral （reducing on branch)45°斜三通（一个直通口为异径） 45° lateral (reducing on one run）45°斜三通(一个直通口及支管为异径） 45° lateral (reducing on one run andbranch)Y型三通（俗称裤衩）true “Y”四通 cross等径四通 straight cross异径四通reducing cross异径四通（一个分支口为异径）reducing cross (reducing on one outlet)异径四通（一个直通口及分支口为异径） reducing cross (reducing on one run and outlet）异径四通（两个分支口为异径） reducing cross （reducing onboth outlet）异径四通（一个直通口及两个分支口为异径） reducing cross (reducing on one run and both outlet）异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台sockolet弯头支管台 elbolet斜接支管台latrolet镶入式支管嘴sweepolet短管支管台 nipolet支管台，插入式支管台 boss●螺纹支管台Threadolet●弯头支管台elbolet●焊接支管台weldolet；on weld●短管支管台nipolet●承插支管台sockolet●烧焊支管台weldolet●斜接支管台latrolet●承插焊支管台Sockolet●支管台，插入式支管台boss管接头 coupling， full coupling半管接头 half coupling异径管接头 reducing coupling活接头union内外螺纹缩接（俗称补芯） bushing管帽cap （C)堵头 plug短节 nipple异径短节 reducing nipple； swage nipple管道英文缩写A Anchor 固定ABS ＊Absolute 绝对的AISI ＊American Iron andSteelInstitute 美国钢铁学会ANSI *American National Standards Institute 美国国家标准学会API *American Petroleum Institute 美国石油学会APPROX ＊Approximate 大约,近似的ASB Asbestos 石棉ASME *American Society Of Mechanical Engineers美国机械工程师协会ASSY *Assembly 装配，组装ASTM *American Society Of Testing Material 美国材料实验协会ATM ＊Atmosphere 大气压AWG ＊American Wire Gage 美国线规AWS ＊American Wel＊*＊* Society 美国焊接协会AWWA *American Water WorksAssociation 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B-B Beveled End—Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆B。

1 管道组成件 Piping component............................... 2 1.1 管子 Pipe ........................................................... 2 1.2 管件 Fitting ....................................................... 2 1.3 弯管 Bend.......................................................... 3 1.4 法兰 Flange (FLG） ...................................... 3 1.5 垫片 Gasket (GSKT)..................................... 4 1.6 阀门 Valve......................................................... 4 1.6.1 阀门结构、零件................................... 4 1.6.2 常用阀..................................................... 5 1.6.3 其它用途的阀....................................... 6 1.6.4 未指明结构（或阀型）的阀............ 7 1.7 管道特殊件 Piping Specialty...................... 8 1.7.1 管道特殊件（组件） ......................... 8 1.7.2 管 道 特 殊 元 件 Piping Special Element............................................................... 8 1.8 端部连接 End Connection........................... 82 管道用紧固件及螺纹.................................................. 9 2.1 紧固件.................................................................. 9 2.2 螺纹 .................................................................... 103 材料、型钢及填料..................................................... 10 3.1 金属材料........................................................... 10 3.1.1 黑色金属 Ferrous Metal.................. 10 3.1.2 镀层及制造方法................................. 11 3.1.3 有色金属 Non-ferrous Metal........... 11 3.1.4 材料性能 .............................................. 11 3.2 非金属材料 Non- metallic Material........12 3.3 型材 .................................................................... 13 3.4 填料及填料函.................................................. 134 管道等级及材料统计................................................ 13 4.1 管 道 材 料 规 定 Piping MaterialSpecification............................................................ 13 4.2 材料统计 Material Take- off (MTO.)..... 14 5 设备布置及管道布置................................................ 14 5.1 设备名称 Equipment Name ..................... 145.1.1 容器 Vessel......................................... 14 5.1.2 工业炉及锅炉..................................... 15 5.2 辅助用房名称................................................. 15 5.2.1 生产用房.............................................. 15 5.2.2 生活用房.............................................. 16 5.3 图名.................................................................... 16 5.4 厂房、站、单元............................................ 16 5.5 设备布置.......................................................... 16 5.6 管道布置.......................................................... 17 5.7 图面标注.......................................................... 18 5.8 相关专业的专业词汇................................... 18 5.8.1 工艺....................................................... 18 5.8.2 建筑、结构......................................... 20 5.8.3 仪表....................................................... 20 5.8.4 电气....................................................... 21 5.8.5 设备....................................................... 21 5.8.6 水道....................................................... 22 6 管道支吊架 Pipe Supports and Hangers.......... 22 6.1 管架零部件 Attachment of Support...... 22 6.2 管支架型式 Type of Pipe Suppor.t......... 23 6.3 标准及通用型支架........................................ 24 6.4 管架安装.......................................................... 24 7 应力计算....................................................................... 24 8 隔热、隔声.................................................................. 26 9 防腐、涂漆及腐蚀种类........................................... 27 10 焊接 Welding ........................................................... 281 / 32化工管道设计技术词汇（中英对照完整版）10.1 焊接种类 Varieties of Welding.............. 28 10.2 焊接形式 Type of Welding...................... 28 10.3 焊接位置 Welding Position..................... 28 10.4 焊接缺陷 Defects of Welding................. 28 10.5 其它.................................................................. 29 11 热处理 Heat Treatment......................................... 29 11.1 普 通 热 处 理 Conventional Heat Treatment................................................................. 29 11.2 表面热处理 Surface Heat Treatment..29 12 检验及试验................................................................ 29 12.1 检验 Inspection........................................... 29 12.2 试验 Test....................................................... 30 13 设计阶段及管理....................................................... 30 14 询价、报价及采购................................................... 31 14.1 询价、报价.................................................... 31 14.2 采购 Procurement; Purchase................. 31 15 单位 Unit ................................................................... 32橡胶管 rubber tube 直管 run pipe; straight pipe化工管道设计技术词汇（中英对照完整版）1 管道组成件Piping component1.2 管 件 Fitting1.1 管 子 Pipe管子(按照配管标准规格制造的) pipe 管子(不按配管标准规格制造的其他用管) tube 钢管 steel pipe 铸铁管 cast iron pipe 衬里管 lined pipe 复合管 clad pipe 碳钢管 carbon steel pipe 合金钢管 alloy steel pipe 不锈钢 stainless steel pipe 奥氏体不锈钢管 austenitic stainless steel pipe 铁合金钢管 ferritic alloy steel pipe 轧制钢管 wrought-steel pipe 锻铁管 wrought-iron pipe 无缝钢管 seamless (SMLS) steel pipe 焊接钢管 welded steel pipe 电阻焊钢管 electric-resistance welded steel pipe 电熔（弧）焊钢板卷管 electric-fusion (arc)-welded steel-plate pipe 螺旋焊接钢管 spiral welded steel pipe 镀锌钢管 galvanized steel pipe 热轧无缝钢管 hot-rolling seamless pipe 冷拔无缝钢管 cold-drawing seamless pipe 水煤气钢管 water-gas steel pipe 塑料管 plastic pipe 玻璃管 glass tube弯头 elbow 异径弯头 reducing elbow带支座弯头 base elbow k 半径弯头 long radius elbow 短半径弯头 short radius elbow长半径 180°弯头 long radius return 短半径 180°弯头 short radius return 带侧向口的弯头（右向或左向） side outlet elbow (right hand or left hand) 双支管弯头（ 形） double branch elbow三通 tee 异径三通 reducing tee 等径三通 straight tee带侧向口的三通（右向或左向） side outlet tee (right hand or 1eft hand) 异径三通（分支口为异径） reducing tee (reducing on outlet) 异径三通（一个直通口为异径）reducing tee (reducing on one run)带支座三通 base tee 异径三通（一个直通口及分支口为异径） reducing tee (reducing on one run and outlet) 异径三通（两个直通口为异径，双头式） reducing tee (reducing on both runs, bull head) 45°斜三通 45° lateral 45°斜三通（支管为异径） 45° lateral (reducing on branch) 45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch)2 / 32化工管道设计技术词汇（中英对照完整版）Y 型三通（俗称裤衩） true “Y” 四通 cross 等径四通 straight cross异径短节 reducing nipple; swage nipple1.3 弯 管 Bend异径四通 reducing cross预制弯管 fabricated pipe bend异径四通（一个分支口为异径）reducing cross (reducing on one outlet) 跨越弯管（^ 形） cross-over bend异径四通（一个直通口及分支口为异径） reducing cross (reducing on 偏置弯管（~ 形） offset bendone run and outlet)90°弯管 quarter bend异径四通（两个分支口为异径） reducing cross (reducing on both outlet) 环形弯管 cirele bend异径四通（一个直通口及两个分支口为异径） reducing cross (reducing 单侧偏置 90°弯管（? 形） single offset quarter bendon one run and both outlet) 异径管 reducer 同心异径管 concentric reducer 偏心异径管 eccentric reducer锻制异径管 reducing swage 螺纹支管台 threadolet 焊接支管台 weldolet承插支管台 sockolet 弯头支管台 elboletS 形弯管 “S” bend 单侧偏置 U 形膨胀弯管（| ?形） single offset “U” bend U 形弯管 “U” bend 双偏置 U 膨胀弯管 double offset expansion “U” bend 斜接弯管 mitre bend 三节斜接弯管 3-piece mitre bend 折皱弯管 corrugated bend 圆度 roundness斜接支管台 latrolet1.4 法 兰 Flange (FLG）镶入式支管嘴 sweepolet 短管支管台 nipolet 支管台，插入式支管台 boss 管接头 coupling, full coupling 半管接头 half coupling 异径管接头 reducing coupling 活接头 union 内外螺纹缩接（俗称补芯） bushing 管帽 cap (C) 堵头 plug 短节 nipple整体管法兰 integral pipe flange 钢管法兰 steel pipe flange 螺纹法兰 threaded flange 滑套法兰（包括平焊法兰） slip-on flange (SO); slip-on welding flange 承插焊法兰 socket welding flange 松套法兰 lap joint flange (LJF) 对焊法兰 welding neckflange (WNF) 法兰盖 blind flange, blind 孔板法兰 orifice flange 异径法兰 reducing flange 盘座式法兰 pad type flange3 / 32松套带颈法兰 loose hubbed flange 焊接板式法兰 welding plate flange 对焊环 welding neck collar （与 stub end 相似） 平焊环 welding-on collar 突缘短节 stub end, lap 翻边端 lapped pipe end 松套板式法兰 loose plate flange 压力级 pressure rating, pressure rating class 压力—温度等级 pressure-temperature rating 法兰密封面，法兰面 flange facing 突面 raised face (RF) 凸面 male face (MF) 凹面 female face (FMF) 榫面 tongue face 槽面 groove face 环连接面 ring joint face 全平面；满平面 flat face; full face (FF) 光滑突面 smooth raised face (SRF) 法兰面加工 facing finish 粗糙度 roughness 光滑的 smooth 齿形 serrated 均方根 root mean square (RMS) 算术平均粗糙高度 arithmetical average roughness height (AARH) 配对法兰 companion-flange 螺栓圆 bolt circle (B.C.)1.5 垫 片 Gasket (GSKT)垫片的型式 type of gasket 平垫片 flat gasket化工管道设计技术词汇（中英对照完整版）环形平垫片 flat ring gasket 平金属垫片 flat metal gasket 夹棉织物的橡胶 elastomer with cotton fabric insertion 夹石棉织物的橡胶 elastomer with asbestos fabric insertion 夹 石 棉 织 物 及 金 属 丝 加 强 的 橡 胶 elastomer with asbestos fabric insertion and with wire reinforcement 无 石 墨 压 缩 白 石 棉 垫 片 non graphited compressed white asbestos gasket 天然白橡胶垫片 natural white rubber gasket 压缩石棉垫片 compressed asbestos class gasket 浸聚四氟乙烯的石棉垫片 PTFE impregnated asbestos gasket 夹石棉的缠绕金属垫片 spiral-wound metal gasket with asbestos filler 内环 inner ring 外环，外定位环 outer ring 波纹金属垫片 corrugated metal gasket 波纹金属包嵌石棉垫片 corrugated metal gasket with asbestos inserted 双夹套波纹金属包石棉垫片 corrugated metal double jacketed asbestos filled gasket 双夹套垫片 double jacketed gasket 金属包石棉平垫片 flat metal jacketed asbestos filled gasket 整体金属齿形垫片 solid metal serrated gasket 槽形金属垫片 grooved metal gasket 环形连接金属垫片 ring joint metal gasket 八角环形垫片 octagonal ring gasket 椭圆环形垫片 oval ring gasket 透镜式垫片 lens gasket 非金属垫片 non-metallic gasket1.6 阀 门 Valve1.6.1 阀门结构、零件4 / 32阀轭 yoke 外螺纹阀杆及阀轭 outside screw and yoke (OS & Y) 阀杆 stem 内螺纹 inside screw (IS) 阀轭套 yoke sleeve 阀杆环 stem ring 阀座 valve seat (body seat) 阀座环、密封圈 seat ring 整体（阀）座 integral seat 堆焊（阀）座 deposited seat 阀芯（包括密封圈、杆等内件） trim 阀盘 disc 阀盘密封圈 disc seat 阀体 body 阀盖 bonnet 阀盖衬套 bonnet bush 螺纹阀帽 screw cap 螺纹阀盖 screw bonnet 螺栓连接的阀盖 bolted bonnet (BB) 活接阀盖（帽） union bonnet (cap) 螺栓连接的阀帽 bolted cap (BC) 焊接阀盖 welded bonnet (WB) 本体阀杆密封 body stem seal 石棉安全密封 asbestos emenen seal 倒密封 back seal 压力密封的阀盖 pressure-tight bonnet 动力操纵器 powered operator 电动操纵器 electric motor operator 气动操纵器 pneumatic operator 液压操纵器 hydraulic operator化工管道设计技术词汇（中英对照完整版）快速操纵器 quick-acting operator 滑动阀杆 sliding stem 正齿轮传动 spur gear operated 伞齿轮传动 bevel gear operated 扳手操作 wrench operated 链轮 chain wheel 手轮 hand wheel 手柄 hand lever (handle) 气缸（或液压缸）操纵的 cylinder operated 链条操纵的 chain operated 等径孔道 full bore; full port 异径孔道 reducing bore, reduced port,venturi port 短型 short pattern 紧凑型（小型） compact type 笼式环 lantern ring 压盖 gland 阀杆填料 stem packing 阀盖垫片 bonnet gasket 升杆式（明杆） rising stem (RS) 非升杆式（暗杆） non-rising stem (NRS) 指示器/限位器 indicator/stopper 注油器 grease injector 可更换的阀座环 renewable seat ring1.6.2 常用阀(1)闸阀 gate valve 平行双闸板 double disc parallel seat 开口楔形闸板 split wedge 挠性整体楔形闸扳 flexible solid wedge 整体楔形闸板 solid wedge5 / 32塞型闸阀 plug gate valve 直通型闸阀 through conduit gate valve (2) 截止阀 globe valve 球心型阀盘 globe type disc 塞型阀盘 plug type disc 可转动的阀盘 swivel disc (3) 节流闪阀 throttle valve 针阀 needle valve (4) 角阀 angle valve (5) Y 型阀（Y 型阀体截止阀） Y-valve (Y-body globe valve) (6) 球阀 ball valve 三通球阀 3-way ball valve 装有底轴的 trunnion mounted 耐火型 fire safe type 浮动球型 floating ball type 防脱出阀杆 blowout proof stem (7) 蝶阀 butterfly valve 对夹式（薄片型） wafer type 凸耳式 lug type 偏心阀板蝶阀 offset disc burerfly valve; eccentric butterfly valve 斜阀盘蝶阀 canted disc butterfly valve 连杆式蝶阀 link butterfly valve 8) 柱塞阀 piston type valve (9) 旋塞阀 plug valve 三通旋塞阀 three-way plug valve 四通旋塞阀 four-way plug valve 旋塞 cock 衬套旋塞 sleeve cock (10) 隔膜阀 diaphragm valve 橡胶衬里隔膜阀 rubber lined diaphragm valve化工管道设计技术词汇（中英对照完整版）直通式隔膜阀 straight way diaphragm valve 堰式隔膜阀 weir diaphragm valve (11) 夹紧式胶管阀 pinch valve（用于泥浆、粉尘等） (12) 止回阀 check valve 升降式止回阀 lift check valve 旋启式止回阀 swing check valve, flap check valve 落球式止回阀 ball check valve 弹簧球式止回阀 spring ball check valve 双板对夹式止回阀 dual plate wafer type check valve 无撞击声止回阀 non-slam cheek valve 底阀 foot valve 切断式止回阀 stop check valve; non-return valve 活塞式止回阀 piston check valve 斜翻盘止回阀 tilting disc check valve 蝶式止回阀 butterfly check valve1.6.3 其它用途的阀安全泄气阀 safety valve (SV) 安全泄液阀 relief valve (RV) 安全泄压阀 safety relief valve 杠杆重锤式 lever and weight type 引导阀操纵的安全泄气阀 pilot operated safety valve 复式安全泄气阀 twin type safety valve 罐底排污阀 flush-bottom tank valve 电磁阀 solenoid valve, solenoid operated valve 电动阀 electrically operated valve, electric-motor operated valve 气动阀 pneumatic operated valve 低温用阀 cryogenic service valve 蒸汽疏水阀 steam trap 机械式疏水阎 mechanical trap6 / 32化工管道设计技术词汇（中英对照完整版）浮桶式疏水阀 open bucket trap, open top bucket trap 浮球式疏水阀 float trap 倒吊桶式疏水阀 inverted bucket trap 自由浮球式疏水阀 loose float trap 恒温式疏水阀 thermostatic trap 金属膨胀式蒸汽疏水阀 metal expansion steam trap 液体膨胀式蒸汽疏水阀 liquid expansion steam trap 双金属膨胀式蒸汽疏水阀 bimetallic expansion steam trap 压力平衡式恒温疏水阀 balanced pressure thermostatic trap 热动力式疏水阀 thermodynamic trap 脉冲式蒸汽疏水阀 impulse steam trap 放气阀（自动放气阀） air vent valve (automatic air vent valve（) 疏水阀用）平板式滑动闸阀 slab type sliding gate valve 盖阀 flat valve 换向阀 diverting valve, reversing valve 热膨胀阀 thermo expansion valve 自动关闭阀 self-closing gate valve 自动排液阀 self-draining valve 管道盲板阀 line-blind valve 挤压阀 squeeze valve（用于泥浆及粉尘等） 呼吸阀 breather valve 风门、挡板 damper 减压阀 pressure reducing valve, reducing valve 控制阀 control valve 膜式控制阀 diaphragm operated control valve 执行机构 actuator 背压调节阀 back pressure regulating valve 差压调节阀 differential pressure regulating valve 压力比例调节阀 pressure ratio regulating valve1.6.4 未指明结构（或阀型）的阀切断阀 block valve; shut-off valve; stop valve 调节阀 regulating valve 快开阀 quick opening valve 快闭阀 quick closing valve 隔断阀 isolating valve 三通阀 three way valve 夹套阔 jacketed valve 非旋转式阀 non-rotary valve 排污阀 blowdown valve 集液排放阀 drip valve 排液阀 drain valve 放空阀 vent valve 卸载阀 unloading valve 排出阀 discharge valve 吸入阀 suction valve 多通路阀 multiport valve 取样阀 sampling valve 手动阀 hand-operated valve; manually operated valve 锻造阀 forged valve 铸造阀 cast valve （水）龙头 bibb; bib; faucet 抽出液阀（小阀） bleed valve 旁路阀 by-pass valve 软管阀 hose valve 混合阀 mixing valve 破真空阀 vacuum breaker 冲洗阀 flush valve 第一道阀；根部阀 primary valve 根部阀 root valve7 / 32总管阀 header valve 事故切断阀 emergency valve1.7 管 道 特 殊 件 Piping Specialty1.7.1 管道特殊件（组件）粗滤器 strainer 过滤器 filter 临时粗滤器（锥型） temporary strainer (cone type) y 型粗滤器 y-type strainer T 型粗滤器 T-type strainer 永久过滤器 permanent filter 丝网粗滤器 gauze strainer 洗眼器及淋浴器 eye washer and shower 视镜 sight glass 阻火器 flame arrester 喷嘴；喷头 spray nozzle 取样冷却器 sample cooler 消声器 silencer 膨胀节 expansion joint 波纹膨胀节 bellow expansion joint 单波 single bellow 双波 double bellow 多波 multiple bellow 压力平衡式膨胀节 pressure balanced expansion 带铰链膨胀节 hinged expansion joint 轴向位移型膨胀节 axial movement type expansion joint 自均衡膨胀节（外加强环）self-equalizing expansion joint 带接杆膨胀节 tied expansion joint 万向型膨胀节 universal type expansion joint化工管道设计技术词汇（中英对照完整版）球形补偿器 ball type expansion joint 填函式补偿器 slip type (packed type) expansion joint 单向滑动填料函补偿器 single actionpacked slip joint1.7.2 管道特殊元件 Piping Special Element软管接头 hose connection (HC) 快速接头 quick coupling 金属软管 metal hose 橡胶管 rubber hose 挠性管 flexible tube 鞍形补强板 reinforcing saddles 补强板 reinforcement pad 特殊法兰 special flange 漏斗 funnel 排液环 drip ring 排液漏斗 drain funnel 插板 blank 垫环 spacer 8 字盲板 spectacle blind; figure 8 blind 限流孔板 restriction orifice 爆破片 rupture disk 法兰盖贴面 protective disc 费托立克接头 victaulic coupling1.8 端 部 连 接 End Connection法兰端 flanged end 坡口端 beveled end (BE) 对焊端 butt welded end 平端 plain end (PE) 承插焊端 socket welding end8 / 32螺纹端 threaded end (TE) 承口 bell end 焊接端 welding end 法兰连接（接头） flanged joint 对焊连接（接头） butt welded joint 螺纹连接，管螺纹连接 threaded joint, pipe threaded joint 锥管螺纹密封焊连接 seal-welded taper pipe threaded joint 承插焊连接（接头） socket welded joint 承插连接（接头） bell and spigot joint 环垫接头 ring joint (RJ) 万向接头 universal joint 软钎焊连接（接头） soldered joint 搭接接头，松套连接 lapped joint 外侧厚度切斜角 bevel for outside thickncss 内侧厚度切斜角 bevel for inside thickness 内外侧厚度切斜角 bevel for combined thickness 法兰式的 flanged (FLGD) 对焊的 butt welded (BW) 螺纹的 threaded (THD) 承插焊的 socket welded (SW) 小端为平的 small end plain (SEP) 大端为平的 large end plain (LEP) 两端平 both ends plain (BEP) 小端带螺纹 small end thread (SET) 大端带螺纹 large end thread (LET) 两端带螺纹 both end thread (BET) 一端带螺纹 one end thread (OET) 支管连接 branch connection 焊接支管 branch pipe welded directly to the run pipe化工管道设计技术词汇（中英对照完整版）2 管道用紧固件及螺纹2.1 紧 固 件螺栓 bolt 六角头螺栓 hexagonal head bolt 方头螺栓 square head bolt 螺柱，双头螺栓 stud bolt 环头螺检 eye bolt 沉头螺栓 countersunk (head) screw 地脚螺栓 anchor bolt; foundation bolt 松紧螺旋扣（花篮螺丝） turnbuckle U 形螺栓 U-bolt T 形螺栓 T-bolt 圆头螺钉 round head bolt 机螺栓，机螺钉 maehine bolt 顶开螺栓，顶起螺栓 Jack screw 自攻螺钉 self tapping screw 膨胀螺栓 expansion bolt 粗制的 coarse 精制的 finished, fine 螺母 nut 六角螺母 hexagonal nut 方螺母 square nut 蝶形螺母 wing nut 扁螺母 flat nut 锁紧螺母 lock nut 垫圈 washer 平垫圈 plain washer 球面垫圈 spherical washer 弹簧垫圈 spring washer9 / 32方垫圈 square washer 斜垫圈 slant washer 销轴 pinned shan 销 pin 开口销 cotter pin 定位销 dowel pin 带孔销 pin with hole 圆锥销 taper pin 铆钉 rivet 键 key2.2 螺 纹左螺纹 left hand thread 右螺纹 right hand thread 管螺纹 pipe thread 锥管螺纹 taper pipe thread 直管螺纹 straight pipe thread 梯形螺纹 trapezoid thread 螺距 pitch of thread 粗牙螺纹 coarse thread 细牙螺纹 fine thread 特细牙螺纹 extra fine thread 通长螺纹 full thread 惠氏螺纹 whitworth thread 公制螺纹 metric ibread 美国标准锥管螺纹 American standard taper pipe thread (NPT) 螺孔 tap3 材料、型钢及填料3.1 金 属 材 料化工管道设计技术词汇（中英对照完整版）3.1.1 黑色金属 Ferrous Metal碳素钢 carbon steel (CS) 低碳钢 low-carbon steel 中碳钢 medium-carbon steel 高碳钢 high-carbon steel 普通碳素钢 general carbon steel 优质碳素钢 high-quality carbon steel 普通低合金结构钢 general structure low-alloy steel 合金结构钢 structural alloy steel 合金钢 alloy steel 低合金钢 low alloy steel中合金钢 medium alloy steel 高合金钢 high alloy steel 耐热钢 heat resisting steel 高强度钢 high strength steel 复合钢 clad steel 工具钢 tool steel 弹簧钢 spring steel 钼钢 molybdenum steel 镍钢 nickel steel 铬钢 chromium steel 铬钼钢 chrome-molybdenum steel 铬镍钢 chromium-nickel steel,chrome-nickel steel 不锈钢 stainless steel (S.S.) 奥氏体不锈钢 Austenitic stainless steel 马氏体不锈钢 Martensitic stainless steel 司特来合金（钨铬钴台金） Stellite 耐蚀耐热镍基合金 Hastelloy10 / 3211 /32铬镍铁合金inconel耐热铬镍铁合金incoloy20合金20 alloy平炉钢（马丁钢）Martin steel镇静钢killed steel半镇静钢semi-killed steel沸腾钢rimmed steel; rimming steel; open-steel锻钢forged steel铸钢cast steel铸铁cast iron (C.I.)灰铸铁grey cast iron可锻铸铁malleable iron (MI)球墨铸铁nodular cast iron; nodular graphite iron生铁pig iron熟铁，锻铁wrought iron铸件casting高硅铸铁high silicon cast iron3.1.2镀层及制造方法渗铬钢，镀铬钢chromized steel镀铬的chromium-plated, chrome-plated镀层plating锻造，型钢swage锻造的，锻造forging轧制rolling热轧hot rolling冷轧cold rolling挤压extruding冷加工cold working热加工hot working拔制drawing3.1.3 有色金属Non-ferrous Metal铝aluminum铜，紫铜copper黄铜brass青铜bronze铝青铜aluminum bronze磷青铜phosphor bronze铝镁合金aluminum magnesium锰青铜manganese bronze蒙乃尔（注：镍及铜合金）Monel镍铜台金nickel copper alloy非铁合金nonferrous alloy钛titanium铅lead硬铅hard lead3.1.4材料性能极限强度ultimate strength抗拉强度tensile strength屈服极限yield limit屈服点yield point延伸率percentage elongation抗压强度compressive strength抗弯强度bending strength弹性极限elastic limit冲击值impact value疲劳极限fatigue limit蠕变极限creep limit持久极限endurance limit12 /32布氏硬度Brinell hardness洛氏硬度Rockwell hardness维氏硬度Vickers diamond hardness, diamond penetrator hardness蠕变断裂强度creep rupture strength断面收缩率reduction of area韧性toughess脆性brittleness延性ductility冷脆cold shortness冷流cold flow3.2 非金属材料Non-metallic Material塑料plastic丙烯腈—丁二烯—苯乙烯acrylonitrile-butadiene-styrene (ABS)聚乙烯polyethylene (PE)聚氯乙烯polyvinyl chloride (PVC)苯乙烯橡胶styrene-rubber (SR)聚丁烯polybutylene (PB)聚丙烯polypropylene (PP)聚苯乙烯polystyrene (PS)氯化聚醚chlorinated polyether (CPE)聚酰胺polyamide (PA)聚碳酸酯polycarbonate (PC)聚甲基丙烯酸甲酯polymethyl methacrylate (PMMA) 醋酸丁酸纤维素cellulose acetate butyrate (CAB)氯化聚氯乙烯chlorinated polyvinyl chloride (CPVC)聚偏二氟乙烯polyvinylidene fluoride (PVDF)缩醛塑料acetal plastic尼龙塑料nylon plastic聚烯烃polyolefin (PO)石墨酚醛塑料graphite phenolic plastics聚四氟乙烯polytetrafluoroethylene (PTFE)纤维增强热塑性塑料fiber reinforced thermoplastics热塑性塑料thermoplastic热固性塑料thermosetting plastics胶粘剂adhesive溶剂胶接剂solvent cement树脂resin环氧树脂epoxy, epoxy resin聚酯树脂polyester resin聚酯纤维polyester fibers氟塑料fluoroplastics聚氨基甲酸酯polyurethane丙烯酸树脂acrylic resin脲醛树脂urea resin呋哺树脂furan resin乙烯丙烯二烃单体ethylene propylene diene monomer (EPDM)合成橡胶synthetic rubber橡胶rubber丁腈橡胶nitrile butadiene rubber氯丁橡胶neoprene天然橡胶natural rubber乙丙橡胶ethylene propylene rubber (EPR)玻璃glass硼硅玻璃borosilicate glass耐火砖fire brick陶瓷ceramic搪瓷porcelain enamel木材wood13 /323.3 型材型钢shaped steel, section steel, swage角钢angle steel槽钢channel工字钢I-beam宽缘工字钢或H钢wide flanged beamT型钢T-bar方钢square bar扁钢flat bar角钢hexagonal steel bar圆钢round steel; rod钢带strap steel钢板plate网纹钢板checkered plate腹板（指型钢的立板）web翼缘（指型钢的缘）wing 3.4 填料及填料函填料packing石棉绳asbestos rope, asbestos cord．O形环O-ring自密封self-sealing四氟带Teflon tap带铬镍合金丝的石棉绳asbestos rope with inconel wire, inconel wire asbestos浸聚四氟乙烯的石棉填料Teflon impregnated asbestos packing金属填料metallic stuffing填料箱，填料函packing box, stuffing box填料函压盖stuffing box gland 4 管道等级及材料统计4.1 管道材料规定Piping Material Specification管道等级piping class; piping classification管道等级号class designation公称直径nominal diameter (DN); nominal (pipe) size公称压力nominal pressure (PN)压力级，等级，类别class (CL)低压low pressure (L.P.)中压medium pressure (M.P.)高压high pressure (H.P.)大气压atmosphere (ATM)真空vacuum工作压力operating pressure; working pressure设计压力design pressure工作温度operating temperature设计温度design temperature环境温度ambient temperature腐蚀裕量corrosion allowance管道附件piping attachment管道元件piping element壁厚wall thickness (WT)壁厚系列号schedule number (SCH. No.)加厚的，加强的extra heavy, extra strong双倍加厚的，双倍加强的double extra heavy, double extra strong通用连接组typieal installation分组（类）形式（如管道等级表）block form数据库data base文件file14 /324.2 材料统计Material Take-off (MTO)汇总表summary sheet材料表bill of material (BM)综合管道材料表consolidated piping material summary sheet (CPMSS)统计材料准确度accuracy of take-off材料情况报告material status report (MSR)散装材料bulk material编位号的itemized代码code number短代码short code数量quantity (QTY)重力weight净重net weight毛重gross weight5 设备布置及管道布置Plot Plan and Piping Layout, Equipment and Piping Arrangement5.1 设备名称Equipment Name5.1.1容器Vessel(1)塔tower, column洗涤塔scrubber吸收塔absorber冷却塔cooling tower精馏塔fractionating tower蒸馏塔distillation tower再生塔regenering tower造粒塔prflling tower汽提塔stripper脱气塔degasifier合成塔synthesis tower(2)反应器reactor聚台釜polymerizer转化器，变换器converter脱硫反应器desulphurization reactor甲烷化器methanator(3)气柜gas-holder螺旋式气柜helical gas-holder湿式气柜wet gas-holder干式气柜dry gas-holder(4)槽罐贮罐tank; storage tank缓冲罐knock out drum球罐spheroid, spherical tank罐drum接受槽receiver计量槽measuring tank加料槽feed tank排污罐blow down tank闪蒸罐flash drum汽包steam drum溶液贮槽solution storage tank地下槽sloptank(5)其它设备分离器separator旋风分离器cyclone分子筛molecular sieve脱氧器deaerator搅拌器agitator15 /32干燥器dryer混合器mixer萃取器extractor结晶器crystallizer澄清器gravity settler净化器purifier气化器vaporizer吸附器adsorber融解槽melter减温器desuperheater升压器booster喷射器ejector喷头sprayer火炬flare消声器silencer(6)换热器、加热器、冷却器换热器heat exchanger空冷器air cooler水冷却器water cooler冷凝器condenser螺旋板式换热器spiral plate heat exchanger蒸发器evaporator再沸器reboiler急冷器quencher深冷器chiller预热器preheater再热器reheater加热器heater电加热器electric heater过热器super heater给水加热器feed water heater中间冷却器inter cooler后冷却器after cooler5.1.2工业炉及锅炉炉子furnace烧嘴burner锅炉boiler烟囱stack废热锅炉waste heat boiler辅助锅炉auxiliary boiler省煤器economizer回热炉direct-fired heater辐射段radiant section对流段convection section裂化炉reformer焚烧炉incinerator回转窑rotary kiln炉管furnace tube吹灰器soot blower观察孔observation door, peep door防爆门explosion door5.2 辅助用房名称5.2.1生产用房分析室analyzer room变压器室transformer room配电室，变电所substation, switch room蓄电池室battery room控制室control room16 /32通风室ventilating room贮藏室storage room维修间maintenance room办公室office5.2.2生活用房更农室locker room盥洗室，厕所closet, lavatory, toilet5.3 图名管道布置平面piping arrangement plan (PAP)管道布置piping layout轴测图isometric drawing分区索引图key plan初版设备布置图（“A”版）preliminary plot plan ( “A” issue)内部审查版设备布置图（“B”版）inrernal approval plot plan ( “B” issue) 用户审查版设备布置图（“C”版) owner approval plot plan ( “C” issue)确认版设备布置图（“D”版）confirm plot plan ( “D” issue)研究版设备布置图（“e”版）planning plot plan ( “E” issue)设计版设备布置图（“F”）designing plot plan ( “F” issue)施工版设备布置图（“G”版）construction plot plan ( “G” issue) 5.4 厂房、站、单元压缩机房compressor house (room)泵房pump house (room)洗眼站eye washer station泡沫站foam station软管站，公用工程站hose station (HS), utility station成套设备package unit设施facilities罐区tank yard空分装置air separation facility5.5 设备布置设备位号equipment item number工厂plant工厂区界plant limit项目区界内侧inside battery limit (I.S.B.L.)项目区界batterylimit (BL)区界area limit区域边界zone iimit界外off site东east (E)西west (W)南south (S)北north (N)上up下down工厂北向plant north真实北向true north道路road小过道cat walk, cat way走道，过道walk way, gangway, access way污水坑（井）sump pit集水池catch basin沟槽through预留区trough场地future area铺砌区paving area非铺砌区unpaved area17 /32碎石铺面gravel paving橡皮铺面rubber paving面积，区域area体积，容积volume (VOL)5.6 管道布置管道设计piping design管道研究piping study走向研究routing study重要管道critical piping地上管道above ground piping地下管道under ground piping管网network of pipes管廊pipe rack管沟piping trench管间距line spacing管道跨距line span总管header, manifold旁路by pass排液drain放空vent上升管，垂直管riser导管canduit裸管bare iine管件直接fitting to fitting (FTF)管段，接口spool piece, spool取样接口sampling connection集液包drip leg伴热管tracing pipe蒸汽伴热steam tracing热水伴热hot-water tracing电伴热electrical tracing夹套管jacketed line, jacketed piping全夹套的full jacketed平面plan详图detail“ ”视图X view “X”“ ”剖视A-A section “A-A”连接图hook up drawing接续图continue on drawing (COD)接续线match line (M.L.)比例scale图例legend符号symbol管口表list of nozzles方位orientation管口方位nozzle orientation定位location相交intersection水平的horizontal垂直的，立式的vertical垂直，正交，垂直的perpendicular平行，平行的parallel水平安装horizontal installation垂直安装vertical installafion对称的symmetric相反（的），对面（的）opposite顺时针方向clock wise逆时针方向counter clock wise计算机辅助设计computer aided design (CAD)18 /325.7 图面标注绝对标高abselute elevation海平面标高over-sea mean level (OSL)标高，立面elevation (EL)混凝土顶面top of concrete架顶面top of support (TOS)钢结构顶面top of steel梁项面top of beam (TOB)支撑点point of suppon (POS)管顶top of pipe (TOP)管底bouom of pipe (BOP)沟底boaom of trench管子内底invert (inside bottom of pipe)底平flat on bottom (FOB)顶平flat on top (FOT)工作点working point (W.P.)面至面face to face (F-F)中心至端面center to end (C-E)中心至面center to face (C-F)中心至中心，中至中center to center (C-C)坐标coordinate坐标原点origin of coordinate出口中心线center line of discharge入口中心线center line of suction中心线centerline (CL)入口inlet, suction出口outlet, discharge排出口exhaust距离distance5.8 相关专业的专业词汇5.8.1工艺(1)图及表流程图flow diagram工艺流程图process flow diagram (PFD)管道及仪表流程图piping andinstrument flow diagram (PID)公用工程流程图utility flow diagram (UFD)管线表line list; line schedule命名表；管道表nomenclature设备表equipment list (schedule)(2)流体fluid空气air仪表空气instrument air工艺空气process air低压蒸汽low pressure steam中压蒸汽medium pressure steam高压蒸汽high pressure steam伴热蒸汽tracing steam饱和蒸汽saturated steam过热蒸汽superheated steam氧气oxygen氢气hydrogen氮气nitrogen燃料气fuel gas天然气natural gas火炬气flare gas。

设备布置及管道布置（中英文对照）Plot Plan and Piping Layout, Equipment and Piping Arrangement5.1 设备名称 Equipment Name5.1.1 容器 Vessel(1) 塔 tower, column洗涤塔 scrubber吸收塔 absorber冷却塔 cooling tower精馏塔 fractionating tower蒸馏塔 distillation tower再生塔 regenerating tower造粒塔 prilling tower汽提塔 stripping tower ; stripper脱气塔 degassing tower ; degasifier合成塔 synthesis tower (2) 反应器 reactor聚合器，聚台釜 polymerizer转化器，变换器 converter脱硫反应器 desulphurization reactor 甲烷化器 methanator(3)气柜 gas-holder螺旋式气柜 helical gas-holder湿式气柜 wet gas-holder干式气柜 dry gas-holder(4)槽罐贮罐 tank; storage tank缓冲罐 knock out drum球罐 spheroid, spherical tank罐 drum接受槽 receiver计量槽 measuring tank加料槽 feed tank排污罐 blow down tank闪蒸罐 flash drum汽包 steam drum溶液贮槽 solution storage tank 地下槽 slop tank(5) 其它设备分离器 separator旋风分离器 cyclone分子筛 molecular sieve脱氧器 deaerator搅拌器 agitator干燥器 dryer混合器 mixer萃取器 extractor结晶器 crystallizer 澄清器 gravity settler净化器 purifier气化器 vaporizer吸附器 absorber融解槽 melter减温器 desuperheater升压器 booster喷射器 ejector喷头 sprayer火炬 flare消声器 silencer(6) 换热器、加热器、冷却器换热器 heat exchanger空冷器 air cooler水冷却器 water cooler冷凝器 condenser螺旋板式换热器spiral plate heat exchanger蒸发器 evaporator再沸器 reboiler急冷器 quencher深冷器 chiller预热器 preheater再热器 reheater加热器 heater电加热器 electric heater过热器 super heater给水加热器 feed water heater中间冷却器 inter cooler后冷却器 after cooler5.1.2 工业炉及锅炉炉子 furnace 烧嘴 burner锅炉 boiler烟囱 stack废热锅炉 waste heat boiler辅助锅炉 auxiliary boiler省煤器 economizer回热炉 direct-fired heater辐射段 radiant section对流段 convection section裂化炉 reformer焚烧炉 incinerator回转窑 rotary kiln炉管 furnace tube吹灰器 soot blower观察孔 observation door, peep door 防爆门 explosion door5.2 辅助用房名称5.2.1 生产用房分析室 analyzer room变压器室 transformer room配电室，变电所 substation, switch room 蓄电池室 battery room控制室 control room通风室 ventilating room贮藏室 storage room维修间 maintenance room办公室 office5.2.2 生活用房更衣室 locker room盥洗室，厕所 closet, lavatory, toilet 5.3 图名管道布置平面 piping arrangement plan (PAP)管道布置 piping layout轴测图 isometric drawing分区索引图 key plan初版设备布置图（“A”版） preliminary plot plan ( “A” issue)内部审查版设备布置图（“B”版） internal approval plot plan ( “B” issue)用户审查版设备布置图（“C”版) owner approval plot plan ( “C” issue)确认版设备布置图（“D”版） confirm plot plan ( “D” issue)研究版设备布置图（“e”版） planning plot plan ( “E” issue)设计版设备布置图（“F”） designing plot plan ( “F” issue)施工版设备布置图（“G”版） construction plot plan ( “G” issue)5.4 厂房、站、单元压缩机房 compressor house (room)泵房 pump house (room)洗眼站 eye washer station泡沫站 foam station软管站，公用工程站 hose station (HS), utility station成套设备 package unit设施 facilities罐区 tank yard空分装置 air separation facility5.5 设备布置设备位号 equipment item number工厂 plant工厂区界 plant limit 项目区界内侧inside battery limit (I.S.B.L.)项目区界 battery limit (BL)区界 area limit区域边界 zone limit界外 off site东 east (E)西 west (W)南 south (S)北 north (N)上 up下 down工厂北向 plant north真实北向 true north道路 road小过道 cat walk, cat way走道，过道 walk way, gangway, access way 污水坑（井） sump pit集水池 catch basin沟槽 trough预留区future area场地铺砌区 paving area非铺砌区 unpaved area碎石铺面 gravel paving橡皮铺面 rubber paving面积，区域 area体积，容积 volume (VOL)5.6 管道布置管道设计 piping design管道研究 piping study 走向研究 routing study重要管道 critical piping地上管道 above ground piping 地下管道 underground piping 管网 network of pipes管廊 pipe rack管沟 piping trench管间距 line spacing管道跨距 line span总管 header, manifold旁路 by pass排液 drain放空 vent上升管，垂直管 riser导管 conduit裸管 bare line管件直接 fitting to fitting (FTF)管段，接口 spool piece, spool取样接口 sampling connection集液包 drip leg伴热管 tracing pipe蒸汽伴热 steam tracing热水伴热 hot-water tracing电伴热 electrical tracing夹套管 jacketed line, jacketed piping 全夹套的 full jacketed平面 plan详图 detail“”视图X view “X”“”剖视A-A section “A-A”连接图 hook up drawing接续图 continue on drawing (COD)接续线 match line (M.L.)比例 scale图例 legend符号 symbol管口表 list of nozzles方位 orientation管口方位 nozzle orientation定位 location相交 intersection水平的 horizontal垂直的，立式的 vertical垂直，正交，垂直的 perpendicular 平行，平行的 parallel水平安装 horizontal installation 垂直安装 vertical installation 对称的 symmetric相反（的），对面（的） opposite顺时针方向 clock wise逆时针方向 counter clock wise计算机辅助设计 computer aided design (CAD)5.7 图面标注绝对标高 absolute elevation海平面标高 over-sea mean level (OSL)标高，立面 elevation (EL)混凝土顶面 top of concrete架顶面 top of support (TOS)钢结构顶面 top of steel梁项面 top of beam (TOB)支撑点 point of support (POS)管顶 top of pipe (TOP)管底 bottom of pipe (BOP)沟底 bottom of trench管子内底 invert (inside bottom of pipe)底平 flat on bottom (FOB)顶平 flat on top (FOT)工作点 working point (W.P.)面至面 face to face (F-F)中心至端面 center to end (C-E)中心至面 center to face (C-F)中心至中心.中至中center to center (C-C)坐标 coordinate坐标原点 origin of coordinate出口中心线 center line of discharge入口中心线 center line of suction中心线 centerline (CL)入口 inlet, suction出口 outlet, discharge排出口 exhaust距离 distance5.8 相关专业的专业词汇5.8.1 工艺(1) 图及表流程图 flow diagram工艺流程图 process flow diagram (PFD)管道及仪表流程图 piping and instrument flow diagram (PID)公用工程流程图 utility flow diagram (UFD)管线表 line list; line schedule命名表；管道表 nomenclature设备表 equipment list (schedule)(2) 流体 fluid 空气 air仪表空气 instrument air工艺空气 process air低压蒸汽 low pressure steam中压蒸汽 medium pressure steam 高压蒸汽 high pressure steam 伴热蒸汽 tracing steam饱和蒸汽 saturated steam过热蒸汽 superheated steam氧气 oxygen氢气 hydrogen氮气 nitrogen燃料气 fuel gas天然气 natural gas火炬气 flare gas酸性气 sour gas液化石油气liquefied petroleum gas (LPG)氨气 ammonia gas冷却水 cooling循环水 circulating water锅炉给水 boiler feed water热水 hot water蒸汽冷凝水 steam condensate盐水 brine工艺水 process water化学污水 chemical sewage防腐剂 corrosion inhibitor重油 heavy oil石脑油 naphtha燃料油 fuel oil润滑油 lubricating oil 密封油 sealing oil冷冻剂 refrigerant载热体 heating medium 溶剂 solvent溶液 solution母液 mother liquor单体 monomer聚合物 polymer均聚物 homopolymer共聚物 copolymer工艺液体 process liquid 工艺气体 process gas硫酸 sulphuric acid盐酸 chlorhydric acid 硝酸 nitric acid烧碱 caustic soda(3) 流体特性 fluid characteristics 蒸汽压 vapor pressure临界温度 critical temperature临界点 critical point临界压力 critical pressure比热 specific heat湿度 humidity密度 density比重 specific gravity粘度 viscosity闪点 flash point融点 melting point凝固点 freezing point浓度 concentration爆炸极限 limit of explosion有毒的 toxic 可燃的；易燃的 flammable (4) 其它回收 recovery再生 regeneration循环 circulation再循环；再生 recycle补充 make-up制备 preparation蒸汽吹扫 steaming out吹扫 purge抽空；排空 evacuation吹出 blow-off排污 blow down破真空 vacuum breaker大气腿 barometric leg备用 stand-by化学清洗 chemical cleaning净正吸入压头 net positive suction head (NPSH)进料 feed成品 product污染 contamination大气污染 atmospheric pollution环境温度 ambient temperature5.8.2 建筑、结构建筑物 building钢结构 steel structure已有钢结构 existing steel structure钢筋混凝土结构reinforced concrete construction楼面 floor平台 platform (PF)地面 ground level 栏杆 handrail楼梯 stair. stair way直梯 ladder柱 column; post; stanchion 基础 foundation; footing 梁 beam斜撑；支撑 bracing桁架；主梁 girder构件 member隔墙 partition wall墙 wall篦子板 grate; grating吊装孔 erection opening吊梁 hoisting beam棚 shelter窗 window天窗 skylight门 door防火门 fire door地漏 floor drain防火层 fire-proofing总图 general plot plan路肩 shoulder桩 pile灌浆 grouting风荷载 wind load雪荷载 snow load动力荷载 dynamic load静荷载 dead load活荷载 live load风速 wind velocity主导风向 most frequent wind direction 5.8.3 仪表盘（操作盘） panel就地盘 local panel仪表盘 instrument panel常开 normally open常闭 normally closed电缆槽（架） cable tray (channel); cable rack仪表电缆槽（架） instrument cable tray (duct)压力计 manometer; pressure gauge热电偶 thermocouple温度计 thermometer液位计 level gauge玻璃液位计 gauge glass温度计保护管 thermowell流量计 flow meter孔板 orifice变送器 transmitter连锁 interlock仪器；设备 apparatus仪器分析 instrumental analysis自动分析 automatic analysis气体分析 gas analysis化学分析 chemical analysis气相色谱仪 gas chromatograph液相色谱仪 liquid chromatograph质谱分析 mass spectrometric analysis 5.8.4 电气危险区划分hazardous area classification危险区平面图 hazardous area plan电气盘 electrical panel 配电盘 switch board电缆沟 cable trench电流 current直流 direct current交流 alternating current频率 frequency相位 phase功率因数 power factor电压 voltage电阻 resistance电容 capacitance静电 static electricity接地 grounding; earthing照明 lighting; illumination 避雷针 lightning preventer 电话 telephone电线 wire接线箱（盒） junction box 导线管 conduit tube5.8.5 设备固定鞍座 fixed saddle滑动鞍座 sliding saddle管口 nozzle人孔 manhole (MH)手孔 hand hole (HH)检查孔 inspection hole吊柱 davit切线 tangent line焊接线 welding line件号 part humbet椭圆形封头 ellipsoidal head 加强圈 reinforcing ring 接地板 earth lug吊耳 lifting lug气缸 cylinder轴 shaft轴承 bearing附件，附属设备 accessory编位号设备 itemized equipment无位号设备 non-itemized equipment 5.8.6 水道(1) 流体原水 raw water硬水 hard water软水 soft water饮用水 potable water循环冷却水给水 cooling water supply 循环冷却水回水 cooling water return脱盐水 demineralized water苦咸水（碱性水） brackish water 生活污水 sanitary sewer工业废水 industrial waste water 雨水 rain water污染雨水 contaminated rain water 消防水 fire water(2) 装置、设施软化装置 softener沉淀器 settler沉淀池 clarifier脱盐装置 demineralizer水处理 water treatment冷却塔 cooling tower中和池 neutralization tank化粪池 septic tank 渗滤井 soak-away pit井 well阀井 valve pit清扫口 clean out（3）消防消火栓 hydrant水炮 water monitor洒水器 sprinkler水喷淋 watering灭火器 fire extinguisher消防水泵 fire pump消防车 fire fighting truck泡沫消防 foam fire-fighting泡沫栓 foam hydrant泡沫炮 foam monitor消防软管接头 fire hose connection。

中石化管道图纸英文对照表1.管子及管件1.1 P EL 弯头1.2管子Pipe1.2.1三通Tee1.2.2 ELS 短半径弯头1.2.3 MEL 斜接弯头（虾米腰弯头）1.2.4 REL 异径弯头1.3 T ELL 长半径弯头1.3.1 LT 斜三通1.3.2 RT 异径三通1.4 R 异径管接头（大小头）Reducer1.4.1 CR 同心异径管接头（同心大小头）Concentric reducer 1.4.2 ER 偏心异径管接头（偏心大小头）Eccentric reducer 1.5 CPL 管箍Coupling1.5.1 FCPL 双头管箍Full coupling1.5.2 HCPL 单头管箍Half coupling1.5.3 RCPL 异径管箍Reducing coupling1.6 BU 内外螺纹接头Bushing1.7 UN 活接头Union1.8 HC 软管接头Hose coupler1.9 SE 翻边短节Stub end1.10 NIP 短节Pipe nipple or straight nipple1.10.1 SNIP 异径短节Swaged nipple1.11 CP 管帽（封头）Cap1.12 PL 管堵（丝堵）Plug1.13 BLK 盲板Blank1.13.1 SB 8字盲板Spectacle blind (blank)1.14 RP 补强板Reinforcing pad2.法兰2.1 FLG 法兰Flange2.1.1 WNF 对焊法兰Welding neck flange2.1.2 SOF 平焊法兰Slip-on flange2.1.3 SWF 承插焊法兰Socket-welding flange2.1.4 T 螺纹法兰Threaded flange2.1.5 LJ 松套法兰Lapped joint flange2.1.6 REDF 异径法兰Reducing flange2.1.7 BF 法兰盖（日法兰）Blind flange2.2 FSF 法兰密封面Flange scaling face2.2.1 FF 全平面Flat face 2.2.2 RF 凸台面Raised face2.2.3 MFF 凹凸面Male and female face2.2.4 LF 凹面Female face2.2.5 LM 凸面Male face2.2.6 RJ 环连接面Ring joint face2.2.7 TG 榫槽面Tongue and groove face2.2.8 TF 榫面Tongue face2.2.9 GF 槽面Groove face3.垫片 3.1 G 垫片Gasket3.1.1 NMG 非金属垫片Non-metallic gasket3.1.1.1 AG 石棉垫片Asbestos gasket3.1.1.2 RG 橡胶垫片Rubber gasket3.1.1.3 TEG 聚四氟乙烯包复垫片PTFE envelope gasket3.1.2 SMG 半金属垫片Semimetallic gasket3.1.2.1 MJG 金属包垫片Meta-jacket gasket3.1.2.2 SWG 缠绕式垫片Spiral wound gasket3.1.3 MG 金属垫片Metallic gasket3.1.3.1 FMG 金属平垫片Flat metallic gasket3.1.3.2 SMSG 齿形金属垫片Solid metal serrated gasket3.1.3.3 LER 透镜式金属环垫Lens ring gasket3.1.3.4 OCR 八角形金属环垫Octagonal ring gasket3.1.3.5 OVR 椭圆形金属环垫Oval ring gakset3.1.3.6 IR/OR 内外定位环Inner ring and outer ring3.1.3.7 IR 内定位环Inner ring3.1.3.8 OR 外定位环Outer ring4.坚固件4.1 B 螺栓Bolt4.1.1 SB 螺柱Stud bolt4.2 NU 螺母Nut4.3 TB 花蓝螺母Turnbuckle4.4 WSR 垫圈Washer4.4.1 SWSR 弹簧垫圈Spring washer5.阀门5.1 GV 闸阀Gate valve5.2 GLV 截止阀Globe valve5.3 CHV 止回阀Check valve5.4 BUV 蝶阀Butterfly valve5.5 BAV 球阀Ball valve5.6 PV 旋塞阀Plug valve (cock)5.7 CV 调节阀Control valve5.8 SV 安全阀Safety valve5.9 RV 减压阀Pressure reducing valve5.10 ST 蒸汽疏水阀Steam trap5.11 PRV 泄压阀Pressur relief valve5.12 BV 呼吸阀Breather valve5.13 NV 针形阀Needle valve5.14 AV 角阀5.15 DV 隔膜阀5.16 TWV 三通阀5.17 SGV 插板阀6.管道上用的小型设备 6.1 SPR 气液分离器Separator 6.2 FA 阻火器Flame arrester6.3 SR 过滤器Strainer6.3.1 SRY Y型过滤器Y-type strainer6.3.2 SRT T型过滤器T-type strainer6.3.3 SRB 桶式过滤器Bucket type strainer6.3.4 TSR 临时过滤器Temporary strainer6.4 SIL 消声器Silencer6.5 SG 视镜Slight glass6.6 SC 取样冷却器Sample cooler6.7 DF 排液漏斗Drain funnel6.8 LM 管道混合器Line mixer6.9 RO 限流孔板Restriction orifice6.9.1 MO 混合孔板Mixing orifice6.1 RD 爆破片（爆破膜）Rupture disk6.11 EJ 补偿器Expansion joint7.隔热、伴热7.1 INS 隔热Thermal insulation7.1.1 H 保温Hot insulation7.1.2 C 保冷Cold insulation7.1.3 P 防烫伤隔热Personnel protection insulation7.2 T&I 伴热Tracing and insulation7.3 T 管道伴热（冷）Tracing7.3.1 EST 蒸汽外伴热External steam tracing7.3.2 IST 蒸汽内伴热Internal steam tracing7.3.3 SJT 蒸汽夹套伴热Steam-jacket tracing7.3.4 ET 电伴热Electric tracing8.配管材料和等级8.1 M 金属材料Metallic material 8.1.1 CS 碳钢Carbon steel8.1.2 CAS 铸钢Cast steel8.1.3 FS 锻钢Forged steel8.1.4 AS 合金钢Alloy steel8.1.5 SS 不锈钢Stainless steel8.1.6 AUSTSS 奥氏体不锈钢Austenitic stainless-steel8.1.7 CI 铸铁Cast iron8.1.8 MI 可锻铸铁Malleable iron8.1.9 DI 球墨铸铁Ductile iron8.1.10 AL 铝Aluminum8.1.11 BRS 黄铜Brass8.1.12 BRZ 青铜Bronze8.1.13 CU 紫铜Copper8.1.14 LAS 低合金钢Low alloy steel8.1.15 FLAS 低合金锻钢Forged low alloy steel8.1.16 CLAS 低合金铸钢Cast low alloy steel8.2 THK 壁厚Thickness8.2.1 SCH 表号Schedule number8.2.2 STD 标准Standard8.2.3 XS 加强Extra strong8.2.4 XXS 特强Double extra strong9.装置布置9.1 CN 建北Construction north9.2 E 东East9.3 W 西West9.4 S 南South9.5 N 北North9.6 H 水平Horizontal9.7 V 竖直、铅直、直立Vertical9.8 GRD 地坪Ground9.9 UG 地下Underground9.10 BL 装置边界线Battery limit line9.11 ESEW 事故沐浴洗眼器Emergency shower and eye washer 9.12 HS 软管站Hose station9.13 ML 接续分界线Match line9.14 PS 管道支架（管架）Piping support9.15 PR 管桥Pipe rack9.16 STRU 构架（构筑物）Structure9.17 BLDG 建筑物Building9.18 PD 清扫设施Purge device9.19 PT 池Pit9.20 SHLT 棚Shelter9.21 COFF 围堰Cofferdam9.22 FL 楼板Floor9.23 PF 平台Plateform10.尺寸标注10.1 EL 标高Elevation10.2 BOP 管底Bottom of pipe10.3 COP 管中心Center of pipe10.4 TOP 管顶Top of pipe10.5 FOB 底平Flat on bottom10.6 FOT 顶平Flat on top10.7 CL(屯) 中心线Center line10.8 TL 切线Tangent line10.9 SYM 对称的Symmetrical10.10 BOS 支架底Bottom of support10.11 TOS 支架顶Top of support10.12 CL 净距（净空）Clearance10.13 CTC 中心至中心Center to center10.14 CTF 中心至面Center to face10.15 CTE 中心至端部Center to end10.16 ETE 端到端End to end10.17 FEF 法兰端面Flange and face10.18 FTF 面到面Face to face10.19 D 直径Diameter10.20 DN 公称直径Nominal diameter10.21 ID 内径Inside diameter10.22 OD 外径Outside diameter10.23 DIM 尺寸Dimension10.24 MAX 最大Maximum10.25 MIN 最小Minimum10.26 AVG 平均Average10.27 APP 约、近似Approximate10.28 PT.EL 点标高Point elevation11.图表11.1 PFD 工艺流程图Process flow diagram11.2 PID 管道和仪表流程图Piping & instrument diagram11.3 COD 接续图Continued on drawing11.4 DTL 详图Datail11.5 SPDWG(ISODWG) 管段图Spool drawing (each line isometric drawing) 11.6 DWGNO 图号Drawing number11.7 DWGI 所在图号Drawing identification11.8 LOW 材料表List of material11.9 MTO 汇料Material take-off11.10 APPX 附录Appendix11.11 JOB. No. 工号Job Number11.12 BEDD 基础工程设计数据Basic engineering design data 11.13 DEDD 详细工程设计数据Detail engineering design data 11.14 REV. No. 修改号Recision number11.15 REFDWG 参考图Reference drawing11.16 SC 采样接口Sample connection12.操作方式及工作参数12.1 AUT 自动Automatic 12.2 ML 手动Manual control12.3 CHOP 链条操作Chain operated12.4 CSC 铅封关Car seal close12.5 CSO 铅封开Car seal open12.6 LC 锁闭Lock closed12.7 LO 锁开Lock open12.8 NC 正常关Normally close12.9 NO 正常开Normally open12.10 ATM 大气压Atmosphere12.11 PN 公称压力Nominal pressure12.12 A 绝压12.13 G 表压12.14 (T) 温度Temperature12.15 (P) 压力Pressure13.施工13.1 W 焊接Welding13.1.1 AW 电弧焊Arc welding13.1.2 GSAW 气体保护电弧焊Gas shielded-acr welding13.1.3 EFW 电熔焊Elecric fusion welding13.1.4 ERW 电阻焊Electric Resistance welding13.1.5 GW 气焊Gas welding13.1.6 LW 搭接焊Lap welding13.1.7 BW 对焊Butt welding13.4.8 TW 定位焊Tack welding13.1.9 SW 承插焊Socket welding13.1.10 CW 连续焊Continuous welding13.1.11 SEW 密封焊Seal welding13.1.12 SFG 堆焊Surfacing13.1.13 FW 现场焊接Field welding13.2 HT 热处理Heat treatment13.2.1 PH 预热Preheating13.2.2 SR 应力消除Stress relief13.2.3 PWHT 焊后热处理Post weld heat treatment13.3 EIT 检查、探伤和实验Examination, inspection & testing 13.3.1 VE 外观检查Visual examination13.3.2 UI (UT) 超声探伤Ultrasonic inspection (test)13.3.3 RI (RT) 射线探伤Radiographic inspection (test)13.3.4 MPI (MT) 磁粉探伤Magnetic particle inspection (test) 13.3.5 LPI (PT) 液体渗透检验Liquid penterant inspection (test) 13.3.6 HADT 硬度实验Hardness testing13.3.7 HYDT 水压实验Hydraulic testing13.3.8 PNET 气压实验Pneumatic testing13.3.9 CE 焊条Covered electrode13.3.10 WW 焊丝Welding wire13.3.11 ASSY 装配、组合Assembly13.3.12 F 现场Field13.3.13 F/F 现场制造Field faricated13.3.14 SF 现场决定Suit in field13.3.15 CSP 冷紧Cold spring13.3.16 BCT 螺栓冷紧Bolt cold tightening 13.3.17 BHY 螺栓热紧Bolt hot tightening 13.3.18 CO 清洗口Clean out13.3.19 ANNY 退火Annealed13.4 PE 平端面Plain end13.5 BE 坡口端Belelled end13.6 THR 螺纹Thread13.7 HB 布氏硬度Brinnel hardness13.8 RC 洛氏硬度14.其他14.1 FDN 基础Foundation 14.2 INF 信息（资料）Information14.3 REF 参考Reference14.4 REV 修改Revision14.5 SEQ 序号（顺序）Sequence14.6 W/E 设备带来With equipment14.7 W/I 仪表带来With instrument14.8 CM 色标Colour mark14.9 CA 腐蚀裕度Corrosion allowance14.10 UTL 公用系统Utility14.11 UC 公用工程接头Utility connection 14.12 QTY 数量Quantity14.13 WT 重量Weight14.14 MHR 工时Man hour14.15 BC 螺栓分布圆Bolt circle14.16 HP 高点High point14.17 LP 低点Low point14.18 SUC 吸入（口）Suction14.19 DIS 排出（口）Discharge14.20 SO 蒸气吹扫（口）Steam out14.21 NPT 美国标准锥管螺纹National standard taper pipe thread 14.22 NPS 美国标准直管螺纹National standard straight pipe thread 14.23 DR 排液Drain14.24 VT 放气Vent14.25 RTG （压力）等级Rating14.26 CL 等级Class。

1.2 管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头（右向或左向) side outlet elbow （right hand or left hand)双支管弯头（形) double branch elbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通（右向或左向) side outlet tee (right hand or 1eft hand）异径三通（分支口为异径) reducing tee （reducing on outlet）异径三通（一个直通口为异径）reducing tee (reducing on one run)带支座三通 base tee异径三通(一个直通口及分支口为异径） reducing tee （reducing on one run and outlet)异径三通（两个直通口为异径,双头式） reducing tee (reducing on both runs, bull head)45°斜三通 45° lateral45°斜三通（支管为异径） 45° lateral （reducing on branch)45°斜三通（一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径） 45° lateral （reducing on one run andbranch）Y型三通（俗称裤衩) true “Y”四通 cross等径四通 straight cross异径四通 reducing cross异径四通（一个分支口为异径）reducing cross （reducing on one outlet)异径四通（一个直通口及分支口为异径） reducing cross (reducing on one run and outlet）异径四通（两个分支口为异径) reducing cross （reducing on both outlet)异径四通（一个直通口及两个分支口为异径) reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管 reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台 sockolet弯头支管台 elbolet斜接支管台 latrolet镶入式支管嘴 sweepolet短管支管台 nipolet支管台，插入式支管台 boss●螺纹支管台Threadolet●弯头支管台elbolet●焊接支管台weldolet；on weld●短管支管台nipolet●承插支管台sockolet●烧焊支管台weldolet●斜接支管台latrolet●承插焊支管台Sockolet●支管台,插入式支管台boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头 union内外螺纹缩接（俗称补芯） bushing管帽 cap (C)堵头 plug短节 nipple异径短节 reducing nipple; swage nipple管道英文缩写A Anchor 固定ABS * Absolute 绝对的AISI ＊American Iron and Steel Institute 美国钢铁学会ANSI ＊ American National Standards Institute 美国国家标准学会API ＊American Petroleum Institute 美国石油学会APPROX ＊Approximate 大约，近似的ASB Asbestos 石棉ASME *American Society Of Mechanical Engineers美国机械工程师协会ASSY ＊ Assembly 装配，组装ASTM ＊ American Society Of Testing Material 美国材料实验协会ATM ＊ Atmosphere 大气压AWG ＊ American Wire Gage 美国线规AWS * American Wel＊＊*＊ Society 美国焊接协会AWWA * American Water Works Association 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B—B Beveled End—Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆B.C Bolted Cover(cap) 螺栓连接的阀兰盖（帽）BE Beveled End (for wel＊***) 坡口(焊接用）B.E Bell End 承口BEP Both Ends Plain 两端平BET Both Ends Threaded 两端带螺纹BL Battery Limit 装置区边界BF Blind Flange 盲板法兰BLD Blind 盲板BLDG ＊Buil**＊* 建筑物BM Bill Of Material 材料表BOP Bottom Of Pipe 管底B—P Beveled End —Plain End 坡口端。

管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头（右向或左向） side outlet elbow (right hand or left hand)双支管弯头（形） double branch elbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通（右向或左向） side outlet tee (right hand or 1eft hand)异径三通（分支口为异径） reducing tee (reducing on outlet)异径三通（一个直通口为异径）reducing tee (reducing on one run)带支座三通 base tee异径三通（一个直通口及分支口为异径） reducing tee (reducing on one run and outlet)异径三通（两个直通口为异径，双头式） reducing tee (reducing on both runs, bull head)45°斜三通45° lateral45°斜三通（支管为异径）45° lateral (reducing on branch)45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run a nd branch)Y型三通（俗称裤衩）true “Y”四通 cross等径四通 straight cross异径四通 reducing cross异径四通（一个分支口为异径）reducing cross (reducing on one outlet)异径四通（一个直通口及分支口为异径） reducing cross (reducing on one run and outlet)异径四通（两个分支口为异径） reducing cross (reducing on both outlet)异径四通（一个直通口及两个分支口为异径） reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管 reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台 sockolet弯头支管台 elbolet斜接支管台 latrolet镶入式支管嘴 sweepolet短管支管台 nipolet支管台，插入式支管台 boss螺纹支管台Threadolet弯头支管台elbolet焊接支管台weldolet；on weld短管支管台nipolet承插支管台sockolet烧焊支管台weldolet斜接支管台latrolet承插焊支管台Sockolet支管台，插入式支管台boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头 union内外螺纹缩接（俗称补芯） bushing管帽 cap (C)堵头 plug短节 nipple异径短节 reducing nipple; swage nipple管道英文缩写A Anchor 固定ABS * Absolute 绝对的AISI *American Iron and Steel Institute 美国钢铁学会ANSI * American National Standards Institute 美国国家标准学会API *American Petroleum Institute 美国石油学会APPROX *Approximate 大约，近似的ASB Asbestos 石棉ASME *American Society Of Mechanical Engineers美国机械工程师协会ASSY * Assembly 装配，组装ASTM * American Society Of Testing Material 美国材料实验协会ATM * Atmosphere 大气压AWG * American Wire Gage 美国线规AWS * American Wel**** Society 美国焊接协会AWWA * American Water Works Association 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B-B Beveled End-Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆Bolted Cover(cap) 螺栓连接的阀兰盖（帽）BE Beveled End (for wel****) 坡口（焊接用）Bell End 承口BEP Both Ends Plain 两端平BET Both Ends Threaded 两端带螺纹BL Battery Limit 装置区边界BF Blind Flange 盲板法兰BLD Blind 盲板BLDG *Buil**** 建筑物BM Bill Of Material 材料表BOP Bottom Of Pipe 管底B-P Beveled End —Plain End 坡口端.平端BV Butterfly valve 蝶阀BWG * Birmingham Wire Gage 伯明翰线规BW Butt Weld 对焊CC Cap 管帽C-C Center to Center 中至中C-E Center to End 中至端面C-F Center to Face 中至面CH-OP Chain Operated 链条操纵的Checkered Plate 花纹钢管*Cast Iron 铸铁CL *Class 英制压力等级，等级，种类CLEAR Clearance 间隙COD Continued on Drawing 接续图COL *Column 柱，塔CONC Concentric 同心的CONN Connection 连接，接口CONT *Continue 连续. Control Valve 控制阀CPLG Coupling 管接头，连轴节CPLH Half Coupling 半管接头，连轴节. Concentric Reducer 同心异径管. *Carbon Steel 碳钢. Cold Spring 冷紧Car Seal Close 在关闭状态下封住 Car Seal Open 在开启状态下封住CUST Customer 客Check Valve 止回阀DDEG *Degree 度DF Drain funnel 排液漏斗DIA *Diameter 直径DIM *Dimension 尺寸DISCH *Discharge 出口，排出Diaphragm VELVE 隔膜阀DMF Double Male And Female 双重凹凸DN Norminal Diameter公称直径DN Down 下DR Drain 排液DS Directional Stop 定向限为架DWG * Drawing 图EE *East 东EC External Coating 外面涂防腐层ECC Eccentric 偏心EFW Electric Fusion Welded 电容焊的EL(ELEV) *Elevation 标高；立面ELL Elbow 弯头EQIOP Equipment 设备，装置EQUIV Equivalent 相当的. Eccentric Reducer 偏心异经管ERW Electric Resistance Welded 电阻焊的EW Eye Washer & Shower 洗眼器及淋浴器 Expansion Joint 膨胀节FFDN Foundation 基础FF Flat Faced Or Full Faced 全平面；满平面F-F Face To Face 面至面FGW Fusion Gas Wel**** 气熔焊FIG *Figure 图FL Floor 楼面FLEX TUBE Flexible Tube 挠性管FLG Flange 法兰FLGD Flanged 法兰式的FLGF Flanged Face 法兰面FOB Flat On Bottom 底面平FOT Flat On Top 顶面平FP Fix Point 固定点FS Forged Steel 锻钢FTF Fitting To Fitting 管件直连FTG Fitting 管件FURND Furnished 提供的，装设的FW Field Weld 现伤焊GG Guide 导向GA * Gage 表，表压，规（线规）GALV *Galvanize 镀锌GL Ground Level 地面GLV Globe Valve 截止阀GEAR OP Gear Operated 齿轮传动的GMAW Gas Metal Arc Wel**** 金属极惰气体保护焊GSKT Gasket 垫片GTAW (Inert)Gas Tungsten Arc Wel**** 惰性气体保护钨极电弧焊GV Gate Valve 闸阀HH Hanger 吊架HC Hose Connection 软管接头Half Coupling 半节管接头HDR Header 总管HEX *Hexagon 六角形HF Hard Alloy Face on阀内件（阀心）为Valve Trim 硬质合金密封面HH Hand Hole 手孔HOR Horizontal 水平的* High Pressure 高压HS Hose Station 软管IID * Inside Diameter 内径IN * Inch 英寸INS Insulation 隔热INST Instrument 仪表INV Invert (inside bottom of pipe) 管子内底IPS Iron Pipe size 铁管尺寸ISO Isometric Drawing 周测图（空视图）Inside Battery Limit 装置边界内恻ISNS Inside screw & Non-rising Stem 内螺纹非升杆ISRS Inside screw & Rising stem 内螺纹升杆JJT Joint 接头JS Jack Screw 顶开（起）螺栓LLC Locked Closed 在关闭状态下锁定LEP Large end plain 大端为平的LET Large end Threaded 大端带螺纹LG Long 长LGF Lens Gasket Face 透镜垫连接面. THD Left Hand Thread 左螺纹LIFT Lift Type 升降式LJ Lap Joint 搭接LJF Lap Joint Flange 松套法兰LO Locked Open 在开启状态下锁定. Low Pressure 低压LR Long Radius 长半径LRE Long Radius Elbow 长半径弯头LTG Large Tongue & Groove 大椎槽MMATL Material 材料MAX Maximum 最大MB Machine Bolt 机器螺栓（单头）MF Male and Female 凸和凹MFG Manufacture 制造MF * Manufacture 制造厂MH Manhole 人孔MI Malleable Iron 可锻铸铁MIN *Minimum 最小MJ Mechanical Joint 机械接头Match Line 连续线MSS * Manufacturers Standardization Society of the Valve and Fittings Industry, Inc.美国阀门和管件制造商标准化协会MTO Material take-off 材料统计MW Minimum Wall 最小壁厚. Mineral Wool 矿（物）棉NN * North 北NB Nominal Bore 公称孔径. Non-Bonnet 无阀盖NC Normally Closed 常闭NIP Nipple 短管NO Normally Open; 常开*Number号；数量NO INS No Insulation 不隔热NOM Nominal 公称的；额定的NOZ Nozzle 管口NPS Nominal Pipe Size 公称管径NPSH Net Positive Suction Head 净正吸入压头NPT *American National Taper 美国锥管螺纹Pipe ThreadNS Nominal Size 公称直径NV Needle Valve 针形阀OOD *Outside Diameter 外径OET One end Threaded 一端带螺纹OR Outside Radius 外半径ORF Orifice 孔板ORIENT Orientation 方位OS & Y Outside Screw and Yoke 外螺纹阀杆和阀轭OSNB Outside Screw Non-Bonnet 外螺纹无阀盖PP Plug 堵头PAP Piping Arrangement Plan 管道布置平面图PB Pressure Seal Bonnet 压力密封的阀盖P-B Plain End –Bevel End 平端—坡口端PC Pressure Seal Cap 压力密封的阀帽Pitch Circle Diameter 节圆直径PE Plain End (not beveled) 平端（无坡口）PF Platform 平台PID Piping & Instrument Diagram管道及仪表流程图PN *Nominal Pressure 公称压力PN Plant North 工厂北向POS point of Support 支承点P-P Plain End—Plain End 两端为平端PREP Preparation 加工准备PSIA *Pounds Per Square Inch Absolute 磅/ PSIG Pounds Per Square Inch Gage 磅/PT Point 点PTFE *Polytetrafluoroethylene 聚四氟乙烯Part No. 件号PV Plug Valve 旋塞阀PVC *Poly Vinyl Chloride 聚氯乙烯QQTY *Quantity 数量RR * Radius 半径RED Reducer 异径管REF Reference 参考REINF Reinforce 加强REQD Required 需要；申请REV *Revision 修改RF Raised Face 凸面RG Ring Gasket 环形垫片Right Hand Thread 右螺旋RJ Ring Joint 环垫接头RO Restriction Orifice 限流孔板RPM * Revolutions Per Minute 转/分RPS * Revolutions Per Second 转/秒RS Resting Support 支承架，滑动架RTJ Ring Type Joint（见RJ）RV Relief Valve 安全泄液阀SS *South 南S Spring 弹簧（管架用）SAW (Automatic)Submerged Arc Wel**** 自动埋弧焊SB Stud Bolt 双头螺栓SB Screwed Bonnet 螺纹阀盖SC Sample Cooler 取样冷却器SCH * Schedule 管壁厚系列号SCRD Screwed 螺纹SEP Small end Plain 小端为平的SET Small end Threaded 小端带螺纹SF Semi-Finished 半光SG Sight Glass 视镜SH Surface Hard Facing 硬质密封面SK Sketch 草图SMAW Shielded Metal Arc Wel**** 有保护的金属电弧焊SMLS Seamless 无缝SN Swaged Nipple 异径短管SO Slip – On 滑套SOF Slip – On Flange 滑套法兰SPEC * Specification 规定，说明SPL Sound Pressure Lever 升压水准SQ * Square 方的，平方SR Shout Radius 短半径SRE Short Radius Elbow 短半径弯头SS *Stainless Steel 不锈钢ST Steam Trap 蒸汽疏水阀STD *Standard 标准STG Small Tongue & Groove 小椎槽面STL *Steel 钢STM Steam 蒸汽Steam Tracing 蒸汽拌热SUCT Suction 吸入口SV Safety Valve 安全泄气阀SW Socket Weld 承插焊SWG Swage 锻造，模锻SWMG Swing Type 旋启式SYM Symmetrical 对称的TT Tee 三通TE Threaded End 螺纹端TEMP *Temperature 温度TG Tongue & Groove 椎槽THD *Threaded 螺纹的THK *Thickness 厚度TL Tangent Line 切线TN True North 真实北向TOC Top of Concrete 混凝土北向TOP Top of pipe 管顶TOS Top of Support 支架顶面Top of Steel 钢结构顶面TY P Typical 典型的UUB Union Bonnet 带活接头的阀盖UC Union Cap 带活接头的阀帽UN Union 活接头VV Valve 阀VAC Vacuum 真空VAR Variable 可变的VERT Vertical 垂直的VOL *Volume 卷，册，容量，体积WW * West 西WB Weld Branch 焊接支管WC Weld Cap 焊接管帽WD Width 宽度WE Weld End 焊接端WL Wel**** Line 焊接线WN Wel**** Neck 对焊法兰（颈部）WNF Weld Neck Flange 对焊法兰WP Working Pressure 工作压力. Working Point 工作点WT Wall Thickness 壁厚Weight 重量XXH Extra Heavy 加强的，加厚的XXH Double Extra Heavy 双倍加强（厚）的XS Extra Strong 加强的XXS Double Extra Strong 双倍加强的YYP Yield Point 屈服点管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头（右向或左向） side outlet elbow (right hand or left hand)双支管弯头（形） double branch elbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通（右向或左向） side outlet tee (right hand or 1eft hand) 异径三通（分支口为异径） reducing tee (reducing on outlet)异径三通（一个直通口为异径） reducing tee (reducing on one run)带支座三通 base tee异径三通（一个直通口及分支口为异径） reducing tee (reducing on one run and outlet) 异径三通（两个直通口为异径，双头式） reducing tee (reducing on both runs, bull head)45°斜三通45° lat eral45°斜三通（支管为异径）45° lateral (reducing on branch)45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch)Y型三通（俗称裤衩）true “Y”四通 cross等径四通 straight cross异径四通 reducing cross异径四通（一个分支口为异径 reducing cross (reducing on one outlet) 异径四通（一个直通口及分支口为异径） reducing cross (reducing on one run and outlet) 异径四通（两个分支口为异径） reducing cross (reducing on both outlet)异径四通（一个直通口及两个分支口为异径） reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管 reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台 sockolet弯头支管台 elbolet斜接支管台 latrolet镶入式支管嘴 sweepolet短管支管台 nipolet支管台，插入式支管台 boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头 union内外螺纹缩接（俗称补芯） bushing管帽 cap (C)堵头 plug短节 nipple异径短节 reducing nipple; swage nipple弯管 Bend预制弯管 fabricated pipe bend跨越弯管（^ 形） cross-over bend偏置弯管（~ 形） offset bend90°弯管 quarter bend环形弯管 cirele bend单侧偏置90°弯管（形） single offset quarter bend S形弯管“S” bend单侧偏置U形膨胀弯管（| 形）single offset “U” bend U形弯管“U” bend双偏置U膨胀弯管double offset expansion “U” bend 斜接弯管 mitre bend三节斜接弯管 3-piece mitre bend折皱弯管 corrugated bend圆度 roundness法兰 Flange (FLG）整体管法兰 integral pipe flange钢管法兰 steel pipe flange螺纹法兰 threaded flange滑套法兰（包括平焊法兰） slip-on flange (SO); slip-on welding flange 承插焊法兰 socket welding flange松套法兰 lap joint flange (LJF)对焊法兰 welding neck flange (WNF)法兰盖 blind flange, blind孔板法兰 orifice flange异径法兰 reducing flange盘座式法兰 pad type flange松套带颈法兰 loose hubbed flange焊接板式法兰 welding plate flange对焊环 welding neck collar （与stub end相似）平焊环 welding-on collar突缘短节 stub end, lap翻边端 lapped pipe end松套板式法兰 loose plate flange压力级 pressure rating, pressure rating class压力—温度等级 pressure-temperature rating法兰密封面，法兰面 flange facing突面 raised face (RF)凸面 male face (MF)凹面 female face (FMF)榫面 tongue face槽面 groove face环连接面 ring joint face全平面；满平面 flat face; full face (FF)光滑突面 smooth raised face (SRF)法兰面加工 facing finish粗糙度 roughness光滑的 smooth齿形 serrated均方根 root mean square (RMS)算术平均粗糙高度 arithmetical average roughness height (AARH)配对法兰 companion-flange螺栓圆 bolt circle .)垫片 Gasket (GSKT)垫片的型式 type of gasket平垫片 flat gasket环形平垫片 flat ring gasket平金属垫片 flat metal gasket夹棉织物的橡胶 elastomer with cotton fabric insertion夹石棉织物的橡胶 elastomer with asbestos fabric insertion夹石棉织物及金属丝加强的橡胶 elastomer with asbestos fabric insertion and with wire reinforcement无石墨压缩白石棉垫片 non graphited compressed white asbestos gasket天然白橡胶垫片 natural white rubber gasket压缩石棉垫片 compressed asbestos class gasket浸聚四氟乙烯的石棉垫片 PTFE impregnated asbestos gasket夹石棉的缠绕金属垫片 spiral-wound metal gasket with asbestos filler内环 inner ring外环，外定位环 outer ring波纹金属垫片 corrugated metal gasket波纹金属包嵌石棉垫片 corrugated metal gasket with asbestos inserted双夹套波纹金属包石棉垫片 corrugated metal double jacketed asbestos filled gasket双夹套垫片 double jacketed gasket金属包石棉平垫片 flat metal jacketed asbestos filled gasket整体金属齿形垫片 solid metal serrated gasket槽形金属垫片 grooved metal gasket环形连接金属垫片 ring joint metal gasket八角环形垫片 octagonal ring gasket椭圆环形垫片 oval ring gasket透镜式垫片 lens gasket非金属垫片 non-metallic gasketTOE是Threaded One End的缩写，意思是一端螺纹POE是Plain One End的缩写，意思是一端平口TBE是Threaded Both End的缩写，意思是两端螺纹PBE是Plain Both End的缩写，意思是两端平口TOE&POE就是一端平口，另一端螺纹连接TBE就是两头都是螺纹连接PBE就是两头都是平口（焊接）。

●弯头 elbow异径弯头 reducing elbow带支座弯头 base elbow长半径弯头（标准1.5倍弯曲半径---1.5D）long radius elbow●三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通（右向或左向） side outlet tee (right hand or 1eft hand)异径三通（分支口为异径） reducing tee (reducing onoutlet)异径三通（一个直通口为异径）reducing tee (reducing on one run)带支座三通 base tee异径三通（一个直通口及分支口为异径） reducing tee(reducing on one run and outlet)异径三通（两个直通口为异径，双头式） reducing tee(reducing on both runs, bull head)45°斜三通 45° lateral45°斜三通（支管为异径） 45° lateral (reducing on branch) 45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch)Y型三通（俗称裤衩） true “Y”四通 cross等径四通 straight cross异径四通 reducing cross异径四通（一个分支口为异径）reducing cross (reducing on one outlet)异径四通（一个直通口及分支口为异径） reducing cross (reducing on one run and outlet)异径四通（两个分支口为异径） reducing cross (reducing on both outlet)异径四通（一个直通口及两个分支口为异径） reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管 reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台 sockolet弯头支管台 elbolet斜接支管台 latrolet镶入式支管嘴 sweepolet短管支管台 nipolet支管台，插入式支管台 boss●螺纹支管台Threadolet●弯头支管台elbolet●焊接支管台weldolet；on weld●短管支管台nipolet●承插支管台sockolet●烧焊支管台weldolet●斜接支管台latrolet●承插焊支管台Sockolet支管台，插入式支管台boss管接头 coupling, full coupling 半管接头 half coupling异径管接头 reducing coupling活接头 union内外螺纹缩接（俗称补芯） bushing管帽 cap (C)堵头 plug短节 nipple异径短节 reducing nipple; swage nipple管道英文缩写A Anchor 固定ABS * Absolute 绝对的AISI *American Iron and Steel Institute美国钢铁学会ANSI * American National Standards Institute 美国国家标准学会API *American Petroleum Institute 美国石油学会APPROX *Approximate 大约，近似的ASB Asbestos 石棉ASME *American Society Of Mechanical Engineers美国机械工程师协会ASSY * Assembly 装配，组装ASTM * American Society Of Testing Material 美国材料实验协会ATM * Atmosphere 大气压AWG * American Wire Gage 美国线规AWS * American Wel**** Society 美国焊接协会AWWA * American Water Works Association 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B-B Beveled End-Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆B.C Bolted Cover(cap) 螺栓连接的阀兰盖（帽）BE Beveled End (for wel****) 坡口（焊接用）B.E Bell End 承口BEP Both Ends Plain 两端平BET Both Ends Threaded 两端带螺纹BL Battery Limit 装置区边界BF Blind Flange 盲板法兰BLD Blind 盲板BLDG *Buil**** 建筑物BM Bill Of Material 材料表BOP Bottom Of Pipe 管底B-P Beveled End —Plain End 坡口端.平端BV Butterfly valve 蝶阀BWG * Birmingham Wire Gage 伯明翰线规BW Butt Weld 对焊CC Cap 管帽C-C Center to Center 中至中C-E Center to End 中至端面C-F Center to Face 中至面CH-OP Chain Operated 链条操纵的CH.PL Checkered Plate 花纹钢管C.I *Cast Iron 铸铁CL *Class 英制压力等级，等级，种类CLEAR Clearance 间隙COD Continued on Drawing 接续图COL *Column 柱，塔CONC Concentric 同心的CONN Connection 连接，接口CONT *Continue 连续CONT.V. Control Valve 控制阀CPLG Coupling 管接头，连轴节C.R. Concentric Reducer 同心异径管C.S. *Carbon Steel 碳钢C.S. Cold Spring 冷紧C.S.C. Car Seal Close 在关闭状态下封住C.S.O. Car Seal Open 在开启状态下封住CUST Customer 客CH Check Valve 止回阀DEG *Degree 度DF Drain funnel 排液漏斗DIA *Diameter 直径DIM *Dimension 尺寸DISCH *Discharge 出口，排出Diaphragm VELVE 隔膜阀DMF Double Male And Female 双重凹凸DN Norminal Diameter公称直径DN Down 下DR Drain 排液DS Directional Stop 定向限为架DWG * Drawing 图EE *East 东EC External Coating 外面涂防腐层ECC Eccentric 偏心EFW Electric Fusion Welded 电容焊的EL(ELEV) *Elevation 标高；立面ELL Elbow 弯头EQIOP Equipment设备，装置EQUIV Equivalent 相当的E.R. Eccentric Reducer 偏心异经管ERW Electric Resistance Welded 电阻焊的EW Eye Washer & Shower 洗眼器及淋浴器EXP.JT Expansion Joint 膨胀节FFDN Foundation基础FF Flat Faced Or Full Faced 全平面；满平面F-F Face To Face 面至面FGW Fusion Gas Wel**** 气熔焊FIG *Figure 图FL Floor 楼面FLEX TUBE Flexible Tube 挠性管FLG Flange 法兰FLGD Flanged 法兰式的FLGF Flanged Face 法兰面FOB Flat On Bottom 底面平FOT Flat On Top 顶面平FP Fix Point 固定点FS Forged Steel 锻钢FTF Fitting To Fitting 管件直连FTG Fitting 管件FURND Furnished 提供的，装设的FW Field Weld 现场焊G Guide 导向GA * Gage 表，表压，规（线规）GALV *Galvanize 镀锌GL Ground Level 地面GLV Globe Valve 截止阀GEAR OP Gear Operated 齿轮传动的GMAW Gas Metal Arc Wel**** 金属极惰气体保护焊GSKT Gasket 垫片GTAW (Inert)Gas Tungsten Arc Wel**** 惰性气体保护钨极电弧焊GV Gate Valve 闸阀HH Hanger 吊架HC Hose Connection 软管接头H.CPLG Half Coupling 半节管接头HDR Header 总管HEX *Hexagon 六角形HF Hard Alloy Face on阀内件（阀心）为Valve Trim 硬质合金密封面HH Hand Hole 手孔HOR Horizontal 水平的H.P * High Pressure 高压HS Hose Station 软管IID * Inside Diameter 内径IN * Inch 英寸INS Insulation 隔热INST Instrument仪表INV Invert (inside bottom of pipe) 管子内底IPS Iron Pipe size 铁管尺寸ISO Isometric Drawing周测图（空视图）I.S.B.L Inside Battery Limit 装置边界内恻ISNS Inside screw & Non-rising Stem 内螺纹非升杆ISRS Inside screw & Rising stem 内螺纹升杆JJT Joint 接头JS Jack Screw 顶开（起）螺栓LLC Locked Closed 在关闭状态下锁定LEP Large end plain 大端为平的LET Large end Threaded 大端带螺纹LG Long 长LGF Lens Gasket Face 透镜垫连接面L.H. THD Left Hand Thread 左螺纹LIFT Lift Type 升降式LJ Lap Joint 搭接LJF Lap Joint Flange 松套法兰LO Locked Open 在开启状态下锁定L.P. Low Pressure 低压LR Long Radius 长半径LRE Long Radius Elbow 长半径弯头LTG Large Tongue & Groove 大椎槽MMATL Material 材料MAX Maximum 最大MB Machine Bolt 机器螺栓（单头）MF Male and Female 凸和凹MFG Manufacture 制造MF * Manufacture 制造厂MH Manhole 人孔MI Malleable Iron 可锻铸铁MIN *Minimum 最小MJ Mechanical Joint 机械接头M.L Match Line 连续线MSS * Manufacturers Standardization Society of the Valve and Fittings Industry, Inc.美国阀门和管件制造商标准化协会MTO Material take-off 材料统计MW Minimum Wall 最小壁厚M.W. Mineral Wool 矿（物）棉NN * North 北NB Nominal Bore 公称孔径N.B. Non-Bonnet 无阀盖NC Normally Closed 常闭NIP Nipple 短管NO Normally Open; 常开*Number号；数量NO INS No Insulation 不隔热NOM Nominal 公称的；额定的NOZ Nozzle 管口NPS Nominal Pipe Size 公称管径NPSH Net Positive Suction Head 净正吸入压头NPT *American National Taper 美国锥管螺纹Pipe ThreadNS Nominal Size 公称直径NV Needle Valve 针形阀OOD *Outside Diameter 外径OET One end Threaded 一端带螺纹OR Outside Radius 外半径ORF Orifice 孔板ORIENT Orientation 方位OS & Y Outside Screw and Yoke 外螺纹阀杆和阀轭OSNB Outside Screw Non-Bonnet 外螺纹无阀盖PP Plug 堵头PAP Piping Arrangement Plan管道布置平面图PB Pressure Seal Bonnet 压力密封的阀盖P-B Plain End –Bevel End 平端—坡口端PC Pressure Seal Cap 压力密封的阀帽P.C.D. Pitch Circle Diameter 节圆直径PE Plain End (not beveled) 平端（无坡口）PF Platform 平台PID Piping & Instrument Diagram管道及仪表流程图PN *Nominal Pressure 公称压力PN Plant North 工厂北向POS point of Support 支承点P-P Plain End—Plain End 两端为平端PREP Preparation 加工准备PSIA *Pounds Per Square Inch Absolute 磅/ PSIG Pounds Per Square Inch Gage 磅/PT Point 点PTFE *Polytetrafluoroethylene 聚四氟乙烯PT.NO Part No. 件号PV Plug Valve 旋塞阀PVC *Poly Vinyl Chloride 聚氯乙烯QQTY *Quantity 数量RR * Radius 半径RED Reducer 异径管REF Reference 参考REINF Reinforce 加强REQD Required 需要；申请REV *Revision 修改RF Raised Face 凸面RG Ring Gasket 环形垫片R.H.THD Right Hand Thread 右螺旋RJ Ring Joint 环垫接头RO Restriction Orifice 限流孔板RPM * Revolutions Per Minute 转/分RPS * Revolutions Per Second 转/秒RS Resting Support 支承架，滑动架RTJ Ring Type Joint（见RJ）RV Relief Valve 安全泄液阀SS *South 南S Spring 弹簧（管架用）SAW (Automatic)Submerged Arc Wel**** 自动埋弧焊SB Stud Bolt 双头螺栓SB Screwed Bonnet 螺纹阀盖SC Sample Cooler 取样冷却器SCH * Schedule 管壁厚系列号SCRD Screwed 螺纹SEP Small end Plain 小端为平的SET Small end Threaded 小端带螺纹SF Semi-Finished 半光SG Sight Glass 视镜SH Surface Hard Facing 硬质密封面SK Sketch 草图SMAW Shielded Metal Arc Wel**** 有保护的金属电弧焊SMLS Seamless 无缝SN Swaged Nipple 异径短管SO Slip – On 滑套SOF Slip – On Flange 滑套法兰SPEC * Specification 规定，说明SPL Sound Pressure Lever 升压水准SQ * Square 方的，平方SR Shout Radius 短半径SRE Short Radius Elbow 短半径弯头SS *Stainless Steel 不锈钢ST Steam Trap蒸汽疏水阀STD *Standard 标准STG Small Tongue & Groove 小椎槽面STL *Steel 钢STM Steam 蒸汽STM.TR Steam Tracing 蒸汽拌热SUCT Suction 吸入口SV Safety Valve 安全泄气阀SW Socket Weld 承插焊SWG Swage 锻造，模锻SWMG Swing Type 旋启式SYM Symmetrical 对称的TT Tee 三通TE Threaded End 螺纹端TEMP *Temperature温度TG Tongue & Groove 椎槽THD *Threaded 螺纹的THK *Thickness 厚度TL Tangent Line 切线TN True North 真实北向TOC Top of Concrete 混凝土北向TOP Top of pipe 管顶TOS Top of Support 支架顶面Top Top of Steel 钢结构顶面TY P Typical 典型的UUB Union Bonnet 带活接头的阀盖UC Union Cap 带活接头的阀帽UN Union 活接头VV Valve 阀VAC Vacuum 真空VAR Variable 可变的VERT Vertical 垂直的VOL *Volume 卷，册，容量，体积WW * West 西WB Weld Branch 焊接支管WC Weld Cap 焊接管帽WD Width 宽度WE Weld End 焊接端WL Wel**** Line 焊接线WN Wel**** Neck 对焊法兰（颈部）WNF Weld Neck Flange 对焊法兰WP Working Pressure 工作压力W.P. Working Point 工作点WT Wall Thickness 壁厚Weight 重量XXH Extra Heavy 加强的，加厚的XXH Double Extra Heavy 双倍加强（厚）的XS Extra Strong 加强的XXS Double Extra Strong 双倍加强的YYP Yield Point 屈服点1.2 管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头（右向或左向） side outlet elbow (right hand or left hand)双支管弯头（形） double branch elbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通（右向或左向） side outlet tee (right hand or 1eft hand)异径三通（分支口为异径） reducing tee (reducing on outlet)异径三通（一个直通口为异径） reducing tee (reducing on one run)带支座三通 base tee异径三通（一个直通口及分支口为异径） reducing tee (reducing on one run and outlet)异径三通（两个直通口为异径，双头式） reducing tee (reducing on both runs, bull head)45°斜三通 45° lateral45°斜三通（支管为异径） 45° lateral (reducing on branch)45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch)Y型三通（俗称裤衩） true “Y”四通 cross等径四通 straight cross异径四通 reducing cross异径四通（一个分支口为异径 reducing cross (reducing on one outlet)异径四通（一个直通口及分支口为异径） reducing cross (reducing on one run and outlet)异径四通（两个分支口为异径） reducing cross (reducing on both outlet)异径四通（一个直通口及两个分支口为异径）reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管 reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台 sockolet弯头支管台 elbolet斜接支管台 latrolet镶入式支管嘴 sweepolet短管支管台 nipolet支管台，插入式支管台 boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头 union内外螺纹缩接（俗称补芯） bushing管帽 cap (C)堵头 plug短节 nipple异径短节 reducing nipple; swage nipple1.3 弯管 Bend预制弯管 fabricated pipe bend跨越弯管（^ 形） cross-over bend偏置弯管（~ 形） offset bend90°弯管 quarter bend环形弯管 cirele bend单侧偏置90°弯管（? 形） single offset quarter bend S形弯管“S” bend单侧偏置U形膨胀弯管（| ?形） single offset “U”bendU形弯管“U” bend双偏置U膨胀弯管 double offset expansion “U”bend斜接弯管 mitre bend三节斜接弯管 3-piece mitre bend折皱弯管 corrugated bend圆度 roundness1.4 法兰 Flange (FLG）整体管法兰 integral pipe flange钢管法兰 steel pipe flange螺纹法兰 threaded flange滑套法兰（包括平焊法兰） slip-on flange (SO);slip-on welding flange承插焊法兰 socket welding flange松套法兰 lap joint flange (LJF)对焊法兰 welding neck flange (WNF)法兰盖 blind flange, blind孔板法兰 orifice flange异径法兰 reducing flange盘座式法兰 pad type flange松套带颈法兰 loose hubbed flange焊接板式法兰 welding plate flange对焊环 welding neck collar （与stub end相似）平焊环 welding-on collar突缘短节 stub end, lap翻边端 lapped pipe end松套板式法兰 loose plate flange压力级 pressure rating, pressure rating class 压力—温度等级 pressure-temperature rating法兰密封面，法兰面 flange facing突面 raised face (RF)凸面 male face (MF)凹面 female face (FMF)榫面 tongue face槽面 groove face环连接面 ring joint face全平面；满平面 flat face; full face (FF)光滑突面 smooth raised face (SRF)法兰面加工 facing finish粗糙度 roughness光滑的 smooth齿形 serrated均方根 root mean square (RMS)算术平均粗糙高度 arithmetical average roughness height (AARH)配对法兰 panion-flange螺栓圆 bolt circle (B.C.)1.5 垫片 Gasket (GSKT)垫片的型式 type of gasket平垫片 flat gasket环形平垫片 flat ring gasket平金属垫片 flat metal gasket夹棉织物的橡胶 elastomer with cotton fabric insertion夹石棉织物的橡胶 elastomer with asbestos fabric insertion夹石棉织物及金属丝加强的橡胶 elastomer with asbestos fabric insertion and with wire reinforcement无石墨压缩白石棉垫片 non graphited pressed white asbestos gasket天然白橡胶垫片 natural white rubber gasket压缩石棉垫片 pressed asbestos class gasket浸聚四氟乙烯的石棉垫片 PTFE impregnated asbestos gasket夹石棉的缠绕金属垫片 spiral-wound metal gasket with asbestos filler内环 inner ring外环，外定位环 outer ring波纹金属垫片 corrugated metal gasket波纹金属包嵌石棉垫片 corrugated metal gasket with asbestos inserted双夹套波纹金属包石棉垫片 corrugated metal double jacketed asbestos filled gasket双夹套垫片 double jacketed gasket金属包石棉平垫片 flat metal jacketed asbestos filled gasket整体金属齿形垫片 solid metal serrated gasket槽形金属垫片 grooved metal gasket环形连接金属垫片 ring joint metal gasket八角环形垫片 octagonal ring gasket椭圆环形垫片 oval ring gasket透镜式垫片 lens gasket非金属垫片 non-metallic gasketTOE是Threaded One End的缩写，意思是一端螺纹POE是Plain One End的缩写，意思是一端平口TBE是Threaded Both End的缩写，意思是两端螺纹PBE是Plain Both End的缩写，意思是两端平口TOE&POE就是一端平口，另一端螺纹连接TBE是两头都是螺纹连接PBE是两头都是平口（焊接）BBE 两端都是坡口- . - -.可修编-。
