PHOENIX CONTACT GmbH & Co. KGPage 1 / 6http://www.phoenixcontact.de
Mar 5, 2008Extract from the onlinecatalog MVSTBR 2,5 HC/ 3-STOrder No.: 1912304The figure shows a 10-position version of the producthttp://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1912304 COMBICON HC plug components, 5.0 mm pitch, color: green, no. ofpositions 3, dimension a 10 mm Commercial dataEAN4017918192488Pack50 Pcs.Customs tariff85366990Weight/Piece0.00689 KGCatalog page informationPage 312 (CC-2007)Product notesWEEE/RoHS-compliant since:01/01/2003http://www.download.phoenixcontact.comPlease note that the data givenhere has been taken from theonline catalog. For comprehensiveinformation and data, please referto the user documentation. TheGeneral Terms and Conditions ofUse apply to Internet downloads.Technical dataDimensions / positionsPitch5 mmDimension a10 mmNumber of positions3Screw threadM 3Tightening torque, min0.5 Nm元器件交易网www.cecb2b.comMVSTBR 2,5 HC/ 3-STOrder No.: 1912304http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1912304
PHOENIX CONTACT GmbH & Co. KGPage 2 / 6http://www.phoenixcontact.deMar 5, 2008Technical dataInsulating material groupIRated surge voltage (III/3)4 kVRated surge voltage (III/2)4 kVRated surge voltage (II/2)4 kVRated voltage (III/2)320 VRated voltage (II/2)630 VConnection in acc. with standardEN-VDENominal current IN16 A (see derating curve)Nominal voltage UN250 VNominal cross section2.5 mm2Maximum load current16 AInsulating materialPAInflammability class acc. to UL 94V0Internal cylindrical gageA3Stripping length7 mmConnection dataConductor cross section solid min.0.2 mm2Conductor cross section solid max.2.5 mm2Conductor cross section stranded min.0.2 mm2Conductor cross section stranded max.2.5 mm2Conductor cross section stranded, with ferrulewithout plastic sleeve min.0.25 mm2Conductor cross section stranded, with ferrulewithout plastic sleeve max.2.5 mm2Conductor cross section stranded, with ferrulewith plastic sleeve min.0.25 mm2Conductor cross section stranded, with ferrulewith plastic sleeve max.2.5 mm2Conductor cross section AWG/kcmil min.24Conductor cross section AWG/kcmil max122 conductors with same cross section, solid min.0.2 mm22 conductors with same cross section, solid max.1 mm22 conductors with same cross section, strandedmin.0.2 mm2元器件交易网www.cecb2b.comMVSTBR 2,5 HC/ 3-STOrder No.: 1912304http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1912304
PHOENIX CONTACT GmbH & Co. KGPage 3 / 6http://www.phoenixcontact.deMar 5, 20082 conductors with same cross section, strandedmax.1.5 mm22 conductors with same cross section, stranded,ferrules without plastic sleeve, min.0.25 mm22 conductors with same cross section, stranded,ferrules without plastic sleeve, max.1 mm22 conductors with same cross section, stranded,TWIN ferrules with plastic sleeve, min.0.5 mm22 conductors with same cross section, stranded,TWIN ferrules with plastic sleeve, max.1.5 mm2Certificates / ApprovalsApproval logo CULNominal voltage UN300 VNominal current IN10 AAWG/kcmil30-12ULNominal voltage UN300 VNominal current IN10 AAWG/kcmil30-12CertificationCB, CUL, GOST, UL, VDE-PZIAccessoriesItemDesignationDescriptionMarking0804183SK 5/3,8:FORTL.ZAHLENMarker card, printed horizontally, self-adhesive, 12 identicaldecades marked 1-10, 11-20 etc. up to 91-(99)100, sufficient for120 terminal blocks0805072SK 5/3,8:SOMarker card, special printing, self-adhesive, labeled acc. tocustomer requirements, 12 identical marker strips per card, max.25-position labeling per strip, color: white0805409SK 5/3,8:UNBEDRUCKTMarker cards, unprinted, with pitch divisions, self-adhesive, 10-section marker strips, 12 strips per card, can be labeled with theM-PEN元器件交易网www.cecb2b.comMVSTBR 2,5 HC/ 3-STOrder No.: 1912304http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1912304
PHOENIX CONTACT GmbH & Co. KGPage 4 / 6http://www.phoenixcontact.deMar 5, 20080803906SK U/3,8 WH:UNBEDRUCKTUnprinted marker cards, DIN A4 format, pitch as desired, self-adhesive, with 40 stamped marker strips, 185 mm strip length, canbe labeled with the CMS system or manually with the M-PENPlug/Adapter1734634CP-MSTBCoding profile, is inserted into the slot on the plug or invertedheader, red insulating materialTools1205053SZS 0,6X3,5Screwdriver, bladed, matches all screw terminal blocks up to 4.0mm² connection cross section, blade: 0.6 x 3.5 mm, without VDEapprovalAdditional productsItemDesignationDescriptionGeneral1923762MSTBA 2,5 HC/ 3-GCOMBICON HC headers, 5.0 mm pitch, color: green, no. ofpositions 3, dimension a 10 mm1924208MSTBVA 2,5 HC/ 3-GCOMBICON HC headers, 5.0 mm pitch, color: green, no. ofpositions 3, dimension a 10 mmDrawingsDiagramDerating curve for: MVSTBR 2,5 HC/..-ST with MSTBVA 2,5HC/..-G元器件交易网www.cecb2b.comMVSTBR 2,5 HC/ 3-STOrder No.: 1912304http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1912304
