pt100b铂电阻分度表PT100热电阻分度表圈子类别:现场仪表 (未知) 2009-8-26 13:19:00[我要评论] [加入收藏] [加入圈子]工控朋友大家好～以下是PT100热电阻分度表。
帮助有需要的朋友，我乐意! PT100型热电阻分度表ORG 3000H;PT100 R_T TABLT ,-101~267cPT100_TABLT:DW 5987,6025,6066,6106,6147,6187,6228,6268,6309,6349,6390,6430 ;-101~-90c DW 6470,6511,6551,6591,6631,6672,6712,6752,6792,6833 ;-89~ -80c DW 6873,6913,6953,6993,7033,7073,7113,7153,7193,7233 ;-79~-70c DW 7273,7313,7353,7393,7433,7473,7513,7553,7593,7633 ;-69~-60c DW7673,7713,7752,7792,7832,7872,7911,7951,7991,8031 ;-59~-50c DW8070,8110,8150,8189,8229,8269,8308,8348,8388,8427 ;-49~-40c DW8467,8506,8546,8585,8625,8664,8704,8743,8783,8822 ;-39~-30c DW8862,8901,8940,8980,9019,9059,9098,9137,9177,9216 ;-29~-20c DW9255,9295,9334,9373,9412,9452,9491,9530,9569,9609 ;-19~-10c DW9648,9687,9726,9765,9804,9844,9883,9922,9961,10000 ;-9~0c DW10039,10078,10117,10156,10195,10234,10273,10312,10351,10390 ;1~10c DW 10429,10468,10507,10546,10585,10624,10663,10702,10740,10779 ;11~20c DW 10818,10857,10896,10935,10973,11012,11051,11090,11128,11167 ;21~30c DW 11206,11245,11283,11322,11361,11399,11438,11477,11515,11554 ;31~40c DW11593,11631,11670,11708,11747,11785,11824,11862,11901,11940 ;41~50c DW 11978,12016,12055,12093,12132,12170,12209,12247,12286,12324 ;51~60c DW 12362,12401,12439,12477,12516,12554,12592,12631,12669,12707 ;61~70c DW 12745,12784,12822,12860,12898,12937,12975,13013,13051,13089 ;71~80c DW 13127,13166,13204,13242,13280,13318,13356,13394,13432,13470 ;81~90c DW13508,13546,13584,13622,13660,13698,13736,13774,13812,13850 ;91~100c DW 13888,13926,13964,14002,14039,14077,14115,14153,14191,14229 ;101~110c DW 14266,14304,14342,14380,14417,14455,14493,14531,14568,14606 ;111~120c DW 14644,14681,14719,14757,14794,14832,14870,14907,14945,14982 ;121~130c DW 15020,15057,15095,15133,15170,15208,15245,15283,15320,15358 ;131~140c DW 15395,15432,15470,15507,15545,15582,15629,15657,15694,15731 ;141~150c DW 15769,15806,15843,15881,15918,15955,15993,16030,16067,16104 ;151~160c DW 16142,16179,16216,16253,16290,16327,16365,16402,16439,16476 ;161~170c DW 16513,16550,16587,16624,16661,16698,16735,16772,16809,16846 ;171~180c DW 16883,16920,16957,16994,17031,17068,17105,17142,17179,17216 ;181~190c DW 17253,17290,17326,17363,17400,17437,17474,17510,17547,17584 ;191~200c DW 17621,17657,17694,17731,17768,17804,17841,17878,17914,17951 ;201~210c DW 17988,18024,18061,18097,18134,18171,18207,18244,18280,18317 ;211~220c DW 18353,18390,18426,18463,18499,18536,18572,18609,18645,18682 ;221~230c DW 18718,18754,18791,18827,18863,18900,18936,18972,19009,19045 ;231~240c DW 19081,19118,19154,19190,19226,19263,19299,19335,19371,19407 ;241~250c DW 19444,19480,19516,19552,19588,19624,19660,19696,19733,19769 ;251~260c DW19805,19841,19877,19913,19949,19985,20021 ;261~267c 以上数据可以直接粘贴到你的汇编中。
pt100电阻与温度对应表.pt100电阻与温度对应表设计原理:pt100是铂热电阻,它的阻值会随着温度的变化而改变。
PT 后的100即表示它在0℃时阻值为100欧姆,在100℃时它的阻值约为138.5欧姆。
它的工业原理:当PT100在0摄氏度的时候他的阻值为100欧姆,它的的阻值会随着温度上升它的阻值是成匀速增涨的。
应用范围:医疗、电机、工业、温度计算、阻值计算等高精温度设备,应用范围非常之广泛。
PT100分度表-50度 80.31欧姆-40度 84.27欧姆-30度 88.22欧姆-20度 92.16欧姆-10度 96.09欧姆0度 100.00欧姆10度 103.90欧姆20度 107.79欧姆30度 111.67欧姆40度 115.54欧姆50度 119.40欧姆60度 123.24欧姆70度 127.08欧姆80度 130.90欧姆90度 134.71欧姆100度 138.51欧姆110度 142.29欧姆120度 146.07欧姆130度 149.83欧姆140度 153.58欧姆150度 157.33欧姆160度 161.05欧姆170度 164.77欧姆180度 168.48欧姆190度 172.17欧姆200度 175.86欧姆组成的部分常见的pt1oo 感温元件有陶瓷元件,玻璃元件,云母元件,它们是由铂丝分别绕在陶瓷骨架, 玻璃骨架,云母骨架上再经过复杂的工艺加工而成薄膜铂电阻薄膜铂电阻:用真空沉积的薄膜技术把铂溅射在陶瓷基片上, 膜厚在2微米以内 , 用玻璃烧结料把 Ni (或 Pd 引线固定,经激光调阻制成薄膜元件。
常用热电阻分度表工业用铂电阻温度计（ptioo ） R （t 分度表（C ）ft Hi T* — 1* IM IW 4KB« ■L* M $4 站 MM M 剂 n L> II it - Bk M- M »- 14 II «T H ■ F lb If li ■ 常 n « «k IL tL ■ 11 M ■ It ■L ■ Mr u u 科 ■1 M kL H. It. M- 卅 a ： it >!■ ■g —™ -il* -M4 ■ ■ 血 ■ »• i-r !• T4 41-1- • U lift- S-l- M- 耳rflTBk« U ■4 ■ * 时■ <T tarn ii. ii 虚 M H ■ ** ■ W H 44 IT n ■* Fl KJ 亦 irr 4 M ia ii • M 9t «1 ■ M 4- ■_ -w 二 J1FH- Gri. k m ■ •I •: er FL hu rt II ■ u M14 u ■9 n. H H Lfl- 1t u II il -H 目 Fl' n u .3 iiii » It %L Vt ■H. fk H H Hi M M -M 1L- 律 th PL U U T* II JI Rl 11 尸 M H- n • F Ab W 1* n a W- ■ » kA iF «i ■fr ft ■ fl IP 出 H- 褂 IF ■ a. iM ■& w4« d II 1? M- «k — ■ isII i-i1! it ■ II lin u M. 14 ft ■ 11 母 tv tbM HL 存 Al «l M ■fA . n W-H ■ M ・ hi w it H H M H M M u kr z n 阿Z M IK H 4 a la w z lw u l H lk l W I.Ti ^A ll M l ・a u l»M ll ta u ■讦 需监= = g ■矇监z x g m y q ll tj p r x …HERE" M m M M ll Z JI M M F 肾霊lit s f u FL xr k LI U E rf H 讥监!£ I 1 _— I .1'M 'vfl H FI HI ui ■ ♦Ir FL J !—皿■缁血 n >I f l 1■»- J I 1.百:M I1S n M n m w ・3l ・・!n S -M I+忖。
PT100热电阻分度表圈子类别：现场仪表 (未知) 2009-8-26 13:19:00[我要评论] [加入收藏] [加入圈子] 工控朋友大家好！以下是PT100热电阻分度表。
帮助有需要的朋友，我乐意!PT100型热电阻分度表ORG 3000H;PT100 R_T TABLT ,-101~267cPT100_TABLT:DW 5987,6025,6066,6106,6147,6187,6228,6268,6309,6349,6390,6430 ;-101~-90cDW 6470,6511,6551,6591,6631,6672,6712,6752,6792,6833 ;-89~ -80cDW 6873,6913,6953,6993,7033,7073,7113,7153,7193,7233 ;-79~-70cDW 7273,7313,7353,7393,7433,7473,7513,7553,7593,7633 ;-69~-60cDW 7673,7713,7752,7792,7832,7872,7911,7951,7991,8031 ;-59~-50cDW 8070,8110,8150,8189,8229,8269,8308,8348,8388,8427 ;-49~-40cDW 8467,8506,8546,8585,8625,8664,8704,8743,8783,8822 ;-39~-30cDW 8862,8901,8940,8980,9019,9059,9098,9137,9177,9216 ;-29~-20cDW 9255,9295,9334,9373,9412,9452,9491,9530,9569,9609 ;-19~-10cDW 9648,9687,9726,9765,9804,9844,9883,9922,9961,10000 ;-9~0cDW 10039,10078,10117,10156,10195,10234,10273,10312,10351,10390 ;1~10cDW 10429,10468,10507,10546,10585,10624,10663,10702,10740,10779 ;11~20cDW 10818,10857,10896,10935,10973,11012,11051,11090,11128,11167 ;21~30cDW 11206,11245,11283,11322,11361,11399,11438,11477,11515,11554 ;31~40cDW 11593,11631,11670,11708,11747,11785,11824,11862,11901,11940 ;41~50cDW 11978,12016,12055,12093,12132,12170,12209,12247,12286,12324 ;51~60cDW 12362,12401,12439,12477,12516,12554,12592,12631,12669,12707 ;61~70cDW 12745,12784,12822,12860,12898,12937,12975,13013,13051,13089 ;71~80cDW 13127,13166,13204,13242,13280,13318,13356,13394,13432,13470 ;81~90cDW 13508,13546,13584,13622,13660,13698,13736,13774,13812,13850 ;91~100c DW 13888,13926,13964,14002,14039,14077,14115,14153,14191,14229 ;101~110c DW 14266,14304,14342,14380,14417,14455,14493,14531,14568,14606 ;111~120c DW 14644,14681,14719,14757,14794,14832,14870,14907,14945,14982 ;121~130c DW 15020,15057,15095,15133,15170,15208,15245,15283,15320,15358 ;131~140c DW 15395,15432,15470,15507,15545,15582,15629,15657,15694,15731 ;141~150c DW 15769,15806,15843,15881,15918,15955,15993,16030,16067,16104 ;151~160c DW 16142,16179,16216,16253,16290,16327,16365,16402,16439,16476 ;161~170c DW 16513,16550,16587,16624,16661,16698,16735,16772,16809,16846 ;171~180c DW 16883,16920,16957,16994,17031,17068,17105,17142,17179,17216 ;181~190c DW 17253,17290,17326,17363,17400,17437,17474,17510,17547,17584 ;191~200c DW 17621,17657,17694,17731,17768,17804,17841,17878,17914,17951 ;201~210c DW 17988,18024,18061,18097,18134,18171,18207,18244,18280,18317 ;211~220c DW 18353,18390,18426,18463,18499,18536,18572,18609,18645,18682 ;221~230c DW 18718,18754,18791,18827,18863,18900,18936,18972,19009,19045 ;231~240c DW 19081,19118,19154,19190,19226,19263,19299,19335,19371,19407 ;241~250c DW 19444,19480,19516,19552,19588,19624,19660,19696,19733,19769 ;251~260c DW 19805,19841,19877,19913,19949,19985,20021 ;261~267c以上数据可以直接粘贴到你的汇编中。
Pt100热电阻计算公式及分度表
热电阻公式都是Rt=Ro(1+A*t+B*t*t);Rt=Ro[1+A*t+B*t*t+C(t-100)*t*t*t] 的形式，t表示摄氏温度，Ro是零摄氏度时的电阻值，A、B、C都是规定的系数，对于Pt100,Ro就等于100，
0到850度
Rt=R0（1+A*t+B*t^2）
-200到0
Rt=R0[1+A*t+Bt^2+C(t-100)^3]
R0是0度是铂电阻的阻值
A=3.940*乘10负3次幂
B=-5.802乘10负7次幂
C=-4.274乘10的负12
Pt100,就是说它的阻值在0度时为100欧姆，负200度时为18.52欧姆，200度时为175.86欧姆，800度时为375.70欧姆。
Pt100温度传感器的主要技术参数如下：测量范围：-200℃～+850℃；允许偏差值△℃：A 级±（0.15＋0.002│t│），B级±（0.30＋0.005│t│）；热响应时间<30s；最小置入深度：热电阻的最小置入深度≥200mm；允通电流≤5mA。
另外，Pt100温度传感器还具有抗振动、稳定性好、准确度高、耐高压等优点。
看到了？电流不能大于5mA，而电阻是随温度变化的，所以电压也要注意。
为了提高温度测量的准确性，应使用1V电桥电源、A/D转换器的5V参考电源要稳定在1mV级；在价格允许的情况下，Pt100传感器、A/D转换器和运放的线性度要高。
同时，利用软件矫正其误差，可以使测得温度的精度在±0.2℃。
Pt100热电阻分度表。
