软件开发中英文对照外文翻译文献(文档含英文原文和中文翻译)
译文：
仿真软件开发低大型复杂腔基于UG的二次开发
摘要---射击和弹跳射线(SBR)二次开发的基础软件是由国标库(UG)。射线跟踪的核心算法是基于优化的非均匀有理b样(NURBS)曲线表面相交算法建立在UG,导致非常高的射线路径跟踪的准确性没有啮合从而保持原有的空腔模型的准确性。它也是有效的避免同任何复杂的蛀牙,因为即使工作屏蔽的过程。两腔的几何建模及其散射模拟成一个统一的平台,形成一个易用的综合和环球环境电磁建模复杂的蛀牙。在本文开发的软件对复杂腔散射建模引入了一些数值结果显示的准确性和效率
关键词--电大型复杂cavit; 雷达截面; UG的二次开发; 射击和弹跳射线(SBR); 射线跟踪
I.介绍
雷达截面(RCS)的分析电等大型复杂洞进口或出口,双面或三面角反射器等,是计算电磁学中最重要的主题之一。低大型复杂的空腔结构,只有基于高频方法如射击和弹跳射线(SBR)[1][2][3]是合适的。传统上,为三步骤采用SBR首先,模型腔的CAD软件和网格表面的内墙,然后出口信息网格的结果;其次发现表面上的光线的反射点ray-surface十字路口和屏蔽计算;最后计算RCS即将离任的射线从腔。虽然这些网基于射线跟踪可用于任意形状的蛀牙从理论上讲,它有不准确的缺点路径建立在复杂的蛀牙导致贫穷的RCS计算精度。电大型复杂的蛀牙,射线跟踪的效率很低,由于分离腔建模与RCS计算复杂的仿真过程。为了解决这些问题, 一个强大的CAD软件,模拟电大型复杂腔并计算其RCS在同一平台。开发的软件具有以下优势: 1)腔建模和RCS计算在UG集成,因此仿真过程大大简化。2)表面啮合没有必要而射线可以追踪精度高和效率在任何任意形状的空腔。3)开发的软件是通用的电磁散射的凹面反射镜结构,如蛀牙和角落。小说射线追踪方法的新的先进的软件是基于UG的二次开发将讨论下一步,和RCS仿真结果。
II.提出的方法
射击和弹跳射线(SBR
SBR的基本概念是一个平面波由足够大量的平行光管(这里使用三角射线管)事件上的孔腔开放,每个射线管的能量集中在中线反映空腔墙基于几何光学定律和最终的开孔和树叶射线管足迹在中央的场振幅计算射线通过考虑几何差异因素,极化和材料加载腔壁。的总散射提起腔由总结发现散射场计算每个管的基尔霍夫近似衍射场的足迹在这里rim是可以忽略的比较从腔背散射的主导部分。SBR的详细理论可以在[1]和[2]。b射线追踪方法基于UG的二次开发UG是先进的CAD / CAM / CAE软件,采用非均匀有理b样(NURBS)作为其主要的建模工具。它提供了强大的建模能力和任意复杂腔建模精度高
UG的二次开发工具UG /开放的API UG和外来的程序之间的交互。UG / Open API包含大约2000个函数可以直接调用c++环境中有两种不同的模式对UG /开放项目:内部模式和外部模式。通过构建一个动态链接库允许访问几何模型及其相对日期在国标库会话直接使用UG /开放的API函数。内部模式是使用DLL链接,在连接速度快的优势,因此,本文选择了使用UG /开放api,可以建立一种有效的射线追踪方法和高精度优化基于NURBS曲线表面相交的算法。没有复杂的啮合和屏蔽程序,新的射线跟踪方法更容易比传统项目。图1显示了发现每个光线的反射点在腔室内的墙上发达的射线追踪方法。如果利用三角射线管,四个射线包括三条边
和一个中央线管,需要追踪如上所述。请全部实现的蛀牙与平台结构通过跟踪只有中央射线正如上面所讨论的。后找到一个反射点内墙,飞机的数学表达式可以使用点的坐标和单位法向量,然后反射光线的三条边射线管根据解析后的飞机可以找到。这进一步进步会带来一个巨大的减少射线追踪的时间。
图1所示。射线路径发现的射线追踪方法基于UG的二次开发。这个图显示三个入射光线入射方向发射的,和路径从参考点的s形腔,然后反映在内墙,最后到达开孔。
事实上,这部小说SBR上面讨论不仅可以应用在蛀牙,但也提供了一种新方法的电大尺寸目标的散射计算考虑多个现场互动,和过程将大大简化由于避免啮合和屏蔽需要在传统的物理光学(PO)。该方法的过程
仿真过程的方法是:1)模型或在UG中导入一个腔会话。2)自动识别腔开放光圈。3)代表了入射波与数量足够大的平行光管开孔腔和发射射线追踪。4)计算每个即将离任的背散射场在开孔管足迹。5)总结的背散射场管足迹和计算RCS的腔。
软件是通用的相对任意蛀牙和凹结构由于小说射线追踪方法建立与UG /开放API函数和一个统一的平台整合腔在UG建模和RCS计算。RAM涂层蛀牙也可以轻松地在这个软件。一个用户友好的界面与UG / Open UIStyler发达,在UG提供的GUI工具
III.数值结果
本文模拟了使用矩形腔,一个三角形的三面角反射器和一个矩形入口压电陶瓷墙来演示开发的软件。计算环境是奔腾4 - 2.8 ghz处理器,1 gb内存和Windows XP操作系统。入射波频率10 GHz,一步是程度1°模拟,俯仰角度θ从+ z方向和方位角度φ从+ x方向的模型。A. RCS的矩形腔和效率分析
图2显示了RCS的矩形腔的比较10 _,_方形截面,30 _长度[7]和模拟结果与开发的软件在不同的N(N是每个波长的节点数量,有四个光管穿过每个网格开放,所以光管的数量N×N×4平方波长)。这个数字表明快速收敛的开发了SBR的基础上提出新的射线追踪与平台腔结构。结果得到收敛当N达到4,线管的数量是64平方波长在这种情况下,N是以下模拟设置为4。模拟结果与[7]中的结果吻合较好。
θ度数
图形2. RCS的矩形腔与不同的N,平行极化
表1显示了CPU时间不同N在上面模拟,演示了该方法的效率高。
表一、CPU时间不同的N
N 2 3 4 5
CPU时间(分钟) 1.70 4.01 8.37 17.49
B.三角形的三面角反射器的RCS
RCS计算的三角形三面角反射器5 _边长度是如图3所示.我们的结果再次同意与MLFMM FEKO的结果很好。微小的区别来自于衍射场不覆盖目前在我们的结果。. 需要1.67分钟和45分钟为我们的软件和FEKO分别模拟结果。如此高的效率使它适合计算电磁散射从电大型复杂腔没有要求额外的计算机内存。
C.矩形进气道的RCS
散射模拟飞机的入口,典型的电大型复杂腔,在计算电——磁学仍然是一个挑战性的任务。图4是一个矩形入口的模型[7]和其RCS模拟软件。需要16.58分钟,25.15分钟得到的结果装具(b)和(c)。找到优秀的协议与参考文献[7]中的结果。所有这些结果验证新的射线追踪方法的准确性对于复杂的蛀牙在我们开发的软件。
(a) 个矩形入口的模型
图4.矩形进气道的RCS,平行极化
IV.结论
一个新颖的射线追踪方法和相应的SBR相对任意腔散射模拟软件开发基于UG的二次开发。软件的仿真程序进行了探讨。一些结果,显示良好的准确性和效率高的散射建模电大型复杂的蛀牙。
参考文献
[1]郝凌、周Ri-chee Shung-wu李。射击和弹跳射线:RCS的计算任意形状的空腔。IEEE反式天线progat,1989年,37(2):194 – 205
[2]角色h·帕沙克,罗伯特·j·霍尔德。模态、射线和梁的技术分析开放式波导腔的电磁散射。IEEE反式天线progat,1989年,37(5):635 - 647
[3]嬴政阮。电磁辐射的基本理论。成都电讯工程学院出版社,1984年
[4]傅雅宁。计算机图形学。国防工业出版社,2005
[5]李建州,徐家栋,等。基于国标库的设计评估软件。中国无线电科学学报,2005,20(2):222 - 225
[6]李建周,徐家栋等.综合RCS(雷达截面)计算一个更有效的RCS计算方法。西北工业大学学报,2003,21(4):449 - 452
[7]郝凌,Shung-wu 李 Ri-chee周。高高频RCS开放腔的矩形和圆形的横截面。IEEE反式天线progat,1989年,37(5):648 – 654
原文：
Development of RCS simulation software for electrically large complex cavities based on the secondary development of UG
LI Jianzhou JIANG Yingfu XU Jiadong School of Electronics and Information, Northwestern Polytechnical University,Xi’an Shanxi 710129, China
Abstrac ---t-A shooting and bouncing ray (SBR) based software is developed by the secondary development of Unigraphics (UG). The core algorithm of ray tracing is based on the optimized Non-uniform Rational B-splines(NURBS) curve-surface intersection algorithm built in UG, which results in very high accuracy of ray path tracing without meshing thus keeping the accuracy of theoriginal cavity model. It is also efficient even if work witha complex cavities because of avoiding of shielding
process. Both geometry modeling of cavity and its scattering simulation are into a uniform platform, which forms an easy-using integrative and universal environment for electromagnetic modeling of complex cavities.。In this paper, the developed software for complex cavity scattering modeling has been introduced with some numerical results todemonstrate the accuracy and efficiency
Key words-electrically large complex cavit; Radar Cross Section; secondary development of UG; shooting and
bouncing rays (SBR); ray-tracing
I. INTRODUCTION
Radar cross section (RCS) analysis of electrically large complex cavities such as inlet or outlet, dihedral or trihedral corner reflector etc.,。is one of the mostimportant topics in computational electromagnetics. Forelectrically large complex cavity structures, only high frequency based method such as shooting and bouncing ray (SBR)[1][2][3] is suitable. Traditionally, there arethree steps to employ SBR Firstly, to model the cavity in CAD software and mesh surfaces of its interior walls,then exports information of the mesh results; secondly finding the reflection points of the rays on the surfaces by ray-surface intersection and shielding calculation;finally calculates RCS from the outgoing rays from the cavity.Although such mesh based ray tracing can be used in arbitrarily shaped cavities theoretically,it has the disadvantage of inaccurate paths founding in complex cavities which lead to a poor RCS calculation accuracy。. For electrically large complex cavities, the
efficiency of ray tracing is very low due to the
separation of cavity modeling and RCS calculation witha complicated simulation procedure. To address theseproblems, an integrated simulation software isdeveloped based on secondary development of Unigraphics (UG), , a powerful CAD software, to model electrically large
complex cavity and calculate its RCS as well in the same platform. The developed software has the following advantages: 1) Cavity modeling and RCS calculation are integrated in UG, therefore the simulation procedure is greatly simplified. 2) Surface meshing is not necessary whereas rays can be traced with high accuracy and efficiency inside any arbitrarily shaped cavity. 3) The developed software is universal for electromagnetic scattering from any kind of concave structures such as cavities and corner reflectors. A novel
ray tracing method of this new advanced software which is based on the secondary development of UG will be discussed next, and the RCS simulation results are followed. II. PROPOSED METHOD A. Shooting and bouncing rays (SBR)
The basic concept of SBR is that a plane wave represented by a sufficiently large number of parallel ray tubes (triangular ray tube is used here) incident onto the aperture at the cavity open end, each ray tube with energy concentrated on the centre line reflects from the cavity walls based on the law of geometrical optics and eventually comes to the opening aperture and leaves a
ray-tube footprint on it The field amplitude of thecentral ray is calculated by taking consideration of geometrical divergence factor, polarization and material loading of the cavity walls. The total scattering filed of the cavity is found by summing up the scattering field calculated by Kirchhoff’s approximation from each individual tube footprint In here the diffracting field of the rim is negligible comparing to the dominate portion of back scattering from the cavity. The detail theory of SBR can be found in [1] and [2]. B. Ray tracing method based on secondary development of UG
UG is advanced CAD/CAM/CAE software which uses Non-uniform Rational B-splines (NURBS) as its main modeling tool. It provides powerful modeling ability and high accuracy for arbitrarily complex cavity modeling. The secondary development tools UG/Open API of UG interact between UG and extern program. UG/Open API contains approximately 2000 functions which can be called directly in C++ environment There are two different modes for UG/Open programs: Internal Mode and External Mode. By building a dynamic-link library allows to access the geometry model and its relative date within a Unigraphics session using UG/Open API functions directly. Internal Mode is using DLL link which has the advantage of fast in speed linking, therefore it has been chosen in this paper By using UG/Open APIs, an efficient ray tracing method can be built with high accuracy based on optimized NURBS curve-surface intersection algorithm. Without complicated meshing and shielding procedures, the novel ray tracing method is much easier to program than the traditional one. Figure 1 shows finding the reflection points of each ray on cavity interior walls with developed ray tracing method.
The procedure of ray tracing is based on the
secondary development of UG: 1) Get the identifier of the simulated cavity. Each item modeled in UG has its own identifier (tag) from which all the geometry information can be identified
ray-surface intersection functions in UG/Open API. The interested parameters including the coordinates of the intersection points on the cavity walls, the unit normal vectors and the radius of principal curvature can be extracted with a few inputting information, such as cavity identifier, the coordinates of the starting point and the incident
direction of the ray. 3) Use Snell’s law to find the reflection ray at the interior intersection point, and repeating the procedures above to find the next interior intersection point till the ray shoot out the cavity from the opening aperture. Also the effect of RAM coating can be easily added to the developed SBR procedure. In general, if triangular ray tube is utilized, four rays
including three edges and one central ray of the tube, are needed to be traced as described above.。be achieved
for the cavities with plat structures by tracing only the central ray as discussed above. After finding a reflection point on the interior walls, the mathematical expression of the plane can be obtained using the coordinates and unit normal vector of that point and then the reflection rays of the three edges of the ray tube can be found
according to the resolved plane. This further
improvement leads to a huge reduction of ray tracing time.
Figure 1. The ray paths found by the ray tracing method based on
the secondary development of UG. This figure displays three incident
rays launched from the incident direction, and the paths start from the
reference points out of the S-shaped cavity, then reflect at the interior
walls, and finally arrive at the opening aperture.
In fact, the novel SBR discussed above not only can be applied on cavities, but also provides a new way of scattering calculation of electrically large targets with considering multiple field interaction, and the procedure
will be greatly simplified thanks to avoiding meshing and shielding needed in traditional physical optics (PO). C. Process of the Proposed Method
The simulation procedure of proposed method is: 1) Model or import a cavity in UG session.
2) Identify the cavity and opening aperture automatically. 3) Represent the incident wave with a sufficiently large number of parallel ray tubes on the opening aperture and launch ray tracing in the cavity. 4) Calculate the back scattering field of each outgoing tube footprint on the opening aperture. 5) Sum up the back scattering field of all the tube footprints and calculate RCS of the cavity.
The software is universal for relatively arbitrary cavities and concave structures due to the novel ray tracing method built with UG/Open API functions and a uniform platform integrating cavity modeling and RCS
computing in UG. RAM coated cavities can also be easily performed in this software. A user friendly interface is developed with UG/Open UIStyler, the GUI tool provided in UG.
III. NUMERICAL RESULTS
In this paper, the simulations have been done using a rectangular cavity, a triangular trihedral corner reflector and a rectangular inlet with PEC walls to demonstrate the developed software. The computation
environment is Pentium 4 - 2.8GHz processor, 1GB memory with Windows XP operating system.
Incident wave frequency is 10 GHz, and the degree step is 1° for all the simulations, the pitching angle θ starts from +z direction and the azimuth a ngle φ starts from +x direction in the models. A. RCS of rectangular cavity and the efficiency analysis
Figure 2 shows the comparison of RCS of a
rectangular cavity with 10_ by 10_ square cross section, 30_ length in [7] and simulated results with developed software in different N (N is the number of nodes per wavelength, there are four ray tubes going through each grid on the opening, so the number of ray tubes is N×N×4 in a square wavelength). This figure indicates fast convergence of the developed SBR based on the proposed novel ray tracing for a cavity with plat
structures. The results get convergent when N reaches 4, and the number of ray tubes is 64 in a square wavelength in this case, so N is set to 4 for the following simulations. The simulated results agree well with the results in [7].
θ（DEGREES)
Figure 2. RCS of rectangular cavity with different N, parallel polarization
Table 1 shows CPU time for different N in above simulation, which demonstrates high efficiency of the proposed method. TABLE I. CPU TIME FOR DIFFERENT N
N 2 3 4 5
CPU time (min) 1.70 4.01 8.37 17.49
B. RCS of a triangular trihedral corner reflector
Calculated RCS of a triangular trihedral corner reflector with 5_ edge length is shown in Figure 3. Our result again agrees very well with the MLFMM result of
FEKO. The slight difference comes from the diffraction
field which is not covered at the moment in our result. It takes 1.67min and 45min for our software and FEKO respectively, to simulate the results. Such high efficiency makes it suitable for calculating electromagnetic scattering from electrically large complex cavities without requirement of additional computer memory.
Figure 3. RCS of a triangular trihedral corner reflector,?= 45°,parallel polarization
C. RCS of a rectangular inlet
Scattering simulation of inlet of aircraft, typical electrically large complex cavity, remains a challenging task in computational electro- magnetics. Figure 4 is the model of a rectangular inlet[7] and its RCS simulated by our software. It takes 16.58min and 25.15min to get the result of Figure4 (b) and (c) respectively. Excellent agreement is found with the result in reference [7]. All these results validate the accuracy of the novel ray tracing method for complex cavities within our
developed software.
(a) The model of a rectangular inlet
Figure 4. RCS of a rectangular inlet, parallel polarization
