Embedded Slab for Oscillator baseframe
Preparation works on slabs by grinding
grinding of slab surface
Surface must be checked by spirit level
Mounting plate with adjusting bolts
welding of support plates with slab
Final alignment of plates
Assembled base frame
Lifting of base frame
Temporary fixation of distance plate with fit on base frame by tack welding
Mounting base frame
Mounting base frame
after erection of base frame remove tack weld on distance plate
Alignment of base frame by using adjusting bolts
Alignment base frame
Adjusting bolts for alignment base frame
Mounting hydraulic Cylinder on oscillator(site)
or on the Oscillator Maintenance Stand (for easier handling)
Mounting Oscillator
