Limits and Tolerances
The breakage of the machine spare parts ,generally always from the surface layer beginning of .The function of the product ,particularly its credibility and durable ,be decided by the quantity of spare parts surface layer to a large extent. Purpose that studies the machine to process the surface quantity be for control the machine process medium various craft factor to process the surface quantity influence of regulation, in order to make use of these regulations to control to process the process, end attain to improve the surface quantity, the exaltation product use the function of purpose .
The machine processes the surface quantity to use the influence of the function to the machine
(A) The surface quantity to bear to whet the sexual influence
1.Rough degree of surface to bear to whet the sexual influence
A just process vice-of two contact surfaces of good friction, the first stage is rough only in the surface of the peak department contact ,the actual contact area is much smaller than theoretical contact area, in contact with each other the peak of the units have very great stress, to produce actual contact with the surface area of plastic deformation, deformation and peak between the Department of shear failure, causing serious wear.
Parts wear may generally be divided into three stages, the initial stage of wear and tear, normal wear and tear all of a sudden intense phase of stage wear.
Parts of the surface roughness of the surface wear big impact. In general the smaller the value of surface roughness, wear better. However, surface roughness value is too small, lubricants difficult to store, contact between the adhesive-prone elements, wear it to increase. Therefore, the surface roughness of a best value, the value and parts of the work related to increased work load, the initial wear increased, the best rough surface is also increased.
2.Cold Working hardening the surface of the wear resistance
Processing the Cold Work hardening the surface of the friction surface layer of metal microhardness increase, it will generally improve the wear resistance. Cold Working but not a higher degree of hardening, wear resistance for the better, because too much will lead to hardening of the Cold Working excessive loose organization of
metal, even a crack and peeling off the surface of the metal, declined to wear resistance.
(B)The surface quality of the impact of fatigue strength
Metal hand alternating loads of fatigue after the damage occurred in parts often Chilled layer below the surface and, therefore parts of the surface quality of fatigue very influential.
1.Surface roughness on the impact of fatigue strength
In alternating load, the surface roughness of the Au-site easily lead to stress concentration, a fatigue crack, the higher the value of surface roughness, surface traces of Yu Shen Wen, Wen at the end of the radius smaller, anti-fatigue damage at the end of the more capacity Worse.
2.Residual stress, fatigue Cold Work hardening of the impact
Residual stress on the impact of large parts fatigue. Surface layer of residual stress fatigue crack will expand and accelerate the fatigue damage the surface layer and the residual stress can prevent fatigue crack growth, delaying the formation of fatigue damage.
(C)The surface quality of the corrosion resistance of the impact
Parts of the corrosion resistance to a large extent depends on the surface roughness. The higher the value of surface roughness, Au Valley accumulate on the more corrosive substances. Corrosion resistance of the more worse.
Surface layer of residual stress will produce stress corrosion cracking, lower parts of the wear-resistance, and the residual stress is to prevent stress corrosion cracking.
(D) The surface quality with quality
Rough surface will affect the value of the size of the co-ordination with the surface quality. The gap with rough value will increase wear and tear, increased space, with the requirements of the destruction of nature. For Fit, the assembly part of the process of convex surface-crowded peak times, the actual reduction of the surplus and reduce the support of the connection between the strength.
Dimensioning
The design of a machine includes many factors other than those of determining the loads and stresses and selecting the proper materials. Before construction or manufacture can begin, it is necessary to have complete assembly and detail drawings to convey all necessary information to the shop men. The designer frequently is called upon to check the drawings before they are sent to the shop. Much experience and
familiarity with manufacturing processes are needed before one can become conversant with all phases of production drawings.
Drawings should be carefully checked to see that the dimensioning is done in a manner that will be most convenient and understandable to the production departments. It is obvious that a drawing should be made in such a way that it has one and only one interpretation. In particular, shop personnel should not be required to make trigonometric or other involved calculations before the production machines can be set up.
Dimensioning is an involved subject and long experience is required for its mastery.
Tolerances must be placed on the dimensions of a drawing to limit the permissible variations in size because it is impossible to manufacture a part exactly to a given dimension. Although small tolerances give higher quality work and a better operating mechanism, the cost of manufacture increases rapidly as the tolerances are reduced, as indicated by the typical curve of Fig 14.1. It is therefore important that the tolerances be specified at the largest values that the operating or functional considerations permit.
Tolerances may be either unilateral or bilateral. In unilateral dimensioning, one tolerance is zero, and all the variations are given by the other tolerance. In bilateral dimensioning, a mean dimension is used which extends to the midpoint of the tolerance zone with equal plus and minus variations extending each way from this dimension.
The development of production processes for large-volume manufacture at low cost has been largely dependent upon interchangeability of component parts. Thus the designer must determine both the proper tolerances for the individual parts, The manner of placing tolerances on drawings depends somewhat on the kind of product or type of manufacturing process. If the tolerance on a dimension is not specifically stated, the drawing should contain a blanket note which gives the value of the tolerance for such dimensions. However, some companies do not use blanket notes on the supposition that if each dimension is considered individually, wider tolerance than those called for in the note could probably be specified. In any event it is very important that a drawing be free from ambiguities and be subject only to a single interpretation.
Dimension and Tolerance
In dimensioning a drawing, the numbers placed in the dimension lines represent dimension that are only approximate and do not represent any degree of accuracy unless so stated by the designer.
To specify a degree of accuracy, it is necessary to add tolerance figures to the dimension. Tolerance is the amount of variation permitted in the part or the total variation allowed in a given dimension. A shaft might have a nominal size of 2.5 in. (63.5mm), but for practical reasons this figure could not be maintained in manufacturing without great cost. Hence, a certain tolerance would be added and , if a variation of ±0.003 in.(±0.08mm) could be permitted, the dimension would be stated 2.500±0.003(63.5±0.008mm).
Dimensions given close tolerances mean that the part must fit properly with some other part. Both must be given tolerances in keeping with the allowance desired, the manufacturing processes available, and the minimum cost of production and assembly that will maximize profit. Generally speaking, the cost of a part goes up as the tolerance is decreased. If a part has several or more surfaces to be machined, the cost can be excessive when little deviation is allowed from the nominal size.
Allowance, which is sometimes confused with tolerance, has an altogether different meaning.
It is the minimum clearance space intended between mating parts and represents
the condition of tightest permissible fit. If a shaft, size 1.4980.0000.003+
-, is to fit a hole of
size 1.5000.0030.000+
-, the minimum size hole is 1.500 and the maximum size shaft is 1.498.
Thus the allowance is 0.002 and the maximum clearance is 0.008 as based on the minimum shaft size and maximum hole dimension.
Tolerances may be either unilateral or bilateral. Unilateral tolerance means that any variation is made in only one direction from the nominal or basic dimension.
Referring to the previous example, the hole is dimensioned 1.5000.0030.000+
-, which
represents a unilateral tolerance. If the dimensions were given as 1.500±0.003, the tolerance would be bilateral; that is , it would vary both over and under the nominal dimension. The unilateral system permits changing the tolerance while still retaining the same allowance or type of fit. With the bilateral system, this is not possible without also changing the nominal size dimension of one or both of the two mating parts. In mass production, where mating parts must be interchangeable, unilateral tolerances are customary. To have an interference or fore fit between mating parts, the tolerances must be such as to create a zero or negative allowance.
Tolerances Limits and Fits
The drawing must be a true and complete statement of the designer’s expr essed in such a way that the part is convenient to manufacture. Every dimension necessary to define the product must be stated once and repeated in different views. Dimensions relating to one particular feature, such as the position and size of hole, where possible, appear on the same view.
There should be no more dimensions than are absolutely necessary, and no feature should be located by more than one dimension in any direction. It may be necessary occasionally to give an auxiliary dimension for reference, possibly for inspection. When this is so, the dimension should be enclosed in a bracket and marked for reference. Such dimensions are not governed by general tolerances.
Dimensions that affect the function of the part should always be specified and not left as the sum or other dimensions. If this is not done, the total permissible variation on that dimension will form the sum or difference of the other dimensions and their tolerance, and this with result in these tolerances having to be made unnecessarily tight. The overall dimension should always appear.
All dimensions must be governed by the general tolerance on the drawing unless otherwise stated. Usually, such a tolerance will be governed by the magnitude of the dimension. Specific tolerances must always be stated on dimensions affecting or interchangeability.
A system of tolerances is necessary to allow for the variations in accuracy that are bound to occur during manufacture, and still provide for interchangeability and correct function of the part.
A tolerance is the difference in a dimension in order to allow for unavoidable imperfections in workmanship. The tolerance range will depend on the accuracy of the manufacturing organization, the machining process and the magnitude of the dimension. The greater the tolerance range is disposed on both sides of the nominal dimension. A unilateral tolerance is one where the tolerance zone is on one side only of the nominal dimension, in which case the nominal dimension may from one of the limits.
Limits are the extreme dimensions of the tolerance zone. For example, nominal dimension
30mm tolerance 30.0230.000++ limits 30.025
30.000
Fits depend on the relationship between the tolerance zones of two mating parts,
and may be broadly classified into a clearance fit with positive allowance, a transition fit where the allowance may be either positive or negative (clearance or interference) , an interference fit where the allowance is always negative.
Type of Limits and Fits
The ISO system of Limits and Fits, widely used in a number of leading metric countries, is considerably more complex than the ANSI system.
In this system, each part has a basic size. Each limit of part, high and sign being obtained by subtracting the basic size form the limit in question. The difference between the two limits of size of a part is called the tolerance, an absolute without sign.
There are three classes of fits: 1) clearance fits, 2) transition fits ( the assembly may have either clearance or interference ), and 3) interference fits .
Either a shaft-basis system or a hole-basis system may be used. For any given basic size, a range of tolerance and deviations may be specified with respect to be line of zero deviation, called the zero line. The tolerance is a function of the basic size and is designated by a number symbol, called the grade-thus the tolerance grade. The position of the tolerance with respect to the zero line also a function of the basic size-is indicated by a letter symbol(or two letter), a capital letter for holes and a lowercase letter for shafts. Thus the specification for a hole and shaft having a basic size of 45mm might be45H8/g7.
Twenty standard grades of tolerance are provided, called IT 01,IT 0 ,IT 1-18, providing numerical values for each nominal diameter, in arbitrary steps up to 500mm (for example 0-3,3-6,6-10…, 400-500mm). The value of the tolerance unit, I, for grades 5-16 is
=+
0.0.001
i D
Where i is in microns and D in millimeters.
Standard shaft and hole deviations similarly are provided by sets of formulas, However, for practical, both tolerances and deviations are provided in three sets of rather complex tables. Additional tables gives the values for basic sizes above 500mm and for “Commonly Used Shafts and Holes” in two categories ---“General Purpose” and “Fine Mecbanisms and Horology”.
中文翻译
极限与误差
机械零件的破坏，一般总是从表层开始的。产品的性能，尤其式它的可靠性和耐久性，在很在程度上取决于零件表层的质量。研究机械加工表面质量的目的就是为了掌握机械加工中各种工艺因素对加工表面质量影响的规律，以便运用这些规律来控制加工过程，最终达到改善表面质量、提高产品使用性能的目的。机械加工表面质量对机器使用性能的影响
（一）表面质量对耐磨性的影响
1.表面粗糙度对耐磨性的影响
一个刚加工好的摩擦副的两个接触表面之间，最初阶段只在表面粗糙度的峰部接触，实际接触面积远小于理论接触面积，在相互接触的峰部有非常大的单位应力，使实际接触表面积处产生塑性变形、弹性变形和峰部之间的剪切破坏，引起严重磨损。
零件磨损一般可分为三个阶段，初期磨损阶段、正常磨损阶段忽然剧烈磨损阶段。
表面粗糙度对零件表面磨损的影响很大。一般说表面粗糙度值越小，其磨损性越好。但表面粗糙度值太小，润滑油不易储存，接触面之间容易发生分子粘接，磨损反而增加。因此，接触面的粗糙度有一个最佳值，其值与零件的工作情况有关，工作载荷加大时，初期磨损量增大，表面粗糙最佳也加大。
2.表面冷作硬化对耐磨性的影响
加工表面的冷作硬化使摩擦副表面层金属的显微硬度提高，故一般可使耐磨性提高。但也不是冷作硬化程度愈高，耐磨性久愈好，这是因为过分的冷作硬化将引起金属组织过度疏松，甚至出现裂纹和表面金属的剥落，使耐磨性下降。（二）表面质量对疲劳强度的影响
金属手交变载荷作用后产生的疲劳破坏往往发生在零件表面和冷硬层下面，因此零件表面质量对疲劳强度影响很大。
1.表面粗糙度对疲劳强度的影响
在交变载荷作用下，表面粗糙度的凹谷部位容易引起应力集中，产生疲劳裂纹，表面粗糙度值愈大，表面的纹痕愈深，纹底半径愈小，抗疲劳破坏底能力就愈差。
2.残余应力、冷作硬化对疲劳强度的影响
残余应力对零件疲劳强度的影响很大。表面层残余拉应力将使疲劳裂纹扩
大，加速疲劳破坏；而表面层残余应力能够阻止疲劳裂纹的扩展，延缓疲劳破坏的产生。
（三）表面质量对耐蚀性的影响
零件的耐蚀性在很大程度上取决于表面粗糙度。表面粗糙度值愈大，则凹谷中聚积腐蚀性物质就愈多。抗蚀性就愈差。
表面层的残余拉应力会产生应力腐蚀开裂，降低零件的耐磨性，而残余应力则能防止应力腐蚀开裂。
尺寸标注
一个机构的设计除了要考虑载荷硬力和选择合适的条件外还包括许多因素。装配或制造之前必须完成装配图和零件图的绘制以便传递所有必要的信息给车间的工人。设计人员非常频繁的被叫检查图纸在这些图纸送到车间之前。要熟悉生产图样的所有情况，需要对制造过程非常熟悉并具有很多经验。
图纸应仔细被检查以便使尺寸标注在生产车间最方便和理解的方式下标注。非常明显图纸应在有一种且只有一种解释的方式下标注。特别是，在生产用机械能被调整好之前，车间工作人员不需要进行三角学或其他复杂的计算。
尺寸标注是一项复杂的工作，要熟悉它需要长期的实践经验。
公差必须标注在图纸尺寸的后面以便限制在尺寸方面的变动偏差，因为不可能知道一个在尺寸方面非常精确的零件。虽然小的公差产生高质量的产品和机器，但是随公差的减小制造成本快速增加，正如图典型曲线所示，因此公差的确定在能保证产品质量或功能下取最大值。
公差可能是单向的或双向的。在单向尺寸标注中一个公差是零，所有的偏差由另一个公差给出。在双向尺寸标注中，使用平均公差即上下偏差绝对值相等的公差带。
工艺制造流程发展大批量制造低成本依靠零部件的互换性。因此设计者必须确定包括单个零件的合适公差和确定装配零件公差是间隙或过盈。生产者把公差标注在图纸上依靠产品类型和制造工艺类型给出注释。如果尺寸公差没有特别注明，图样必须要一个给出这些尺寸的公差值的综合注释。然而一些生产者并不用综合注释假定每个尺寸是单独的被考虑的可能会规定出注释中要求的更宽的公差。在任何情况下非常重要的是图纸不能模棱两可和只能有一种解释。
尺寸和公差
在图样标注时，除非设计者有意标明，注在尺寸线上的数字表明的尺寸仅是近似的，并不代表任何精确的等级。为了明确尺寸等级，在尺寸后面加上公差等
级是必须的。公差是在某一零件上被允许的变化量或在尺寸上总的变化量。一个轴可能有一个名义尺寸2.5英尺，但由于实际操作原因它不能实现在花费大量制造成本。因此一个确定的公差将被加上，如果±0.003英尺的变化被允许，尺寸将标注为2.500±0.003。
尺寸标准给定小的公差意味着相应零件比其他零件更合适。配合的零件都必须保持渴望的允差值，制造过程有效，生产装配中实现最小成本和最大利率。一般的说，如果公差减小生产成本上升。如果一个零件有几个或多个面要生产，当要求小的偏差生产成本将急剧上升。
允差有时会和公差混淆，它具有完全不同的意义。允差是设计最小的公差空间在配合零件和代表最紧的配合条件下。如果一个轴尺寸为1.4980.000
0.003+-,与它配合的孔的尺寸1.5000.0030.000+-,最小孔为1.500和最大轴的尺寸为1.498。因此最大允差为0.002和最大间隙为0.008，在最小轴和最大孔尺寸的基础上。
公差可能是单边的或双边的。单边公差意味以前任何偏差只在名义尺寸的一个方向。如上面的例子，孔的尺寸标注为1.5000.0030.000+-,表示单边公差。如果尺寸标注为1.500±0.003,公差表示为双边的。单边系统允许公差值发生变化但依然能保持相同的允差或配合类型，对双边的公差系统，它是不可以的，如果配合零件中一个或两个名义标注尺寸发生变化。在大批量生产中配合必须满足互换性，单边公差是常用的。为了在配合零件有过盈或受力配合，公差必须产生一个零或负的允差。 公差极限和配合
图纸必须真实和完整反映设计者的意图在这样方法下零件方便于制造。每一个尺寸必须表达不同视图里尺寸至少且只能为一次。对于有特殊要求的尺寸，如既有尺寸大小位置和要求，把尺寸和位置最好标在同一视图里。
除绝对需要的尺寸之外，不应该再有更多的尺寸，而在任一方向上，只能在一个尺寸上注上特殊要求。在偶尔情况下给出一个辅助的尺寸作为参考，可能为检验时用。在这种情况下，尺寸应该用括号括起来，以便参考。这样的尺寸不标公差。
影响零件功能的尺寸必须总是明确的给出不能留下另外的尺寸。如果不直接标注，在这种尺寸可能产生总的变化将要有以下构成的，有其他尺寸和他们公差的和或差，而且这会导致这些不能不定得过紧。整体尺寸应该能表现出现。
在图纸上所有尺寸都有由一般公差来制定除非特别标明。一般，如一个公差被标注的尺寸数字的旁边。专门公差标注在影响尺寸功能或互换性必须专门标注公差。
公差系统是必须允许这样一种变化在制造过程中必须出现的精度变化，仍然提供互换性和功能真确的零件。
公差在不同尺寸上不同的是为了允许在制造上不可避免的缺陷。公差变化依赖制造机器的精度，加工过程和尺寸大小。公差范围越大，制造过程中成本越低。双边公差的公差带会以名义尺寸上下移动，单边公差的公差带只能在名义尺寸的一边变动，在这种情况下名义尺寸可能是一个极限尺寸。
极限是公差带最外边尺寸。如名义尺寸30mm公差带
30.025
30.000
+
+极限尺寸
30.025
30.000
。
配合依赖于两个配合零件公差带关系，可以分成公差为正的间隙配合，过渡配合它的允差可能是正值或负值，过盈配合它的允差总是负值。
极限和配合的种类
世界标准组织的极限和配合，广泛用在许多先进米制国家，它比英制标准体系更相当复杂。
在世界标准公差系统，每个零件有一个基本尺寸。每个零件有一个极限尺寸，上下偏差从基本尺寸分开，大小和符号是极限尺寸减去基本获得的。差值为零件的两个极限尺寸之差称为公差，它是没有符号的绝对值。
这里有三种配合：1）间隙配合2）过渡配合（此配合可组成过渡或过盈）和3）过盈配合。
任何一个基轴制或基孔制都有使用。任一给定基本尺寸，公差范围和偏差被标准化根据零偏差，这个零偏差称为零线。公差是体现基本尺寸的一个功能被一些数字符号设计，这些数字符号叫等级即公差等级。公差带位置相对零线的位置也是基本尺寸一个功能—用字母符号来表示，用大写字母表示孔和用小写字母表示轴。对有基本尺寸为45mm孔和轴的配合就可以写成45H8/g7。
规定了20种标准公差等级，即IT01，IT0，IT1-118，它们是在500mm 以内硬性划分的每一段（例如0-3，3-6，6-10，……,400-500mm）的基本尺寸都对应有不同的标准公差数值。基本公差单元值为i，公差等级为5-16是i单位为nm和D单位为mm.
通过一系列公式轴和孔基本偏差标准化，但是在实际应用下，公差和偏差被提供在三套复杂表格里。轴表给出基本尺寸在500mm以上和“通用的轴和孔”分成两个表---“一般用途”和“精密机械和钟表”。
