德标和国标,国际标准中英文对照表
序号德国标准中文品名英文品名国际标准中国标准
Item DIN-Standard Description in Chinese Description in English
ISO-Standard GB-Standard
1DIN1 圆锥销taper pins ISO2339 GB117
2DIN7 圆柱销parallel pins ISO2338 GB119-86
3DIN84 开槽圆柱头螺钉slotted cheese head screws ISO1207 GB65-85 4DIN85 开槽盘头螺钉slotted pan head screws ISO1580 GB67-85
5DIN93 单耳止动垫圈tab washers GB854
6DIN94 开口销split cotter pins ISO1234 GB91
7DIN95 开槽半沉头木螺钉slotted raised csk head wood screws GB101
8DIN96 开槽半圆头木螺钉slotted round head wood screws GB99
9DIN97 开槽沉头木螺钉slotted countersunk head wood screws GB100 10DIN125-A 平垫plain washers ISO7089 GB97.1-85
11DIN125-B 平垫（带倒角） mediun washers ISO7090 GB97.2-85
12DIN126 平垫plain washers ISO7091
13DIN127-A 重型弹垫spring lock washers,tang ends GB7244
14DIN127-B 标准弹垫spring lock washers,square ends GB93-87
15DIN128-A 鞍形弹垫single coil spring lock washers GB7245-87
16DIN137-A 弹簧止动垫圈curved spring washers
17DIN137-B 波形弹垫wave spring washers GB955
18DIN186 T 型方颈螺栓T-head bolts with square neck GB37-88
19DIN188 T 型双接头螺栓T-head bolts with double nip
20DIN258 螺纹圆锥销taper pins with threaded end ISO8737
21DIN261 T 型头螺栓T-head bolts
22DIN315AF 蝶型螺母（美制） wing nuts amercia form
23DIN315DF 蝶型螺母（德制） wing nuts germany form GB62-88
24DIN316AF 蝶型螺钉（美制） wing screws amercia form
25DIN317DF 蝶型螺钉（德制） wing screws germany form
26DIN319 圆球型盖型螺母ball knobs
27DIN404 开槽带孔球面圆柱头螺钉slotted capstan screws
GB832-88
28DIN417 开槽长圆柱端紧定螺钉slotted set srews with full dog point ISO7435 GB75-85
29DIN427 开槽平端紧定螺钉（半牙） slotted set srews with chamfered end ISO2342 GB73-85
30DIN431 小六角特薄细牙螺母pipe nuts with thread GB808-88
31DIN432 外舌止动垫圈external tap GB856-88
32DIN433 小垫圈（用于圆柱头螺钉） washers for cheese head screws ISO7092 GB848-95
33DIN434 方斜垫圈（U 型）square taper washers for U-section GB852-88 34DIN435 方斜垫圈（I 型）square taper washers for l-sections
GB852-88
35DIN436 方垫圈square washers
36DIN438 开槽凹端紧定螺钉slotted set with cup point ISO7436 GB74-85 37DIN439 六角薄螺母hexagon thin nuts ISO4035 GB6172-86
38DIN439 细牙六角薄螺母hexagon thin nuts ISO8675 GB6173-86
39DIN440 木螺钉专用垫圈rounds washers for wood constructions
ISO7094
40DIN443 密封帽sealing caps,push-in type
41DIN444 活节螺栓B 型eye bolts form B GB798-88
42DIN462 内舌止动垫圈internal tab washers
43DIN463 双耳止动垫圈washers with two taps GB855-88
44DIN464 滚花高头螺钉knurled thumb screws with collar GB834-88 45DIN465 开槽滚花高头螺钉slotted knurled thumb screws with collar 46DIN466 滚花高螺母knurled thumb nuts with collar GB806-88 47DIN467 滚花薄螺母knurled thumb thin nuts GB807-88
48DIN470 锁紧垫圈sealing washers
49DIN471 轴用弹性挡圈retaining rings for shafts(external),circlips
GB894.1-86
50DIN472 孔用弹性挡圈retaining rings for bores(internal),circlips
GB893.1-86
51DIN478 方头带垫螺栓square head bolts with collar
52DIN479 方头圆柱底端螺栓square head bolts with half dog point
53DIN480 方头带垫半圆底端螺栓square head bolts with collar,half dog point and rounded end
54DIN508 T 型槽螺母T-slot nuts ISO299
55DIN525 单头螺柱single end studs
56DIN529 地脚螺栓masonry bolts GB799-88
57DIN546 带槽圆螺母slotted round nuts GB817-76
58DIN547 端面带孔圆螺母round nuts with drilled holes in one face
GB815-88
59DIN551 开槽平端紧定螺钉slotted sit screws with flat point ISO4776 GB73-85
60DIN553 开槽锥端紧定螺钉slotted set screws with cone point ISO7434 GB71-85
61DIN555 六角螺母hexagon nuts ISO4034
62DIN557 方螺母-C square nuts GB39-88
63DIN558 六角头螺钉hexagon screws ISO4018
64DIN561 六角头圆柱端紧定螺钉hexagon set screws with full dog point 65DIN562 薄型方螺母-B square nuts without bevel(pressed nuts)
66DIN571 六角头木螺钉hexagon head wood screws (coach screws) GB102-86
67DIN580 吊环螺钉lifting eye bolts ISO3266 GB825-76
68DIN582 吊环螺母lifting eye nuts
69DIN601 六角头螺栓hexagon bolts ISO4016
70DIN603 大半圆头方颈螺栓(马车螺栓) mushroom head square neck bolts (carriage bolts) ISO8677 GB14-88
71DIN604 沉头带插销马车螺栓flat countersunk nib bolts
72DIN605 沉头长方颈马车螺栓flat countersunk long square neck bolts 73DIN607 半圆头带插销马车螺栓cup head nib bolts
74DIN608 沉头短方颈马车螺栓flat countersunk short square neck bolts 75DIN609 六角头精配螺栓(长螺纹) hexagon fitted bolts,long thread
86 DIN835 双头螺柱（牙长 =2D ）
87 DIN906 内六角锥型闭锁螺钉
thread
88 DIN908 内六角直型闭锁螺钉
thread
89 DIN909 外六角锥型闭锁螺钉
thread
90 DIN910 外六角直型闭锁螺钉
91 DIN911 内六角扳手 studs-metal (end=2d) GB900-88 hexagon socket pipe plugs,conical hexagon socket screw plugs,cyl.
hexagon head pipe plugs,conical socket wrenches ISO2936 92 DIN912 内六角圆柱头螺钉
GB70-85
93 DIN913 内六角平端紧定螺钉
point ISO4026 GB77-85
94 DIN914 内六角尖端紧定螺钉 76 DIN610 六角头精配螺栓 (短螺纹) hexagon fitted bolts,short thread 77 DIN653 滚花平头螺钉 knurled thumb screws thin type GB835-88 78 DIN660 半圆头铆钉 round head rivets ISO1051 GB867-86
79 DIN661 沉头铆钉 contersunk head rivets ISO1051 GB869-86
80 DIN662 半沉头铆钉 raised contersunk head rivets ISO1051
81 DIN674 大扁头铆钉 mushroom head rivets ISO1051
82 DIN703 重型侧面带孔圆螺母 adjusting rings,heavy range (shafting collars)
83 DIN705 侧面带孔 圆螺母 adjusting rings,light range (shafting collars) GB816-88
84 DIN741 卡头 wire rope clips
85 DIN787 T 型槽螺钉 T-slot screws ISO299
hexagon socket cap screws ISO4762 hexagon socket set screws with flat
hexagon socket set screws with cone point ISO4027 GB78-85 95DIN915 内六角圆柱端紧定螺钉hexagon socket set screws with dog point ISO4028 GB79-85
96DIN916 内六角凹端紧定螺钉hexagon socket set screws with cup point ISO4029 GB80-85
97DIN917 薄型盲螺母hexagon cap nuts
98DIN920 开槽小圆柱头螺钉slotted short cheese head screws
99DIN921 开槽大圆柱头螺钉slotted large cheese head screws GB838-88 100DIN923 开槽圆柱头轴肩螺钉slotted pan head screws with shoulder GB830-88
101DIN927 开槽无头轴肩螺钉slotted shoulder screws
102DIN928 焊接方螺母square weld nuts GB/T13680-92
103DIN929 焊接六角螺母hexagon weld nuts GB/T13681-92
104DIN931 六角头螺栓（半牙）hexagon head screws ISO4014
GB5782-86
105DIN933 六角头螺栓（全牙）hexagon head screws ISO4017
GB5783-86
106DIN934 六角头螺母（1型） hexagon full nuts ISO4032 GB6170-86 107DIN934 细牙六角头螺母（1 型） hexagon full nuts ISO8673 GB6171-86 108DIN935 开槽六角螺母hexagon slotted and castle nuts ISO7035
GB6178-86
109DIN936 六角头薄螺母hexagon thin nuts ISO4035 GB6172.1-86
110DIN937 六角头开槽薄螺母hexagon thin slotted and castle nuts
ISO7038 GB6181-86
studs metal （end=1.5d ） hexagon head bolts,metric fine
hexagon head bolts,metric fine 111 DIN938 双头螺距（牙长 =1D ） studs metal （end=1d ） GB897-88
112 DIN939 双头 螺 距 （牙 长 =1.25D ） studs metal （end=1.25d ） GB898-88 113 DIN940 双头螺距（牙长 =1.5D ）
114 DIN960 六角头细牙螺栓（半牙）
pitch thread ISO8765 GB5785-86
115 DIN961 六角头细牙螺栓（全牙）
pitch thread ISO8676 GB5786-86
116 DIN962 头部穿孔六角头螺栓 additional shapes and versions for bolts 117 DIN963 开槽沉头螺钉 slotted countersund head screws ISO 2009 GB68-85
118 DIN964 开槽半沉头螺钉 slotted raised countersunk oval head screws ISO 2010 GB69-85
119 DIN965 十字槽沉头螺钉 cross recessedcountersunk head screws ISO7046 GB819-85
120 DIN966 十字槽半沉头螺钉 cross recessed raised countersunk head screws ISO7047 GB820-85
121 DIN970 六角头螺母 hexagon nuts type-1
122 DIN971 六角头螺母 hexagon nuts type-2
123 DIN972 细牙六角头螺母 （2 型 ） hexagon nuts with fine thread ISO8674 GB6176-86
124 DIN975 牙条 （全螺纹 ） threaded rods （studdings ） GB15389-94 125 DIN976 螺纹销 threaded pins （stud bolts ）
126 DIN979 六角头开槽薄螺母 （2 型） hexagon thin slotted and castle nuts 127 DIN980 全金属六角锁紧螺母（ 1 型） prevailling torque type hexagon nuts,all metall nuts ISO7199 GB6184-86
128 DIN981 圆螺母 locknuts ISO2982 GB812-88
129DIN982 六角头尼龙锁紧螺母prevailling torque type hexagon nuts,heavy type ,with nylon insert ISO7040 GB889.1-86
130DIN985 六角头薄型尼龙锁紧螺母prevailling torque type hexagon nuts,heavy type ,with nylon insert ISO10511 GB6172.2-86
131DIN986 六角盖型尼龙锁紧螺母prevailling torque typedomed capnuts with nylon insert
132DIN988 配合垫片shim rings
133DIN1052 木材连接用垫片washers for timber connectors
134DIN1151 沉头钢钉round plain head nails
135DIN1440 销钉专用垫片A 型plain washers for clevis pins（A 型） ISO8738 136DIN1441 销钉专用垫片plain washers for clevis pins
137DIN1444 带头销钉clevis pins with head ISO2341
138DIN1471 圆锥型槽销grooved pins,taper grooved ISO8744
GB/T13829.2
139DIN1472 圆锥型槽销（半槽） grooved pins,taper grooved half length ISO8745 GB/T13829.2
140DIN1473 平行槽销（带倒角） grooved pins,parallel grooved full length ISO8740
141DIN1474 前端凹槽槽销grooved pins,reserve grooved half length
ISO8741
142DIN1475 中部凹槽槽销grooved pins,centre grooved ISO8742
143DIN1476 圆头槽销grooved pins with round head ISO8746
GB/T13829.3
144DIN1477 沉头槽销grooved pins with countersunk head ISO8747
145DIN1479 六角螺母棒turnuckles（centre parts）,made out of hexagon bar 146DIN1480 花篮螺栓turnuckles with eye bolt and hook bolt
147DIN1481 弹性圆柱销spring pins,heavy type ISO8752 GB879-86
148DIN1587 组合式盖型螺母hexagon domed cap nuts GB802-88
149DIN1804 开槽圆螺母（配合沟头扳手）slotted round nuts for hook spanner 150DIN1816 圆螺母（带插销孔）round nuts with set holes
151DIN2093 盘型弹簧垫圈disc springs
152DIN3017 喉箍hose clamps
153DIN3404 润滑油嘴（旋扭头）lubricating nipples,button head
154DIN3567 管夹shackles for conduilts
155DIN3570 U 型螺栓stirrup bolts（U-bolts）
156DIN6319 球面垫圈spherical washers,conical seats GB849-88
157DIN6325 圆柱销parallel pins ISO8734
158DIN6330 厚六角螺母hexagon nuts ,1.5d GB56-88
159DIN6331 厚六角法兰面螺母hexagon nuts ,1.5d with collar GB6177-86 160DIN6334 长六角螺母hexagon nuts ,3d
161DIN6797-A 外齿锁紧垫圈external teeth lock washers GB862.1-87
162DIN6797-I 内齿锁紧垫圈internal teeth lock washers GB861.1-87
163DIN6798-A 外锯齿锁紧垫圈external teeth serrated lock washers
GB862.2-87
164DIN6798-I 内锯齿锁紧垫圈internal teeth serrated lock washers
GB861.2-87
165DIN6799 开口挡圈retaining rings for shafts(E-rings),circlips GB896-76 166DIN6885 平键(A 型)parallel keys(form A ) ISO773/2491
167DIN6888 半圆键woodruff keys ISO3912
168DIN6899 嵌环(支撑环) thimbles
169DIN6900 机器螺钉和垫圈组合件screws and washers assemblies
GB9074.1-.17
170DIN6901 自攻螺钉和垫圈组合件tapping screws and washers assemblies GB9074.18-.23
171DIN6912 薄型带孔内六角圆柱头螺钉hexagon socket head cap screws with hole,low head
172DIN6914 大六角头螺栓hexagon head bolts with large head(friction grip bolts)
173DIN6915 大六角螺母hexagon nuts with large wideth across flat(friction grip nuts)
174DIN6916 大垫圈round washers for friction grip bolts
175DIN6917 楔型方垫圈spuare taper washers for friction grip bolts on
T-sections
176DIN6923 六角法兰面螺母hexagon flange nuts ISO4161 GB6177-86 177DIN6925 全金属六角锁紧螺母(2 型) prevailing torque type hexagon nuts,all metallic nuts ISO7042 GB6185.1-2000
178DIN7337 开口型抽芯铆钉( 沉头、扁圆头) blind rivets GB12617/12618 179DIN7338 扁平头半空心/全空心铆钉rivets for brake and clutch lining GB875/975-86
180DIN7343 螺旋夹紧销spiral pins ISO8750
181DIN7346 轻型弹性圆柱销spring pins,light type ISO13337
182DIN7349 重型弹性圆柱销用垫圈washers for bolts with heavy type spring pinss
183DIN7500 ISO 公制螺纹螺钉（多种头型） threadforming screws for ISO-metric thread
184DIN7504 自攻自钻螺钉（多种头型） self-drilling tapping screws
185DIN7513 开槽切削螺纹螺钉（多种头型） thread cutting screws
186DIN7516 十字槽切削螺纹螺钉（多种头型） thread cutting screws cross
recess
187DIN7965 T 型四爪螺母tee nuts with pronge
188DIN7968 钢结构用六角头螺栓连接副hexagon head fitted bolts for steel structures GB1228/1229/1230
189DIN7971 开槽盘头自攻螺钉pan head tapping screws with slot ISO1481 GB5282-85
190DIN7972 开槽沉头自攻螺钉countersunk flat head tapping screws with slot ISO1482 GB5283-85
191DIN7973 开槽半沉头自攻螺钉raised countersunk oval head tapping screws with slot ISO1483 GB5284-85
192DIN7976 六角头自攻螺钉hexagon tapping screws ISO1479 GB5285-85 193DIN7980 圆柱头螺钉用弹簧垫圈spring lock washers for screws with cylindrical heads ISO8738
194DIN7981 十字槽盘头自攻螺钉pan head tapping screws with cross recessed ISO 7049 GB845-85
195DIN7982 十字槽沉头自攻螺钉countersunk flat head tapping screws with cross recessed ISO7050 GB846-85
196DIN7983 十字槽半沉头自攻螺钉raised countersunk oval head tapping screws with cross recessed ISO7051 GB847-86
197DIN7984 薄型内六角圆柱头螺钉hexagon socket head cap screws with ，reduced head
198DIN7985 十字槽盘头螺钉pan head screws with cross recessed ISO7045 GB818-85
199DIN7989 钢结构用垫圈washers for steel structures GB1230-84
200DIN7990 钢结构用六角头螺栓hexagon head bolts for steel structures GB1229-84
201DIN7991 内六角沉头螺钉hexagon socket countersunk head screws ISO10642
202DIN7993 轴用钢丝挡圈roundwire snap rings for shafts GB895.2-86 203DIN7995 十字槽半沉头木螺钉cross recessedraised countersunk head wood screws GB952-86
204DIN7996 十字槽圆头木螺钉cross recessed round head wood screws GB950-86
205DIN7997 十字槽沉头木螺钉cross recessed countersunk head wood screws GB951-86
206DIN8140 螺纹护套（普通自锁等）ciol inserts,coarse,fine thread,silf locking
207DIN9021 大外径垫圈washers,outside diameter appro.3d ISO7093 GB96-85
208DIN11024 弹簧卡子spring cotter for a bolt
209DIN13257 平板螺栓belting bolts (elevator bolts)
210DIN18182 干壁钉(墙板钉) dry wall screws
211DIN28129 环型螺母lifting nuts(eye nuts) GB63-88
212DIN70952 圆螺母用止退垫圈tab washers for slotted round nuts
GB858-88
最佳答案 1.紧固件对照件 序号中国德国 1 GB65-85 ISO1207 2 GB5782-86 ISO4014 GB5783-86 3 GB5782-86 ISO4017 GB5783-86 4 GB6170-86 ISO4032 5 GB2510-81 ISO4379 6 GB827-86 ISO8746 7 GB879-86 ISO8752 8 GB91-86 DIN94 9 GB95-85 DIN125 10 JB/ZQ4349-86 DIN422 11 GB853-88 DIN434 12 GB894.1-86 DIN471 13 GB893.1-86 DIN472 14 JB/ZQ4446-86 DIN906 15 JB/ZQ4444-86 DIN908 16 GB70-85 DIN912 17 GB78-85 DIN914 18 GB5782-86 DIN931 19 GB6184-86 DIN980 20 GB812-88 DIN981 21 GB11263-89 DIN1025 22 GB707-85 DIN1026 23 GB9787-88 DIN1028 24 GB9788-88 DIN1029 25 GB2510-81 DIN1850 26 GB8163-87 DIN2448 27 GB4141.29-84 DIN6336 28 GB1096-79 DIN6885 29 GB2673-86 DIN7991 30 GB93-87 DIN7980 JB/ZQ4340-97 SN778 31 JB/ZQ4454-86 DIN7603 32 GB7277-87 DIN31211 33 GB10603-89 DIN82101 34 GB704-88 EN10029 35 GB119-86 SN530 36 GB/T1230 SN808
德标和国标,国际标准中英文对照表 序号德国标准中文品名英文品名国际标准中国标准 Item DIN-Standard Description in Chinese Description in English ISO-Standard GB-Standard 1 DIN1 圆锥销taper pins ISO2339 GB117 2 DIN7 圆柱销parallel pins ISO2338 GB119-86 3 DIN8 4 开槽圆柱头螺钉slotted cheese head screws ISO1207 GB65-85 4 DIN8 5 开槽盘头螺钉slotted pan head screws ISO1580 GB67-85 5 DIN93 单耳止动垫圈tab washers GB854 6 DIN94 开口销split cotter pins ISO1234 GB91 7 DIN95 开槽半沉头木螺钉slotted raised csk head wood screws GB101 8 DIN96 开槽半圆头木螺钉slotted round head wood screws GB99 9 DIN97 开槽沉头木螺钉slotted countersunk head wood screws GB100 10 DIN125-A 平垫plain washers ISO7089 GB97.1-85 11 DIN125-B 平垫(带倒角) mediun washers ISO7090 GB97.2-85 12 DIN126 平垫plain washers ISO7091 13 DIN127-A 重型弹垫spring lock washers,tang ends GB7244 14 DIN127-B 标准弹垫spring lock washers,square ends GB93-87 15 DIN128-A 鞍形弹垫single coil spring lock washers GB7245-87 16 DIN137-A 弹簧止动垫圈curved spring washers 17 DIN137-B 波形弹垫wave spring washers GB955 18 DIN186 T型方颈螺栓T-head bolts with square neck GB37-88
德标与国标对照表 德标与国标对照表 德国标准（DIN）和中国国家标准（GB）是两个不同国家的标准化组织所制定的标准。虽然有相似之处，但在某些领域有所不同。以下是德标与国标的对照表。 一、电气工程 1. 电线和电缆 德标：DIN VDE 0250 国标：GB 5023 2. 无绝缘导体 德标：DIN EN 60228 国标：GB/T 3956 3. 低压电器
德标：DIN EN 60 439-1 国标：GB 14048.1 4. 高压开关设备 德标：DIN 43620 国标：GB 1984 5. 潜水电泵 德标：DIN 24255 国标：GB/T 281-2004 二、机械工程 1. 标准零件 德标：DIN 931/1 国标：GB/T 5782 2. 对焊接
德标：DIN 8563/1-3 国标：GB/T 985-1998 3. 货物运输 德标：DIN 15185 国标：GB/T 12183 4. 机床 德标：DIN 863 国标：GB/T 10860 5. 尺寸公差 德标：DIN EN ISO 2768 国标：GB/T 1804-2000 三、建筑工程
1. 路面标准 德标：DIN 18035 国标：GB 50487 2. 接缝放样 德标：DIN 18202 国标：GB 50581 3. 钢筋连接 德标：DIN 1045 国标：GB 1499 4. 建筑钢材 德标：DIN 488 国标：GB/T 706-1988 5. 水泥制品
德标：DIN 18550 国标：GB/T 11785 以上是德标与国标的对照表，可以看到，在不同领域，德标与国标相比有些区别。因此，在进行相关工程和产品设计时，需要根据当地标准进行设计和生产，以满足当地需求。
国标和德标金属材料 对照表
最佳答案 1.紧固件对照件 序号中国德国 1 GB65-85 ISO1207 2 GB5782-86 ISO4014 GB5783-86 3 GB5782-86 ISO4017 GB5783-86 4 GB6170-86 ISO4032 5 GB2510-81 ISO4379 6 GB827-86 ISO8746 7 GB879-86 ISO8752 8 GB91-86 DIN94 9 GB95-85 DIN125 10 JB/ZQ4349-86 DIN422 11 GB853-88 DIN434 12 GB894.1-86 DIN471 13 GB893.1-86 DIN472 14 JB/ZQ4446-86 DIN906 15 JB/ZQ4444-86 DIN908 16 GB70-85 DIN912 17 GB78-85 DIN914 18 GB5782-86 DIN931 19 GB6184-86 DIN980 20 GB812-88 DIN981 21 GB11263-89 DIN1025 22 GB707-85 DIN1026 23 GB9787-88 DIN1028 24 GB9788-88 DIN1029 25 GB2510-81 DIN1850 26 GB8163-87 DIN2448 27 GB4141.29-84 DIN6336 28 GB1096-79 DIN6885 29 GB2673-86 DIN7991 30 GB93-87 DIN7980 JB/ZQ4340-97 SN778 31 JB/ZQ4454-86 DIN7603 32 GB7277-87 DIN31211 33 GB10603-89 DIN82101
德标、欧标、国际、国标对照表 —— DIN EN ISO GB 对照表 新德标 旧德标 英文名 中文名 国标 DIN EN ISO 4014 DIN 931-1 Hexagon head bolts - Product grades A and B(ISO 4014:1999) 六角头螺栓 GB/T 5782-2000 DIN EN ISO 4016 DIN 601 Hexagon head bolts - Product grade C(ISO 4016:1999) 六角头螺栓 C 级 GB/T 5780-2000 DIN EN ISO 4017 DIN 933 Hexagon head screws - Product grade A and B (ISO 4017:1999) 六角头螺栓 全螺纹 GB/T 5783-2000 DIN EN ISO 4018 DIN 558 Hexagon head screws - Product grade C (ISO 4018:1999) 六角头螺栓 全螺纹 C 级 GB/T 5781-2000 DIN EN ISO 8676 DIN 961 Hexagon head screws with metric fine pitch thread - Product grade A and B(ISO 8676:1999) 六角头螺栓 细牙 全螺纹 GB/T 5786-2000 DIN EN ISO 8765 DIN 960 Hexagon head bolts with fine pitch thread - Product grades A and B(ISO 8765:1999) 六角头螺栓 细牙 GB/T 5785-2000 DIN EN ISO 4032 DIN 934 Hexagon nuts,style 1-Product grades A and B(ISO: 4032:1999) 1型六角螺母 GB/T 6170-2000 DIN EN ISO 4033 Hexagon nuts,style 2-Product grades A and B(ISO: 4033:1999) 2型六角螺母 GB/T 6175-2000 DIN EN ISO 4034 DIN 555 Hexagon nuts - Product grade C (ISO 4034:1999) 六角螺母 C 级 GB/T 41-2000 DIN EN ISO 4035 DIN 439-2 Hexagon thin nuts(chamfered)-Product grade A and B (ISO 4035:1999) 六角薄螺母 GB/T 6172.1-2000 DIN EN ISO 4036 DIN 439-1 Hexagon thin nuts - Product grade B(unchamfered)(ISO 4036:1999) 六角薄螺母 无倒角 GB/T 6174-2000 DIN EN ISO 8673 DIN 934| DIN 971-1 Hexagon nuts,style 1,with metric fine pitch thread - Product grades A and B (ISO 8673:1999) 1型六角螺母 细牙 GB/T 6171-2000 DIN EN ISO 8674 DIN 971-2 Hexagon nuts,style 2,with metric fine pitch thread - Product grades A and B (ISO 8674:1999) 2型六角螺母 细牙 GB/T 6176-2000 DIN EN ISO 8675 DIN 439-2 Hexagon thin nuts with metric fine pitch thread - Product grades A and B (ISO 8675:1999) 六角薄螺母 细牙 GB/T 6173-2000 DIN EN ISO 4762 DIN 912 Hexagon socket head cap screws(ISO 4762:1997) 内六角圆柱头螺钉 GB/T 70.1-2000 DIN EN ISO 7380 Hexagon socket button head sxrews (ISO 7380:1997) 内六角平圆头螺钉 GB/T 70.2-2000 DIN EN ISO 10642 DIN 7991 Hexagon socket countersunk head screws (ISO 10642:1997) 内六角沉头螺钉 GB/T 70.3-2000 DIN EN ISO 1207 DIN 84 Slotted cheese head screws-Product grade A(ISO 1207:1992) 开槽圆柱头螺钉 GB/T 65-2000 DIN EN ISO 1580 DIN 85 Slotted pan head screws-Product grade A(ISO 1580:1994) 开槽盘头螺钉 GB/T 67-2000
国标和德标金属材料对照表
最佳答案 1.紧固件对照件 序号中国德国 1 GB65-85 ISO1207 2 GB5782-86 ISO4014 GB5783-86 3 GB5782-86 ISO4017 GB5783-86 4 GB6170-86 ISO4032 5 GB2510-81 ISO4379 6 GB827-86 ISO8746 7 GB879-86 ISO8752 8 GB91-86 DIN94 9 GB95-85 DIN125 10 JB/ZQ4349-86 DIN422 11 GB853-88 DIN434 12 GB894.1-86 DIN471 13 GB893.1-86 DIN472 14 JB/ZQ4446-86 DIN906 15 JB/ZQ4444-86 DIN908 16 GB70-85 DIN912 17 GB78-85 DIN914 18 GB5782-86 DIN931 19 GB6184-86 DIN980 20 GB812-88 DIN981 21 GB11263-89 DIN1025 22 GB707-85 DIN1026 23 GB9787-88 DIN1028 24 GB9788-88 DIN1029 25 GB2510-81 DIN1850 26 GB8163-87 DIN2448 27 GB4141.29-84 DIN6336 28 GB1096-79 DIN6885 29 GB2673-86 DIN7991 30 GB93-87 DIN7980 JB/ZQ4340-97 SN778 31 JB/ZQ4454-86 DIN7603 32 GB7277-87 DIN31211 33 GB10603-89 DIN82101 34 GB704-88 EN10029 35 GB119-86 SN530 36 GB/T1230 SN808
Page 1 of 3 新旧德标、英标、国际、国标对照表（二） —— DIN EN ISO GB 对照表 新德标 旧德标 英文名 中文名 国标 DIN EN ISO 4014 DIN 931-1 Hexagon head bolts - Product grades A and B(ISO 4014:1999) 六角头螺栓 GB/T 5782-2000 DIN EN ISO 4016 DIN 601 Hexagon head bolts - Product grade C(ISO 4016:1999) 六角头螺栓 C 级 GB/T 5780-2000 DIN EN ISO 4017 DIN 933 Hexagon head screws - Product grade A and B (ISO 4017:1999) 六角头螺栓 全螺纹 GB/T 5783-2000 DIN EN ISO 4018 DIN 558 Hexagon head screws - Product grade C (ISO 4018:1999) 六角头螺栓 全螺纹 C 级 GB/T 5781-2000 DIN EN ISO 8676 DIN 961 Hexagon head screws with metric fine pitch thread - Product grade A and B(ISO 8676:1999) 六角头螺栓 细牙 全螺纹 GB/T 5786-2000 DIN EN ISO 8765 DIN 960 Hexagon head bolts with fine pitch thread - Product grades A and B(ISO 8765:1999) 六角头螺栓 细牙 GB/T 5785-2000 DIN EN ISO 4032 DIN 934 Hexagon nuts,style 1-Product grades A and B(ISO: 4032:1999) 1型六角螺母 GB/T 6170-2000 DIN EN ISO 4033 Hexagon nuts,style 2-Product grades A and B(ISO: 4033:1999) 2型六角螺母 GB/T 6175-2000 DIN EN ISO 4034 DIN 555 Hexagon nuts - Product grade C (ISO 4034:1999) 六角螺母 C 级 GB/T 41-2000 DIN EN ISO 4035 DIN 439-2 Hexagon thin nuts(chamfered)-Product grade A and B (ISO 4035:1999) 六角薄螺母 GB/T 6172.1-2000 DIN EN ISO 4036 DIN 439-1 Hexagon thin nuts - Product grade B(unchamfered)(ISO 4036:1999) 六角薄螺母 无倒角 GB/T 6174-2000 DIN EN ISO 8673 DIN 934| DIN 971-1 Hexagon nuts,style 1,with metric fine pitch thread - Product grades A and B (ISO 8673:1999) 1型六角螺母 细牙 GB/T 6171-2000 DIN EN ISO 8674 DIN 971-2 Hexagon nuts,style 2,with metric fine pitch thread - Product grades A and B (ISO 8674:1999) 2型六角螺母 细牙 GB/T 6176-2000 DIN EN ISO 8675 DIN 439-2 Hexagon thin nuts with metric fine pitch thread - Product grades A and B (ISO 8675:1999) 六角薄螺母 细牙 GB/T 6173-2000
国标和德标金属材料 对照表 ------------------------------------------作者 ------------------------------------------日期
最佳答案 1.紧固件对照件 序号中国德国 1 GB65-85 ISO1207 2 GB5782-86 ISO4014 GB5783-86 3 GB5782-86 ISO4017 GB5783-86 4 GB6170-86 ISO4032 5 GB2510-81 ISO4379 6 GB827-86 ISO8746 7 GB879-86 ISO8752 8 GB91-86 DIN94 9 GB95-85 DIN125 10 JB/ZQ4349-86 DIN422 11 GB853-88 DIN434 12 GB894.1-86 DIN471 13 GB893.1-86 DIN472 14 JB/ZQ4446-86 DIN906 15 JB/ZQ4444-86 DIN908 16 GB70-85 DIN912 17 GB78-85 DIN914 18 GB5782-86 DIN931 19 GB6184-86 DIN980 20 GB812-88 DIN981 21 GB11263-89 DIN1025 22 GB707-85 DIN1026 23 GB9787-88 DIN1028 24 GB9788-88 DIN1029 25 GB2510-81 DIN1850 26 GB8163-87 DIN2448 27 GB4141.29-84 DIN6336 28 GB1096-79 DIN6885
最正确答案 1.紧固件对照件 序号中国德国 1 GB65-85 ISO1207 2 GB5782-86 ISO4014 GB5783-86 3 GB5782-86 ISO4017 GB5783-86 4 GB6170-86 ISO4032 5 GB2510-81 ISO4379 6 GB827-86 ISO8746 7 GB879-86 ISO8752 8 GB91-86 DIN94 9 GB95-85 DIN125 10 /ZQ4349-86 DIN422 11 GB853-88 DIN434 12 GB894.1-86 DIN471 13 GB893.1-86 DIN472 14 /ZQ4446-86 DIN906 15 /ZQ4444-86 DIN908 16 GB70-85 DIN912 17 GB78-85 DIN914
19 GB6184-86 DIN980 20 GB812-88 DIN981 21 GB11263-89 DIN1025 22 GB707-85 DIN1026 23 GB9787-88 DIN1028 24 GB9788-88 DIN1029 25 GB2510-81 DIN1850 26 GB8163-87 DIN2448 27 GB4141.29-84 DIN6336 28 GB1096-79 DIN6885 29 GB2673-86 DIN7991 30 GB93-87 DIN7980 /ZQ4340-97 SN778 31 /ZQ4454-86 DIN7603 32 GB7277-87 DIN31211 33 GB10603-89 DIN82101 34 GB704-88 EN10029 35 GB119-86 SN530 36 GB/T1230 SN808 37 膨胀螺栓SN845 38 GB858-88 DIN5406
