CDLE04-03(2ed) 1/5 High Performance Compact EDFA Data Sheet

FAH0360 Series EDFA Preliminary

Overview

The Oki high performance FAH0360 series EDFA’s offer flexible functionality in

compact form factor. Oki’s FAH0360 series can be optimized for either booster or

in-line single channel or narrow band applications, and are available with optional

output powers of 14,17, 19, or 22 dBm. The flexible-functionality allows various

control modes including: Automatic Level Control (ALC) or Automatic Power

Control (APC), Automatic Temperature Control (ATC), and Input Loss or Output

Connector Off Shutdown. Alarms such as Temperature, and Input and Output

Power, are available to monitor the operation of the EDFA.

Features

• High Performance, Low Cost

• Small Compact Size – 90 x 70 x 12 mm

• Constant Gain or Power Modes – User Option

• 4 output power options (14, 17, 19, 22 dBm)

• Alarm and Status Monitor Functions

• RS-232 and I2C Interface Options

Applications

• CATV, Metro, or Long Haul networks

• Booster or In-line Amplification

• Single channel or narrow band applications

• C band FAH0360 : Output power +14dBm

FAH0361 : Output power +17dBm

FAH0362 : Output power +19dBm

FAH0363 : Output power +22dBm

FAH036x : Pump source 1.48µm

FAH036x-A : Pump source 0.98µm 元器件交易网www.cecb2b.comFAH0360 Series Rev.2: [Apr.2004]

CDLE04-03(2ed)

2/5 Specifications and Typical Performance

• Parameters reflect performance over 0-60C operating range.

• Please contact Oki to discuss customer specific requirements.

Min.Max.

Pump Wavelength (FAH036x)nm

Pump Wavelength (FAH036x-A)nm

Power Dissipation4WT=25C, Pout= 19dBm Cooling

Optical Bandwidth 15301560nmC-band Optical Input Power dBmNominal Optical Output Power+14 to +22dBm14, 17, 19, 22 dBm Noise Figure (FAH036x)6.5dBInput Power=0dBm

Noise Figure (FAH036x-A)5.0 to 6.0dBInput Power=0dBmDepend on Input Power Return Loss Input/Output45dB

Gain FlatnessdB Polarization Dependent Gain 0.5dB

Input Loss Shutdown

Output Connector Off Shutdown

ALC(Automatic Level Control)

Pump Power APC(Automatic Power Control) External ShutdownTTL interface ATC(Automatic Temperature Control)

Temperature Alarm

Output Power Drop Alarm

Physical DimensionsmmWithout Heatsink Electrical ConnectorOption Operating Voltage4.55.5V

Operating Temperature060C+/-1.5

JST SHD, (SM20B-SRDS-G-TF)ALC orAPC(User Choice)

90 x 70 x 12OptionalParameterSpecifications

0Remarks

1480

Peltier Thermoelectric CoolersUnits

980元器件交易网www.cecb2b.comFAH0360 Series Rev.2: [Apr.2004]

CDLE04-03(2ed)

3/5 Outline Drawings and Fiber Configuration

PIN Assignments

PIN NO Function PIN NO Function

1 Optical output monitor 11 +V

2 GND 12 GND

3 Input Loss Shutdown alarm 13 +V

4 - 14 GND

5 Output Connector off shutdown alarm 15 +V

6 - 16 GND

7 Output Power Drop alarm 17 +V

8 Temperature alarm 18 GND

9 VREF(2.5V) 19 +V

10 External shutdown 20 GND

* VREF Internally Generated reference voltage (for use of monitor reference) 90

65 44

4-M3 42 70

0.5 16.2

6.1 12

7

#1 #2 #19 #20

PIN No. (Unit: mm)

Electrical lead with φ1 jacket (Length is based on Customer specification.) 3

2 3 1×9

元器件交易网www.cecb2b.comFAH0360 Series Rev.2: [Apr.2004]

CDLE04-03(2ed)

4/5 Optical Connector and Fiber Specifications

Parameter Specifications Unit

Fiber Type SM ---

Mode Field Diameter 9 +/- 1 µm

Cladding Diameter 125 +/- 2 µm

Jacket Diameter 900 µm

Length 1 (+0 /-0.15) m

Connector Type FC/LC/SC ---

Optional parts

Item

Heat Sink

Electrical Connector

Ordering Information

FAH0360 +14 dBm

FAH0361 +17 dBm

FAH0362 +19 dBm

FAH0363 +22 dBm

FAH036x : Pump source 1.48µm

FAH036x-A : Pump source 0.98µm

元器件交易网www.cecb2b.comFAH0360 Series Rev.2: [Apr.2004]

CDLE04-03(2ed) 5/5
