RocketIO GTX Transceiver User Guide

UG198 (v3.0) October 30, 2009Ports and Attributes

Table5-4 defines the shared clocking ports.

Table5-5 defines the shared clocking attributes.Table 5-4:Shared Clocking PortsPortDirClock DomainDescription

CLKINInN/AReference clock input to the shared PMA PLL.

REFCLKOUTOut

N/AThe REFCLKOUT port from each GTX_DUAL

tile provides access to the reference clock

provided to the shared PMA PLL (CLKIN). It

can be routed for use in the FPGA logic.

Table 5-5:Shared Clocking Attributes

AttributeTypeDescription

CLK25_DIVIDERInteger CLK25_DIVIDER is set to get an internal clock for the tile.

1: CLKIN < 25 MHz

2: 25MHz < CLKIN < 50 MHz

3: 50MHz < CLKIN < 75 MHz

4: 75MHz < CLKIN < 100 MHz

5: 100MHz < CLKIN < 125 MHz

6: 125MHz < CLKIN < 150 MHz

10: 150MHz < CLKIN < 250 MHz

12: CLKIN > 250MHz
