第１９卷　Ｖｏ１．１９　第１７期　Ｎｏ．１７　电子设计工程　Ｅｌｅｃｔｒｏｎｉｃ　Ｄｅｓｉｇｎ　Ｅｎｇｉｎｅｅｒｉｎｇ　２０１　１年９月　Ｓｅｏ．２０１１　

高速高密度ＰＣＢ的ＳＩ问题　

周胜海．涂友超　

（信阳师范学院物理与电子工程学院，河南信阳４６４０００）　

摘要：随着数字电子产品向高速高密度发展，ＳＩ问题逐渐成为决定产品性能的因素之一，高速高密度ＰＣＢ设计必须　

有效应对ＳＩ问题。在ＰＣＢ级。影响ＳＩ的３个主要方面是互联阻抗不连续引起的反射、邻近互联引起的串扰和逻辑器　件开关引起的ＳＳＮ。从高速高密度ＰＣＢ设计的角度，在介绍ＳＩ问题的产生的基础上，着重分析了反射、串扰和ＳＳＮ的　机理、特性及对ＳＩ的影响。分析结论对高速高密度ＰＣＢ设计实践具有参考作用。　

关键词：ＳＩ；反射；串扰；ＳＳＮ　

中图分类号：ＴＮ４１；ＴＰ３３　文献标识码：Ａ　文章编号：１６７４—６２３６（２０１１）１７—００３７一ｏ４　

ＳＩ　ｐｒｏｂｌｅｍｓ　ｉｎ　ｈｉｇｈ—ｓｐｅｅｄ　ａｎｄ　ｈｉｇｌｌ—ｄｅｎｓｉｔｙ　ＰＣＢｓ　

ＺＨＯＵ　Ｓｈｅｎｇ—ｈａｉ．ＴＵ　Ｙｏｕ—ｃｈａｏ　（Ｃｏｌｌｅｇｅ　ｏｆＰｈｙｓ．＆Ｅｌｅｃ．Ｅｎｇ．，Ｘｉｎｙａｎｇ　Ｎｏｒｍａｌ　Ｕｎｉｖｅｒｓｉｔｙ，Ｘｉｎｙａｎｇ　４６４０００，Ｃｈｉｎａ）　

Ａｂｓｔｒａｃｔ：Ｈｉｇｈ－ｓｐｅｅｄ　ａｎｄ　ｈｉｇｈ－ｄｅｎｓｉｔｙ　ｉｓ　ａ　ｓｔｒｉｋｉｎｇ　ｔｒｅｎｄ　ｏｆ　ｄｉｇｉｔａｌ　ｅｌｅｃｔｒｏｎｉｃ　ｐｒｏｄｕｃｔｓ，ＳＩ（ｓｉｇｎａｌ　ｉｎｔｅｇｒｉｔｙ）ｈａｓ　ｋｅｙ　ｉｍｐａｃｔｓ　

ｏｎ　ｐｅｒｆｏｒｍａｎｃｅ　ｏｆ　ｔｈｅ　ｐｒｏｄｕｃｔｓ，ａｎｄ　ｉｔ　Ｓ　ｃｒｉｔｉｃａｌｌｙ　ｉｍｐｏｒｔａｎｔ　ｔｏ　ｆｉｘ　ＳＩ　ｐｒｏｂｌｅｍｓ　ｉｎ　ｈｉｇｈ￣ｐｅｅｄ　ａｎｄ　ｈｉｇｈ－ｄｅｎｓｉｔｙ　ＰＣＢ　ｄｅｓｉｇｎｓ．Ａｔ　

ｔｈｅ　ｌｅｖｅｌ　ｏｆ　ＰＣＢ，ｔｈｅ　ｔｈｒｅｅ　ｍａｉｎ　ｉｓｓｕｅｓ　ｏｆ　ｃｏｎｃｅｒｎ　ｆｏｒ　ＳＩ　ａｒｅ　ｒｅｆｌｅｃｔｉｏｎｓ　ｏｃｃｕｒｒｉｎｇ　ｂｅｃａｕｓｅ　ｏｆ　ｉｎｔｅｒｃｏｎｎｅｃｔ　ｄｉｓｃｏｎｔｉｎｕｉｔｉｅｓ，　
