夏普PC-1501袖珍计算机的检修夏普PC-1501袖珍计算机的检修某日在广播论坛闲逛，看到天津的朋友转让一套PC-1500。
由于关注此机已久早有收入囊中之意，所以赶紧喊出标准语我要了，代价是只要45米还包邮。
收到机器后发现该机比想象的要大。
原本印象中只是普通计算器，看到实物才觉得确有些Pocket Computer的味道。
现将近几日的把玩情况和收集资料与大家作些分享。
Sharp PC-1500是上世纪80年代初由夏普公司推出的袖珍计算机。
网上有评论是：“论资历，它比IBM PC普及得更早；论体积，当今大多数便携机也仍不是它的对手；论年龄，它比当代部分IT精英出生得更早。
是极具收藏价值的计算机。
” 其原本的辉煌可见一斑，当年国内的不少企、事业单位都购置了该机，尤其是在石油、气象、测绘、地质勘探等部门更是应用广泛。
该机型一共推出了三个型号：PC-1500，PC-1500A，PC-1501，除有微小区别外均是大同小异。
该机的出生年代正好与IBM PC机同年，但其价格和便携性显然都比IBM PC更具有优势，所以普及速度要比PC更快。
但只是其处理能力和应用场景是远不及PC，进而渐渐被市场所淘汰。
现今的机器多是留给一些计算器爱好者在收藏。
过去本人无幸接触此类机器。
只记得上大学的当年，班上同学有海外亲戚从国外带回一台计算器都让我们感到非常的神奇。
后来学习了ALGOL60语言，让我一下就喜欢上计算机这玩艺为将来的发展打下基础。
在学校的计算中心上过DJS-130机，顺利的编过一些程序。
再后来写毕业论文也是在TQ-16机上用ALGOL60语言编程实现最优路径的查找。
清楚的记得当学习校的DJS-130机不能用时，还从系里特批经费去一个设计院的计算中心在其TQ-16机上调试相关程序。
当时上机费用为60元/小时，这可是30年前的人民币啊！一、主要参数：微处理器：LH5801 8位CMOS集成芯片，指令兼容Z80，主频1.3MHz存储器：ROM 16KBRAM 3.5KB（PC-1500）/8.5KB（PC-1500A，PC-1501）程序语言：BASIC、汇编语言计算位数：10位有效数字加2位指数。
