GB082A VER: 3.0 - 0 - Issue date: 2006/07/27 JEWEL HILL ELECTRONIC CO.,LTD. Module No. GB082A JEWEL HILL ELECTRONIC CO.,LTD. SPECIFICATIONS FOR LCD MODULE
Office Address: Rm. 518,5/F., 101 Shangbu Industrial District, HuaqiangNorthRoad, Shenzhen, China TEL : (86)-755-83362489 83617492 FAX: (86)-755-83286396 83365871 E-mail: sales@jhlcd.com jhlcd@21cn.com Website: www.jhlcd.com
元器件交易网www.cecb2b.com GB082A VER: 3.0 - 1 - Issue date: 2006/07/27
JEWEL HILL ELECTRONIC CO.,LTD. TABLE OF CONTENTS LCM NUMBER SYSTEM.....................................................................2 1. GENERAL DESCRIPTION...........................................................3 2. FEATURES......................................................................................3 3. MECHANICAL SPECIFICATION..............................................3 4. MECHANICAL DIMENSION.......................................................4 5. MAXIMUM RATINGS..................................................................5 6. ELECTRICAL CHARACTERISTICS.........................................5 7. MODULE FUNCTION DESCRIPTION......................................6 8. ELECTRO-OPTICAL CHARACTERISTICS..........................12 9. RELIABILITY...............................................................................16 10. PRECAUTIONS FOR USING LCD MODULES......................17 11. USING LCD MODULES..............................................................19 12. REVISION HISTORY..................................................................21 SAMPLE APPROVED REPORT.......................................................22
元器件交易网www.cecb2b.com GB082A VER: 3.0 - 2 - Issue date: 2006/07/27
JEWEL HILL ELECTRONIC CO.,LTD. LCM Number System
NUMBER OF CHAR. PER LINEF: FSTN; X: OTHERVERSION NUMBER: V00~V99IC TYPE:
VIEWING DIRECTION:TEMPERATURE RANGE:
BACKLIGHT TYPE:
SERIAL NUMBER: A~ZGRAPHIC MODULEs: NUMBER OF COMMONs
GRAPHIC MODULEs:NUMBER OF SEGMENTs
COB & SMT LCM
BACKLIGHT COLOR:CHARACTER MODULEs:CHARACTER MODULEs: NUMBER OF LINEG: REFLECTIVE,NONE BACKLIGHTA: TRANSFLECTIVE, EL BACKLIGHTB: TRANSMISSIVE, EL BACKLIGHTC: TRANSFLECTIVE, LED BACKLIGHTD: TRANSMISSIVE, LED BACKLIGHTE: TRANSFLECTIVE, CCFL BACKLIGHTF: TRANSMISSIVE, CCFL BACKLIGHT
A: AMBER; B: BLUE; Y: YELLOW-GREENR: RED; W: WHITE; O: THER COLOR
N: NORMAL TEMPERATURE RANGEU: UPPER(12:00); D: DOWN(6:00)L: LEFT(9:00); R: RIGHT(3:00);
A: BONDING IC, WITH CONTROLLERB: BONDING IC, WITHOUT CONTROLLERC: SMT IC, WITH CONTROLLERD: SMT IC, WITHOUT CONTROLLERO: OTHER TYPE
W: BLACK-WHITE; O: OTHERG: GRAY; Y: YELLOW-GREEN; B: BLUE; LCD COLOR MODE:N: TN; H: HTN; S: STNLCD TYPE:
S: SUPER WIDE TEMPERATURE RANGEW: WIDE TEMPERATURE RANGEM: MIDDLE TEMPERATURE RANGEGB 08 2 A S Y C Y N D A - V01 元器件交易网www.cecb2b.com GB082A VER: 3.0 - 3 - Issue date: 2006/07/27
JEWEL HILL ELECTRONIC CO.,LTD. 1. GENERAL DESCRIPTION The GB082A is a 8C x 2L Character LCD module. It has a STN panel composed of 40 segments and 16 commons. The LCM can be easily accessed by micro-controller via parallel interface.
2. FEATURES Transflective and positive Display Mode STN(Yellow - Green) module
Display Format Character 8C x 2L Input Data 8/4-bit parallel data input from MPU Multiplexing Ratio 1/16 Duty Bias 1/5 Bias Viewing Direction 6 O’clock Backlight None
3. MECHANICAL SPECIFICATION Item Specifications Unit Dimensional outline 40.0 x 35.4 x 7.5(max) mm Resolution 40segs x 16coms dots Active area 26.4(W) x 9.9(H) mm Char. pitch 3.35(W) x 5.15(H) mm Char. size 2.95(W) x 4.75(H) mm Dots pitch 0.6 (W)×0.6(H) mm Dots size 0. 55(W)×0.55(H) mm
元器件交易网www.cecb2b.com GB082A VER: 3.0 - 4 - Issue date: 2006/07/27
JEWEL HILL ELECTRONIC CO.,LTD. 4. MECHANICAL DIMENSION
RS4
R&EL4.07.5DB314131211DB7DB5DB6DB4--LED-1098765DB0DB2DB1ER/W*2TYPE*1
321VSSVOVDD
元器件交易网www.cecb2b.com GB082A VER: 3.0 - 5 - Issue date: 2006/07/27 JEWEL HILL ELECTRONIC CO.,LTD. 5. MAXIMUM RATINGS Item Symbol Min Max Unit Note VDD - Vss -0.3 7.0 V Supply voltage VLCD -0.3 13.0 V
Input Voltage VIN -0.3 VDD+0.3 V Operating temperature TOPR 0 +50 Storage temperature TSTR -10 +60 Humidity --- --- 90 %RH
6. ELECTRICAL CHARACTERISTICS Item SymbolCondition Min. Typ. Max. UnitSupply Voltage Logic VDD --- --- 5.0 --- V H level VIH 0.8VDD--- VDD Input Voltage L level VIL --- VSS --- 0.2VDD V
Current Consumption (LCD DRIVER) IDD VDD=5.0V; VLCD=4.7V,Tamb=25; --- --- 1.0 mA
LCD Driving Voltage VLCD Bias=1/5 VLCD=VDD-VO --- 4.7 --- V
