Win7修改MAC地址方法图文教程

Win7修改MAC地址方法本人结合了下以前所有的经验，Win7修改MAC地址方法有以下三种：

Win7 to change the MAC address method combining with the all previous experience,

Win7 to change the / MAC address method has the

following three:

方法一：使用Win7MAC地址修改工具1，只适用于windows7系统的网卡MAC地址修改。XP的可以用，但没做什么测试。2，部分windows7下的无线网卡地址无法修改，理论上也可以使用本软件修改。3，修改MAC地址前，请先在开始菜单-运行，输入cmd打开控制台，输入getmac获取原来网卡MAC并记下来，用于以后可以改回来。4，软件使用方法很简单，只需在下拉列表选择所要修改的网卡，然后在文本框里面输入一个新的MAC地址，比如EF2d32BC6525（注意不要加横杠），然后点击修改按钮即可修改。

Method: using the Win7MAC address modification tool 1, only for the windows7

system network card MAC address changes. XP can be used, but did not do what

test. 2, the wireless network / card windows7 address part

cannot be modified, the theory can also modify the use of this software. 3, change

the MAC address, please in the start menu - run, open the console input CMD, input

getmac to obtain the original card MAC and down, for the later can change it back. 4,

the software is easy to use, only need to modify in the drop-down list to select a

card, then in the text box to enter a new MAC address, such as EF2d32BC6525 (be careful not to add bar), then click the Edit button to modify.

个性后开始，运行输入cmd打开控制台，输入getmac查看是否修改成功

Personality after the start, run / the input CMD to open the console, type getmac to see whether the modified successfully

方法二：利用Win7系统自身功能在“本地连接”图标上单击右键，选择“属性”，会弹出一个“本地连接属性”的对话框，单击“配置”按钮，选择“高级”，选中左栏“属性”中“Network Address”(注意:有的网卡叫“网络地址，有的用“Network

Address”，Intel网卡用“Locally Administered Address”，当然也有些网卡没这个选项)，然后选中右栏框“值”中的上面一个单选项(非“不存在”)，此时便可在右边的框中输入想改的网卡MAC地址，形式如“EF2d32BC6525”。点击“确定”按钮，修改就完成了。

Two methods: the use of Win7 system's function in the "local connection" icon on

the right click, choose "properties", will pop up a "local area connection properties"

dialog box, click the "configuration" button, select "advanced", select the left column

"properties" in the "Network Address" (Note: some cards called "network address,

some with" Network Address ", Intel" Locally Administered Address "card, but also

some card no this option, and then select the right column) above the box" value "of

a single option (non" does not exist "), this time can be input to the change MAC

address of network card on the right in the box, such as" EF2d32BC6525". Click "OK"

button, modification is complete.

方法三：利用Regedit注册表修改

Three methods: the use of Regedit registry modification

第1步，单击“开始”，选中“运行”，键入“regedit”调出注册表。

The first step, click "start", select "run", type "regedit" out of the registry.

第2步，在HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\Class\{4D36E972-E325-11CE-BFC1-08002BE10318}\0000、0001、0002 等主键下，查找 DriverDesc ，内容为要修改的网卡的描述，如Intel的网卡会被描述成“Intel(R) PRO/100+

Management Adapter”，3Com的网卡会被描述成“3Com EtherLink XL 10/100 PCI

For Complete PC Management NIC (3C905C-TX)”等。注:上面提到的关于网卡描述的选项出现的位置，和网卡本身以及操作系统有关。不同的网卡可能出现在不同的主键下，而同一网卡用不同版本的操作系统(如OEM版，VOL或者VLK等)也会出现在不同的位置。而这一步的任务就是找到含有网卡描述的主键。

The second step, find DriverDesc in the

HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\Class\{4D36E972-E325-11CE-BFC1-08002BE10318}\0000, 0001, 0002, primary key, content is to modify the

network card is described, such as the Intel card will be described as "Intel (R) PRO

/100+ Management Adapter", 3Com card can be described as "3Com EtherLink XL 10/100 PCI For Complete PC Management NIC (3C905C-TX" etc.). Note: on the

network card options described above occurs, and the card itself and the operating

system. Different card may appear in different primary key, while the same card with

a different version of the operating system (such as OEM, VOL or VLK) will appear in

different positions. And this step is the task of finding containing describe the card key.

第3步，选中在第二步找到的主键，在右栏框中添加一个字符串，命名为“Network

Address”，其值设为要改的MAC地址，形式如“000B6AF6F4F9”。注:到这一步，修改网卡物理地址的任务可以说是完成了，有的网卡需要重启以下才能正常的工作。下面的几步是为了以后再修改物理地址方便用的。

The third step, select the find in the second step of the primary key, add a string in

the right column frame, named "Network Address", its value is set to change the

MAC address, such as "000B6AF6F4F9". Note: this step, modify the network card

physical address tasks can be said to have been completed, some cards need to

restart the following work properly. The following step is to modify the physical

address for later use.

第4步，在“第一步选中的主键”\Ndi\params下添加一项名为“NetworkAddress”的主键，此时一般都会随着在右栏框中产生一个“(默认)”的字符串，将其值设置为最终想要修改的MAC地址，形式如“000B6AF6F4F9”。如果没有此字符串，读者也可自行添加此字符串。注:此步骤就是为网卡设置一个初始MAC地址。

The fourth step, add a "first step in the selected primary key" \Ndi\params

"NetworkAddress" key, the general will be produced in the right column frame with a

"(the default)" string, the value is set to finally want to modify the MAC address,
