Extract from the onlinecatalogMC 1,5/16-GF-3,5Order No.: 1843936The figure shows a 10-position version of the producthttp://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1843936Header, nominal current: 8 A, rated voltage: 160 V, pitch: 3.5 mm, no. of positions: 16, mounting: Solderinghttp://Please note that the data givenhere has been taken from theonline catalog. For comprehensiveinformation and data, please referto the user documentation. TheGeneral Terms and Conditions ofUse apply to Internet downloads. Technical dataDimensions / positionsPitch 3.5 mmDimension a52.5 mmNumber of positions16Pin dimensions0,8 x 0,8 mmHole diameter 1.2 mmTechnical dataInsulating material group IIIaRated surge voltage (III/3) 2.5 kVRated surge voltage (III/2) 2.5 kVRated surge voltage (II/2) 2.5 kVRated voltage (III/2)160 VRated voltage (II/2)250 VConnection in acc. with standard EN-VDENominal current I N8 ANominal voltage U N160 VMaximum load current8 AInsulating material PBTInflammability class acc. to UL 94V0Certificates / ApprovalsApproval logoCSANominal voltage U N300 VNominal current I N8 ACULNominal voltage U N300 VNominal current I N8 AULNominal voltage U N300 VNominal current I N8 ACertification CB, CSA, CUL, GOST, UL, VDE-PZIAccessoriesItem Designation DescriptionGeneral1841161MC 1,5/10-LWL 1,5-3,5MINI-COMBICON optical fibers, pitch 3.5 mm, 10-position,divisible, are snapped into the back of the MC header, color:transparent, dimension a: 1.5 mm1841187MC 1,5/10-LWL 2,3-3,5MINI-COMBICON optical fibers, pitch 3.5 mm, 10-position,divisible, are snapped into the back of the MC header, color:transparent, dimension a: 2.3 mm1841200MC 1,5/10-LWL 4-3,5MINI-COMBICON optical fibers, pitch 3.5 mm, 10-position,divisible, are snapped into the back of the MC header, color:transparent, dimension a: 4.0 mmMarking0804073SK 3,5/2,8:FORTL.ZAHLEN Marker card, printed horizontally, self-adhesive, 10-section markerstrip, 14 identical decades marked 1-10, 11-20 etc. up to 91-100,sufficient for 140 terminal blocksPlug/Adapter1734634CP-MSTB Coding profile, is inserted into the slot on the plug or invertedheader, red insulating materialAdditional productsItem Designation DescriptionGeneral1847262MC 1,5/16-STF-3,5Plug with screw flange, nominal current: 8 A, rated voltage: 160V, pitch: 3.5 mm, no. of positions: 16, type of connection: Screwconnection1863440MCVR 1,5/16-STF-3,5Plug component, nominal current: 8 A, rated voltage: 160 V, pitch:3.5 mm, no. of positions: 16, type of connection: Screw connection 1863149MCVW 1,5/16-STF-3,5Plug component, nominal current: 8 A, rated voltage: 160 V, pitch:3.5 mm, no. of positions: 16, type of connection: Screw connectionDrawingsDrilling diagramDimensioned drawingAddressPHOENIX CONTACT GmbH & Co. KGFlachsmarktstr. 832825 Blomberg,GermanyPhone +49 5235 3 00Fax +49 5235 3 41200http://www.phoenixcontact.de© 2008 Phoenix ContactTechnical modifications reserved;。
Extract from the onlinecatalogVC-MP-S1Order No.: 1884720The illustration shows versions, powder-coated and EMC-coated box mounting basehttp://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1884720Box mounting base, made of metal, powder-coated type 1, number of modules 2, cable screw connection Pg16http://Please note that the data givenhere has been taken from theonline catalog. For comprehensiveinformation and data, please referto the user documentation. TheGeneral Terms and Conditions ofUse apply to Internet downloads. Technical dataGeneral characteristicsNote When using fiber optics, the bending radii of the cablemanufacturers must be observed.Design VC 4Degree of protection IP65/IP66/IP67Type of the screw connection Pg21Pg screw connection NoneHeight61 mmNumber of module slots5Housing material Zinc die-castHousing surface material Nickel-platedSeal material EPDM, conductiveAmbient temperature (operation)-40 °C ... 125 °CAccessoriesItem Designation DescriptionGeneral1885619VC-M-KV-PG21 1X6/2X9Multiple screw connection Pg21, made of metal, consisting ofrubber seal with several holes and a pressure screw, for cablescrew connection support VC-M-KV-PG21...1885635VC-M-KV-PG21 2X6/2X8Multiple screw connection Pg21, made of metal, consisting ofrubber seal with several holes and a pressure screw, for cablescrew connection support VC-M-KV-PG21...1885648VC-M-KV-PG21 2X7,2/1X10,5Multiple screw connection Pg21, made of metal, consisting ofrubber seal with several holes and a pressure screw, for cablescrew connection support VC-M-KV-PG21...1885651VC-M-KV-PG21 3X7Multiple screw connection Pg21, made of metal, consisting ofrubber seal with several holes and a pressure screw, for cablescrew connection support VC-M-KV-PG21...1885664VC-M-KV-PG21 3X9Multiple screw connection Pg21, made of metal, consisting ofrubber seal with several holes and a pressure screw, for cablescrew connection support VC-M-KV-PG21...1885677VC-M-KV-PG21 4X6,5Multiple screw connection Pg21, made of metal, consisting ofrubber seal with several holes and a pressure screw, for cablescrew connection support VC-M-KV-PG21...1885680VC-M-KV-PG21 4X8Multiple screw connection Pg21, made of metal, consisting ofrubber seal with several holes and a pressure screw, for cablescrew connection support VC-M-KV-PG21...1853997VC-M-KV-PG21( 7-10,5)Half screw connection Pg21, made of metal, consisting ofrubber seal with one hole and one pressure screw, for type 2 - 4housings, cable [mm] 7 - 10.51854006VC-M-KV-PG21( 9-13)Half screw connection Pg21, made of metal, consisting ofrubber seal with one hole and one pressure screw, for type 2 - 4housings, cable [mm] 9 - 131854035VC-M-KV-PG21(11,5-15,5)Half screw connection Pg21, made of metal, consisting ofrubber seal with one hole and one pressure screw, for type 2 - 4housings, cable [mm] 11.5 - 13.51854048VC-M-KV-PG21(14-18)Half screw connection Pg21, made of metal, consisting ofrubber seal with one hole and one pressure screw, for type 2 - 4housings, cable [mm] 14 - 181854051VC-M-KV-PG21(17-20,5)Half screw connection Pg21, made of metal, consisting ofrubber seal with one hole and one pressure screw, for type 2 - 4housings, cable [mm] 17 - 20.51885305VC-M-KV-PG21(20X 7)Single screw connection PG21, made of metal, consisting ofrubber seal with a long hole and pressure screw, for type 2-4housings, cable [mm] 20 x 7 mm (for flat-ribbon cable) 1854970VC-M-KV-PG21- 1X8,5/1X12Half screw connection Pg21, made of metal, consisting of rubberseal with several holes and one pressure screw, for type 2 - 4housings:Marking1852875VC-BZS WH Marker labels, unprinted, 5-section, for individual labeling with M-PEN or CMS system, whiteDrawings Dimensioned drawingAddressPHOENIX CONTACT GmbH & Co. KGFlachsmarktstr. 832825 Blomberg,GermanyPhone +49 5235 3 00Fax +49 5235 3 41200http://www.phoenixcontact.de© 2008 Phoenix ContactTechnical modifications reserved;。
