AMD羿龙II X6 1065T CPU性能如何
推荐文章
线程撕裂者2990WX性能如何天梯图排行榜热度：如何让CPU 能发挥系统最大性能热度：如何判断cpu性能高低热度：如何更换CPU涂硅胶热度： cpu制造工艺如何性能热度：
现在市场上CPU品牌型号繁多，让不少朋友觉得眼花缭乱，那么哪个CPU才适合自己呢?店铺在这里就给大家介绍AMD 羿龙II X6 1065TCPU，让大家了解认识。

基本参数
适用类型台式机
CPU系列羿龙II
CPU频率
CPU主频2.9GHz
外频200MHz
倍频14.5倍
CPU插槽
插槽类型Socket AM3
针脚数目938pin
CPU内核
核心代号Thuban
CPU架构K10.5
核心数量六核心
制作工艺45纳米
热设计功耗(TDP)95W
内核电压1.25V
CPU缓存
一级缓存6×128KB
二级缓存6*512KB
三级缓存6MB
技术参数
虚拟化技术AMD VT
64位处理器是
Turbo Boost技术不支持
病毒防护技术不支持
显卡参数
集成显卡否
其他参数
工作温度62℃
