ISOCOM COMPONENTS LTD
Unit 25B, Park View Road West,
Park View Industrial Estate, Brenda Road
Hartlepool, Cleveland, TS25 1YD
Tel: (01429) 863609 Fax :(01429) 863581
31/3/03DB92193m-AAS/A4OPTION G 7.620.260.51
346Dimensions in mm
SURFACE MOUNTOPTION SM
10.167.06.0
1.2
7.62
3.013°Max
3.354.03.02.54
0.267.626.6225
ABSOLUTE MAXIMUM RATINGS
(25°C unless otherwise specified)
Storage Temperature-55°C to + 150°COperating Temperature-55°C to + 100°CLead Soldering Temperature(1/16 inch (1.6mm) from case for 10 secs) 260°C
INPUT DIODE
Forward Current60mAReverse Voltage6VPower Dissipation105mW
OUTPUT TRANSISTOR
Collector-emitter Voltage BVCEO30VEmitter-collector Voltage BVECO6VPower Dissipation160mW
POWER DISSIPATION
Total Power Dissipation200mW
(derate linearly 2.67mW/°C above 25°C)NON-BASE LEAD
OPTICALLY COUPLED ISOLATOR
PHOTOTRANSISTOR OUTPUT
0.5APPROVALS
lUL recognised, File No. E91231'X' SPECIFICATION APPROVALS
lVDE 0884 in 3 available lead form : -- STD- G form- SMD approved to CECC 00802
lCertified to EN60950 by the followingTest Bodies :-Nemko - Certificate No. P01102464Fimko - Certificate No. FI18166Semko - Reference No. 0202037/01-22Demko - Certificate No. 311158-01
lBSI approved - Certificate No. 8001DESCRIPTION
The MOC8101, MOC8102, MOC8103, MOC8104,MOC8105 series of optically coupled isolatorsconsist of infrared light emitting diode and NPNsilicon photo transistor in a standard 6 pin dualin line plastic package with the base pinunconnected.
FEATURES
lOptions :-10mm lead spread - add G after part no.Surface mount - add SM after part no.Tape&reel - add SMT&R after part no.
lHigh Isolation Voltage (5.3kVRMS ,7.5kVPK )
lBase pin unconnected for improved noiseimmunity in high EMI environment
APPLICATIONS
lDC motor controllers
lIndustrial systems controllers
lSignal transmission between systems ofdifferent potentials and impedancesMOC8101X,MOC8102X,MOC8103X,MOC8104X,MOC8105X
MOC8101, MOC8102, MOC8103,MOC8104,MOC8105
10.46 9.860.60.1 1.25 0.75元器件交易网www.cecb2b.comDB92193m-AAS/A4PARAMETERMINTYPMAXUNITS TEST CONDITION
InputForward Voltage (VF)1.01.151.5VIF = 10mA
Reverse Current (IR)10µAVR = 6V
OutputCollector-emitter Breakdown (BVCEO)30VIC = 1mA( Note 2 )
Emitter-collector Breakdown (BVECO) 6VIE = 100µA
Collector-emitter Dark Current (ICEO)50nAVCE = 10V
CoupledOutput Collector Current ( IC ) ( Note 3 )
MOC81015.08.0mA10mA IF , 10V VCEMOC81027.311.7mA10mA IF , 10V VCEMOC810310.817.3mA10mA IF , 10V VCEMOC81041625.6mA10mA IF , 10V VCEMOC81056.513.3mA10mA IF , 10V VCECollector-emitter Saturation VoltageVCE (SAT)0.150.4V5mA IF , 0.5mA IC
Input to Output Isolation Voltage VISO 5300VRMSSee note 1
7500VPKSee note 1
Input-output Isolation Resistance RISO 5x1010ΩVIO = 500V (note 1)
Response Time (Rise), tr2µsVCC = 5V , IF = 10mA
Response Time (Fall), tf2µsRL = 75Ω, (FIG 1)
Note 1Measured with input leads shorted together and output leads shorted together.
Note 2Special Selections are available on request. Please consult the factory.
Note 3Production testing - limits verified with pulse test
31/3/03ELECTRICAL CHARACTERISTICS ( TA= 25°C Unless otherwise noted )
FIGURE 1元器件交易网www.cecb2b.comDB92193m-AAS/A431/3/03
50
Ambient temperature TA ( °C )150
0200
Ambient temperature TA ( °C )Collector power dissipation PC (mW)
60
30
20
10
04050
-30 0 25 50 75 100 125Collector Power Dissipation vs. Ambient Temperature
Forward Current vs. Ambient Temperature
-30 0 25 50 75 100100
00.51.0
1.5IF = 10mAVCE = 10VForward current IF (mA)
080120160200240
40280320
Forward current IF (mA)Current Transfer Ratio vs. Forward Current
Relative Current Transfer Ratiovs. Ambient Temperature
Relative current transfer ratioCurrent transfer ratio CTR (%)
MOC8102VCE = 10VTA = 25°C7080
1 2 5 10 20 50Collector Current vs. Collector-emitter Voltage
Collector-emitter voltage VCE ( V )Collector current IC (mA)
0 2 4 6 8 1001020304050TA = 25°C
IF = 5mA1015203050
MOC8101MOC8103MOC8104-30 0 25 50 75 100 125
Ambient temperature TA ( °C )Ambient temperature TA ( °C )Collector-emitter saturation voltage VCE(SAT) (V)Collector-emitter SaturationVoltage vs. Ambient Temperature
00.040.080.120.160.200.240.28
IF = 5mAIC = 0.5mA
-30 0 25 50 75 100元器件交易网www.cecb2b.com
