Series N35
Heavy Duty Incremental Rotary Shaft EncoderMechanicalShaft Speed6000 RPM maximumShaft DirectionBidirectionalStandard Shaft Sizes .3747'', .4997"Shaft Extension(s)Std 0.875", .50 x .05" flatShaft SealsNeoprene or PTFE OptionsMountingRefer to dimensional drawingsBearingsABEC 5 SpindleRadial Loading90 lbs. OperatingAxial Loading45 lbs. OperatingAccuracy+0.1ºof Shaft Rotation TypicalHousingBlack Anodized AluminumWeight (N35)36 oz.Connector6, 7, 10 Pin MS3102E or 18" Cable OutElectricalPulse Rate15 kHz typical, up to 200 kHz availableOutputs NPN w/ 3.3K pullup or open collectorPNP sourcingLine Driver (with complementary outputs) Output RatingsOpen Collector Transistor40 Vdc maximumLine Drivers 8-15 Vdc15 Vdc maximum5 Vdc TTL5.5 Vdc maximumSupply Voltage8 to 28 Vdc5 Vdc TTL outputSupply Current, per channel30 mA typical, 50 mA maximumCurrent Sinking250 mA maximumOutput Duty Cycle50/50 w/ +20% typical toleranceTighter to +5% by specPulsed Outputs5-10 µsec or 25-35 µsecRise/Fall Times1 µsec typical, other options availableSee Wiring Diagrams for Pin OutsEnvironmentalOperating Temp. -40ºto +85ºC (-40ºto +185ºF)Shock50 g’s for 11 MillisecondsVibration5 to 2000 Hertz at 20 g’sHumidity100% Relative HumidityEnclosures (Sealed) NEMA4X equiv. — Water-tight• Enclosure: N35-3.5'' Dia. NEMA 4 type SealingServo, Flush or Flanged Mounting• Vibration-resistant Anti-Jitter Circuitry, ShatterproofMetal Code Discs• Shielded ABEC 5 Stainless Steel Spindle Bearings,Standard and Self-Mounting options• Low Supply Current Requirement - 30 milliampstypical per encoder, maximum of 50 mA• Operating Voltage Flexibility - 8 to 28 Vdc or 5 VdcTTL Output, 5V or 8 - 15V with Line Driver• Operating Temperature Rating designed forextremes, from -40ºto +85ºC (-40ºto +185ºF)
