NetApp全闪存存储FAS指南

NETAPP FAS系列安装配置手册赞融电子上海分公司2003年11月修订控制1简介1.1说明本文简要说明了Network Appliance公司FAS系列存储产品配置过程。

本手册基于DataOntap 6.4.2P6操作系统1.2适用对象和前提本文是针对赞融电子的内部人员。

要求阅读者具有以下方面的专业能力:熟悉Unix操作系统；熟悉Windows操作系统；具有NETAPP FAS系统的基本知识.1.3参考资料Data ONTAP™ System Administrator’s GuideData ONTAP™ Software Setup Guide1.4术语表NFS：Network File System 网络文件系统CIFS：Common Internet File System 通用 Internet文件系统NAS：Network Attached Storage 网络附加存储WAFL：Write Anywhere File Layout 随地写入文件格式2配置过程2.1检查Filer硬件安装2.2设置Filer使用计算机串口连接Filer背板上的Console口使用Windows附件中的超级终端建立连接，参数如下：每秒位数 9600，数据位 8，奇偶校验无，停止位 1，数据流控制无建立连接依次打开Disk Shelf和Filer电源使用setup命令配置Filerfas940> setupPlease enter the new hostname []: fas940Do you want to configure virtual network interfaces? [n]: yNumber of virtual interfaces to configure? [0] 3Name of virtual interface #1 []: vif1Is vif1 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif1? [0] 2Name of link #1 for vif1 []: e5aName of link #2 for vif1 []: e5bName of virtual interface #2 []: vif2Is vif2 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif2? [0] 2Name of link #1 for vif2 []: e9aName of link #2 for vif2 []: e9bName of virtual interface #3 []: vif3Is vif3 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif3? [0] 2Name of link #1 for vif3 []: e11aName of link #2 for vif3 []: e11bPlease enter the IP address for Network Interface vif1 []: 165.204.224.173 Please enter the netmask for Network Interface vif1 [255.255.0.0]: 255.255.254.0Please enter media type for vif1 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: EnterPlease enter the IP address for Network Interface vif2 []: 165.204.224.174 Please enter the netmask for Network Interface vif2 [255.255.0.0]: 255.255.254.0Please enter media type for vif2 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]:Please enter the IP address for Network Interface vif3 []: 165.204.224.175Please enter the netmask for Network Interface vif3 [255.255.0.0]: 255.255.254.0Please enter media type for vif3 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]:Please enter the IP address for Network Interface e0 []: 165.204.224.172 Please enter the netmask for Network Interface e0 [255.255.0.0]: 255.255.254.0Please enter media type for e0 {100tx-fd, tp-fd, 100tx, tp, auto} [auto]: Would you like to continue setup through the web interface? [n]:Please enter the name or IP address of the default gateway: 165.204.224.254 T he administration host is given root access to the filer's/etc files for system administration. To allow /etc root accesst o all NFS clients enter RETURN below.Please enter the name or IP address of the administration host:Please enter timezone [GMT]: Asia/ShanghaiWhere is the filer located? []: Suzhou ChinaWhat language will be used for multi-protocol files (Type ? for list)?:zh.GBK Setting language on volume vol0The new language mappings will be available after rebootMon Sep 29 03:45:14 GMT [rc:ALERT]: Language on volume vol0 changed to zh.GBK Language set on volume vol0Do you want to run DNS resolver? [n]: yPlease enter DNS domain name []: You may enter up to 3 nameserversPlease enter the IP address for first nameserver []: 165.204.224.2Do you want another nameserver? [n]: yPlease enter the IP address for alternate nameserver []: 139.95.33.235Do you want another nameserver? [n]: EnterDo you want to run NIS client? [n]: EnterT his system will send event messages and weekly reportst o Network Appliance Technical Support. To disable this feature,e nter "options autosupport.support.enable off" within 24 hours.E nabling Autosupport can significantly speed problem determinationa nd resolution should a problem occur on your system.F or further information on Autosupport, please see:.h ttp:///autosupport/P ress the return key to continue.Now type 'reboot' for changes to take effect.fas940> Reboot重新启动Filer 之后，进行 cifs setup 安装fas940> cifs setupEnable CIFS access to the filer by a Windows(tm) PCY our filer is currently only visible to PCs on the same net.Do you wish to make the system visible via WINS? [no]: yPlease enter next WINS IP address (or return to end list) []: 165.204.224.225 Please enter next WINS IP address (or return to end list) []: 163.181.3.225 Please enter next WINS IP address (or return to end list) []:C IFS requires local /etc/passwd and /etc/group files for multiprotocol.D efault passwd file will be created containing 'root', 'pcuser',a nd 'nobody'.Enter the password for root []:Retype the password:T his filer is currently licensed for CIFS only.T he filer will be configured as a NTFS_only filer. It canb e changed to a Multiprotocol filer by reissuing the CIFS setup command.T he default name of this filer will be 'FAS940'.Do you want to modify this name? [no]: EnterC IFS supports three types of user authentication:1. Windows Domain authentication.2. Windows Workgroup authentication using the filer's user accounts.3. /etc/passwd and/or NIS based authentication.What type of authentication will this filer use? [1]: 1T he filer will use Windows Domain authentication.Enter the Windows Domain for the filer []:I t is highly recommended that you create the local administratora ccount (FAS940\administrator) for this filer. This account enablesa ccess to the filer from Windows when domain controllers are nota ccessible.Create the FAS940\administrator account? [yes]: yesSet the password for FAS940\administrator:Retype the password:Mon Sep 29 11:53:46 CST [rc:info]: User <administrator> addedMon Sep 29 11:53:46 CST [rc:notice]: security style for /vol/vol0/ changed from unix to ntfsA is a Windows 2000(tm) domain.I n order to create this filer's domain account, you must supply then ame and password of an administrator account with sufficient privileget o add the filer to the domain.Please enter the Windows 2000 user [Administrator@]: admin_mweizhi@Password for admin_mweizhi@:CIFS - Logged in as admin_mweizhi@.B y default, setup creates the filer account in the ActiveD irectory container named 'Computers'. Alternatively, you cani nstall the filer in an organizational unit (OU) by specifyingt he domain relative distinguished name of the OU, as in'ou=innerOU,ou=outerOU'.Active Directory container for filer account? [cn=computers]: EnterCIFS - Connecting to domain controller.Mon Sep 29 11:57:22 CST [rc:info]: Connection with DC \\SSUZDC2 established Mon Sep 29 11:57:22 CST [nbns_timer:info]: All CIFS name registrations complete for local serverWelcome to the AMD () Windows 2000(tm) domain.CIFS local server is running.2.3创建volume通过Telnet或串口，用命令行方式创建卷vol create <volume name, such as ‘/vol/vol1’> [ -r <RAID Size> ] [ disks]例，创建名为vol1的卷，RAID组最大为8，包含2块盘vol create /vol/vol1 –r 8 2使用vol status –r 命令观察初始化进程通过Web界面创建卷在浏览器中输入http://IP_Address/na_admin点击FilerView，根据提示输入用户名密码从右侧窗口Volume Add在New Volume Name栏中填写新建卷名vol1在Raid Group Size中填写RAID组的大小8在Language中选择Simplified Chinese(GBK)选择Automatic Disk Selection在Number of Disks中填写Volume的磁盘数2点击Add2.4通过CIFS共享通过命令行cifs shares -add <share name> <path>e.g. cifs shares add vol1 /vol/vol1通过Web界面设置Filerview CIFS Shares AddShare Name 填写 vol1Mount Point 填写 /vol/vol1点击Add2.5通过NFS共享通过命令行exportfs -o anon=0 /vol/vol1或者通过Web界面配置Filerview NFS Manage Exports Insert Line 在Path中输入/vol/vol1Permission选择rwAnonymous UID填写0点击OK3FilerView 使用介绍3.1Filer菜单3.1.1Show Status 显示Filer的整体状态，包括Filername, Model,System ID,Version, Disks, Status 等信息3.1.2Manage Licenses 管理Filer 的license 如常用的CIFS, NFS,FCP, iSCSI,SnapRestore, SnapMirror, SnapVault, SyncMirror, MultiStore 等，详情可参见/products/filer/或/products/filer/（中文网页）3.1.3Report 显示Filer目前配置及使用情况，如 Uptime, Network Interfaces, Disk Usage, System Configuration 等信息3.1.4Syslog Messages 这里是系统的syslog messages 信息，里面会记录系统运行时产生的一些信息，特别是一些系统的报错信息，这些信息非常重要，对于发现各种问题有很大帮助，Netapp Technical Support 也需要这些信息，最好每天都查看一下这里的信息3.1.5Use Command Line 在这里可以使用FilerView自带的telnet工具，方便你管理时使用Data Ontap系统的命令。

NETAPP FAS系列安装配置手册赞融电子上海分公司2003年11月修订控制1简介1.1说明本文简要说明了Network Appliance公司FAS系列存储产品配置过程。

本手册基于DataOntap 6.4.2P6操作系统1.2适用对象和前提本文是针对赞融电子的内部人员。

要求阅读者具有以下方面的专业能力:熟悉Unix操作系统；熟悉Windows操作系统；具有NETAPP FAS系统的基本知识.1.3参考资料Data ONTAP™ System Administrator’s GuideData ONTAP™ Software Setup Guide1.4术语表NFS：Network 网络文件系统CIFS：Common Internet 通用Internet文件系统NAS：Network Attached Storage 网络附加存储WAFL：Write Anywhere 随地写入文件格式2配置过程2.1检查Filer硬件安装2.2设置Filer使用计算机串口连接Filer背板上的Console口使用Windows附件中的超级终端建立连接，参数如下：每秒位数 9600，数据位 8，奇偶校验无，停止位 1，数据流控制无建立连接依次打开Disk Shelf和Filer电源使用setup命令配置Filerfas940> setupPlease enter the new hostname []: fas940Do you want to configure virtual network interfaces? [n]: yNumber of virtual interfaces to configure? [0] 3Name of virtual interface #1 []: vif1Is vif1 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif1? [0] 2Name of link #1 for vif1 []: e5aName of link #2 for vif1 []: e5bName of virtual interface #2 []: vif2Is vif2 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif2? [0] 2Name of link #1 for vif2 []: e9aName of link #2 for vif2 []: e9bName of virtual interface #3 []: vif3Is vif3 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif3? [0] 2Name of link #1 for vif3 []: e11aName of link #2 for vif3 []: e11bPlease enter the IP address for Network Interface vif1 []: 165.204.224.173Please enter the netmask for Network Interface vif1 [255.255.0.0]: 255.255.254.0Please enter media type for vif1 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Enter Please enter the IP address for Network Interface vif2 []: 165.204.224.174Please enter the netmask for Network Interface vif2 [255.255.0.0]: 255.255.254.0Please enter media type for vif2 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Please enter the IP address for Network Interface vif3 []: 165.204.224.175Please enter the netmask for Network Interface vif3 [255.255.0.0]: 255.255.254.0Please enter media type for vif3 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Please enter the IP address for Network Interface e0 []: 165.204.224.172Please enter the netmask for Network Interface e0 [255.255.0.0]: 255.255.254.0Please enter media type for e0 {100tx-fd, tp-fd, 100tx, tp, auto} [auto]:Would you like to continue setup through the web interface? [n]:Please enter the name or IP address of the default gateway: 165.204.224.254 The administration host is given root access to the filer's/etc files for system administration. To allow /etc root accessto all NFS clients enter RETURN below.Please enter the name or IP address of the administration host:Please enter timezone [GMT]: Asia/ShanghaiWhere is the filer located? []: Suzhou ChinaWhat language will be used for multi-protocol files (Type ? for list)?:zh.GBKSetting language on volume vol0The new language mappings will be available after rebootMon Sep 29 03:45:14 GMT [rc:ALERT]: Language on volume vol0 changed to zh.GBK Language set on volume vol0Do you want to run DNS resolver? [n]: yPlease enter DNS domain name []: You may enter up to 3 nameserversPlease enter the IP address for first nameserver []: 165.204.224.2Do you want another nameserver? [n]: yPlease enter the IP address for alternate nameserver []: 139.95.33.235Do you want another nameserver? [n]: EnterDo you want to run NIS client? [n]: EnterThis system will send event messages and weekly reportsto Network Appliance Technical Support. To disable this feature,enter "options autosupport.support.enable off" within 24 hours.Enabling Autosupport can significantly speed problem determinationand resolution should a problem occur on your system.For further information on Autosupport, please see:.Press the return key to continue.Now type 'reboot' for changes to take effect.fas940> Reboot重新启动Filer 之后，进行cifs setup 安装fas940> cifs setupEnable CIFS access to the filer by a Windows(tm) PCYour filer is currently only visible to PCs on the same net.Do you wish to make the system visible via WINS? [no]: yPlease enter next WINS IP address (or return to end list) []: 165.204.224.225Please enter next WINS IP address (or return to end list) []: 163.181.3.225Please enter next WINS IP address (or return to end list) []:CIFS requires local /etc/passwd and /etc/group files for multiprotocol.Default passwd be created containing 'root', 'pcuser',and 'nobody'.Enter the password for root []:Retype the password:This filer is currently licensed for CIFS only.The filer will be configured as a NTFS_only filer. It canbe changed to a Multiprotocol filer by reissuing the CIFS setup command.The default name of this filer will be 'FAS940'.Do you want to modify this name? [no]: EnterCIFS supports three types of user authentication:1. Windows Domain authentication.2. Windows Workgroup authentication using the filer's user accounts.3. /etc/passwd and/or NIS based authentication.What type of authentication will this filer use? [1]: 1The filer will use Windows Domain authentication.Enter the Windows Domain for the filer []:It is highly recommended that you create the local administratoraccount (FAS940\administrator) for this filer. This account enablesaccess to the filer from Windows when domain controllers are notaccessible.Create the FAS940\administrator account? [yes]: yesSet the password for FAS940\administrator:Retype the password:Mon Sep 29 11:53:46 CST [rc:info]: User <administrator> addedMon Sep 29 11:53:46 CST [rc:notice]: security style for /vol/vol0/ changed from unix to ntfs is a Windows 2000(tm) domain.In order to create this filer's domain account, you must supply thename and password of an administrator account with sufficient privilegeto add the filer to the domain.Please enter the Windows 2000 user []:Password for :CIFS - Logged in as .By default, setup creates the filer account in the ActiveDirectory container named 'Computers'. Alternatively, you caninstall the filer in an organizational unit (OU) by specifyingthe domain relative distinguished name of the OU, as in'ou=innerOU,ou=outerOU'.Active Directory container for filer account? [cn=computers]: EnterCIFS - Connecting to domain controller.Mon Sep 29 11:57:22 CST [rc:info]: Connection with DC \\SSUZDC2 establishedMon Sep 29 11:57:22 CST [nbns_timer:info]: All CIFS name registrations complete for local serverWelcome to the AMD () Windows 2000(tm) domain.CIFS local server is running.2.3创建volume通过Telnet或串口，用命令行方式创建卷vol create <volume name, such as ‘/vol/vol1’> [ -r <RAID Size> ] [ disks] 例，创建名为vol1的卷，RAID组最大为8，包含2块盘vol create /vol/vol1 –r 8 2使用vol status –r 命令观察初始化进程通过Web界面创建卷在浏览器中输入点击，根据提示输入用户名密码从右侧窗口Volume Add在New Volume Name栏中填写新建卷名vol1在Raid Group Size中填写RAID组的大小8 在Language中选择Simplified Chinese(GBK)选择Automatic Disk Selection在Number of Disks中填写Volume的磁盘数2点击Add2.4通过CIFS共享通过命令行cifs shares -add <share name> <path> e.g. cifs shares add vol1 /vol/vol1通过Web界面设置→CIFS→Shares→AddShare Name 填写 vol1Mount Point 填写 /vol/vol1点击Add2.5通过NFS共享通过命令行exportfs -o anon=0 /vol/vol1或者通过Web界面配置→NFS→Manage Exports→Insert Line 在Path中输入/vol/vol1Permission选择rwAnonymous UID填写0点击OK3使用介绍3.1Filer菜单3.1.1Show Status 显示Filer的整体状态，包括, Model, System ID,Version, Disks,Status 等信息3.1.2Manage Licenses 管理Filer 的license 如常用的CIFS, NFS, FCP,iSCSI,SnapRestore, SnapMirror, SnapVault, SyncMirror, MultiStore等，详情可参见或（中文网页）3.1.3Report 显示Filer目前配置及使用情况，如Uptime, Network Interfaces, DiskUsage, System Configuration 等信息3.1.4Syslog Messages 这里是系统的syslog messages 信息，里面会记录系统运行时产生的一些信息，特别是一些系统的报错信息，这些信息非常重要，对于发现各种问题有很大帮助，Netapp Technical Support 也需要这些信息，最好每天都查看一下这里的信息3.1.5Use Command Line 在这里可以使用自带的telnet 工具，方便你管理时使用Data Ontap系统的命令。

NetApp 内置FTP功能设置FTP服务是NetApp FAS/V系列产品上唯一一个不需要许可证管理的服务。

但是NetApp提供的FTP服务相对简单，不能够承担太复杂的设置和操作，仅作为管理员日常FTP管理的一个补充。

1.新建ftp用户：ftptest> useradmin user add ftptest -g Users2.查看并保存/etc/passwd的内容> rdfile /etc/passwdroot:_J9..7w2Uydu6G1yWY4E:0:1::/:pcuser::65534:65534::/:nobody::65535:65535::/:ftp::65533:65533:FTP Anonymous:/vol/ftp/share:从上述文件可以看到，格式是：用户名:密码:UID:GID::目录:3.生成加密后的ftptest用户的密码> cifs passwd pass1234password is _J9..NapU4yybn/zXP9.4.将ftptest用户写入/etc/passwd，指定/vol/ftp/share为ftp的根目录，将其UID和GID设置为0:1> wrfile /etc/passwdroot:_J9..7w2Uydu6G1yWY4E:0:1::/:pcuser::65534:65534::/:nobody::65535:65535::/:ftp::65533:65533:FTP Anonymous:/vol/ftp/share:ftptest:_J9..NapU4yybn/zXP9.:0:1::/vol/ftp/share:5.创建FTP用Volume>vol create ftp aggr0 500g #在Aggr0下创建一个名为ftp的500GB大小的卷，>vol options ftp create_ucode on #允许ftp卷使用通用字符集>vol options ftp convert_ucode on #允许将存放在上面的数据转换成通用字符集>vol options ftp nosnap on #关闭卷上的快照功能>vol options ftp nosnapdir on #不允许创建快照目录>snap sched ftp 0 0 0 #禁用快照计划任务6.创建Qtree>qtree create /vol/ftp/share # 创建名为share的qtree>qtree security /vol/ftp unix #设置/vol/ftp的安全类型为unix>qtree security /vol/ftp/share unix #设置/vol/ftp/share的安全类型为unix7. 与FTP相关的options参数以下是与FTP相关的options参数的缺省设置> options ftpdftpd.3way.enable offftpd.anonymous.enable offftpd.anonymous.home_dir anonymousftpd.auth_style mixedftpd.bypass_traverse_checking offftpd.dir.overrideftpd.dir.restriction offftpd.enable offftpd.idle_timeout 900s (value might be overwritten in takeover) ftpd.locking noneftpd.log.enable onftpd.log.filesize 512kftpd.log.nfiles 6ftpd.max_connections 500 (value might be overwritten in takeover) ftpd.max_connections_threshold 0% (value might be overwritten in takeover) ftpd.tcp_window_size 289608、启用匿名FTP服务>options ftpd. anonymous.enable on #启用FTP匿名服务，缺省为offoptions options ftpd.anonymous.home_dir /vol/ftp/share #指定用户FTP匿名登陆后的缺省目录为/vol/ftp/shareoptions anonymous #指定匿名FTP登录的用户名为anonymous options ftpd.auth_style mixed #指定FTP服务的认证方式为混合性options ftpd.bypass_traverse_checking off #启用FTP目录权限遍历检查options ftpd.dir.restriction on #限制FTP用户仅能访问自己的主目录或默认目录options ftpd.dir.override /vol/ftp/share #指定FTP用户访问缺省目录为/vol/ftp/shareoptions ftpd.log.enable on #启用FTP服务日志options ftpd.log.files 512k #指定log文件大小为512KBoptions ftpd.log.nfiles 6 #指定log文件数量为69.启用/停用FTP服务>options ftpd.enable onThu Sep 29 16:34:05 CST [JMGTJ-B: ftpd.service.on:info]: The FTP subsystem started. >options ftpd.enable off10.FTP服务测试C:\>ftp 172.16.100.22 #使用ftp命令进行测试。

FAS3200 系列快速参考指南价值主张 — FAS3200 系列面向中端存储市场，用于处理 SAN 和 NAS 工作负载，具有领先的性能和扩展能力。

与之前的系统相比，全新 FAS3200 系统可将性能提高多达 80%， 并将容量提高一倍，从而提升了中端存储市场的价值标准。

关键信息FAS3200 系列规格 优势 • 专为敏睿数据基础架构而设计，实现“至能”管理、“至久”运行和“至极”扩展• 针对闪存进行了优化，提供更多选择和更高的灵活性，可实现应用加速• 启用了集群功能，可实现无中断运行，从而消除计划停机和非计划停机•行业领先的存储效率，降低存储成本立竿见影且长久有效客户难点 • 在严格的预算和人员限制下无法扩展 IT 服务 • 无法无中断地添加容量、处理能力和更多资源 •计划停机影响用户访问数据目标客户和环境 • 大中型企业• 区域数据中心、复制站点和部门系统•需要功能全面、高效且具备高可用性和高性能的存储的中型企业FAS3250（具有扩展 I/O ）FAS3220（具有扩展 I/O ）FAS3220最大原始容量 2160 TB 1440 TB 1440 TB 最大磁盘驱动器数 720480480控制器外形规格 双机箱高可用性；两个 3U 机箱中装有 2 个控制器，共 6U双机箱高可用性；两个 3U 机箱中装有 2 个控制器，共 6U单机箱高可用性； 一个 3U 机箱中装有 2 个控制器内存40 GB 24 GB 24 GB 每个系统总闪存上限 2 TB 1 TB 1 TB PCIe 扩展插槽数 12 12 4 板载 I/O ：4 Gb FC 4 4 4 板载 I/O ：6 Gb SAS 4 4 4 板载 I/O ：GbE 444支持的存储网络 FC 、FCoE 、IP SAN (iSCSI)、NFS 、CIFS 、HTTP 、FTP操作系统版本Data ONTAP ®8.1.2 软件及更高版本所有规格均针对双控制器高可用性配置。

N ET A PP FAS2040/A存储系统技术规范系统概述卓越的价值FAS2040是NetApp统一网络存储的FAS2000系列的产品，专为满足中端企业用户数据存储的应用需求而设计。

FAS2000系列不但支持FC和SATA磁盘,还内置支持最新的SAS磁盘，不仅性价比提高两倍，而且在单个系统上支持更多的用户，存储合并功能也得到增强.作为 NetApp 统一体系结构的一部分，这些系统同时支持NAS文件服务、FC SAN、IP SAN 和多种网络配置，同时能够灵活为更高性能的系统提供无缝隙、无差错升级，无需进行目前市场上其它多数产品所需要的“升降机式”数据迁移。

此外，FAS2000 系统进一步提高针对小数据卷的磁盘性能，充分扩大了 FAS存储系统内核Data ONTAP 7G 内置的 FlexVol功能的使用价值。

FlexVol 技术可以降低存储管理成本，将客户的存储利用率提高 50%。

结合新的 SATA 存储选件，主要存储成本可以减少一半以上。

企业级可扩展性和可管理性FAS2000型系统在设计上满足了快速增长的中层企业存储市场的需要。

FAS2000 系列系统非常适合用于企业应用基础设施，比如数据库、电子邮件/消息收发、主目录合并和灾难恢复解决方案。

由于在设计过程中贯彻企业适用性、连续可用性和易管理性的思想，因此FAS2000 系列提高了可靠性，简化了维护过程，并降低了存储基础设施的复杂性。

硬件特性FAS2040A系统（双活动配置）包括：•8GB系统内存•512MB NVRAM•远程管理模块（Remote LAN Module –选配）•内置8个10/100/1000Base-T千兆以太网接口•内置4个光纤通道（FC）接口•内置2个SAS接口•最多136个磁盘，内置支持最大12个SAS硬盘•后端最大支持136个磁盘，支持SAS、FC和SATA硬盘混合使用•最多136TB的裸盘容量，其中SAS最大108TB，FC最大50.4TB，SATA最大136TB •最大单卷容量30TBFAS2040系统（单控制器）包括：•4GB系统内存•256MB NVRAM•远程管理模块（Remote LAN Module –选配）•内置4个10/100/1000Base-T千兆以太网接口•内置2个光纤通道（FC）接口•内置1个SAS接口•最多136个磁盘，内置支持最大12个SAS硬盘•后端最大支持136个磁盘，支持SAS、FC和SATA硬盘混合使用•最多136TB的裸盘容量，其中SAS最大108TB，FC最大50.4TB，SATA最大136TB •最大单卷容量30TBFAS2040控制器系统如下图所示：图 1：FAS2040外观图图2：FAS2040后视图SAN性能: 320000 IOPS;1600MB/s吞吐带宽NAS性能: 29000 OPS / ORT 1.52msFAS2040 系列产品技术规格技术亮点SAN 协议支持用于 SCSI (4/2/1Gb) 的 FCP（光纤通道协议）；光纤网络存储和直连式存储；IP SAN (iSCSI)网络协议支持NFS V2/V3/V4（采用 UDP 或 TCP）、PCNFSD V1/V2 for (PC) NFS 客户端验证、Microsoft®CIFS、HTTP 1.0、HTTP 1.1 虚拟主机LUN 可达 1,024。

NetApp存储设备配置说明修改记录目录1编写目的 (1)2专业名词和缩略语 (2)3组网方式和环境介绍 (3)4安装配置方法 (3)4.1N ET A PP硬件安装 (3)4.2设备初始化和系统设定 (4)4.2.1设备初始化 (4)4.2.2系统设定 (4)4.3操作系统安装 (6)4.3.1注册现有系统的cifs服务，将操作系统文件上传至FAS存储系统 (6)4.4应用配置 (8)4.4.1系统参数配置 (8)4.4.2注册需要使用的服务 (10)4.4.3创建一个卷并输出空间 (12)4.4.4创建一个Qtree并实施quota限制 (17)4.4.5配置autosupport (19)4.4.6配置snapshot策略及数据恢复方法 (19)4.4.7磁盘故障的数据恢复方法 (19)4.4.8配置Cluster (19)1 编写目的编写本文档的目的在于详细地说明NetApp FAS存储系统的安装、配置以及常用命令的介绍和可靠性维护、故障检查与恢复的方法，便于开发、测试、用服和工程维护人员安装、使用和维护NetApp FAS存储系统存储系统。

2 专业名词和缩略语3 组网方式和环境介绍NetAppFAS3240AESX ServerSWITCHESX Server图3.1 NetApp FAS存储系统组网结构NetApp FAS存储系统存储设备以NAS存储方式使用，通过万兆交换机与主机相连接。

4 安装配置方法4.1 NetApp硬件安装存储设备硬件的安装主要是各盘柜间线缆的连接、磁盘安装、盘柜上架、上电等，以上操作多由NetApp技术支持工程师完成。

使用存储设备随机携带的“DB－9 to RJ－45”转接线将FAS存储系统的CONSOLE端口和安装了WINDOWS操作系统的主机串口相连，在WINDOWS主机上安装SecureCRT软件，新建一个serial协议的连接，其中port参数根据所连接的是COM1还是COM2来进行选择，其余参数参考图4.1所示，通过串口连接登录到FAS存储系统。

NetApp-FAS系列安装配置说明NETAPP FAS系列安装配置⼿册赞融电⼦上海分公司2003年11⽉修订控制1简介1.1说明本⽂简要说明了Network Appliance公司FAS系列存储产品配置过程。

本⼿册基于DataOntap 6.4.2P6操作系统1.2适⽤对象和前提本⽂是针对赞融电⼦的内部⼈员。

要求阅读者具有以下⽅⾯的专业能⼒:熟悉Unix操作系统；熟悉Windows操作系统；具有NETAPP FAS系统的基本知识.1.3参考资料Data ONTAP? System Administrator’s GuideData ONTAP? Software Setup Guide1.4术语表NFS：Network ⽹络⽂件系统CIFS：Common Internet 通⽤Internet⽂件系统NAS：Network Attached Storage ⽹络附加存储WAFL：Write Anywhere 随地写⼊⽂件格式2配置过程2.1检查Filer硬件安装2.2设置Filer使⽤计算机串⼝连接Filer背板上的Console⼝使⽤Windows附件中的超级终端建⽴连接，参数如下：每秒位数 9600，数据位 8，奇偶校验⽆，停⽌位 1，数据流控制⽆建⽴连接依次打开Disk Shelf和Filer电源使⽤setup命令配置Filerfas940> setupPlease enter the new hostname []: fas940Do you want to configure virtual network interfaces? [n]: yNumber of virtual interfaces to configure? [0] 3Name of virtual interface #1 []: vif1Is vif1 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif1? [0] 2Name of link #1 for vif1 []: e5aName of link #2 for vif1 []: e5bName of virtual interface #2 []: vif2Is vif2 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif2? [0] 2Name of link #1 for vif2 []: e9aName of link #2 for vif2 []: e9bName of virtual interface #3 []: vif3Is vif3 a single [s] or multi [m] virtual interface? [m] sNumber of links for vif3? [0] 2Name of link #1 for vif3 []: e11aName of link #2 for vif3 []: e11bPlease enter the IP address for Network Interface vif1 []: 165.204.224.173Please enter the netmask for Network Interface vif1 [255.255.0.0]: 255.255.254.0Please enter media type for vif1 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Enter Please enter the IP address for Network Interface vif2 []: 165.204.224.174Please enter the netmask for Network Interface vif2 [255.255.0.0]: 255.255.254.0Please enter media type for vif2 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Please enter the IP address for Network Interface vif3 []: 165.204.224.175Please enter the netmask for Network Interface vif3 [255.255.0.0]: 255.255.254.0Please enter media type for vif3 {100tx-fd, tp-fd, 100tx, tp, auto (10/100/1000)} [auto]: Please enter the IP address for Network Interface e0 []: 165.204.224.172Please enter the netmask for Network Interface e0 [255.255.0.0]: 255.255.254.0Please enter media type for e0 {100tx-fd, tp-fd, 100tx, tp, auto} [auto]:Would you like to continue setup through the web interface? [n]:Please enter the name or IP address of the default gateway: 165.204.224.254 The administration host is given root access to the filer's/etc files for system administration. To allow /etc root accessto all NFS clients enter RETURN below.Please enter the name or IP address of the administration host:Please enter timezone [GMT]: Asia/ShanghaiWhere is the filer located? []: Suzhou ChinaWhat language will be used for multi-protocol files (Type ? for list)?:zh.GBKSetting language on volume vol0The new language mappings will be available after rebootMon Sep 29 03:45:14 GMT [rc:ALERT]: Language on volume vol0 changed to zh.GBK Language set on volume vol0 Do you want to run DNS resolver? [n]: yPlease enter DNS domain name []: /doc/13ed3844f58a6529647d27284b73f242336c3134.html You may enter up to 3 nameserversPlease enter the IP address for first nameserver []: 165.204.224.2Do you want another nameserver? [n]: yPlease enter the IP address for alternate nameserver []: 139.95.33.235Do you want another nameserver? [n]: EnterDo you want to run NIS client? [n]: EnterThis system will send event messages and weekly reportsto Network Appliance Technical Support. To disable this feature,enter "options autosupport.support.enable off" within 24 hours.Enabling Autosupport can significantly speed problem determinationand resolution should a problem occur on your system.For further information on Autosupport, please see:.Press the return key to continue.Now type 'reboot' for changes to take effect.fas940> Reboot重新启动Filer 之后，进⾏cifs setup 安装fas940> cifs setupEnable CIFS access to the filer by a Windows(tm) PCYour filer is currently only visible to PCs on the same net.Do you wish to make the system visible via WINS? [no]: yPlease enter next WINS IP address (or return to end list) []: 165.204.224.225Please enter next WINS IP address (or return to end list) []: 163.181.3.225Please enter next WINS IP address (or return to end list) []:CIFS requires local /etc/passwd and /etc/group files for multiprotocol.Default passwd be created containing 'root', 'pcuser',and 'nobody'.Enter the password for root []:Retype the password:This filer is currently licensed for CIFS only.The filer will be configured as a NTFS_only filer. It canbe changed to a Multiprotocol filer by reissuing the CIFS setup command.The default name of this filer will be 'FAS940'.Do you want to modify this name? [no]: EnterCIFS supports three types of user authentication:1. Windows Domain authentication.2. Windows Workgroup authentication using the filer's user accounts.3. /etc/passwd and/or NIS based authentication.What type of authentication will this filer use? [1]: 1The filer will use Windows Domain authentication.Enter the Windows Domain for the filer []:/doc/13ed3844f58a6529647d27284b73f242336c3134.html It is highly recommended that you create the local administratoraccount (FAS940\administrator) for this filer. This account enablesaccess to the filer from Windows when domain controllers are notaccessible.Create the FAS940\administrator account? [yes]: yesSet the password for FAS940\administrator:Retype the password:Mon Sep 29 11:53:46 CST [rc:info]: User addedMon Sep 29 11:53:46 CST [rc:notice]: security style for /vol/vol0/ changed from unix to ntfs/doc/13ed3844f58a6529647d27284b73f242336c3134.html is a Windows 2000(tm) domain.In order to create this filer's domain account, you must supply thename and password of an administrator account with sufficient privilegeto add the filer to the /doc/13ed3844f58a6529647d27284b73f242336c3134.html domain.Please enter the Windows 2000 user []:Password for :CIFS - Logged in as .By default, setup creates the filer account in the ActiveDirectory container named 'Computers'. Alternatively, you caninstall the filer in an organizational unit (OU) by specifyingthe domain relative distinguished name of the OU, as in'ou=innerOU,ou=outerOU'.Active Directory container for filer account? [cn=computers]: EnterCIFS - Connecting to domain controller.Mon Sep 29 11:57:22 CST [rc:info]: Connection with DC \\SSUZDC2 establishedMon Sep 29 11:57:22 CST [nbns_timer:info]: All CIFS name registrations complete for local serverWelcome to the AMD (/doc/13ed3844f58a6529647d27284b73f242336c3134.html ) Windows 2000(tm) domain.CIFS local server is running.2.3创建volume通过Telnet或串⼝，⽤命令⾏⽅式创建卷vol create [ -r ] [ disks] 例，创建名为vol1的卷，RAID组最⼤为8，包含2块盘vol create /vol/vol1 –r 8 2使⽤vol status –r 命令观察初始化进程通过Web界⾯创建卷在浏览器中输⼊点击，根据提⽰输⼊⽤户名密码从右侧窗⼝Volume Add在New Volume Name栏中填写新建卷名vol1在Raid Group Size中填写RAID组的⼤⼩8 在Language中选择Simplified Chinese(GBK)选择Automatic Disk Selection在Number of Disks中填写Volume的磁盘数2点击Add2.4通过CIFS共享通过命令⾏cifs shares -add e.g. cifs shares add vol1 /vol/vol1通过Web界⾯设置→CIFS→Shares→AddShare Name 填写 vol1Mount Point 填写 /vol/vol1点击Add2.5通过NFS共享通过命令⾏exportfs -o anon=0 /vol/vol1或者通过Web界⾯配置→NFS→Manage Exports→Insert Line 在Path中输⼊/vol/vol1 Permission选择rwAnonymous UID填写0点击OK3使⽤介绍3.1Filer菜单3.1.1Show Status 显⽰Filer的整体状态，包括, Model, System ID,Version, Disks, Status 等信息3.1.2Manage Licenses 管理Filer 的license 如常⽤的CIFS, NFS, FCP,iSCSI,SnapRestore, SnapMirror, SnapVault, SyncMirror, MultiStore等，详情可参见或（中⽂⽹页）3.1.3Report 显⽰Filer⽬前配置及使⽤情况，如Uptime, Network Interfaces, DiskUsage, System Configuration 等信息3.1.4Syslog Messages 这⾥是系统的syslog messages 信息，⾥⾯会记录系统运⾏时产⽣的⼀些信息，特别是⼀些系统的报错信息，这些信息⾮常重要，对于发现各种问题有很⼤帮助，Netapp Technical Support 也需要这些信息，最好每天都查看⼀下这⾥的信息3.1.5Use Command Line 在这⾥可以使⽤⾃带的telnet ⼯具，⽅便你管理时使⽤Data Ontap系统的命令。

NetApp-FAS-存储整合方案和配置清单————————————————————————————————作者：————————————————————————————————日期：2i广东恒峰信息技术有限公司存储整合设计方案建议March 24, 2022ii目录1 前言 ............................................................................................................... 3 2 N ET A PP 公司介绍 ............................................................................................. 4 3 系统需求分析 .................................................................................................. 5 4 方案设计原则 .................................................................................................. 7 5 网络存储架构的选择 . (8)5.1以太网文件系统存储区域网NAS （FS SAN ） 8 5.2光通道数据块存储区域网SAN （FC SAN ） 8 5.3SAN （FC SAN ）与NAS （FS SAN ）的比较 9 5.4以太网数据块存储区域网iSCSI （IP SAN ）10 5.5 SAN （FC SAN ）与NAS （FS SAN ）的融合 116 技术方案建议 (14)6.1 方案总体设计 146.1.1 iSCSI 整合方案 (16)6.1.2 NAS 整合方案（可选） (16)6.1.3 配置列表 (17)6.1.4 卷组容量和RAID 划分 (17)6.1.5 iSCSI 的容量调整 (18)6.1.6 IP 网络相关设计 (18)6.2 存储虚拟化管理 196.2.1 Flexible Volumes 的概念 (20)6.2.2 性能的提高 (21)6.2.3 灵活的容量规划 (22)6.2.4 FlexVol 的技术优势 (23)6.3 数据保护 246.3.1 增强型RAID-4 (25)6.3.2 RAID-DP ....................................................................................................................... 26 6.4 FlexShare 数据卷优先级别管理 276.5 A-SIS 重复数据删除技术 286.6 系统扩展性 296.7 系统管理 296.7.1 FilerView ...................................................................................................................... 30 7 N ET A PP FAS 存储系统介绍 .. (32)7.1 FAS2020/A 32 7.1.1 系统概述 (32)7.1.2 硬件特性 (32)7.2 FAS2000 系列产品技术规格 3331 前言本文描述了NetApp 公司针对揭阳榕城区政府的服务器整合存储工程的整体技术方案。

Netapp fas2020安装配置实际操作重新配置fas2020时，如果不改变硬盘归属，可以在web界面中操作，建立aggr和vol，如果需要改变硬盘的分配，比较简便的是进入维护命令行操作，可以避免因为已有aggr和vol，而必须挨个删除的麻烦。

注意：重新配置前要备份licenses，存储初始化后所有licenses 会被清掉。

然后按照第6、7两步的方法，备份etc目录。

1、要进入维护命令行进行操作，必须通过串口连接存储。

输入“reboot”重启控制器。

在显示以下信息时，按下“CTRL-C”Loading:....................0x200000/42260756 0x2a4d914/14350236 0x37fd0b0/1732666 0x39a40ea/6 Entry at 0x00200000Starting program at 0x00200000Press CTRL-C for special boot menu2、进入特别菜单，选择5，如果不需要改变硬盘归属可以跳过。

(1) Normal boot.(2) Boot without /etc/rc.(3) Change password.(4) Initialize owned disks (6 disks are owned by this filer).(4a) Same as option 4, but create a flexible root volume.(5) Maintenance mode boot.3、进入系统后，可以使用命令改变硬盘的管理者。

*> disk remove_ownership all （可将所有硬盘取消管理，也可以指定某块硬盘）*> disk assign 0c.00.0 （取得硬盘的管理权）*> disk reassign -o storage30-a -n storage30-b 磁盘管理由storage30-a 切换为storage30-b4、调整完硬盘管理后再次重启控制器，进入特别菜单，选择4a，初始化硬盘。

专有信息和机密。

仅限 NetApp 员工及渠道合作伙伴使用，且均需遵守 NDA 规定。

更新时间：2014 年 5 月未经过 NetApp 的事先书面许可，不得共享该文档。

© 2014 NetApp, Inc.。

保留所有权利。

价值最优性能最佳密度和容量最高存储整合、数据保护和灾难恢复。

环境和虚拟环境的最佳整体性价比和最大容量4U ，24 个驱动器FAS2500 系列：快速参考指南FAS2500 为入门级混合阵列设立了新标准，可以帮助您更加充分地利用 IT 投资，减少运营成本，并最大限度地降低增长带来的风险。

具有竞争优势的功能：■ 业内独一无二的统一纵向扩展和横向扩展集群架构，无需停机即可提高性能和扩展容量；在数分钟内完成部署 ■ 为更广泛的 SAN 和 NAS 工作负载提供支持，并且免费附带所有数据协议 ■ 业内最先进的自动分层技术，混合闪存量相较于上一代产品提高 5 倍，即装即用，无需安装其他软件 ■ 免费标配业内领先的效率技术，可将容量占用空间减少多达 50% ■ 所有入门级系统中最简单、最先进的自动化和分析功能，支持一键式操作并内置 QoS 策略引擎，可以简化存储操作 ■ 实现与 Microsoft® 和VMware® 环境的集成，其集成深度与广度当属业界之最 ■ 提供端到端数据保护，包括本地副本、异地存储、以及最简单且最快速的应用程序保护和恢复 ■ 利用安全的数据可移动性，轻松接入云环境并在云中移入和移出数据 ■ 在升级到更大型的 NetApp 系统时，通过将 FAS255x 转变为二级存储或磁盘架，提供内置投资保护* 所有规格均针对双控制器主动-主动配置。

专有信息和机密。

仅限 NetApp 员工及渠道合作伙伴使用，且均需遵守 NDA 规定。

更新时间：2014 年 5 月未经过 NetApp 的事先书面许可，不得共享该文档。

© 2014 NetApp, Inc.。

DatasheetDisk Shelves and Storage Media for FAS and V-Series SystemsFlexibility to Optimize Storage for a Variety of NeedsThe NetApp® family of disk shelves and storage media gives you the flexibility to optimize for the highest performance or the highest capacity or to strike a balance between the two. Integrated Flash SSD Support Choose full solid state disk (SSD) configurations or mixed SSD and hard disk drive (HDD) configurations that combine the performance of flash with the capacity of hard disks.High Availability and Resiliency Full redundancy, multipath connections, out-of-band management, and advanced analytics are standard features in NetApp disk shelves.Greater SimplicityUse the same storage media and disk shelves across NetApp FAS and V-Series systems. This allows you to use the same storage media and disk shelves even as you upgrade storage controllers.The ChallengeProvide reliability and flexibilityto support a broad set ofapplication needsAddressing the performance, capacity,and density needs of different applica-tions can be a tricky balancing act,especially in shared virtual infrastruc-tures where the supported workloadscan change quickly and withoutsignificant lead time.Storage administrators must constantlythink ahead to make sure that theirarchitecture is highly available andcontains the right amount of HDDand new SSD storage so that they areprepared for the growing capacity andperformance requirements driven bymodern business applications.Acquiring and supporting separate stor-age systems for each workload canquickly exhaust your available budget,staff, and resources. Add to this theever-present need to optimize power,cooling, and floor space utilization, andit’s clear that storage hardware needsto be more flexible than ever.The SolutionLeading flexibility, performance, andcross-platform leverage from NetAppDesigned for the most demanding envi-ronments, the NetApp Data ONTAP®architecture offers a high degree offlexibility and choice in supported diskshelves and storage media. From high-capacity HDD to ultraperformancesolid state drives, NetApp deliversthe right drive technology to meetyour specific capacity, density, andperformance needs.Our selection of disk shelves lets youoptimize for capacity, performancedensity, or versatility. You can attachdifferent types of disk shelves to asingle storage system to satisfy diverserequirements without the need todeploy new storage systems, makingyour infrastructure more agile and moreresponsive to your business needs.NetApp is also a leader in the use offlash technology to optimize storagecost and performance. NetApp FlashPool™ intelligent caching technologycaches “hot” data to flash SSD in realtime to accelerate performance inmixed shelves that use both SSD andHDD. All-SSD shelves provide highperformance for longer term storage.The NetApp family of disk shelves delivers the enterprise-class resiliency and availability that you expect when leveraging all of the storage efficiencies of NetApp Data ONTAP , the world’s #1 storage operating system 1.Plus, the same drives and shelves work across multiple system platforms with nondisruptive controller upgrades for the utmost in flexibility. All shelves and media are also supported in clustered Data ONTAP 2 configurations. Highly Resilient and Available NetApp disk shelves are deployed using multipath high availability with storage controller pairs to improve overall system availability. NetApp HA features include:• Full redundancy, including fans and power supplies, is standard in our disk shelf design.• Alternate control path provides out-of-band management connections from disk shelf to storage controller.• NetApp RAID-DP ® offers superior data protection and performance over traditional RAID implementations.• Maintenance Center, the newest addition to our storage resiliency software, performs proactive health monitoring of drives, distinguishes between transient events and real underlying issues based on drive diagnostics, and attempts preventive maintenance when necessary.Optimize Performance and Capacity Many workloads are characterized by a large dataset with a small “hot spot” of active data that tends to move unpre-dictably. Examples include databases, e-mail, file shares, and home directo-ries. Previously, you had to choose between storage media that optimized for performance or for cost. Now it’s possible to optimize for both.As a key component of the NetApp Virtual Storage Tier, Flash Pool enables the creation of a Data ONTAP RAID-protected aggregate with a combination of HDDs and SSDs. SSD is used to dynamically cache random read and write operations for hot data to acceler-ate throughput while minimizing latency. Flash Pool keeps track of the cached data to determine how frequently it is used and evicts data from cache when it “cools down.” With Flash Pool, theNetApp storage system takes advantage of the latency and throughput benefits of SSDs while maintaining the mass storage capacity of HDDs.Flash Pool is compatible with deduplication, thin provisioning, and other storage features. Existing aggregates can be converted into a Flash Pool configuration withoutrequiring any data copying, downtime, or disruptions to data access 3.Storage Media to Meet a Variety of NeedsFor low-latency and high-IOPS applica-tions such as OLTP databases, solid state drives used either by themselves or in combination with hard disk drives in a NetApp Flash Pool aggregate can deliver a performance edge and faster completion of business processes that generate revenue.If extreme IOPS and submillisecond latency aren’t required by your applica-tions, then consider using 15K RPM drives to achieve the highest perfor-mance available from hard disk drives. Choose small form factor (SFF) drives to maximize performance density (IOPS per rack unit) to conserve data center space.Figure 1) The DS4243, DS4246, and DS4486 disk shelves.Figure 2) The DS2246 disk shelf.1. Source: NetApp internal estimates of revenue and storage capacity in the worldwide open-networked storage market, as of June 2012. VNX, VNXe, and Celerra NS can run any Flare or Dart operating system. The contribution of these products to the OS share has been estimated based on the proportion of NAS and SAN installations in these products (NAS – Dart; SAN – Flare).2. For details about Data ONTAP , see /us/media/ds-3231-0412.pdf.3. For details about Flash Pool technology, see /us/media/ds-3345.pdf.Conversely, you can maximize storage density and minimize cost per gigabyte by using high-capacity disk drives. They are ideal for infrequently accessed data and for data archiving or when used in combination with Flash Pool or Flash Cache™ intelligent caching.See Table 1, “Storage media selection guide,” to identify the right media and disk shelf options for your applications. DS2246 disk shelfThe NetApp DS2246 is our performance-optimized disk shelfthat packs 24 drives in only 2U of rack space by using SFF drives. Compared to the 4U-high DS4243 disk shelf, the DS2246 doubles the storage density, increases performance density (IOPS per rack unit) by 60%, and reduces power consumption by 30% to 50%. DS4246 disk shelfThe NetApp DS4246 provides an ideal balance between performance and capacity. It is 4U high and supports6Gb/sec SAS connection. It can be configured with either 24 large form factor (LFF) high-capacity disk drives or a combination of SSDs and high-capacity disk drives to support Flash Pool configurations.DS4243 disk shelfThe NetApp DS4243 is 4U high and supports up to 24 hard disk drives (high capacity or high performance)or up to 24 SSDs with 3Gb/sec SAS connection.DS4486 disk shelfThe capacity-optimized DS4486 holds 48 high-capacity disk drives. This disk shelf looks like the DS4246 from the front, but it is slightly longer and uses a tandem disk carrier to enclose twice as many LFF disk drives in 4U of rack space.In contrast to many capacity-optimized disk shelves, the DS4486 can be serviced from the front, and 10 DS4486 shelves in a 42U rack weigh less than 2,000 pounds (910kg). The rack can be sup-ported by a raised floor in a traditional data center.About NetAppNetApp creates innovative storageand data management solutions that deliver outstanding cost efficiency and accelerate business breakthroughs. Discover our passion for helping companies around the world go further, faster at .Go further, fasterSELECTION CRITERIA STORAGE MEDIA DISK SHELF • Performance density Performance (10K RPM) density HDDs DS2246• Best performance with hard disk drives Performance (15K RPM) HDDs DS4243• Maximum capacity• Lowest cost per gigabyte • Maximum storage density High-capacity (7.2K RPM) HDDs DS4246DS4486• Highest IOPS for random I/O • Lowest latency SSDs DS4243DS2246• Data security• NetApp Storage Encryption Self-encrypting disk drives(AES-128 and AES-256)DS2246DS4243DS4246• Flash Pool support Pure SSD shelf:Mixed shelf:SSDs + HDDs DS2246, DS4243 DS2246, DS4246Table 1) Storage media selection guide.Follow us on:© 2013 NetApp, Inc. All rights reserved. No portions of this document may be reproduced without prior written consent of NetApp, Inc. Specifications are subject to change without notice. NetApp, theNetApp logo, Go further, faster, Data ONTAP , Flash Cache, Flash Pool, MetroCluster, and RAID-DP are trademarks or registered trademarks of NetApp, Inc. in the United States and/or other countries. All other brands or products are trademarks or registered trademarks of theirrespective holders and should be treated as such. DS-3096-0313SPECIFICATIONDS2246DS4246DS4243DS4486Rack units2U 4U 4U 4U Drives per shelf enclosure 24242448High-capacity HDDs N/A7.2K RPM 6Gb/s1TB, 2TB, 3TB and 4TB 7.2K 6Gb/s1TB, 2TB, and 3TB 7.2K RPM 6Gb/s 3TB and 4TB High-performance HDDs10K RPM 6Gb/s450GB, 600GB, and 900GBN/A15K RPM 6Gb/s 450GB and 600GB N/AHigh-security HDDs10K RPM 6Gb/s600GB AES-256 FIPS 140-210K RPM 6Gb/s3TB AES-256 FIPS 140-215K RPM, 6Gb/s600GB 128-bit AES FIPS 140-2N/AUltraperformance SSDs 200GB, 800GB200GB + 900GB (mixed shelf) 100GB + 1TB or 3TB 200GB + 2TB 100GB 1N/AI/O modules Dual 6Gb/sDual 6Gb/sDual 3Gb/sDual 6Gb/sPower supplies CoolingDual, redundant, hot-pluggable,integrated power supply and fan assembliesDual, redundant, hot-pluggable,integrated power supply and fan assembliesDual (high-capacity) or quadruple (high-performance), redundant, hot-pluggable, integrated power supply and fan assemblies Dual, redundant, hot-pluggable,integrated power supply and fan assembliesDrive carrier form factor 2.5”Small form factor 3.5”Large form factor 3.5”Large form factor 3.5”Large form factor Drive carrierSingle driveSingle driveSingle driveTandem drives Enclosure dimensionsHeight: 3.4” (8.5 cm)Width: 19” (48.0 cm)Depth: 19.1” (48.4 cm)Weight: 49lb. (22.2kg)Height: 7” (17.8 cm)Width: 19” (48.3 cm)Depth: 24” (61 cm)Weight: 110lb. (49.9kg)Height: 7” (17.8 cm)Width: 19” (48.3 cm)Depth: 24” (61 cm)Weight: 110lb. (49.9kg)Height: 7” (17.8 cm)Width: 19” (48.3 cm)Depth: 28” (71 cm)Weight: 160lb. (72.5kg)MetroCluster ™2 support✔✔✔1 100GB SSDs will be EOL in June 2013.2 For details about MetroCluster, go to /us/media/ds-2893-metrocluster-solnbrief.pdf.Table 2) Comparison of NetApp disk shelves for FAS/V-Series storage systems.NetApp disk shelves and storage media enable you to build a flexible and efficient shared infrastructure today as your foundation for an agile data infrastructure. All shelves and media are supported in both Data ONTAP operating in 7-Modeand clustered Data ONTAP configurations.。

NetAppFAS2552-安装⽂档NetApp FAS2552 存储安装实施⼿册西安新丰站⼆零⼀六年七⽉⽬录1实施步骤 (3)1.1设备连接图 (3)1.2配置检查 (4)1.3初始化安装 (6)1.4基本安装配置 (6)2参数表 (9)2.1存储系统配置信息 (9)2.2存储空间划分信息 (11)3⽇常管理及配置 (13)3.1图形界⾯管理配置⼿册 (13)1 实施步骤1.1设备连接图设备内部连接图：光纤交换机A 光纤交换机BNetApp FAS2252-A NetApp FAS2252-BIBM ⼩型机A IBM ⼩型机B1.2 配置检查1) 磁盘检查和调整，查看磁盘ownership 情况:进⼊维护模式#disk show2)Data ONTAP OS 及FirmWare版本检查；以下为查看当前版本的⽅法：查看当前Data ONTAP OS 及FirmWare版本，例：# sysconfigNetApp Release 8.2.3P3 7-Mode: Tue Apr 28 14:48:22 PDT 2015System ID: 0537041594 (netapp-2); partner ID: 0537041546 (netapp-1) System Serial Number: 941614000031 (netapp-2)System Rev: E1System Storage Configuration: Single-Path HASystem ACP Connectivity: Partial ConnectivityBackplane Part Number: DS224Backplane Rev:Backplane Serial Number: 021*********slot 0: System Board 1.7 GHz (System Board XIX E1)Model Name: FAS2552Part Number: 111-01324Revision: E1Serial Number: 0316********BIOS version: 8.3.0Loader version: 4.3Processors: 4Processor ID: 0x106e4Microcode Version: 0x3Processor type: Intel(R) Xeon(R) CPU C3528 @ 1.73GHzMemory Size: 18432 MBMemory Attributes: HoistingNormal ECCNVMEM Size: 1280 MB of Main Memory UsedCMOS RAM Status: OKController: BService Processor Status: OnlineFirmware Version: 2.2.4Mgmt MAC Address: 00:A0:98:92:DF:ADEthernet Link: down, 10Mb, half duplexUsing DHCP: yesIPv4 configuration:IP Address: unknownNetmask: unknownGateway: unknownIPv6 configuration: Disabled3)Raid和Aggrate的建⽴系统缺省会建⽴aggr0，由3块磁盘，采⽤raid-dp⽅式构成。
