Features• Low Power Consumption• Industry Standard Size• Industry Standard Pinout• Choice of Character Size7.6 mm (0.30 in), 10 mm (0.40in), 10.9 mm (0.43 in), 14.2mm (0.56 in), 20 mm (0.80 in)• Choice of ColorsAlGaAs Red, High EfficiencyRed (HER), Yellow, Green• Excellent AppearanceEvenly Lighted Segments±50° Viewing Angle• Design FlexibilityCommon Anode or CommonCathodeSingle and Dual DigitLeft and Right Hand DecimalPoints±1. Overflow Character• Categorized for LuminousIntensityYellow and Green Categorizedfor ColorUse of Like Categories Yields aUniform Display• Excellent for Long DigitString MultiplexingDescriptionThese low current seven segmentdisplays are designed for applica-tions requiring low powerconsumption. They are tested andselected for their excellent lowcurrent characteristics to ensurethat the segments are matched atlow currents. Drive currents aslow as 1 mA per segment areavailable.
Pin for pin equivalent displaysare also available in a standardcurrent or high light ambientdesign. The standard currentdisplays are available in all colorsand are ideal for most applica-tions. The high light ambientdisplays are ideal for sunlightambients or long string lengths.For additional information seethe 7.6 mm Micro Bright SevenSegment Displays, 10 mm SevenSegment Displays, 7.6 mm/10.9mm Seven Segment Displays,14.2 mm Seven SegmentDisplays, 20 mm Seven SegmentDisplays, or High Light AmbientSeven Segment Displays datasheets.
Low Current Seven SegmentDisplays
Technical DataHDSP-335x Series
HDSP-555x SeriesHDSP-751x SeriesHDSP-A10x SeriesHDSP-A80x SeriesHDSP-A90x SeriesHDSP-E10x SeriesHDSP-F10x SeriesHDSP-G10x SeriesHDSP-H10x SeriesHDSP-K12x, K70x SeriesHDSP-N10x SeriesHDSP-N40x Series
元器件交易网www.cecb2b.com2DevicesAlGaAsHERYellowGreenPackageHDSP-HDSP-HDSP-HDSP-DescriptionDrawing
A1017511A801A9017.6 mm Common Anode Right Hand DecimalAA1037513A803A9037.6 mm Common Cathode Right Hand DecimalBA1077517A807A9077.6 mm Common Anode ±1. OverflowCA1087518A808A9087.6 mm Common Cathode ±1. OverflowDF10110 mm Common Anode Right Hand DecimalEF10310 mm Common Cathode Right Hand DecimalFF10710 mm Common Anode ±1. OverflowGF10810 mm Common Cathode ±1. OverflowHG10110 mm Two Digit Common Anode Right Hand DecimalXG10310 mm Two Digit Common Cathode Right Hand DecimalYE100335010.9 mm Common Anode Left Hand DecimalIE101335110.9 mm Common Anode Right Hand DecimalJE103335310.9 mm Common Cathode Right Hand DecimalKE106335610.9 mm Universal ±1. Overflow[1]LH101555114.2 mm Common Anode Right Hand DecimalMH103555314.2 mm Common Cathode Right Hand DecimalNH107555714.2 mm Common Anode ±1. OverflowOH108555814.2 mm Common Cathode ±1. OverflowPK121K70114.2 mm Two Digit Common Anode Right Hand DecimalRK123K70314.2 mm Two Digit Common Cathode Right Hand DecimalSN10020 mm Common Anode Left Hand DecimalQN101N40120 mm Common Anode Right Hand DecimalTN103N40320 mm Common Cathode Right Hand DecimalUN10520 mm Common Cathode Left Hand DecimalVN106N40620 mm Universal ±1. Overflow[1]W
Note:1. Universal pinout brings the anode and cathode of each segment’s LED out to separate pins. See internal diagrams L or W.
元器件交易网www.cecb2b.com3Part Numbering System 5082-xxxx-xxxxxHDSP-xxxx-xxxxx
Mechanical Options[1]00: No mechanical option
Color Bin Options[1,2]0: No color bin limitation
Maximum Intensity Bin[1,2]0: No maximum intensity bin limitation
Minimum Intensity Bin[1,2]0: No minimum intensity bin limitation
Device Configuration/Color[1]G: Green
Device Specific Configuration[1]Refer to respective datasheet
Package[1]Refer to Respective datasheet
Notes:1. For codes not listed in the figure above, please refer to the respective datasheet or contact your nearest Agilent representative fordetails.2. Bin options refer to shippable bins for a part-number. Color and Intensity Bins are typically restricted to 1 bin per tube (excep-tions may apply). Please refer to respective datasheet for specific bin limit information.
