Parallel Redundancy Protocol anupcoming standard for hard-realtime redundancy in IndustrialEthernetApplication to IEC61850Hubert Kirrmann, ABB Corporate Research,SwitzerlandIEC SC65C MT9HAAbstract: description of a method to implementhighly available automation networks by usingparallel redundant networks,currently standardized in IEC 62439Highly Available Automation Networks2 Highly available automation networksAutomation networks require a high availability to ensure continuous plant operation.Beyond high quality elements and good maintenance, availability is increased by redundant elements (links, switches, interfaces or devices) activated automatically in case of failure.The most important factor of the recovery process is the disruption time, during which the network is unavailable.IEC SC65C MT9 is standardizing as IEC 62439 (CDV) several methods to implement high availability networks, divided into two main categories:-“redundancy in the network”, e.g. redundant rings, with devices attached to a single switch only (singly attached devices)-“redundancy in the devices”, using devices with two network interfaces attached to redundant networks (doubly attached devices)This presentation describes a “redundancy in the devices” method, the Parallel Redundancy Protocol(PRP) that provides bumpless switchover in case of failure or reintegration. Application to IEC 61850 (Substation Automation) Ethernet network is appended.Highly Available Automation Networks3PRP Network Architecturenode node node node node node nodeswitchswitchswitchswitchswitchswitchLAN ALAN BTwo separate, similar Ethernet networks (LANs) operate in parallel, their topologies may differ. Each end node (doubly attached node) has two network interfaces, one for each LAN A and B.Each end node sends simultaneously on both LANs and receives from both LANs.Highly Available Automation Networks4 PRP characteristicsPRP allows to attach nodes to a network by redundant network interfaces and links:•Addresses high availability networks tolerating any single network component failure •Provides bumpless switchover (0 nanoseconds) in case of network failure.•Is transparent to the application•Can be used with any Industrial Ethernet on layer 2 or above•Does not rely on higher layer protocols to operate or be configured•Allows nodes not equipped for redundancy to communicate with redundant nodes •Uses off-the shelf components (network interfaces, controllers, switches and links)•Can be used with any topology (tree, ring,…)Highly Available Automation Networks5Basic IdeaA Bsend TxRxTxTx RxTx Rxreceivesend on both LANs: the stack sends each frame simultaneously on LAN A and LAN B.Frames over LAN A and B have different transmission delays (or may not arrive at all)receive from both LANs:the stack receives both frames, the entity between the link and the network layer handles the frames and can filter duplicates. Both lines are treated equal.network layertransport layer send Rxreceivenetwork interfaces linkredundancy entity transceivers A B A B publisher/subscriber upper layers LAN A LAN Bapplicationsnetwork layertransport layer publisher/subscriber applicationsHighly Available Automation Networks6 Why a layer 2 redundancy ?Many Industrial Ethernet networks operate with a layer 2 (Link Layer) protocol.One motivation for this is the use of the publisher-subscriber method, that relies on broadcast of source-addressed data within the MAC broadcast domain.This excludes a redundancy scheme based on routers (Layer 3).Each node in PRP has the same MAC address on both network interfaces. Therefore, management protocols such as ARP operate as usual and assign that MAC address to the IP address(es) of that node.Highly Available Automation Networks7Typical Industrial Ethernet stackMAC/PHYEthernet 802.3TCPUDPIPClient / Server servicesAPIPT=0800Link Layer application application applicationSNTP ,PTP ,(SNMP)ARP802.p1 / 802.1QPriority tag0806PTID=8100802.2spanning tree (802.1d)Hard Real-Time stackoptional priority taggingSoft Real-Time stackICMPLayer 7publisher/subscriber (producer/consumer)Layer 2Publisher /Subscribervoidredundancy methods must operate on Layer 2 (Logical Link) to address IndustrialHighly Available Automation Networks8LAN B What happens in case of fault ?LAN AA receiver always processes both frames it receives.In case of failure, it just ceases to receive frames from one port. When traffic is reestablished, it resumes processing both frames For diagnostics purposes, it supervises the network errorsLAN BDANP DANPDANPDANP DANP DANP DANPDANP = Doubly Attached Node with PRPHighly Available Automation Networks9PRP supports any network topologycentralized wiringswitch BStar topologyParty-Line topologyboth cables can run in the same conduct if common mode failure unlikelyswitch Acommon mode failures cannot be excluded since wiring switches to be separately poweredLAN A LAN BHighly Available Automation Networks10Attachment of non-redundant nodesinter-switch link edge portsswitchDANP switchlocal area network Bleaf linkDANP switchswitchinter-switchportswitchSAN leaf linkswitchDANPDANP local area network ASANSANSANred boxSANSingly attached nodes are preferably all attached to the same network.Network traffic is asymmetrical, but this does not affect redundant operation.Singly attached nodes can also be attached through a “redundancy box” (red box )DANPHighly Available Automation Networks11 Filtering: duplicate discard and duplicate acceptA node receives twice the same frame if both redundant LANs are fault-free. It couldforward both frames to the higher layer of communication.There is in principle no need to discard duplicates at the link layer.Any communication or application software must be able to deal with duplicates, since switching networks (e.g. 802.1D RSTP) could generate duplicates:•Most applications work on top of TCP, which was designed to discard duplicates •Applications on top of UDP or Layer 2 protocols (publisher/subscriber) must be able to ignore duplicates because they rely on a connectionless communication. PRP can operate without duplicate filtering (“Duplicate Accept” mode).However, PRP also offers a “Duplicate Discard” mode, helpful:1) to offload the processors, especially when communication controllers are used.2) to supervises redundancy, bus errors, partner nodes and topology.Highly Available Automation Networks12 Discarding duplicates: solutions evaluatedDiscarding duplicates means that the link layer can identify that two frames received on both LANs are duplicates.Several methods were evaluated:1) Compare frames: a buffer with recent frames must be kept. At 20'000 frames per second and skews of several seconds, this is not bearable.2) Keep a checksum for each frame. Costs more processing power than it saves.3) Use IEEE 802.2 Type 2 which has a link layer sequence control. Unfortunately, few use 802.2.4) introduce a sequence counter in each frame. Problem: where to locate this sequence counter so that nodes not aware of redundancy can interoperate with doubly attached nodes ?Solution 4 was retained and will be explained.Highly AvailableAutomation Networks 13Discarding duplicates: sequence counter -each frame carries a sequence counter , a line indicator and a size field , inserted after the payload to remain transparent to normal network traffic.-the send inserts the same sequence counter in both frames of a pair, andincrements it by one for each sending from this node to that other node.-the receiver keeps track of the sequence counter for each for each source MACaddress it receives frames from. Frames with the same source andcounter value coming from different lines are ignored.-to this purpose, each node keeps a table of all other nodes in the network,based on observation of the network. This allows to detect nodes absence and bus errors at the same time.timedestination source LLC FCS payload preamble size sequencecounter l i n e standard Ethernet frameHighly Available Automation Networks14Discarding duplicates: Drop Window Algorithm startSeq(A)expectedSeq(A)LAN A currentSeq(A)c es LAN A dropWindowkeepBdropB keepB eLAN A s LAN B c if B dropped expectedSeq(B)eLAN B LAN B e if B kept c c scurrentSeq(B)startSeq(B)sstartSeq(A)currentSeq(B)initial:A is leading late earlyc e expectedSeq(A)sstartSeq(B)Highly AvailableAutomation Networks 15Distinguishing redundant from non-redundant frames timedestination source LLC FCS payload preamble size sequencel i n e In a frame sent by a singly attached node, assuming random data in the payload,there is a probability of 2-12that the size field matches the payload.However, this frame will not be discarded, unless a second frame arrives from theother line from that same source and with that same sequence numberand with the correct line identifier, which is not possible since a singlyattached node is attached only on one half network.The receiver detects if a frame is sent by a doubly attached node running PRP oris sent by a singly attached node with no redundancy trailer.To this purpose, a receiver identifies the PRP frames using the size field. If thelast 12 bits of the frame match the size of the payload, the receiverassumes that this frame is a PRP frame and a candidate for discarding.Highly Available Automation Networks16 Is appending a redundancy trailer in line with 802.3 ?PRP’s Duplicate Discard mode requires that frames be stretched by 4 octets.All protocols must be able to deal with data in the frames after the payload,since padding is part of the Ethernet protocol.E.g., IP has its own length control and checksum –data after the IP payload are ignored.The size of the payload must however be reduced by four octets to match the size of 1498 octets foreseen by 802.3.This would not be necessary for the switches, since all commercial switches permit longer frames to allow double tagging.However, some Ethernet Network Interfaces do not accept longer frames. Therefore, frames must be reduced by acting on the IP protocol.Network analyzers can deal with PRP, the corresponding extension already exists.Highly AvailableAutomation Networks 17Frame formats in Industrial Ethernet …LPDU = 1500 octetsLPDU = 1500 octets(TCP , UDP , ICMP)length < x0600destination source DSAP LLC (802.2)SSAPprotocol type >x0600destination sourcechecksum destinationsource protocol type checksumETPID = x8100TCI, CFI 1518octets 1518octets 1522 octets801.d (VLAN)Ethernet II 802.2 / 802.3Most Industrial Ethernet allow a mix of 802.2, 802.3, etc…resulting in 3 different frame types... IP traffic STP trafficPrioritized traffic checksumLPDU = 1494 octetsHighly AvailableAutomation Networks 18PRP frames: redundancy control after the payload length <x0600destination source DSAP LLC SSAP protocol type >x0600destination source destinationsourceprotocol typechecksumETPID = x8100TCI, CFI = x81001518 octets 1518 octets 1522 octets801.d802.3/802.2Ethernet II LPDU = 1492 octetsLPDU = 1496 octetsLPDU = 1492 octetssequencechecksum sequence checksum sequence size line size line sizeline The additional four bytes could generate oversize frames of more than 1522 octets.Although these frames are accepted by all certified switches (up to 1536 octets), some older bus controllers do not accept oversize frames, and therefore the sender must reduce the payload byplaying on the LSDU size in the network layer.appendedredundancy control trailerHighly AvailableAutomation Networks 19Redundancy Control Trailer and Padding timedestination source LLC FCS LSDU preamble padding size sequence l i n e Small frames use padding to meet the minimum frame size of 64 octets.Since padding can be introduced by switches, the sender should always insert the padding itself to reduce the decoding burden (otherwise, the receiver has to search backwards for a matching field)64 octets timedestination source LLC FCS LSDUpreamble padding size sequence l i n e 64 octets Padding inserted by the senderPadding introduced automatically:Highly AvailableAutomation Networks 20Why a size field is also useful timetime truncated destination source PT LPDU FCS ?destination source LLC FCS LPDU 01010101size sequencedestination source PT FCSLPDU LPDU truncation error: the last 32 bits are treated as CRCpreambleEthernet frames have, contrary to IEC 8802.3 frames, only a Hamming Distance of 1 against synchronization errors (frames truncation), since they do not contain a length field.To improve protection of the frames, a size field is appended to the frames.A node that receives a PRP frame from a known partner with incorrect size can flag an error. 01010101preamble01010101FCS l i n e only the application (if it is aware of it) can detect the problem...."We detected a mismatch between TCP and Ethernet checksum in up to one frame in 400“(Siggcom 2000, J. Stone & C. Patridge @standford, bbn)Highly Available Automation Networks21 Network supervisionThe duplicate discard mode allows to keep track of all nodes in the network.In order not to rely on application cyclic data for this, each DANP sends periodically a supervision frame (beacon) that indicates its state.The period is relatively long (some seconds) since the supervision frame is not needed for switchover, but only to check redundancy.All nodes keep a node table of all detected partners and registers the last time a node was seen as well as missing duplicates and out-of-sequence frames.Changes to the topology are communicated over SNMP or to the Link Management Entity.Highly Available Automation Networks22Network managementsingle-attachednodes 172.16.1.14172.16.1.66node 1node 2node 4node 65node 66switch A"red box"LAN ALAN Bswitch B2172.16.1.11172.16.1.12172.16.1.129172.16.1.192dual-attached nodesswitch B3172.16.1.195COTS NM tool172.16.1.14switch B1172.16.1.193Switches are single-attached devices and have different IP addresses on each LAN, although their function can be the same as that of a corresponding switch on the other network.Each PRP node has an SNMP agent to keep track of redundancy.Highly Available Automation Networks23Extension: Serial Redundancy Protocol modeworkstation1gatewayPRP nodes can also operate in networks that are not fully duplicatedThis mode is called SRP (Serial Redundancy Protocol) –it uses a subset of RSTP ,in which the nodes never become root bridges.SAN switch 1SANSAN bay 1switch 2SAN SANSAN bay 2SANSANSAN bay N. . .switch 10switch 20switch 30DANP nodes operating in SRPmodeHighly Available Automation Networks24 State of standardizationThe “Highly Available Automation Networks” maintenance group MT9 selected PRP is one of the three redundancy methods, along with Siemens-Hirschmann’s Hyperring (MRP) and Fieldbus Foundation’s (CRP).Siemens-Hischmann’s MRP implements “redundancy in the network” with singly attached devices attached to a ring, with moderate increase in availability and disruption delay of 200ms-500ms.Fieldbus Foundation’s CRP implements –like PRP –“redundancy in the devices”, offers the same availability increase as PRP, but has disruption times of 200 ms, compared with 0 ns for PRP. Its advantage is to allow to connect singly attached devices to both network halves, incurring the cost of aggregated links in the root switches to sustain performance.IEC 62439 is being circulated as a CDV and should become an IEC standardin 2007.Highly Available Automation Networks25 State of implementationPRP is supported by ABB and the Swiss Technical University of Wintherthur, which built an independent Linux implementation based only on the standard document.An interoperability test was performed between VxWorks, Linux and Windows implementations without problems.Highly Available Automation Networks26 PRP: Pros & Cons+ suits any Industrial Ethernet network in IEC 61784-2 (Profinet IRT has its own redundancy). + deterministic, seamless switchover+ uses standard switches and protocols+ supervises constantly the redundancy in duplicate discard mode (both LANs are active)+ monitors actual topography (over network management / SNMP)+ application-independent-requires a complete doubling of the network (twice the costs)-is limited to a layer 2 broadcast domain-requires two Ethernet controllers per node and special drivers (link redundancy entity)-request that singly attached nodes are connected to the same LAN (or use a red box).Highly Available Automation Networks27 Application to IEC 61850PRP can be readily applied to IEC 61850.It supports the layer 2 communication of GOOSE in 61850-8It offers the seamless switchover necessary for Sampled Values in 61850-9-2It provides the same redundancy scheme and hardware for the station bus and the process bus It offers a higher Hamming distance than plain Ethernet due to the length check.It can expose the link layer redundancy objects through the management interface directly as IEC 61850 objects rather than using SNMP.PRP has been tested with a real IEC 61850 installation.Highly Available Automation Networks28Redundant IEC 61850 network with PRPworkstation1loggerprinterCOM NCCDANPDANP SANduplex bay COMNCClegacylegacyduplex bayback-up workstation2GatewaylegacySAN non-redundant bayDANP gatewayDANP gatewayMixing redundant (DANP), non-redundant (SAN) and legacy devicesswitch A1switch B1SANHighly Available Automation Networks29PRP layer in IEC 61850link redundancy entityEthernet BEthernet A TCP RFC 793UDPIPISO TransportRFC 1006ISO SessionACSEISO/IEC 8649:1996MMSISO 9506-1:2003Client/ServerservicesACSIPT=0800Link Layerapplication application applicationSNTP ,PTPARPclock802.p1 / 802.1QTagging PT=0806PTID=8100802.2STP(802.1d)MAC Layerx88B9x88B8x88BAGSEmgtGOOSESVhard real-time-soft real timeHighly Available Automation Networks30 ConclusionPRP (IEC 62439 CDV)-is a redundancy method independent of IEC 61850 and used in automation networks.-provides bumpless switchover and reintegration for real-time data-permits to supervise redundancy continuously for asset management-suitable for hot swap -24h/365d operation in substations-allows to mix devices with double and single network attachment for cost optimization-allows to connect laptops and workstations to the network with standard Ethernet adapters -supports any topology-is well suited for IEC 61850。
