HD74BC373AOctal D Type Transparent Latches With 3 State Outputs

ADE-205-009A(Z)Rev. 1March 1993

Description

The HD74BC373A provides high drivability and operation equal to or better than high speed bipolar

standard logic IC by using Bi-CMOS process. The device features low power dissipation that is about 1/5

of high speed bipolar logic IC, when the frequency is 10 MHz. The device has eight D type latches with

three state outputs in a 20 pin package. When the latch enable input is high, the Q outputs will follow the

D inputs. When the latch enable goes low, data at the D inputs will be retained at the outputs until latch

enable returns high again. When a high logic level is applied to the output control input, all outputs go to a

high impedance state, regardless of what signals are present at the other inputs and the state of the storage

elements.

Features

• Input/Output are at high impedance state when power supply is off.

• Built in input pull up circuit can make input pins be open, when not used.

• TTL level input

• Wide operating temperature range input pins

Ta = –40 to + 85°C

Function Table

Inputs

GLEDOutput Q

HXXZ

LHLL

LHHH

LLXNo change

H:High levelL:Low levelX:ImmaterialZ:High impedanceHD74BC373A

2Pin Arrangement

(Top view)1

2

3

4

5

6

7

8

9

1011121314151617181920VCC

GND1Q

1D

2D

2Q

3Q3D

4D

4Q8Q

8D

7D

7Q

6Q

6D

5D

5Q

LEG

Absolute Maximum Ratings

ItemSymbolRatingUnit

Supply voltageVCC–0.5 to +7.0V

Input diode currentIIK±30mA

Input voltageVIN–0.5 to +7.5V

Output voltageVOUT–0.5 to +7.5V

Off state output voltageVOUT(off)–0.5 to +5.5V

Storage temperatureTstg–65 to +150°C

Note:1.The absolute maximum ratings are values which must not individually be exceeded, andfurthermore, no two of which may be realized at the same time.HD74BC373A

3Recommended Operating Conditions

ItemSymbolMinTypMaxUnit

Supply voltageVCC4.55.05.5V

Input voltageVIN0—VCCV

Output voltageVOUT0—VCCV

Operating temperatureTopr–40—85°C

Input rise/fall time*1tr, tf0—8ns/V

Note:1.This item guarantees maximum limit when one input switches.Waveform: Refer to test circuit of switching characteristics.

Logic Diagram

1Q

2Q

7Q

8QG

1D

2D

7D

8D

LED Q

D Q

D Q

D QHD74BC373A

4Electrical Characteristics (Ta = –40°C to +85°C)

ItemSymbolVCC(V)MinMaxUnitTest Conditions

Input voltageVIH2.0—V

VIL—0.8V

Output voltageVOH4.52.4—VIOH = –3 mA

4.52.0—VIOH = –15 mA

VOL4.5—0.4VIOL = 24 mA

4.5—0.5VIOL = 48 mA

Input diode voltageVIK4.5—–1.2VIIN = –18 mA

Input currentII5.5—–250µAVIN = 0 V

5.5—1.0µAVIN = 5.5 V

5.5—100µAVIN = 7.0 V

Short circuit output current*1IOS5.5–100–225mAVIN = 0 or 5.5 V

Off state output currentIOZH5.5—50µAVO = 2.7 V

IOZL5.5—–50µAVO = 0.5 V

Supply currentICCL5.5—29.5mAVIN = 0 or 5.5 V

All outputs is “L”

ICCH5.5—2.5mAVIN = 0 or 5.5 V

All outputs is “H”

ICCZ5.5—2.5mAVIN = 0 or 5.5 V

All outputs is “Z”

ICCT*25.5—1.5mAVIN = 3.4 or 0.5 V

Notes :1.Not more than one output should be shorted at a time and duration of the short circuit should notexceed one second.2.When input by the TTL level, it shows ICC increase at per one input pin.HD74BC373A

5Switching Test Method (CL = 50 pF)

Ta = 25°CVCC = 5.0 VTa = –40 to 85°CVCC = 5.0 V ±10%

ItemSymbolMinMaxMinMaxUnitTest Conditions

PropagationD → QtPLH3.08.03.010.0nsSee under figure

delay timetPHL3.08.03.010.0

LE →

QtPLH3.08.03.010.0ns

tPHL3.08.03.010.0

Output enable timetZH3.09.03.011.0ns

tZL3.09.03.011.0

Output disable timetHZ3.08.03.010.0ns

tLZ3.08.03.010.0

Setup timetS(H)2.0—2.0—ns

tS(L)2.0—2.0—

Hold timeth(H)2.0—2.0—ns

th(L)2.0—2.0—

Pulse widthtw6.0—6.0—ns

Input capacitanseCIN3.0(Typ)—pFVIN = VCC or GND

Output capacitanceCO15.0(Typ)—pFVO = VCC or GND

Test Circuit

VCC

1Q to 8Q1D to 8D

LEGOutput

OPEN

7VPulse GeneratorZout= 50Ω

Pulse GeneratorZout= 50ΩInput

Input

See Function Table

C =50 pFLVCC

50 ScopeΩ450Ω500Ω*2

Notes:1.CL includes probe and jig capacitance.

2.Open: tPLH, tPHL, tZH, tHZ, th, tSU, tw7 V: tZL, tLZHD74BC373A

6Waveforms-1

tPLHtPHL

VOH

VOL0 V1.5 V

1.5 V3 V

1.5 V1.5 VInput LE

Input D

Output Q3 V

0 Vtrtf

tr90%

10%90%

10%

90%90%

10%10%tf

Waveforms-2

tPLHtPHL

VOH

VOL0 V

1.5 V3 V

1.5 VInput LE

Input D

Output Q3 V

0 V1.5 Vtftr90%

10%

90%90%

10%10%tr

1.5 V
