MTU4000 系列柴油机共轨式喷射系统工作原理与故障分析摘要：本文主要描述了MTU4000系列柴油机共轨式喷射系统的工作原理，就其在日常运行中柴油机出现的突然降速或自动熄火等故障做了分析，同时说明了这些故障的处理措施。
关键词：共轨式喷射系统分析措施MTU4000系列柴油机于1997年初推出，是全球极少数装有电子监控管理系统MDEC的柴油发动机，是世界首家应用共轨式喷射系统技术的大型柴油机。
共轨式喷射系统的运用代替了传统的波许泵系统，使发动机在极低的转速下也可得到高的喷油压力。
通过精确控制喷油定时、喷油量及喷油压力，改善了燃烧与排放，降低能耗及燃油系统零件受力。
1.MTU4000系列柴油机共轨式喷射系统工作原理MTU4000系列柴油机共轨式喷射系统主要有高压泵、共轨管、喷油器和电子控制装置（ECS-发动机控制系统），它把燃油的高压产生与喷射的定时、定量完全分开，其工作原理如图：整个系统由高压泵、蓄压器（公共油轨）、喷油嘴和电子控制装置组成。
高压泵是一个多缸径向柱塞泵，由柴油机通过齿轮机构传动，它将燃油供入各缸共同的、位于柴油机两侧的公共油轨中，油轨中压力可达120Mpa左右，这相当于在普通系统上的160Mpa-180Mpa的喷射压力。
每个气缸盖上装一个由电磁阀控制的喷油器，由高压油管将共用油管与喷油器相连通。
高压燃油在油轨中蓄势待发，一旦某一喷油嘴接通，燃油即进入喷油嘴喷入气缸。
油轨中燃油压力及喷油嘴开、闭的时刻决定了各缸的喷油量，这些都是电子装置控制。
电子装置通过装于油轨前的压力传感器感知系统中的压力。
而燃油是通过一节流阀进入高压泵的，在电子装置的控制下，通过对流量的节流实现对压力的调整。
喷油嘴则具有控制喷油开始、停止，从而控制喷油量以及调整着火延迟期喷油量等多项功能，这种喷油嘴如图所示，通过一个电磁阀使针阀上方泄压，然后由燃油压力把针阀打开。
着火延迟内的喷油量通过调节阀的开启速度加以控制，当控制阀泄流后，一个附加的液压阀开始动作，使针阀快速关闭，这种辅助（喷油嘴能分别调整开启、关闭的特性）动作极其精确。
