Document Number: 88636For technical questions within your region, please contact one of the following:www.vishay.comRevision: 15-Mar-11DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com1This datasheet is subject to change without notice.THE PRODUCT DESCRIBED HEREIN AND THIS DATASHEET ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT

www.vishay.com/doc?91000Glass Passivated Junction RectifierGP08A thru GP08JVishay General Semiconductor

FEATURES

•Superectifier structure for high reliabilityapplication

•Cavity-free glass-passivated junction

•Low forward voltage drop

•Low leakage current

•High forward surge capability

•Meets environmental standard MIL-S-19500

•Solder dip 275 °C max. 10 s, per JESD 22-B106

•AEC-Q101 qualified

•Compliant to RoHS Directive 2002/95/EC and inaccordance to WEEE 2002/96/EC

TYPICAL APPLICATIONS

For use in general purpose rectification of power supplies,inverters, converters and freewheeling diodes application

MECHANICAL DATA

Case: DO-204AL, molded epoxy over glass bodyMolding compound meets UL 94 V-0 flammability ratingBase P/N-E3 - RoHS compliant, commercial gradeBase P/NHE3 - RoHS compliant, AEC-Q101 qualified

Terminals: Matte tin plated leads, solderable perJ-STD-002 and JESD 22-B102E3 suffix meets JESD 201 class 1A whisker test, HE3 suffixmeets JESD 201 class 2 whisker test

Polarity: Color band denotes cathode endPRIMARY CHARACTERISTICS

IF(AV)0.8 A

VRRM50 V to 600 V

IFSM25 A

IR5.0 μA

VF1.3 V

TJ max.175 °C

DO-204AL (DO-41)SUPERECTIFIER®MAXIMUM RATINGS (TA = 25°C unless otherwise noted)

PARAMETERSYMBOLGP08AGP08BGP08DGP08GGP08JUNIT

Maximum repetitive peak reverse voltageVRRM50100200400600V

Maximum RMS voltageVRMS3570140280420V

Maximum DC blocking voltageVDC50100200400600V

Maximum average forward rectified current 0.375" (9.5 mm) lead length at TA = 55 °CIF(AV)0.8A

Peak forward surge current 8.3 ms single half sine-wave superimposed on rated loadIFSM25A

Maximum full load reverse current full cycle average0.375" (9.5 mm) lead length at TA = 55 °CIR(AV)30μA

Operating junction and storage temperature rangeTJ, TSTG- 65 to + 175°C

http://oneic.com/

www.vishay.comFor technical questions within your region, please contact one of the following:Document Number: 886362DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.comRevision: 15-Mar-11This datasheet is subject to change without notice.THE PRODUCT DESCRIBED HEREIN AND THIS DATASHEET ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT

www.vishay.com/doc?91000GP08A thru GP08JVishay General Semiconductor

Note(1)Thermal resistance from junction to ambient at 0.375" (9.5 mm) lead length, P.C.B. mounted

Note(1)AEC-Q101 qualified

RATINGS AND CHARACTERISTICS CURVES

(TA = 25 °C unless otherwise noted)

Fig. 1 - Forward Current Derating Curve Fig. 2 - Maximum Non-repetitive Peak Forward Surge CurrentELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise noted)

PARAMETERTEST CONDITIONSSYMBOLGP08AGP08BGP08DGP08GGP08JUNIT

Maximum instantaneous forward voltage0.8 AVF1.3V

Maximum DC reverse current at rated DC blocking voltageTA = 25 °CIR5.0μATA = 125 °C50

Typical reverse recovery timeIF = 0.5 A, IR = 1.0 A,Irr = 0.25 Atrr2.0μs

Typical junction capacitance4.0 V, 1 MHzCJ8.0pF

THERMAL CHARACTERISTICS (TA = 25°C unless otherwise noted)

PARAMETERSYMBOLGP08AGP08BGP08DGP08GGP08JUNIT

Typical thermal resistanceRJA (1)55°C/W

ORDERING INFORMATION (Example)

PREFERRED P/NUNIT WEIGHT (g)PREFERRED PACKAGE CODEBASE QUANTITYDELIVERY MODE

GP08J-E3/540.33554550013" diameter paper tape and reel

GP08J-E3/730.335733000Ammo pack packaging

GP08JHE3/54 (1) 0.33554550013" diameter paper tape and reel

GP08JHE3/73 (1)0.335733000Ammo pack packaging

2040608010012014016018000.20.40.60.81.0

Average Forward Current (A)

Ambient Temperature (°C)60 HzResistive or Inductive Load0.375" (9.5 mm) Lead Length

11010010

5.0152025

0

Number of Cycles at 60 HzPeak Forward Surge Current (A)TJ = TJ Max.8.3 ms Single Half Sine-Wave
