This Document is the Confidential property of NSF International
NSF International (NSF)
Physical& Mechanical Testing Laboratory/Food Equipment Testing Program
Test Procedure P218A
Reference NSF Standard2,3,4,6,7,26 and Criteria C-2
TEMPERATURE INDICATING DEVICE TEST
A.PURPOSE:
1.To determine the accuracy of a temperature indicating device in the critical use ranges.
B.APPARATUW/EQUIPMENT:
1.Calibrated thermometer with the appropriate range having an accuracy of ±0.1℉.
2.Conditioning chamber or dry well calibrator capable of producing and maintaining the necessary temperature.
3.Sand filled container large enough to contain the thermometers to be tested and the standard thermometer and
which allows at least 25mm(1”) of sand to completely cover the sensing bulbs, if applicable.
4.NSF test data sheet P218A-D.
C.TEST CONDITIONS:
1.Temperature indicating devices may be allowed to stabilize for up to 8 hours at the test temperature before readings
are taken.
D.PROCEDURE:
1.Examine the temperature sensing portion of the indicating device and determine if it will fit into the constant
temperature block assembly of the dry well calibrator (B2). IF it does not, continue with steps 2 through 4, if it
does, continue with steps 6 through 13.
2.Place the temperature sensing portion of each of three indicating devices and the calibrated thermometer (B1) into
the sand filled container (B3) and position to allow 2.5 ±3mm(1±1/8”) of sand to cover the sensing bulbs.
3.Place the sand container with the sensing bulbs and thermometer into the conditioning chamber (B2) and establish
the test temperature.
4.After the temperature indicating devices have stabilized (C1), read and record each temperature.
5.Follow steps 2 through 4 for each test temperature.
6.Determine which dry well calibrator (B2) will be used. Model 9105 has a use range of -13 to 284℉and model
9122 has a use range of 60 to 1112℉.
7.Place the temperature sensing portion of each of 3 indicating devices into the constant temperature block assembly
of the applicable dry well calibrator (B2). Choose the holes that provide the slightest clearance. For larger diameter sensing bulbs, use the 20 mm (.75”) holes and sleeve down with inserts for various sized probes.
8.Turn on the dry well calibrator and follow the appropriate procedure;“red” for the 9122 or “blue” for the
9105,Be sure the procedure is still active by verifying the date of expiration on the procedure.
9.Follow the steps and set the test temperature.
10.Allow at least 1/2” hour for the temperature to be reached and maintained.
11.Read and record each temperature.
12.Follow steps 9 through 11 for each test temperature.
13.Turn off dry well calibrator when complete.
E.PERFORMA NCE/CRITERIA:
1.Refrigerator thermometers shall be accurate to within ±2℉at 40℉.
2.Freezer thermometers shall be accurate to within ±2℉at 0℉.
3.Ware washing thermometers shall be accurate to within ±3℉at specified temperatures.
4.Oven thermometers shall be accurate to within ±25℉at 25 and 75% of the temperature scale. beginning at 200℉.
5.Product thermometers shall be accurate to within ±2℉,at 45℉,140℉and 165℉.
6.High temperature holding thermometers shall be accurate to within ±3℉at 145℉and 170℉.
7.Candy/Deep Fryer thermometer shall be accurate to within ±5 ℉at 25 and 75% of
the temperature scale.
THTS IS A CONTROLLED DOCUMENT,REVISIONS MUST BE AUTHORI ZED, DO NOT DUPLICATE。
