基于STM-32指纹识别密码锁控制系统的设计与实现毕业论文
- 格式:doc
- 大小:247.50 KB
- 文档页数:27
基于STM-32指纹识别密码锁控制系统的设计与实现毕业论
文
本科生毕业论文(设计)
此处为论文中文
题目,要求居中填写
主标题不超过24题目:基于STM-32指纹密码锁控制系统的设计与实现
个汉字;可加副标题 (副标题前加破折号),副标题与主标题间空一行的位置主标题:黑体,小
二,居中
副标题:楷体 _GB2312,四号,居中
阅后删除此文本
框。
基于STM-32指纹密码锁控制系统的设计与实现
摘要:本文首先介绍了指纹密码锁控制系统的开发背景和意义~简单介绍了一些
国内外常见的指纹识别装置和指纹识别密码锁~并指出了当前指纹识别控制系统存在的
问题~再根据完整的指纹识别模块指令确定了本系统的目标和要求~以战舰STM-32为
开发平台进行了系统的总体结构设计~阐述了系统的软、硬件组成~并重点探讨了指纹
识别模块、键盘模块、LCD液晶显示模块和报警模块等几个主要功能模块的设计与实现。
最后~对系统的设计与实现做相应总结。
关键词:指纹识别,战舰 STM32,模式识别
Design and Implementation of STM32-based fingerprint combination
lock control System
Abstract: This paper introduces the fingerprint lock control system development background and significance simply, introduced some common fingerprint identification device and fingerprint identification combination lock at home and abroad, and points out the problems
existing in the current fingerprint identification control system, according to the complete fingerprint identification module instruction to determine the objectives and requirements of this system, the warship STM - 32 as a development platform for the overall structure of the system design, this paper expounds the hardware and software of the system, and probes into the input fingerprint identification module, keyboard module, LCD liquid crystal display module and alarm module, etc. Several main function module design and implementation. Finally, summarizes the design and implementation of the system.
Key words: Fingerprint identification; Warship STM32; Pattern recognition
