DW06D (文件编号：S&CIC1057)二合一锂电池保护IC一、概述DW06D 产品是单节锂离子/锂聚合物可充电电池组保护的高集成度解决方案。

DW06D 包括了先进的功率MOSFET ，高精度的电压检测电路和延时电路。

DW06D 具有非常小的SOT23-6的封装,这使得该器件非常适合应用于空间限制得非常小的可充电电池组应用。

DW06D 具有过充，过放，过流，短路等所有的电池所需保护功能，并且工作时功耗非常低。

该芯片不仅仅是为手机而设计，也适用于一切需要锂离子或锂聚合物可充电电池长时间供电的各种信息产品的应用场合。

二、特点内部集成等效50mΩ左右的先进的功率MOSFET ；3段过流保护：过放电流1、过放电流2（可选）、负载短路电流； 充电器检测功能；延时时间内部设定；高精度电压检测；低静态耗电流：正常工作电流3.8uA 兼容ROHS 和无铅标准；采用SOT23-6封装形式塑封；支持0V 充电。

三、应用单芯锂离子电池组；锂聚合物电池组。

四、订货信息五、引脚图及说明DW06D(文件编号：S&CIC1057)二合一锂电池保护IC 六、极限参数七、电气特性参数DW06D(文件编号：S&CIC1057)二合一锂电池保护IC八、功能描述DW06D监控电池的电压和电流，并通过断开充电器或负载，保护单节可充电锂电池不会因为过充电压，过放电压，过放电流以及短路等情况而损坏。

这些功能都使可充电电池工作在制定的范围内。

MOSFET已内置，等效电阻典型值为50mΩ正常工作模式如果没有检测到任何异常情况，充电和放电过程都将自由转换。

这种情况称为正常工作模式。

过充电压情况在正常条件下的充电过程中，当电池电压高于过充检测电压(VOCP)，并持续时间达到过充电压检测延迟时间(TOC)或更长，DW06D将控制MOSFET以停止充电。

这种情况称为过充电压情况。

以下两种情况下，过充电压情况将被释放：1、当电池电压低于过充解除电压(VOCR),DW06D控制充电的FET导通，回到正常工作模式下。

The BlackArmor® NAS 220 server is a small-business-specific network attached storage solution designed toprovide centralized storage and data backup, helping to deliver business continuity for up to 20 PCs. Automaticallybackup business-critical data with RAID 1 mirroring, full-system backup, SafetyDrill+™ bare metal recoverysoftware and powerful hardware-based encryption.Highlights• Designed to provide centralized storage and data backup for up to 20 PCs.• Enables automatic data mirroring with RAID 1 configuration.• Help protect network connected PCs with incremental and full-system, automatic backup.*• Time Machine® software compatible, for Mac® computer backup• Functions as an FTP server for remote file access.• Stream media to DLNA® compliant devices and computers running iTunes® software.• Includes two reliable, user-replaceable Seagate® hard drives.• Connect external drives, share a printer or utilize an uninterrupted power supply with the two USB 2.0 ports.• Secure files with powerful hardware-based encryption.• Microsoft® Active Directory 2003/2008 support for populating users and groups.• Multi-volume management.• Event email notification.• 3-year limited warranty.© 2010 Seagate Technology LLC. All rights reserved. Seagate, Seagate Technology, the Wave logo, Barracuda, Global Access and BlackArmor are trademarks or registered trademarks of Seagate Technology LLC or one ofits affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners. When referring to hard drive capacity, one terabyte, or TB, equalsone thousand billion bytes. Your computer’s operating system may use a different standard of measurement and report a lower capacity. In addition, some of the listed capacity is used for formatting and other functions andwill not be available for data storage. The export or re-export of hardware or software containing encryption may be regulated by the U.S. Department of Commerce, Bureau of Industry and Security (for more information,visit ) and controlled for import and use outside of the U.S. Actual data rates may vary depending on operating environment and other factors. Seagate reserves the right to change, without notice, productofferings or specifications. Seagate Technology LLC, 920 Disc Drive, Scotts Valley CA 95066 U.S.A. DS1691.3-1010 AMERVisit for more information about these and other Seagate retail products.Perfect for when you need to:• S tore and access files from acentral, secure location.• A ccess and manage filesremotely.• S tream media with DLNA oriTunes®.• A utomatically perform full-system backups on networkconnected PC and Mac®computers.*• S ecure files with hardware-based encryption.• S hare a USB printer withnetwork connected PCs andMacs.Interface 10/100/1000 Ethernet, USB 2.0Capacities2TB, 4TB, 6TBSoftware Requirements PC On Network• Pentium® III, 500MHz equivalent processor or higher• Microsoft Windows® XP or Vista®• I nternet Explorer® 6.0 or later, or Firefox™ 2.X or later(for management interface and web access)• 256MB RAMMac On Network• Mac OS® X 10.4.11 or later• Apple® Safari® 3.1 or laterSystem Requirements• Local area network (LAN)• Internet connection (for system updates and web access)• W ired or wireless router with an available 10/100/1000Ethernet port• USB printer or USB disk drive (optional)Inside the Box • BlackArmor NAS 220 storage server• 2M – RJ45 cable• AC power cord• Quick Start Guide• DVD-ROM with– BlackArmor® Discovery Software for Windows® OS– BlackArmor® Discovery Software for Mac® OS– BlackArmor® Backup Software for Windows (5 licenses*)– Online registration link– Warranty information card*Additional licenses available for purchase at Connectivity• O ne Ethernet port for localnetwork connection, web-based management and remoteaccess.• T wo USB 2.0 ports for externaldrives, printers and uninterruptedpower supplies (UPS).• Two internal SATA II ports.* Includes data backup software licenses for 5 PCs. Additional licenses available for purchase at .Product Dimensions Horiz x Vert x Depth - 6.30”x 8.15” x 10.59” (160mm x 207mm x 269mm)Weight: 13.60lbs (6.16kg)Retail Packaging Specs Box dimensions: Horiz x Vert x Depth – 14.37” x 9.29” x 9.5” (277mm x 156mm x 279mm)Box weight: 16.6lbs (7.62Kg)Master carton dimensions: Horiz x Vert x Depth – 19.33” x 15.00” x 10.20” (322mm x 288mm x 301mm)Master carton weight: 36.05lbs (8.39Kg)Master carton quantity: 2Master cartons per pallet: 36Pallet dimensions: Horiz x Vert x Depth – 47.25” x 39.37” x 47.10” (1,016mm x 1,219.20mm x 1,030mm)Pallet weight: 718.85 lbs (326.06 kg)Pallet layers: 3Technical Specifications ConnectivityNetwork ProtocolsNetwork AuthenticationFile Sharing ProtocolsFile System ManagementVolume ManagementDisk ManagementBackup ManagementEvent ManagementMedia StreamingDownload ServerRemote Access• 2 internal SATA II ports• 2 USB 2.0 host portsCIFS, NFS, HTTP, HTTPS, FTP, Bonjour®RAID 0, 1, JBOD• Share management• Volume level encryption• Multi-volume management• SMART status monitor• L ocal backup(USB device to NAS, NAS to USB device)• Network NAS to NAS replicationEvent email notification• iTunes® server• DLNA® compliant digital media serverDownloader (HTTP and FTP)Seagate Global Access™ service• 1 RJ45 Ethernet port (Gigabit)• Share/folder-level access control list (ACL) support• Quotas setting• Drive standby mode• C lient system backup, Bare MetalRestore(full-system recovery) over network• Time Machine® software compatibleMicrosoft Windows® Server Active Directory 2000/2003/2008 integration for population of users and groups.CIFS, NFS, HTTPS, FTP over SSL/TLS, FTP, Bonjour, Microsoft RallyExpansionThe two rear-mounted USB 2.0 ports allow you to connectexternal USB hard drives for additional storage, easily share a USB printer with your network connected computers or connect an uninterrupted power supply (UPS) to safeguard from power failure.Business-grade ProtectionSoftware plays an important role in achieving business continuity and with the BlackArmor storage server, you can expect nothing less than business-grade protection. To help protect your critical data, our software package provides automatic, incremental and full-system backup. In the event of PC hardware failure, you can utilize the SafetyDrill+™ bare metal restore software feature to recover your entire system, including the operating system, programs and settings. The included software also allows you to secure your files with powerful hardware-based encryption. Furthermore, the two internal drives can be configured to RAID 1, which automatically mirrors your data.You’re in ControlIn addition to the included software, the web-based management interface and BlackArmor ® Discovery Tool are also straightforward to use. The BlackArmor Discovery Tool allows you to get up and running quickly by displaying all of the BlackArmor NAS products connected to your network. From the Discovery Tool, with a single click, you can view or map shared volumes to your computer, access the web-based management interface or back up the PC you are working from. The BlackArmor NAS 220 storage server can also be managed remotely with DDNS, which can be configured from the web-based management interface or back up the PC you are working from. Mac ® computers can be backed up by using Time Machine ® software, which offers full-system, incremental backup over the network.The BlackArmor ® NAS 220 storage server can also function as an FTP server, allowing remote access to files. Using the web-basedmanagement interface, you can designate user access manually or integrate with Microsoft ® Active Directory to populate users and groups..Moreover, the BlackArmor NAS 220 storage server can stream media files to DLNA ® compliant devices or computers running iTunes ® software, allowing you to centralize media in your office and display content simultaneously on multiple devices.Designed to provide centralized storage and data backup.Performance that Keeps Pace with Your Business The BlackArmor ® NAS 220 storage server makes no compromises when it comes to hardware, with Seagate ® Barracuda ® drives, 800 MHZ processor, 128 MB RAM and Gigabit Ethernet port, you will experience incredible performance – including read speeds of up to 70 MB/s in RAID 1 configuration*.The BlackArmor NAS 220 storage server includes two energy efficient, reliable Seagate hard drives, which are user-replaceable, allowing you to upgrade to larger capacity drives as your business grows.* Read performance obtained with CrystalDiskMark 3.0 on a Windows ® 7 x64 system.。

2.MTTF calculator available at /rf. Select Tools/Software/Application Software/Calculators to accessthe MTTF calculators by product. (Calculator available when part is in production.)3.Refer to AN1955, Thermal Measurement Methodology of RF Power Amplifiers. Go to /rf.Select Documentation/Application Notes - AN1955.This document contains information on a preproduction product. Specifications and information herein are subject to change without notice.Document Number: Order from RF MarketingRev. 6, 10/2006 Freescale SemiconductorTechnical Data2RF Device DataFreescale SemiconductorMRF6V2150N MRF6V2150NB Table 3. ESD Protection CharacteristicsTest MethodologyClass Human Body Model (per JESD22-A114)TBD (Minimum)Machine Model (per EIA/JESD22-A115)TBD (Minimum)Charge Device Model (per JESD22-C101)TBD (Minimum)Table 4. Moisture Sensitivity LevelTest MethodologyRating Package Peak TemperatureUnit Per JESD 22-A113, IPC/JEDEC J-STD-0203260°CTable 5. Electrical Characteristics (T C = 25°C unless otherwise noted)CharacteristicSymbolMinTypMaxUnitOff CharacteristicsZero Gate Voltage Drain Leakage Current (V DS = 110 Vdc, V GS = 0 Vdc)I DSS ——10μAdc Zero Gate Voltage Drain Leakage Current (V DS = 50 Vdc, V GS = 0 Vdc)I DSS ——10μAdc Drain-Source Breakdown Voltage (I D = 75 mA, V GS = 0 Vdc)BV DSS 110——Vdc Gate-Source Leakage Current (V GS = 5 Vdc, V DS = 0 Vdc)I GSS——10μAdcOn CharacteristicsGate Threshold Voltage(V DS = 10 Vdc, I D = 400 μAdc)V GS(th)— 2.4—Vdc Drain-Source On-Voltage (V GS = 10 Vdc, I D = 1 Adc)V DS(on)—0.3—VdcDynamic CharacteristicsReverse Transfer Capacitance(V DS = 50 Vdc, V GS = 0 Vdc, f = 1.0 MHz)C rss — 1.54—pF Output Capacitance(V DS = 50 Vdc, V GS = 0 Vdc, f = 1.0 MHz)C oss —94—pF Input Capacitance(V DS = 50 Vdc, V GS = 0 Vdc, f = 1.0 MHz)C iss—163—pFFunctional Tests (In Freescale Test Fixture, 50 οhm system) V DD = 50 Vdc, I DQ = 450 mA, P out = 150 W, f = 220 MHz, CWPower Gain G ps —25.5—dB Drain Efficiency ηD —69—%Input Return LossIRL —-17—dB P out @ 1 dB Compression Point, CW (f = 220 MHz)P1dB—165—WATTENTION: The MRF6V2150N and MRF6V2150NB are high power devices and special considerations must be followed in board design and mounting. Incorrect mounting can lead to internal temperatures which exceed the maximum allowable operating junction temperature. Refer to Freescale Application Note AN3263(for bolt down mounting) or AN1907 (for solder reflow mounting) PRIOR TO STARTING SYSTEM DESIGN to ensure proper mounting of these devices.MRF6V2150N MRF6V2150NB3RF Device DataFreescale SemiconductorTYPICAL CHARACTERISTICS2027262524232221G p s , P O W E R G A I N (d B )I M D , T H I R D O R D E R I N T E R M O D U L A T I O N4RF Device Data Freescale SemiconductorMRF6V2150N MRF6V2150NB PACKAGE DIMENSIONSBOTTOM VIEW TO-270 WB-4PLASTICMRF6V2150NMRF6V2150N MRF6V2150NB5RF Device DataFreescale Semiconductor6RF Device Data Freescale SemiconductorMRF6V2150N MRF6V2150NBMRF6V2150N MRF6V2150NB7RF Device DataFreescale SemiconductorInformation in this document is provided solely to enable system and softwareimplementers to use Freescale Semiconductor products. There are no express orimplied copyright licenses granted hereunder to design or fabricate any integratedcircuits or integrated circuits based on the information in this document.Freescale Semiconductor reserves the right to make changes without further notice toany products herein. Freescale Semiconductor makes no warranty, representation orguarantee regarding the suitability of its products for any particular purpose, nor doesFreescale Semiconductor assume any liability arising out of the application or use ofany product or circuit, and specifically disclaims any and all liability, including withoutlimitation consequential or incidental damages. “Typical” parameters that may beprovided in Freescale Semiconductor data sheets and/or specifications can and dovary in different applications and actual performance may vary over time. All operatingparameters, including “Typicals”, must be validated for each customer application bycustomer’s technical experts. Freescale Semiconductor does not convey any licenseunder its patent rights nor the rights of others. Freescale Semiconductor products arenot designed, intended, or authorized for use as components in systems intended forsurgical implant into the body, or other applications intended to support or sustain life,or for any other application in which the failure of the Freescale Semiconductor productcould create a situation where personal injury or death may occur. Should Buyerpurchase or use Freescale Semiconductor products for any such unintended orunauthorized application, Buyer shall indemnify and hold Freescale Semiconductorand its officers, employees, subsidiaries, affiliates, and distributors harmless against allclaims, costs, damages, and expenses, and reasonable attorney fees arising out of,directly or indirectly, any claim of personal injury or death associated with suchunintended or unauthorized use, even if such claim alleges that FreescaleSemiconductor was negligent regarding the design or manufacture of the part.Freescale t and the Freescale logo are trademarks of Freescale Semiconductor, Inc.All other product or service names are the property of their respective owners.© Freescale Semiconductor, Inc. 2006. All rights reserved.How to Reach Us:Home Page:E-mail:support@USA/Europe or Locations Not Listed:Freescale SemiconductorTechnical Information Center, CH3701300 N. Alma School RoadChandler, Arizona 85224+1-800-521-6274 or +1-480-768-2130support@Europe, Middle East, and Africa:Freescale Halbleiter Deutschland GmbHTechnical Information CenterSchatzbogen 781829 Muenchen, Germany+44 1296 380 456 (English)+46 8 52200080 (English)+49 89 92103 559 (German)+33 1 69 35 48 48 (French)support@Japan:Freescale Semiconductor Japan Ltd.HeadquartersARCO Tower 15F1-8-1, Shimo-Meguro, Meguro-ku,Tokyo 153-0064Japan0120 191014 or +81 3 5437 9125support.japan@Asia/Pacific:Freescale Semiconductor Hong Kong Ltd.Technical Information Center2 Dai King StreetTai Po Industrial EstateTai Po, N.T., Hong Kong+800 2666 8080@For Literature Requests Only:Freescale Semiconductor Literature Distribution CenterP.O. Box 5405Denver, Colorado 802171-800-441-2447 or 303-675-2140Fax: 303-675-2150LDCForFreescaleSemiconductor@。

PhilipsLCD widescreen monitor51 cm (20.1") wideWSXGA200WS8FB Vista-ready widescreen forbusiness productivityDo more, see more on budget! With high resolution and a large, wide viewing area, thisultra-slim Philips 200WS8 boosts your business productivity - and is ready for immediateor future upgrade to Windows Vista.Designed for maximum productivity•Big, widescreen ideal for viewing two A4 pages side-by-side•Display more images and content without scrollingBest total cost of ownership solution•Empowered for Windows Vista•Complies with RoHS standards to care for the environment•The lowest power consumption in the industryOutstanding front of screen performance•WSXGA+, wide format 1680x1050 resolution for sharper display•5ms fast response time•DVI-D input and HDCP supportGreat convenience•Dual input accepts both analog VGA and digital DVI signals•Embedded power supply eliminates external power adaptors•Adjust display settings with hot key or on-screen controlsHighlightsWidescreenA big, widescreen display that improves productivity by displaying two A4 pages side-by-side.Large viewing areaViewing area is the visible portion of a monitor screen available for displaying data. Windows Vista readyPhilips Vista-ready monitors are empowered for vibrant, exciting display of this new, visually sophisticated and demanding Windows operating system, designed to enhance your entertainment experience, make you more productive and help you control your computing experience at home and in the office, making viewing, finding and organizing information for work or play quick, efficient and easy.Compliant with RoHS standards Philips designs and produces display products in compliance with strict Restriction of Hazardous Substances (RoHS) standards that restrict lead and other toxic substances that can harm the environment.Lowest power consumptionLower power consumption reduces the energyrequired to operate a device, saving its owneroperating costs and conserving power.WSXGA+, wide format 1680x1050Wide format, super extended graphics array isa display specification that is capable ofdisplaying 1680 x 1050 resolution orapproximately 1.7 million pixels.5ms on/off response timeOn-Off response time is the period requiredfor a liquid crystal cell to go from active (black)to inactive (white) and back to active (black)again. It is measured in milliseconds. Faster isbetter: Lower response time means fastertransitions and, therefore, results in fewervisible image artifacts in the display oftransition of texts and graphics. On-Offresponse time is a more important measure inthe display of business content like documents,graphs and photos.HDCP readyHigh-Bandwidth Digital Content Protection(HDCP) is a copyright protection system thatis incorporated into the DVI connector. Ithelps stop unauthorized duplication ofcopyrighted content. HDCP allows you to playprotected content media such as movies andconcerts. It checks the signal to prevent piracy,allowing only legal copies of content to display.Dual inputDual input provides connectors toaccommodate input of both analog VGA anddigital DVI signals.Embedded power supplyAn embedded power supply is a poweradaptor built into the body of a display devicethat replaces a bulky external power adaptor.User friendly hot key and OSDThe user friendly hot key and on-screen displaycontrols are dual systems for convenientlyfine-tuning display settings to meet a variety ofneeds. Press the hot key on your monitor'sframe for automatic picture, quick contrast andbrightness control or use the on-screen displayfeature to fine-tune your display settings.Issue date 2022-05-18 Version: 3.0.1012 NC: 8670 000 30111 EAN: 87 12581 30351 8© 2022 Koninklijke Philips N.V.All Rights reserved.Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.SpecificationsPicture/Display•LCD panel type: 1680 x 1050 pixels, Anti-glare polarizer, RGB vertical stripe•Panel Size: 20.1"/ 51 cm•Effective viewing area: 433.4 x 270.9 mm •Pixel pitch: 0.258 x 0.258 mm •Brightness: 300 cd/m²•Contrast ratio (typical): 800:1•Display colors: 16.7 M•Viewing angle: 160º (H) / 160º (V), @ C/R > 10•Response time (typical): 5 ms•White Chromaticity, 6500K: x = 0.313 / y = 0.329•White Chromaticity, 9300K: x = 0.283 / y = 0.297•Maximum Resolution: 1680 x 1050 @ 60Hz •Optimum resolution: 1680 x 1050 @ 60Hz •Video Dot Rate: 205 MHz•Horizontal Scanning Frequency: 30 - 93 kHz •Vertical Scanning Frequency: 56 - 76 Hz •Aspect ratio: 16:10•sRGBConnectivity•Signal Input: VGA (Analog ), DVI-D•Sync Input: Composite Sync, Separate Sync, Sync on Green•Video input impedance: 75 ohm•Sync input impedance: 2.2k ohm•Video input signal levels: 0.7 Vpp Convenience•User convenience: On-screen Display •Monitor Controls: Auto, Brightness (Left), Contrast (Right), Menu, Power On/Off•OSD Languages: English, French, German, Italian, Simplified Chinese, Spanish•Other convenience: Kensington lock compatible •Plug & Play Compatibility: DDC/CI, sRGB, Windows 98/ME/2000/XP/Vista•Regulatory approvals: CE Mark, Energy Star, FCCClass B, SEMKO, TCO '03, TÜV/GS, TÜV Ergo, UL/cUL•Tilt: -5° to 25°•VESA Mount: 100 x 100 mmAccessories•Included accessories: AC Power Cord, VGA cable •User ManualDimensions•Box dimensions(W x H x D):525 x 174 x 452 mm•Box dimensions in inch (W x H x D):20.7 x 6.9 x 17.8 inch•Set dimensions(W x H x D):472.89 x 310.23 x 73 mm•Set dimensions in inch (W x H x D):18.6 x 12.2 x 2.9 inch•Set dimensions with stand (W x H x D):472.89 x 400.42 x 213.59 mm•Set dimensions with stand in inch (W x H x D): 18.6 x 15.8 x 8.4 inch•MTBF: 50,000 hrs•Relative humidity: 20% - 80%•Temperature range (operation): 5°C to 35°C •Temperature range (storage): -20°C to 60°C •Product weight (+stand): 5.3 kg•Product weight (+stand) (lb): 11.7 lb•Weight incl. Packaging: 6.1 kg•Weight incl. Packaging (lb): 13.4 lbPower•Complies with: Energy Star•Consumption (On mode): < 43 W (Typical)•Consumption(Off Mode): < 1 W•Power LED indicator: Operation - green, Stand by/ sleep - Amber•Power supply: Built-in, 100-240VAC, 50/60Hz。
