Features • ON-Resistance RDS(on)1=54mΩ (typ) • 1.8V Drive • Pb-Free, Halogen Free and RoHS Compliance Specifications Absolute Maximum Ratings at Ta = 25°C Parameter Symbol Value Unit Drain to Source Voltage VDSS 20V Gate to Source Voltage VGSS ±12V Drain Current (DC) ID 3.5

A Drain Current (Pulse) PW≤10μs, duty cycle≤1% IDP 14A

Power Dissipation When mounted on ceramic substrate (900mm2

×0.8mm) PD 1.0 W

Junction Temperature Tj 150°C Storage Temperature Tstg −55 to +150°C This product is designed to “ESD immunity < 200V*”, so please take care when handling. * Machine Model Thermal Resistance Ratings Parameter Symbol Value

Unit Junction to Ambient RθJA 125 °C/W When mounted on ceramic substrate (900mm2×0.8mm) Power MOSFET

20V, 71mΩ, 3.5A, Single N-Channel

StressesexceedingthoselistedintheMaximumRatingstablemaydamagethedevice.Ifanyoftheselimitsareexceeded,devicefunctionalityshouldnotbeassumed,damagemayoccurandreliabilitymaybeaffected.TLElectrical Connection N-Channel

Packing Type:TL Marking1

23

1:Gate2:Source3:Drain

LNLOTNo.VDSS RDS(on) Max ID Max

20V 71 mΩ@4.5V 3.5A 103 mΩ@2.5V 156 mΩ@1.8V CPH3456

www.onsemi.com 2 Electrical Characteristics at Ta = 25°C

Parameter Symbol Conditions Value Unitmin typ max Drain to Source Breakdown Voltage V(BR)DSS ID=1mA, VGS=0V 20 V Zero-Gate Voltage Drain Current IDSS VDS=20V, VGS=0V 1μA Gate to Source Leakage Current IGSS VGS=±8V, VDS=0V ±10μA Gate Threshold Voltage VGS(th) VDS=10V, ID=1mA 0.4 1.3V Forward Transconductance gFS VDS=10V, ID=1.5A 2.8 S

Static Drain to Source On-State Resistance RDS(on)1 ID=1.5A, VGS=4.5V 54 71mΩ RDS(on)2 ID=1A, VGS=2.5V 73 103mΩ RDS(on)3 ID=0.5A, VGS=1.8V 104 156mΩ Input Capacitance Ciss VDS=10V, f=1MHz 260 pF Output Capacitance Coss 65 pF Reverse Transfer Capacitance Crss 50 pF Turn-ON Delay Time td(on)

See specified Test Circuit 6.2 ns Rise Time tr 19 ns Turn-OFF Delay Time td(off) 30 ns Fall Time tf 28 ns Total Gate Charge Qg VDS=10V, VGS=4.5V, ID=3.5A 2.8 nC Gate to Source Charge Qgs 0.6 nC Gate to Drain “Miller” Charge Qgd 0.9 nC Forward Diode Voltage VSD IS=3.5A, VGS=0V 0.85 1.2V Switching Time Test Circuit

ProductparametricperformanceisindicatedintheElectricalCharacteristicsforthelistedtestconditions,unlessotherwisenoted.ProductperformancemaynotbeindicatedbytheElectricalCharacteristicsifoperatedunderdifferentconditions.

PW=10μsD.C.≤1%4.5V0VVIN

P.G50ΩG

SID=1.5ARL=6.67ΩVDD=10V

VOUTVIND
