DESCRIPTION
The SD 066-24-21-011 is a red enhanced Bi-Cell silicon photodiode used for nulling, centering, or measuring small positional changes packaged in a hermetic TO-46 metal package.
元器件交易网
Red Enhanced Bi-Cell Silicon Photodiode SD 066-24-21-011
PACKAGE DIMENSIONS INCH [mm] PACKAGE DIMENSIONS INCH [mm]
.209 [5.31] .200 [5.08] .055 [1.40] 3X Ø.018 [0.46] Ø.156 [3.96] Ø.152 [3.86] 42° VIEWING Ø.187 [4.75] ANGLE Ø.181 [4.60] 45°
Ø.215 [5.46] Ø.210 [5.33] Ø.100 [Ø2.54] PIN CIRCLE
1
1 2
2
3 3X .50 [12.7] MIN
CHIP DIMENSIONS INCH [mm]
.057 [1.45] SQUARE
1 CELL 1 2 CELL 2 3
ANODE CELL #1 CASE GROUND & COMMON CATHODE ANODE CELL #2
CHIP DIMENSIONS INCH [mm]
1 2 2X .023 [0.58] ACTIVE AREA .0008 [0.020] GAP 2X .047 [1.19] ACTIVE AREA
TO-46 PACKAGE SCHEMATIC
TO-46 PACKAGE
FEATURES
• • • • Low noise Red enhanced High shunt resistance High response
0.70 Responsivity (A/W) 0.60 0.50 0.40 0.30 0.20 0.10 0.00
APPLICATIONS
• Emitter Alignment • Position sensing • Medical and Industrial
ABSOLUTE MAXIMUM RATING (TA)= 23°C UNLESS OTHERWISE NOTED
3
350 0.32 0.50
**Response time of 10% to 90% is specified at 660nm wavelength light.
Information in this technical datasheet is believed to be correct and reliable. However, no responsibility is assumed for possible inaccuracies or omission. Specifications are subject to change without notice.
