WF14045-400套CRP主副板单

SmartLine STIW400 Wireless Temperature DI Transmitter Specification 34-SW-03-11, April 2022Model STIW400•Up to 4 channels of inputs for T/C’s or mV.•Up to 2 channels of RTD’s or 3-wire resistance.•Up to 4 channels for discrete input or 2-wireresistance.IntroductionSmartLine Wireless Temperature continues theevolution of Honeywell’s wireless transmitter productoffering and provides the latest critical advancementsto support industrial automation users’ desire to expandwireless use for monitoring and control.With over 14 years of industrial wireless experience,the SmartLine Wireless Temperature builds upon andis compatible with the current XYR 6000 productporfotlio. Similar to the XYR 6000 wireless transmitter,the SmartLine Wireless product line is part of theHoneywell OneWireless™ system and is ISA100 -ready.The SmartLine Wireless Temperature transmitterenables customers to obtain data and createinformation from remote and hazardous measurement locations without the need to run wires, where running wire is cost prohibitive and/or the measurement is in a hazardous location. Without wires, transmitters can be installed and operational in minutes, quickly providing information back to your system.The previous generation transmitters primarily were applied to monitoring applications but experienced users know that Honeywell’s wireless products are as reliable, secure, and safe as their wired counterparts. With this knowledge, users are now looking for wireless transmitters for use in specific control applications.Figure 1 — SmartLine Wireless Temperature DITransmitterSmartLine Wireless introduces a step change in performance and most notably, performance suitable for control. SmartLine Wireless performance is improved in these ways:•Fast ½ second publication rate.•Higher radio range coverage.•More powerful 4dBi integral antenna.•Smarter local display with more localdiagnostics and radio signal and qualityindicators.•More input channels and types than earlier.XYR 6000 Wireless Pressure Transmitter Differential Pressure Models 2SmartLine Wireless Temperature retains the following desirable features from the XYR 6000 product offering:•Mesh or non-mesh configuration within each transmitter.•Generic, off-the-shelf lithium ion battery.•Two “D” size batterie s for longer life.•Choice of over-the-air or local provisioning (network security join key).•Over-the-air firmware upgrade capability.•Unique, encrypted provisionng key delivered from the factory.•Remote and integral antenna options.•24 VDC power option.•Publication rates of 1, 5, 10, or 30 seconds, plus new selections of ½ seconds and 1, 15,30, 60 minutes.•Transmitter range (integral antenna) of 1150’ (350 m) under ideal conditions.The STIW400 is a high-performance Temperature transmitter featuring performance over a wide of temperature configurations and applications.The SmartLine family is also fully tested and compliant with Experion® PKS providing the highest level of compatibility assurance and integration capabilities. SmartLine easily meets the most demanding application needs for Temperature measurement applications. SmartLine Wireless FeaturesLocal and over-the-air provisioning capability:All Honeywell wireless devices feature a secure method to join the local wireless network, also known as provisioning. SmartLine Wireless transmitters feature two methods to provision a transmitter onto the network which are eitherby using a handheld device to locally communicate through the IR interface or remotely using the over-the-air function. The over-the-air function is managed by the OneWireless gateway, Wireless Device Manager (WDM). Over-the-air firmware updates:Once joined as a member of your OneWireless network, the WDM can download new transmitter firmware releases to each SmartLine Wireless transmitter over the wireless network. Locating and accessing the transmitter locally is not required thus saving time and keeping your personnel in safe environments.Mesh and non-mesh capability: All SmartLine Wireless transmitters can be configured to operate in either a mesh network or a star (non-mesh) network. The configuration is specific to each wireless transmitter and thus the network can consist of a mixture of meshing and non-meshing devices. Non-meshing is desirable for deterministic communications which is preferred for control. Transmission power setting:To comply with local and regional requirements, SmartLine Wireless transmitters are set at the factory to the maximum transmission power setting allowed for the country of use.Non-proprietary battery:Sourcing lithium thionyl chloride batteries is much simpler since SmartLine Wireless utilizes commercial off-the-shelf batteries. Please see the list of approved battery manufacturers later in this specification. Batteries are housed in an IS-approved battery compartment making battery changes safe and easy. Backward compatibility:SmartLine Wireless transmitters can join existing OneWireless networks and interoperate with existing XYR 6000 wireless transmitters or otherISA100 Wireless compliant transmitters or networks.OneWireless Network FeaturesThe core of the Honeywell wireless solution is the OneWireless Network which consists a gateway, access point(s), and field routers.The Wireless Device Manager (WDM) serves as the gateway function and in this role, manages the communication from the wireless field devices to the process control application. Typically, the WDM connects logically to the process control network (Level 2 or wireless DMZ). As the wireless network manager, the WDM provides easy access to the entire wireless network through a browser-based user interface. The Honeywell WDM can manage devices communicating over theISA100 Wireless protocol and the Wireless HART protocol.The ability to deploy redundant WDMs improves the reliability ensuring no loss of process data which is a requirement for control applications.The Field Device Access Point (FDAP) serves in two roles in the OneWireless network infrastructure, which are: 1) access point, and 2) field router. As an access point, the FDAP directly connects to the WDM via Ethernet LAN cable. More than one access point is permitted and, when more than one is present, it ensures dual path for communications into the WDM from the field devices. As a field router, the FDAP located in the field would communicate to the FDAP acting as an access point. Using the FDAP as a router is more efficient than using field devices as routers since FDAPs are line powered devices whereas field devices are typically battery powered, and the FDAP offers greater range. The meshing capability of FDAPs allows flexibility in the setup of the wireless network to fit the requirements for wireless network performance, in terms of reliable communications, performance, and future growth. The choice of non-meshing network may be desirable for reduced communication latencies with a FDAP serving as a field router.Wireless Specifications*Actual range will vary depending on antennas, cables and site topography.SpecificationsOperating Conditions1 The Ambient Limits shown are for Ordinary Non-Hazardous locations only. Refer to the Hazardous Locations Approvals section for the Ambient Limits when installed in Hazardous Locations.Remote Antenna CablesRemote Antennas8 dBi Omnidirectional Antenna14 dBi Directional AntennaPerformance SpecificationsPerformance under Rated Conditions** Field Calibration available for increased accuracy applications.** Performance specifications are based on reference conditions of 25°C (77°F), 10 to 55% RH. *** Default values; user configurable.Physical Specifications1 Add 8.0 pounds (3.6 Kg) to any model equipped with the stainless steel housing option (Model Selection Guide Table IV selection M or N).STIW400 ISA100.11a Compliant InputsAny combination of sensor type inputs is allowed. The input channels can be configured for the following input types by using the OneWireless User Interface with the corresponding device descriptor file:Selecting any RTD / 3-Wire Ohm Resistance input on Channel 1 and on Channel 3 renders Channel 2's and Channel 4’s input terminals unavailable.The transmitter measures the analog signal from temperature sensors, discrete inputs, millivolt values or ohm values and transmits a digital output signal proportional to the measured value for direct digital communications with systems.The discrete input channels support voltage-free floating contacts. Maximum ON contact resistance is 200 ohms. Minimum OFF contact resistance is 300 ohms. Discrete Input threshold values are user configurable.The Process Variable (PV) is available for monitoring and alarm purposes. The cold junction temperature is also available for monitoring. Available PV update rates are 1, 5, 10, or 30 seconds, plus new selections of ½ sec (Refer User Manual for applicable conditions) and 1, 15, 30, 60 minutes and are set using the Wireless Builder. Slower update rates extend battery life.Input Types and RangesSTIW400 TEMPERATURE TRANSMITTER CONNECTIONST/C or mV or DI or 2 Wire ResistancePV1PV2PV3PV43 Wire RTD or ResistancePV1PV33 Wire RTD or ResistancePV1PV3PV4T/C or mV or DI or 2 Wire ResistanceMounting and DimensionsReference Dimensions:Figure 2 — Examples of typical mounting positionsFigure 3 — Examples of typical mounting positionsFigure 4 – STIW400 Informational and dimensional drawingFigure 5 — Typical mounting dimensions for STIW400Figure 6 — Typical mounting dimensions for STIW400Hazardous Locations ApprovalsRefer to control drawing 50136129, in the user manual #34-SW-25-04, for intrinsically safe installation details.Transmitter Options(indicated selection code is shown)ISA100 Wireless Release Selections (A or B)OneWireless R2xx represents the previous releases whereas R3xx is the current release. A OneWireless system with R3xx firmware can host R2xx and R3xx devices. Please select the option to match the targeted OneWireless system.Remote Antenna and Cables (M or D)The user can select one of the optional remote antennas listed. The selection of the antenna option automatically includes the remote antenna adapter.To complete the option selection, one of the remote antenna cables (1, 2, or 3) must also be selected.Lightning (Surge) Diverter and Cables (1, 2, or 3)The lightning surge diverter options includes the surge diverter and cable. The diverter features Type N connections (female) on both ends. The remote antenna adapter is not included.Remote Antenna Adapter (A)This option provides an adapter to be inserted into the opening where the integral antenna normally connects. The adapter is designed to connect to a remote antenna that the user supplies. It features a female Type N connection.Destination Country (CA, EU, or US)This selection sets the transmission power at the factory to comply with the installation country location.Mounting Brackets (1, 3, 5, or 7)The angle mounting bracket is available in either zinc-plated carbon steel or 316 stainless steel and is suitable for horizontal or vertical mounting on a two-inch (50 millimeter) pipe, as well as wall mounting.An additional flat mounting bracket is also available in carbon steel and 316 stainless steel for two-inch (50 millimeter) pipe mounting.Tagging (Option 1 or 2)The choice of 1 or 2 stainless steel wired-on tags is available. Each tag can accommodate additional data of up to 4 lines of 28 characters. The number of characters includes spaces.Note that the standard nameplate on the meter body contains the serial number and body-related data.Model Selection GuideModel Selection Guides are subject to change and are inserted into the specifications as guidance only.For more informationTo learn more about SmartLine Transmitters, visit Or contact your Honeywell Account ManagerProcess Solutions Honeywell1250 W Sam Houston Pkwy S Houston, USA, TX 77042Honeywell Control Systems LtdHoneywell House, Skimped Hill Lane Bracknell, England, RG12 1EB34-SW-03-11 April 2022©2022 Honeywell International Inc.Shanghai City Centre, 100 Jungi Road Shanghai, China 20061Sales and ServiceFor application assistance, current specifications, ordering, pricing, and name of the nearest Authorized Distributor, contact one of the offices below.ASIA PACIFICHoneywell Process Solutions, Phone: + 800 12026455 or +44 (0) 1202645583 (TAC) hfs-tac-*********************AustraliaHoneywell LimitedPhone: +(61) 7-3846 1255 FAX: +(61) 7-3840 6481 Toll Free 1300-36-39-36 Toll Free Fax: 1300-36-04-70China – PRC - Shanghai Honeywell China Inc.Phone: (86-21) 5257-4568 Fax: (86-21) 6237-2826SingaporeHoneywell Pte Ltd.Phone: +(65) 6580 3278 Fax: +(65) 6445-3033South KoreaHoneywell Korea Co Ltd Phone: +(822) 799 6114 Fax: +(822) 792 9015EMEAHoneywell Process Solutions, Phone: + 800 12026455 or +44 (0) 1202645583Email: (Sales)*************************** or (TAC)*****************************AMERICASHoneywell Process Solutions, Phone: (TAC) (800) 423-9883 or (215) 641-3610(Sales) 1-800-343-0228Email: (Sales)*************************** or (TAC)*****************************。

如何进入SP 模式可以使用下面两种模式：启动SP 模式1. 输入下列键：[Clear Modes] > [1] > [0] > [7]2. 按住[Clear/Stop] 键不放，直到显示SP 模式菜单（约3s 钟）。

启动SSP 模式对于基本型机器（不带可选控制箱的机器），请按下列1 至4 步执行。

对于GDI 机器（带有可选控制箱的机器），请按下列1 至5 步执行。

1. 输入下列键：[Clear Modes] > [1] > [0] > [7]2. 按住键不放，直到显示SP 模式菜单（约3s 钟）。

3. 按住[Enter] 键不放。

4. 在按住[Enter] 键时，请按[1] 键（在数字小键盘上）。

5. 在按住[Enter] 键时，请按"OK"键。

选择程序? 当出现一条闪烁的下划线（或几条闪烁的下划线）时，您可从数字小键盘[D] 输入一个数字。

? 当" /OK" [A] 标记显示在右上角时，您可通过按左箭头[B] 或右键头[C] 来滚动菜单。

若要选中一个程序，请按“OK”键[F]。

指定值1. 在定位一个程序后，请按“OK”键。

闪烁的下划线（或几条闪烁的下划线）指示您可更改的值。

括弧中的值是菜单的默认值。

2. 从数字小键盘输入所需的值。

若要在正值（＋）和负值（－）之间切换，请按[./*]（句号/星号）键。

3. 若要使该值生效，请按“OK”键。

若要取消该值，请按取消键[E]。

激活复印模式您可在SP 模式正在运行时激活复印模式。

在您这样做时，复印机输出图像或图形，帮助您调整SP 模式程序。

1. 按“ ”键。

复印模式被激活。

2. 指定复印设置，按“OK”键。

3. 若要返回SP 模式，请按“ ”键。

? 您不能在复印模式激活时结束SP 模式。

退出程序/结束（S）SP 模式请按键或“Cancel”键退出该程序。

您可数次按这些键中的一个来结束SP 模式。

Operating Instructions and Parts Manual12 x 48 in. Box and Pan BrakeModel BPF-1248JET427 New Sanford RoadLaVergne, Tennessee 37086 Part No. M-754110 Ph.: 800-274-6848 Edition 1 10/2015 Copyright © 2015 JET1.0 IMPORTANT SAFETYINSTRUCTIONSREAD ALL INSTRUCTIONS BEFORE USING THIS BOX AND PAN BRAKE.WARNING – To reduce the risk of injury:1. Read and understand the entire owner'smanual before attempting assembly or operation.2. Read and understand the warnings posted onthe machine and in this manual. Failure tocomply with all of these warnings may causeserious injury.3. Replace the warning labels if they becomeobscured or removed.4. This box and pan brake is designed andintended for use by properly trained and experienced personnel only. If you are notfamiliar with the proper and safe operation of abrake, do not use until proper training andknowledge have been obtained.5. Do not use this brake for other than its intendeduse. If used for other purposes, JET disclaimsany real or implied warranty and holds itselfharmless from any injury that may result fromthat use.6. Always wear ANSI Z87.1 approved safetyglasses or face shield while using this drumsander. (Everyday eyeglasses only have impactresistant lenses; they are not safety glasses.) 7. Before operating this machine, remove tie,rings, watches and other jewelry, and rollsleeves up past the elbows. Do not wear looseclothing. Confine long hair. Non-slip footwear oranti-skid floor strips are recommended.8. Wear ear protectors (plugs or muffs) if noisereaches unsafe levels.9. Some dust created by power sanding, sawing,grinding, drilling and other construction activities contain chemicals known to causecancer, birth defects or other reproductive harm. Some examples of these chemicals are:•Lead from lead based paint.•Crystalline silica from bricks, cement and other masonry products.•Arsenic and chromium from chemically treated lumber.Your risk of exposure varies, depending on howoften you do this type of work. To reduce yourexposure to these chemicals, work in a well-ventilated area and work with approved safetyequipment, such as face or dust masks that arespecifically designed to filter out microscopicparticles.10. Do not operate this machine while tired or underthe influence of drugs, alcohol or any medication.11. Remove adjusting keys and wrenches. Form ahabit of checking to see that keys and adjustingwrenches are removed from the machine before turning it on.12. Keep safety guards in place at all times whenthe machine is in use. If removed for maintenance purposes, use extreme caution and replace the guards immediately after completion of maintenance.13. Check damaged parts. Before further use of themachine, a guard or other part that is damagedshould be carefully checked to determine that itwill operate properly and perform its intendedfunction. Check for alignment of moving parts,binding of moving parts, breakage of parts, mounting and any other conditions that mayaffect its operation. A guard or other part that isdamaged should be properly repaired or replaced.14. Provide for adequate space surrounding workarea and non-glare, overhead lighting.15. Keep the floor around the machine clean andfree of scrap material, oil and grease.16. Keep visitors a safe distance from the workarea. Keep children away.17. Make your workshop child proof with padlocks,master switches or by removing starter keys. 18. Give your work undivided attention. Lookingaround, carrying on a conversation and “horse-play” are careless acts that can result in seriousinjury.19. Maintain a balanced stance at all times so thatyou do not fall into the blade or other movingparts. Do not overreach or use excessive forceto perform any machine operation.20. Use recommended accessories; improperaccessories may be hazardous.21. Maintain tools with care. Keep blades sharp andclean for the best and safest performance.Follow instructions for lubricating and changingaccessories.22. Do not stand on the machine. Serious injurycould occur if the machine tips over.23. Remove loose items and unnecessary workpieces from the area before operating the machine. 24. Don’t use in dangerous environment. Don’t usemachine in damp or wet location, or expose to rain. Keep work area well lighted. 25. Sheet metal stock has sharp edges; use cautionwhen handling to prevent cuts.26. Keep hands clear of bending area whileoperating. 27. Do not exceed rated capacity of brake.28. The brake should be secured to floor withappropriate fasteners.Familiarize yourself with the following safety notices used in this manual:This means that if precautions are not heeded, it may result in minor injury and/or possiblemachine damage.This means that if precautions are not heeded, it may result in serious, or possibly even fatal,injury.SAVE THESE INSTRUCTIONS2.0 About this manualThis manual is provided by JET, covering the safe operation and maintenance procedures for a JET Model BPF-1248 Box and Pan Brake. This manual contains instructions on installation, safety precautions, general operating procedures, maintenance instructions and parts breakdown. Your machine has been designed and constructed to provide consistent, long-term operation if used in accordance with the instructions as set forth in this document. If there are questions or comments, please contact your local supplier or JET. JET can also be reached at our web site: .Retain this manual for future reference. If the machine transfers ownership, the manual should accompany it.Read and understand the entire contents of this manual before attempting assembly oroperation! Failure to comply may cause serious injury!3.0 Table of contentsSection Page1.0 IMPORTANT SAFETY INSTRUCTIONS (2)2.0 About this manual (3)3.0 Table of contents (4)4.0 Specifications (4)5.0 Setup and assembly (5)5.1 Shipping contents (5)5.2 Tools required for assembly (5)5.3 Unpacking and cleanup (5)5.4 Assembly (5)6.0 Adjustments (6)6.1 Counterweight position (6)6.2 Apron adjustment (6)6.3 Adjusting for metal thickness (6)6.4 Adjusting clamping pressure (6)6.5 Repeat bends (6)7.0 User-maintenance (7)7.1 Lubrication (7)8.0 Replacement Parts (7)8.1.1 BPF-1248 Floor Box and Pan Brake – Exploded View (8)8.1.2 BPF-1248 Floor Box and Pan Brake – Parts List (9)9.0 Warranty and service (11)4.0 SpecificationsModel number ......................................................................................................................................... BPF-1248 Stock number . (754110)Capacity (mild steel) ................................................................................................................... 12 gauge (2.5mm) Bending length capacity ................................................................................................................ 48 in. (1220mm) Maximum box depth .......................................................................................................................... 4 in. (100mm) Maximum lift of beam .................................................................................................................... 1-1/2 in. (38mm) Beam adjustment, front to rear ......................................................................................................... 7/8 in. (22mm) Recommended minimum flange in capacity material ....................................................................... 1 in. (25.4mm) Number of fingers and width .......................................................................................... 5@3 in., 2@4 in., 5@5 in. Finger nose angle . (45)Finger nose radius ...................................................................................................................... 1/32 in. (0.79mm) Overall dimensions, assembled (LxWxH) ............................................. 81.5 x 29 x 69 in. (2070 x 740 x 1745mm) Overall dimensions, shipping (LxWxH) ...................................................... 69 x 30 x 35 in. (1750 x 770 x 900mm) Weight, net ................................................................................................................................. 1100 lbs. (498 kg) Weight, shipping ......................................................................................................................... 1250 lbs. (560 kg)The specifications in this manual were current at time of publication, but because of our policy of continuous improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring obligations.5.0 Setup and assemblyRead and understand all assembly instructions before attempting assembly. Failure to comply may cause serious injury.5.1 Shipping contentsRefer to Figures 1 and 2.1 Box and pan brake (not shown)2 Support legs – A1 Curved handle – B2 Straight handles – C1 Stop rod – D2 Counterweight assemblies – E1 Stop rod pin – F1 Stop collar – G1 Hex key, 6mm – H4 Hex cap bolts, M12x40 – HP18 Hex cap bolts, M10x40 – HP21 Flat washer, M16 – HP38 Flat washers, M12 – HP48 Flat washers, M10 – HP58 Lock washers, M12 – HP68 Lock washers, M10 – HP74 Hex nuts, M12 – HP81 Hex nut, M16 – HP91 Cotter pin – HP10Figure 1Figure 2 5.2 Tools required for assembly6mm hex key (provided)pliers5.3 Unpacking and cleanup1. Remove all contents from shipping crate andcompare to the contents list in this manual. Ifshipping damage or any part shortages areidentified, contact your distributor. Do not discard packing material until brake is assembled and operating satisfactorily.2. Carefully clean all rust protected surfaces witha mild solvent or kerosene and a soft rag. Donot use lacquer thinner, paint thinner, or gasoline – these will damage painted surfaces.3. Coat all machined surfaces with a light coat ofoil to inhibit rust.5.4 AssemblyRefer to exploded view if additional clarification is needed for assembly.1. Remove bolts holding support legs and brake topallet.2. Locate brake in a dry, well-lighted area with asturdy, level floor. Machine location must allowroom for loading and offloading stock, and access on all sides for maintenance.3. Use hoist or forklift to carefully lift brake ontosupport legs. Secure with M12 bolts, washersand nuts (HP1/HP4/HP6/HP8).Do not allow anyone beneath brake while moving it into positionand until it is secured on support legs.4. Verify that brake is level; use shims ifnecessary. Secure support legs to floor withappropriate fasteners, such as lag bolts (notprovided).5. Install counterweight assemblies to left andright hinges with M12 bolts, lock washers andflat washers (HP1/HP4/HP6). See Figure 3.Figure 36. Install handles to front of apron (Figure 4).Figure 47. Install stop rod assembly on left side of brake,through weldment on apron, as shown in Figure5. Secure stop rod pin (F) with flat washer andhex nut (HP3,HP9). Install cotter pin (HP10) atend of stop rod, and bend with pliers to secure.Figure 56.0 Adjustments6.1 Counterweight positionProper counterweight position determines amount of leverage for the bend, and most efficient movement of apron for the operator.Adjust counterweight by backing out screw (J, Figure 6) and rotating upper and lower collars (K) as needed. When counterweight is at desired position, turn screw (J) until it re-engages counterweight.Figure 6 6.2 Apron adjustmentThe apron assembly has been adjusted by the manufacturer for use with material having the capacity listed in the Specifications section. If any misalignment occurs, correct as follows.The forward edge of hold-down fingers should be adjusted parallel to pivot edge of press bar. Release clamping pressure on hold-down assembly by pushing clamp handles (L) slightly to the rear. Turn knobs (M) to adjust fingers for parallel.Figure 7The truss nuts (N, Figure 7) can be used to help achieve alignment in apron and hold-down assemblies, by eliminating any bowing at the center of these assembles.Finger alignment can be achieved by loosening cap screws on the fingers, and raising apron to 90-degree position. Push fingers forward against apron bar for proper alignment. Retighten all screws.6.3 Adjusting for metal thicknessThe holddown assembly must be adjusted to allow for clearance when making bends according to thickness of material. Clearance for material within four gauges of the capacity should be twice the thickness of the material. For lighter gauges use 1-1/2 times the thickness.When adjusting for thickness, turn both knobs (M, Figure 7) the same amount to maintain parallelism of fingers with apron.6.4 Adjusting clamping pressure Clamping pressure should be adjusted according to material thickness. Clamping pressure should be great enough to hold material securely in place but not so much that it is difficult to lock clamping handles. Clamping pressure can be adjusted by turning nuts on threaded rod portion of yoke assembly (P, Figure 8).6.5 Repeat bendsAdjust stop collar on stop rod (Figure 5) to limitapron swing.7.1 LubricationThe machine must be lubricated every day ofservice with a few drops of oil at the pivot points. Oilpinholes are located at both yoke assemblies (A,Figure 8) and the apron assembly near the hinge pin(B).Lightly oil all machined (unpainted) parts when notin use, to inhibit rust.Figure 88.0 Replacement PartsReplacement parts are listed on the following pages. To order parts or reach our service department, call 1-800-274-6848 Monday through Friday, 8:00 a.m. to 5:00 p.m. CST. Having the Model Number and Serial Number ofyour machine available when you call will allow us to serve you quickly and accurately.8.1.1 BPF-1248 Floor Box and Pan Brake – Exploded View8.1.2 BPF-1248 Floor Box and Pan Brake – Parts ListIndex No Part No Description Size Qty1 ................ F005384 .................... Socket Head Cap Screw.......................................... M6-1.0x25 (2)2 ................ BPF1248-02 .............. Sleeve ...................................................................... .. (2)3 ................ BPF1248-03 .............. Clamp ...................................................................... .. (2)4 ................ BPF1248-04 .............. Clamp Handle (LH) .................................................. .. (1)5 ................ BPF1248-05 .............. Zerk Fitting ............................................................... .. (4).................. BPF1248-06A............ Yoke Assembly (includes #5,6,28) .......................... .. (2)6 ................ .................................. Yoke (RE: BPF1248-06A)........................................ .. (2)7 ................ BPF1248-07 .............. Hold-Down Assembly .............................................. .. (1)8 ................ BPF16100-68 ............ Scale (LH) ................................................................ .. (1)9 ................ BPF1248-09 .............. Clamp Handle (RH) ................................................. .. (1)10 .............. F005431 .................... Socket Head Cap Screw.......................................... M10-1.5x40 . (5)11 .............. BPF1248-11 .............. Long Press A ........................................................... .. (1)12 .............. BPF1248-12 .............. Joint Open ............................................................... 3 in. (5)13 .............. BPF1248-13 .............. Joint Open ............................................................... 4 in. (2)14 .............. BPF1248-14 .............. Joint Open ............................................................... 5 in. (5)15 .............. F005433 .................... Socket Head Cap Screw.......................................... M10-1.5x50 .. (36)16 .............. F005435 .................... Socket Head Cap Screw.......................................... M10-1.5x60 .. (24)17 .............. F002116 .................... Lock Washer ............................................................ 10mm .. (38)18 .............. BPF1248-18 .............. Holder, Finger .......................................................... 3 in. (5)19 .............. BPF1248-19 .............. Holder, Finger .......................................................... 4 in. (2)20 .............. BPF1248-20 .............. Holder, Finger .......................................................... 5 in. (5)21 .............. BPF1248-21 .............. Washer, Finger ........................................................ 3 in. (5)22 .............. BPF1248-22 .............. Washer, Finger ........................................................ 4 in. (2)23 .............. BPF1248-23 .............. Washer, Finger ........................................................ 5 in. (5)24 .............. F002643 .................... Flat Washer ............................................................. ø10xØ20x2mm .. (38)25 .............. BPF1248-25 .............. Finger....................................................................... 3 in. (5)26 .............. BPF1248-26 .............. Finger....................................................................... 4 in. (2)27 .............. BPF1248-27 .............. Finger....................................................................... 5 in. (5)28 .............. BPF1248-28 .............. Stop Pin ................................................................... .. (2)29 .............. F003091 .................... Hex Nut .................................................................... M20-2.5 . (4)30 .............. F003084 .................... Hex Nut .................................................................... M12-1.75 .. (5)31 .............. BPF1248-31 .............. Swivel Pin Assembly................................................ .. (2)32 .............. BPF1248-32 .............. Adjusting Nut ........................................................... .. (2)33 .............. BPF1248-33 .............. Stop Nut .................................................................. .. (2)34 .............. BPF1248-34 .............. Long Press B ........................................................... .. (1)35 .............. BPF1248-35 .............. Knob Lock ................................................................ .. (2)36 .............. BPF1248-36 .............. Base Assembly ........................................................ .. (1)37 .............. BPF1248-37 .............. Stop Rod .................................................................. .. (1)38 .............. BPF1248-38 .............. Stop Rod Pin............................................................ .. (1)39 .............. BPF1248-39 .............. Stop Collar ............................................................... .. (1)40 .............. BPF1248-40 .............. Bracket Bar .............................................................. .. (1)41 .............. F005430 .................... Socket Head Cap Screw.......................................... M10-1.5x35 . (5)42 .............. BPF1248-42 .............. Key .......................................................................... 8x70 mm .. (2)43 .............. F009542 .................... Hex Cap Bolt............................................................ M12-1.75x40 (10)44 .............. F003875 .................... Cotter Pin ................................................................. 3x40 mm .. (1)45 .............. BPF1248-45 .............. Round Pin ................................................................ 4x40 mm .. (2)46 .............. BPF1248-46 .............. Round Pin ................................................................ 6x30 mm .. (2)47 .............. BPF1248-47 .............. Lead Screw .............................................................. .. (2)48 .............. F003127 .................... Hex Nut .................................................................... M16-2.0 . (3)49 .............. F002650 .................... Flat Washer ............................................................ ø16xØ30x3 mm (3)50 .............. BPF1248-50 .............. Special Bolt ............................................................. M8x25 (1)51 .............. BPF1248-51 .............. Hinge (RH) ............................................................... .. (1)52 .............. BPF1248-52 .............. Hinge Pin ................................................................. .. (2)53 .............. BPF1248-53 .............. Hinge (LH) ............................................................... .. (1)54 .............. BPF1248-54 .............. Special Washer........................................................ .. (6)55 .............. F005405 .................... Socket Head Cap Screw.......................................... M8-1.25x30 . (2)56 .............. BPF1248-56 .............. Copper Sleeve ......................................................... .. (2)57 .............. BPF1248-57 .............. Apron ....................................................................... .. (1)58 .............. BPF1248-58 .............. Insert Bar ................................................................. .. (1)Index No Part No Description Size Qty59 .............. F005428 .................... Socket Head Cap Screw.......................................... M10-1.5x25 . (5)60 .............. BPF1248-60 .............. Round Pin ................................................................ 8x20 mm .. (4)61 .............. BPF1248-61 .............. Straight Handle ........................................................ .. (2)62 .............. BPF1248-62 .............. Grip .......................................................................... .. (2)63 .............. BPF1248-63 .............. Handle .................................................................... .. (1)64 .............. F009503 .................... Hex Cap Bolt............................................................ M10-1.5x40 . (8)65 .............. F002118 .................... Lock Washer ............................................................ 12 mm (8)66 .............. F002646 .................... Flat Washer ............................................................. ø12xØ24x2.5 mm (8)67 .............. BPF1248-67 .............. Rod .......................................................................... .. (2)68 .............. BPF1248-68 .............. Counterweight Assembly ......................................... .. (2)69 .............. BPF1248-69 .............. Special Nut B .......................................................... .. (2)70 .............. BPF1248-70 .............. Support Leg ............................................................. .. (2)71 .............. BPF1248-71 .............. Hex Nut .................................................................... .. (2)72 .............. BPF1248-72 .............. Special Nut A ........................................................... .. (2)73 .............. F005383 .................... Socket Head Cap Screw.......................................... M6-1.0x20 (2)74 .............. F010405 .................... Socket Set Screw .................................................... M6-1.0x20 (4)75 .............. BPF1248-75 .............. Scale Pointer ........................................................... .. (1).................. F012226 .................... Hex Key (not shown) ............................................... 6mm (1).................. LM000079 ................. ID Label, BPF-1248 (not shown) ............................. .. (1).................. LM000133 ................. Warning Label (not shown) ...................................... .. (1).................. JET-165..................... JET Logo with adhesive (not shown) ....................... 165x68 mm . (1)Some parts are shown for reference only, and may not be available individually.Non-proprietary parts, such as fasteners, can usually be found at local hardware stores, or may be ordered from JET.9.0 Warranty and serviceJET warrants every product it sells against manufacturers’ defects. If one of our tools needs service or repair, please contact Technical Service by calling 1-800-274-6846, 8AM to 5PM CST, Monday through Friday.Warranty PeriodThe general warranty lasts for the time period specified in the literature included with your product or on the official JET branded website.•JET products carry a limited warranty which varies in duration based upon the product. (See chart below) •Accessories carry a limited warranty of one year from the date of receipt.•Consumable items are defined as expendable parts or accessories expected to become inoperable within a reasonable amount of use and are covered by a 90 day limited warranty against manufacturer’s defects. Who is CoveredThis warranty covers only the initial purchaser of the product from the date of delivery.What is CoveredThis warranty covers any defects in workmanship or materials subject to the limitations stated below. This warranty does not cover failures due directly or indirectly to misuse, abuse, negligence or accidents, normal wear-and-tear, improper repair, alterations or lack of maintenance. JET woodworking machinery is designed to be used with Wood. Use of these machines in the processing of metal, plastics, or other materials outside recommended guidelines may void the warranty. The exceptions are acrylics and other natural items that are made specifically for wood turning. Warranty LimitationsWoodworking products with a Five Year Warranty that are used for commercial or industrial purposes default to a Two Year Warranty. Please contact Technical Service at 1-800-274-6846 for further clarification.How to Get Technical SupportPlease contact Technical Service by calling 1-800-274-6846. Please note that you will be asked to provide proof of initial purchase when calling. If a product requires further inspection, the Technical Service representative will explain and assist with any additional action needed.JET has Authorized Service Centers located throughout the United States. For the name of an Authorized Service Center in your area call 1-800-274-6846 or use the Service Center Locator on the JET website.More InformationJET is constantly adding new products. For complete, up-to-date product information, check with your local distributor or visit the JET website.How State Law AppliesThis warranty gives you specific legal rights, subject to applicable state law.Limitations on This WarrantyJET LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR EACH PRODUCT. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.JET SHALL IN NO EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY, OR FOR INCIDENTAL, CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.JET sells through distributors only. The specifications listed in JET printed materials and on official JET website are given as general information and are not binding. JET reserves the right to effect at any time, without prior notice, those alterations to parts, fittings, and accessory equipment which they may deem necessary for any reason whatsoever. JET® branded products are not sold in Canada by JPW Industries, Inc.Product Listing with Warranty Period90 Days – Parts; Consumable items1 Year – Motors; Machine Accessories2 Year – Metalworking Machinery; Electric Hoists, Electric Hoist Accessories; Woodworking Machinery usedfor industrial or commercial purposes5 Year – Woodworking MachineryLimited Lifetime – JET Parallel clamps; VOLT Series Electric Hoists; Manual Hoists; Manual HoistAccessories; Shop Tools; Warehouse & Dock products; Hand Tools; Air ToolsNOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries, Inc., or any of its successors in interest to the JET brand.。
