THANK YOUfor purchasing a JBL ®GTO17T automotive tweeter. We’ve organized this manual to make your installation as simple and trouble-free as possible. Please read it thoroughly before proceeding. Remember to keep your sales receipt and this manual in a safe place so both are available for future reference.GRAND TOURING ®SERIESGTO17Ttweeter owner’s manualINSTALLATION WARNINGS AND TIPSABOUT THESE INSTRUCTIONSInstallation of automotive stereo components can require extensive experience with a variety of mechanical and electrical procedures. Although these instructions explain how to install JBL GTO17T tweeters in a general sense, they do not show the exact installation methods for your particular vehicle. If you feel you do not have the experience, do not attempt the installation yourself – instead, ask your authorized JBL car audio dealer about professional installation options.LOUD MUSIC AND HEARINGPlaying loud music in an automobile canpermanently damage your hearing, as wellas hinder your ability to hear traffic. Themaximum volume levels achievable withJBL speakers, combined with high poweramplification, may exceed safe levels forextended listening. We recommend usinglow volume levels when driving. JBLaccepts no liability for hearing loss, bodilyinjury or property damage as a result of useor misuse of this product.ABOUT THE FILTERPassive filter design involves precisecircuit design and component selection.Moreover, a well-designed filter circuitprovides an intended electrical response,when combined with the electrical proper-ties of the speaker, to provide a particularacoustic response. Each enclosed filter hasbeen optimized to provide a flat responsewhen used with a JBL GTO17T tweeter.Do not use another brand or type ofpassive crossover, or connect more thanone tweeter to a crossover. Doing so maydamage the tweeter.INSTALLATION TIPS•Always wear protective eyewear whenusing any tools.•Turn off all audio components and otherelectrical devices before you start.Disconnect the negative (–) lead fromyour vehicle’s battery.•Keep speakers in their package untilfinal installation. When moving a speaker,always rest it with the cone or domefacing up. Never use force to installany speaker.•Check clearances on both sides of aplanned mounting surface before drillingany holes or installing any screws.Remember that the screws can extendbehind the surface.•At the installation sites, locate and make anote of all fuel lines, hydraulic brake lines,vacuum lines and electrical wiring. Useextreme caution when cutting or drillingin and around these areas.•Before drilling or cutting holes, use autility knife to remove unwanted fabricor vinyl to keep material from snaggingin a drill bit or saw.•For door installations, check theclearance with the windows throughoutthe range of the window’s travel, andverify that a mounted speaker will notinterfere with the window crank orpower-window mechanism.•If mounting speakers elsewhere, checkfor clearance around rear-deck torsionbars, glove box or other structuralelements.•Do not mount speakers where they willget wet.ABOUT PLACEMENTFigures 1 through 3 show possible speakerplacements, with Figure 1 being moredesirable. We recommend using the kickpanel for mounting to obtain the beststaging and imaging in most vehicles.Figure 3.Mounting the woofer in the doorSPEAKER PLACEMENTSURFACE-MOUNTFLUSH-MOUNTFigure 5.Mounting the tweeter using the I-Mount ™(patent no. 5,859,917) flush-mounting kit.Figure 6.Aim the tweeter at the listening position by sliding the screw in the groove on the back of the tweeter cup and lock the tweeter in place using the small retaining screw. Rotate the entire assembly in the mounting surface and tighten the large hand nut.Figures 7A through 7D.The Starfish ™tweeter mount is intended to be used when the tweeter will be installed behind a factory grille (e.g., replacing the factory tweeter behind a door panel). The Starfish will allow you to mount the component tweeter directly to the panel itself or to the area behind the panel. The six mounting tabs can be removed easily to create a number of custom configurations.Note: Check screw clearance before installing. Use glue if clearance is an issue.Note: Not all possible mounting configurations are shown.Figure 7A.Surface-mounted behind grille panel.Figure 7B.Flush-mounted to surface behind grille panel.Figure 7C.Mounted to grille panel.Figure 7D.In-dash location (may require TWEETER INSTALLATIONSECURELY TIGHTEN THE LARGE HAND NUT.3ROTATE ENTIRE ASSEMBLYJBL Consumer Products250 Crossways Park Drive, Woodbury, NY 11797 USA 516.255.4JBL (4525) (USA only) ©2005 Harman International Industries, Incorporated. All rights reserved.JBL, Harman International and Grand Touring Series are trademarks of Harman International Industries, Incorporated, registered in the United States and/or other countries. I-Mount and Starfish are trademarks of Harman International Industries, Incorporated. Part No. GTO17TOM12/05SPECIFICATIONSGTO17T 1" TweeterPower Handling, RMS 50W*Power Handling, Peak 150W*Sensitivity (2.83V/1m)92dB Frequency Response 2.5kHz – 21kHz Impedance 2 Ohms Mounting Depth 3/4" (19mm)Cutout Diameter 1-7/8" (48mm)*With enclosed filterGENERAL CAREThe loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.A valid serial number is required for warranty coverage.Features, specifications and appearance are subject to change without notice.This product is designed for mobile applications and is not intended for connections to the mains.。
智能中控台说明T98智能中控台说明书目录注意事项 (3)一、产品概览 (4)(一) 基本功能 (4)(二) 硬件接口、按键 (5)(三) 快速指南 (7)二、行车录影（DVR）及ADAS（行车辅助预警系统） (10)三、导航 (17)四、蓝牙电话 (18)五、调频（FM）发射 (19)六、多媒体娱乐 (20)七、语音指令 (21)八、设置 (25)九、蓝牙键盘操作 (21)十、手机客户端：车车助手 (22)十一、安装说明 (22)十二、产品常见问题指南 (24)注意事项1. GPS要在户外才能正常接收到卫星信号并用于导航，在开阔地带，系统正常运行时，通常约半分钟左右可以搜星并定位。
一般接收到4颗卫星的信号，就能完成GPS 定位。
2. 当本产品位于建筑物内、隧道或周围有高大阻挡物时，天气不佳或有密集的障碍物（树林或建筑物林立之处），都有可能会影响GPS卫星信号及移动数据信号接收，此时系统将暂时无法给您提供定位导航及通信服务。
3. 由于交通建设的高速发展，可能出现导航电子地图数据与实际交通指示不完全一致的情况，请您务必遵照道路现状、现场标志等交通规则行驶。
我们不建议您在汽车驾驶过程中操作导航仪，建议使用语音声控。
禁止使用本产品出厂标配以外的电源线，禁止用力弯曲或用重物挤压电源线，以免引起短路等意外造成机器故障甚至火灾。
4. 因软件或者配置升级，导致某些界面和功能与说明书有差异，恕不另行通知。
5. 本手册已经过仔细核对，但不排除有少量文字错误的可能性，如发现，请联系本公司。
6. 本手册中的图片仅供参考，请以实物为准。
一、产品概览本产品采用八核处理器的高性能主控方案，2G DDR+16G EMMC ，外置GPS、WiFi和蓝牙，语音声控，ADAS预警系统，云电子狗，高德地图，前后双摄像头，Android5.1操作系统①。
(一)基本功能简介*ADAS预警系统：车道偏移预警，车辆碰撞提醒，前车起步提醒1.行车录影/倒车影像：前1080P高清摄像头，后720P摄像头；前后双录像双显示；支持碰撞锁影；自动循环清理TF卡空间，轻松实现自动循环录影；支持倒车后视。
