PHOENIX CONTACT GmbH & Co. KGPage 1 / 3http://www.phoenixcontact.de

Jul 16, 2008Extract from the onlinecatalog IPC 5/ 8-STGCL-7,62Order No.: 1718326The figure shows a 5-pos. version of the producthttp://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1718326 Plug, inverted, no. of positions: 8, pitch: 7.62 mm, U = 1000 V, I = 41 A Commercial dataEAN4046356175333Pack50 Pcs.Customs tariff85366990Weight/Piece0.035354 KGCatalog page informationPage 337 (CC-2007)http://www.download.phoenixcontact.comPlease note that the data givenhere has been taken from theonline catalog. For comprehensiveinformation and data, please referto the user documentation. TheGeneral Terms and Conditions ofUse apply to Internet downloads.Certificates / ApprovalsCertificationCUL, ULCULNominal voltage UN600 VNominal current IN41 AAWG/kcmil24-8ULNominal voltage UN600 V元器件交易网www.cecb2b.comIPC 5/ 8-STGCL-7,62Order No.: 1718326http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1718326

PHOENIX CONTACT GmbH & Co. KGPage 2 / 3http://www.phoenixcontact.deJul 16, 2008Nominal current IN41 AAWG/kcmil24-8DrawingsDiagramDerating curve for: IPC 5/...-ST-7.62 with PC5/...-ST-7.62Conductor cross section = 10 mm2Derating curve for: IPC 5/...-ST-7.62 with IPC5/...-G-7.62Conductor cross section = 10 mm2Derating curve for: IPC 5/...-ST-7,62 with IPC 5/....-G-7,62Conductor cross section 6 mm2Dimensioned drawing元器件交易网www.cecb2b.comIPC 5/ 8-STGCL-7,62Order No.: 1718326http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1718326

PHOENIX CONTACT GmbH & Co. KGPage 3 / 3http://www.phoenixcontact.deJul 16, 2008AddressPHOENIX CONTACT GmbH & Co. KGFlachsmarktstr. 832825 Blomberg,GermanyPhone +49 5235 3 00Fax +49 5235 3 41200http://www.phoenixcontact.de© 2008 Phoenix ContactTechnical modifications reserved;元器件交易网www.cecb2b.com
