Pvsyst后台参数的翻译
Grid-connected systempre-sizing 并网系统初步设置
Monocrystalline module efficiency单晶组件效率
Polycrystalline efficiency多晶组件效率
Thin film efficiency 薄膜组件效率
Free standing temperature correction自由安装温度纠正系数
Roof ventilated temperature correction屋顶通风温度纠正系数
No ventilation temperature correction无通风温度纠正系数
Ohmic wiring loss mismatch loss correction线缆欧姆损失，失配损失纠正系数 IAM incidene angle
modifier correction入射角改变纠正系数
Inverter average efficiency逆变器平均效率
Stand-alone systempre-sizing 独立系统初步设计
Stand-alone:pv-array=>battery globa efficiency 阵列到电池整体效率
Batterycharge/discharge energy efficiency 电池充放电能量效率
Soc minimum threshold 荷电率最小阈值
Battery capacity:C100/C10 ratio100 小时率比10小时率系数
Generatorefficiency(15%=1.5kwh/liter)发电机效率
Pumping:pv-array daily effic(optical,thermal ,etc) 光伏水泵方阵综合效率(光，热等) Matching effic（thresh.andmppt loss）direct coupling
直接耦合匹配效率（阈值及最大跟踪损失） Matching effic（thresh.andmppt loss）with booster
升压耦合匹配效率（阈值及最大跟踪损失）
Matching effic（thresh.andmppt loss）cascading级联匹配效率（阈值及最大跟踪损失） Global effic.with
fixed V DC converter 固定电压直流变换器耦合的综合效率 Global effic.withmppt converter mppt 逆变器耦合综合效率
DC-positive displacement pump efficiency 直流容积泵效率
AC-positive displacement pump efficiency 交流容积泵效率
Centrifugal pump efficiency 离心泵效率
Oversizing{(pv field stc-losses)/pump power} 裕度（光伏阵列/泵功率）
Specific pre-sizing costs(all systems) 所有系统初步设计价格
Loan duration(=sexpected system lifetime) 系统寿命25 year
Scale exponential factor(mouning and maintenance)规模指数因子 0.6
Systemdesign parameters 系统设计参数
Minimum temperature for inverter Vmax design（需相应改动）
逆变器最大电压设计使用的最低温度
Winter operating temp.for inverter VmppMax design（需相应改动）
逆变器跟踪最大电压值设计冬季运行温度
Usual operating temperature at r1000W/m（需相应改动）平常运行温度
Summer operating temp.for inverter VmppMin design（需相应改动）
逆变器跟踪最小电压值设计夏季运行温度
Voltage initial degradation amorphous 非晶硅初期压降
Voltage initial degradation,microcrystalline 微晶硅初期压降
Voltage initial degradation.CdTe 碲化镉太阳能组件初期压降
Heat loss factor free mounting 自由安装式热损失因子
Heat loss factor semi integrated 半集成式热损失因子
Heat loss factor fully integrated 集成式热损失因子
Heat loss factor according to wind velocity 根据风速定义的热损失因子
Heat loss factor max./min. value 热损失最大/最小值
Incidence angle modifier bo parameter 入射角改变纠正系数
Copper Resistivity(at T=50 度)铜电阻率
Aluminium Resistivity(at T=50 度)铝电阻率
Max. wire section for specific admissible current对特定电流最大可接受线缆截面积 Max. admissible
current derating factor最大可允许电流衰减
Default wiring resistance loss ratio at STC标况下默认线阻损失率
Array resitance voltage drop at STC标况下阵列阻耗压降
Irrad.absorption coefficient for tarray calculation阵列计算用辐射吸收系数 Module dfficiency for
temp.array calculation阵列计算用组件效率
Series diode voltage drop二极管压降
External transfo:iron losses外置变压器铁损 External transfo:resist losses at STC外置变压器铜损
Light soaking gain factor光辐照增益系数
Default module quality factor默认组件质量因数
Module quality loss:tolerance fraction组件质量因数公差
LIDloss factorLID损失因子
Default array mismatch power loss,crystalline默认阵列功率失配损失，晶硅组件
Default array mismatch power loss, amorphous默认阵列功率失配损失，非晶硅
Default array mismatch voltage loss ,crystalline默认阵列电压失配损失，晶硅组件
Default array mismatch voltage loss , amorphous默认阵列电压失配损失，非晶硅 Default soiling
loss,yearly average默认年平均脏污损失
Default unavailability loss默认无效损失
Module strings shading ratio组串阴影率
Module strings thin film shading ratio组串薄膜阴影率
Grid inverter oversizing array/inverter nominal power并网阵列功率/逆变器裕度值
SolaredgePnom ratio sizing,0=STC,1=real conditions
Solaredge功率比定型0=标况，1=真实条件
Nominal medium voltage grid默认中压网络
DC grid:arrayVnom/system Vnom ratio直流网：组件电压/系统电压
Average pumping hours during a clear day晴空下平均抽水时间
Pumps lifetime(economical evaluation)水泵寿命
Fuel price (economical evaluation)燃油价格
Flowrate oversizing accounting for average days平均流量裕度值
Array current /pumps nominal current阵列电流/泵额定电流
Detailed simulation verification conditions详细模拟检定条件
Measured meteo in coll.plane:max.orientation difference
吸收平面测量数据最大方位差
Shading:max.orientation difference shaded #1-pv array遮光：遮光#1 阵列最大方位差
Shading:max.orientation difference between shading planes遮光：遮光平面允许最大方位差
Shadings with heterogeneous field:max.angle difference异形区域遮光最大角度差
Helios3D:max.angle between palnes Helios3D:平面间最大角度差
Shading:absolutemin.shading/field area ratio遮光：3D区域/系统定义区域绝对极小值
Shading:warningmin. shading/field area ratio遮光：3D区域/系统定义区域禁告极小值
Shading:warningmax.shading/field area ratio遮光：3D区域/系统定义区域禁告极大值
Shading:absolutemax.shading/field area ratio遮光：3D区域/系统定义区域绝对极大值
the inverter power is strongly oversized逆变器功率值严重过大
the inverter power is slightly oversized逆变器功率值轻微过大
acceptable overload loss for design可接受设计过载损失
limit overload loss for design设计过载损失限值
pv array/battery pack voltage：光伏阵列/蓄电池电压
strongly undersized/oversized光伏阵列/蓄电池电压严重过小/过大
slightly undersized/oversized光伏阵列/蓄电池电压轻微过小/过大
