ANNEX 1附录ⅠMANUFACTURE OF STERILE MEDICINAL PRODUCTS无菌药品的生产Principle原则The manufacture of sterile products is subject to special requirements in order to minimize risks of microbiological contamination, and of particulate and pyrogen contamination. Much depends on the skill, training and attitudes of the personnel involved. Quality Assurance is particularly important, and this type of manufacture must strictly follow carefully established and validated methods of preparation and procedure. Sole reliance for sterility or other quality aspects must not be placed on any terminal process or finished product test.为将微生物、微粒和热原污染的风险降低至最小限度，无菌药品的生产应有各种特殊要求。

这在很大程度上取决于生产人员的技能、所接受的培训及其工作态度。

质量保证极为重要，无菌药品的生产必须严格按照精心制订并经验证的方法及规程进行。

产品的无菌或其它质量特性绝不能仅依赖于任何形式的最终操作或成品检验。
