基于KNX总线的智能家居网关

更专业专业，是一种品质，一种承诺，更是一份安心。

TS-BUS智能家居控制系统基于KNX/EIB标准设计，整合家居和楼宇控制领域最先进的自获能式无线传感技术，通过对使用功能的模拟，结合使用者习惯，充分实现功能的同时，为客户提供更专业、更贴合需求的家居智能化解决方案。

家居智能化设计不应该是简单的功能堆砌，实用、适用、易用是TS-BUS方案设计的最高标准。

KNX 总线标准是住宅和楼宇控制领域唯一开放式国际标准，由欧洲三大总线协议EIB、BatiBus和EHS合并发展而来。

目前已被批准为欧洲标准（CENELEC EN 50090 & CEN EN 13321-1）、国际标准（ISO/IEC 14543-3）、美国标准（ANSI/ASHRAE 135）和中国标准（GB/Z 20965）。

基于KNX标准的控制系统能够实现对家居及楼宇的照明、遮光/百叶窗、供暖、通风、空调、安防、音频/视频控制、计量、能源管理、远程控制、大型家电等的全面控制。

TS-BUS提供基于KNX/EIB标准自主研发的各种智能模块。

EnOcean是一种基于微弱能量收集技术的无线通信标准。

TS-BUS基于EnOcean标准开发的自获能式无线传感器，能够从光、热、电波、振动、人体动作等获得微弱能量供电，而不需额外提供能量。

传感器利用868.3MHz频段进行无线通信，实现125Kbps的传输速率。

结合微弱能量收集技术和高效的无线通信技术，TS-BUS实现了真正便于安装和免维护的智能无线传感器。

KNX总线标准KNX总线标准更舒适舒适，源自细节的体贴，我们更在乎您的满意。

TS-BUS遵从以客户为中心的设计lining，通过对用户需求的深入理解，在充分实现用户的个性化需求的同时，提供性能卓越的家居智能控制系统。

持续的新产品研发与技术创新，为您提供专业的技术支持与服务保障。

TS-BUS，舒适生活的缔造者。

工作一天回到家，坐在沙发上，按下背景音乐按钮，很快传来舒缓的音乐，一天工作的疲倦，伴随着音乐渐渐散去……一首曲目的时间，浴缸已经放好了热水，打开沐浴场景，躺在浴缸里，轻快的音乐，配合舒适的灯光效果，一天的疲倦顿时烟消云散。

D-Controls IC5系列主机是智能家居系统中专用的中心服务器。

它包含完整的KNX通信系统，通过TCP/IP 方式与KNX总线进行交互通信，能够让KNX系统迅速接入局域网和Internet，实现KNX系统的远程控制与管理。

同时IC5可通过D-Controls Cloud (云服务平台）实现对KNX系统的远程控制与管理。

用户可以使用D-Controls App（iPad、iPhone、Android等）智能终端，实现控制灯光、窗帘、影音、中央空调、地暖、安防、监控、电梯、家用电器等等设备；同时可以实时监控各个设备运行状态。

每个用户拥有自己唯一的用户名或身份识别码，可自行修改密码，并支持通过手机短信或电子邮件自行找回密码；每个用户需要与控制主机的硬件序列号绑定后才能获得控制权限，一个控制主机有且仅有一位管理员，未经管理员同意其他用户无法获得控制权限；多个用户可以同时控制同一个主机，管理员拥有查看主机控制组成员列表、删除成员的权限。

D-Controls KNX IC5(Version 1.01)IC5标准版IC5升级版一、前言后使用。

安装电气施工1.1 为了您的安全，请严格遵守在使用前，请仔细阅读《为了您的安全，请严格遵守》，然后再安装。

能因实际情况不同而导致严重后果。

在安装完成之后，试运行，确认是否有异常情况，并依据本说明书对客户说明使用方法。

【符号的意思】• 本公司致力于不断地对产品进行改进，如有变化恕不另行通知。

• 本公司不提供将产品改作它用的服务。

• 未经过允许，本手册的任何部分均不得擅自复制。

采用64位A53做为核心CPU，4核心1.5GHz 1GB DDR3 RAM 1个KNX接口IC5升级版自带4路RS485串口及1路RS232串口，每路串口均可支持标准协议或自定义Modbus（RS485）协议1个RJ45端口，支持Ethernet 10/100/1000 Mbits/s，并可扩展为TCP/UDP、XML、HTTP等协议3路可扩展USB接口，每路USB均可支持D-Controls扩展模块***支持D-Controls SHCS系统软件，支持固件远程更新、远程访问、远程管理支持D-Controls Smarthome 2019 App版移动终端软件可编辑定时任务、命令转发任务、逻辑条件任务，并保存在主机内运行支持编辑信息远程推送，信息将推送至安装D-Controls Smarthome 2019 App软件的手机D-Controls Smarthome App可自动根据移动终端网络状态，自动切换远程控制或本地局域网控制可跨越多级路由器（域名）连接D-Controls Cloud云服务器，适应复杂的局域网环境支持移动网络（2G/3G/4G）路由器连接，实现远程控制无需动态域名解析、无需端口映射、无需固定IP，只需保证设备和手机能上网，就可实现远程控制自带系统恢复功能，在网络不稳定时可自动重启每RS485串口支持从D-Controls SHCS系统中直接导入驱动TCP/IP网口支持从D-Controls SHCS系统中直接导入无线系统或无线单品的驱动，例如nest、hue等设备***支持多台移动终端访问支持D-Controls Remote(遥控器）可扩展集成TCP/UDP协议、XML、HTTP、ArtNetIC5系列远程中控主机说明书：表示若错误作业，很可能导致使用者死亡或重伤。

- 34 -高 新 技 术0 引言当前，随着通信和互联网+技术的发展，网络正在改变整个世界，人类的生活正在发生翻天覆地的变化，随着智能楼宇的出现，不论是医院、高铁站、机场以及体育场等大型公共场所，还是都市居民家居生活，都逐渐开辟了现代生活新境界。

借助物联网高速推动人工智能发展，由云计算与大数据辅助工作，智慧生活的发展具有更强的可操作性和舒适性，物联网控制技术的发展将真正实现现代生活的高度智能化、信息化和人性化[1]。

1 控制要求1.1 系统概况控制器、传感器和执行器是总线设备的3种类型。

模拟量、开关量等信息利用总线完成报文发送，有效联通各个设备。

控制要求、信息校验和起始信息是KNX 报文的结构构成。

校验通过令牌环增加奇校验或者偶校验。

报文只能对物理地址进行识别，将数据的源地址表示出来，可以把组地址或者物理地址作为目标地址，表明数据的受体。

设备的物理地址是唯一的，但可以有多个组地址，表明通过多个控制源来控制1台设备[2]。

在调试物理地址时，将唯一目标逐一确定出来，按照设置的要求，在同一组内放置有关设备；此外，将组地址设定出来，将指令发送给组地址相同的设备，并执行动作。

在楼宇控制与家居领域中，KNX 属于唯一的国际化开放式标准，由欧洲三大总线协议EIB、BatiBus 和EHS 融合发展而来[3]。

KNX 有丰富的标准功能，可以在工业建筑以及功能性建筑中发挥重要作用，总线选择电力线、无线通信以及双绞线等作为通信介质，KNX/EIB 总线借助事件管控，通过这条总线完成电源控制与数据传输，其配置模式有S 型、E 型和A 型3种，通过改变报文数据发送的起始地址和奇偶校验标志，达到异步传输直流信号的目的。

系统最基本的单元称为线路，通常情况下在1条线路上可以挂接64个设备，设备电流不大于640 mA，设备编号为20~26-1[4]。

根据通信要求，每条线路的长度应小于1 000 m。

总线工作支持电源与设备之间的距离不宜过大，在700 m 之内控制各个设备间的基本距离，通过增加系统设备，将相应的总线设备数量增设进去，最多可以将28个总线设备增设到1条线路上（1条线路最多可以增加28个总线设备）。

KNX转zigbee网关模块一、产品概述：1、KNX转zigbee网关，是打通KNX网络到zigbee网络之间传输通道，接收并解析KNX协议，转换成zigbee控制协议，发送到zigbee网络。

2、适用场合：（1）通过KNX面板控制zigbee设备(灯光、窗帘、空调、场景等…)（2）通过KNX兼容软件控制zigbee设备（3）通过智能家居APP监控KNX相关设备操作、动作、状态等…KNX转zigbee模块产品特点：●安装简单：标准86盒嵌入式安装，零火线设计。

●穿透性强：可穿墙进行远距离遥控。

●互不干扰：采用ZigBee无线网络技术，组网能力强，功耗低，与附近同型号产品不会相互干扰。

●断电记忆：重新上电后，用户无需重新设置。

●网状网络：设备均具有路由功能，之间可以互相转发信号，实现大范围信号全覆盖，控制无死角。

从而可组建一个安全、可靠、稳定的无线网络。

●材质环保：进口ABS塑胶外壳包装，阻燃、低烟无毒、耐高温。

-----产品参数-----尺寸：50*50*20mm(L*W*H)供电电压：AC220-240V/50HZ工作频率：2.4GHz静态功耗：270mW工作环境：温度：-10～40℃；湿度：10%～95%通讯协议：ZigBee 2007/pro 协议频点设置：0x0B~0x1A(11-26)PANID设置：0x0000~0xFFFF(0~65535)组网方式：无线ZigBee组网上电自动组网网络协议：ZigBee IEEE 802.15.4加密方式：AES-128 位密钥动态加密二、KNX转zigbee网关接入设备工作流程图如下：1、220V交流电,AC线；2、KNX转zigbee模块的VCC线对应KNX的VCC的接线；3、KNX转zigbee模块的VCC线对应KNX的VCC的接线；4、KNX转zigbee模块的R（RXD）线对应接入设备的TXD的接线；5、KNX转zigbee模块的T（TXD）线对应接入设备的RXD的接线；6、KNX转zigbee模块的GND与对接入设备的GND的接线；7、KNX转zigbee模块的GND与对接入设备的GND的接线；。

KNX智能家居基础知识731. 简介KNX智能家居系统是一种基于开放标准的智能家居控制系统，它采用了一种统一的通信协议，允许不同的设备相互通信和控制。

本文将介绍KNX智能家居系统的基础知识及其应用。

2. KNX系统架构KNX系统由三个主要组成部分构成：KNX设备、KNX总线和KNX 软件。

2.1 KNX设备KNX设备是指连接到KNX总线上的各种智能家居设备，包括灯光控制器、温控器、窗帘控制器等。

这些设备可以通过KNX总线进行通信和控制。

2.2 KNX总线KNX总线是一种串行数据通信系统，用于连接KNX设备和KNX软件。

它支持多个设备同时通信，采用了开放的物理介质，如电力线、射频和以太网。

2.3 KNX软件KNX软件是用于配置和控制KNX系统的工具，通常由厂商提供。

用户可以使用KNX软件来配置设备、创建场景和设置定时任务等。

3. KNX智能家居应用KNX智能家居系统可以应用于各种场景，包括家庭、商业和工业领域。

以下是一些常见的KNX智能家居应用：3.1 照明控制通过KNX智能家居系统，用户可以方便地控制家中的照明设备。

可以通过手机应用或触摸屏幕控制灯光的开关、亮度和颜色等。

3.2 温控管理KNX智能家居系统还可以对室内温度进行智能管理。

用户可以通过温控器调整房间的温度，并根据自定义的时间表自动调节温度。

3.3 安防监控KNX智能家居系统可以与安防设备集成，实现对家庭安全的监控和管理。

例如，用户可以通过手机应用查看家中的监控摄像头，并设置警报和报警器。

3.4 窗帘控制通过KNX智能家居系统，用户可以自动控制窗帘的开合和角度。

可以根据天气情况、时间表或外部触发条件来调整窗帘的状态。

3.5 能源管理KNX智能家居系统还可以用于能源管理。

通过监控家中的能耗数据，用户可以优化能源使用，节约能源成本。

4. KNX智能家居系统的优势相比于其他智能家居系统，KNX智能家居系统具有以下优势：1.开放标准：KNX智能家居系统采用了开放的通信协议，允许不同厂商的设备相互兼容和通信。
