模具各部件常用术语中英文对照

模具各部件常用术语中英文对照

模具常用术语中英文对照

模芯Parting Core

局部视图Partial View

冷料# Cold Slag

线切割Wire E.D.M

轮廊Contour

螺纹孔Tapping Hole

连接件Fittings

斜针Angle Pin

接合Engage

替换镶件Interchangeable Mold Inserts 指定吨位的注塑机Specific Press

水嘴接头Water Fittings

螺纹Eyebolt Thread

回针Stop Pin

二级顶出针Sub-Leaderd Pin

镶件Mold Insert

加硬Harden

唧嘴Sprue

设计筒图Design Preliminary

名称块表Title Block

版本标识Revision Level

材料清单Stock List

制模Build Mold

手动滑块Hand Slide

漏水测试Leak Test

流道排气Runner Vents

抛光Draw Polish 侧抽芯Side Action

加强筋Reinforcing

三角撑Gusset

柱子Bossed

出模斜度Draft

外廊Contour

落单会议Kick-Off Meeting

装卸孔Handling Hole

运输安全带Mold strap(shipping strap) 码模槽Clamp Slot

撑头Support Pillar

螺牙1/2-13 Eye Bolt 1/2-13Tap

导柱位Leader Pin Location

耐落胶Teflon Paste 偏移量Offset

水塞Water Line Plug

撬模脚Pry Slot

重新加工Reworked

配件Components

补偿Compensation

平面度Parallel

倒角Chamfer

模胚Mold Base

热嘴Hot nozzle

火花机Edm

熔接线Weld line

压机Press

晒纹Texturing

梯形Trapezoid

凸缘、法兰Flange

方铁Spacer Block

顶针板Ejector Plate 顶针底板Ejector Retainer Plate

垫板Retainer Plate

后模镶针Core Pin

拉圾钉Stop Pin

有托顶针Shoulder Ejector Pin

顶针板导套Guided Ejection Bushing

针板导柱Guided Ejection Leader Pin 唧嘴Sprue Bushing

三板模延伸式唧嘴Extension Nozzle Bushing 水口板导套Runner Stripper Plate Bushing 定位圈（法兰）Locating Ring

管钉（定位销）Dowel Pin

管状管钉Tubular Dowel

吊环Safety Hoist Ring

日期印Dating Insert

环保印Recycling Insert

气顶Air Poppet Valve

截水口镶件Runner Shut-Off Insert

早回Early Ejector Return

加速项Accelerated Ejector

客户Client

产品名Part Name

产品编号Part No

缩水Shrinkage

版本Rev

模胚Mold Base

下模镶件Core Block

上模镶件Cavity Block

小镶件Sub-Insert

下模小镶件Core Sub-Insert

上模小镶件Cavity Sub-Insert

行位Slide 行位镶件Slide Insert

压条Gib

压紧块（铲机）Jaw

硬片（摩擦片）Wear Plate

水口铁Runner Bar

上模水口铁Upper Runner Bar

下模水口铁Lower Runner Bar

弹簧Spring

水口勾针Sprue Puller Pin

顶针Ejector Pin

撑头Support Pillar

直身锁Side Lock

斜度锁Interlock

锁模板Safety Bar

‘O’令（密封圈）O'Ring

喉塞Plug

隔水片Baffle

波子螺丝（行位定位螺丝）Ball-Catch

斜顶Lifter

控制开关Switch

回针Return Pin

斜导柱Angle Pin

推板Stripper Plate

A’板A'Plate

B’板B'Plate

方铁（垫铁）Spacer Block

顶针板Ejector Plate

顶针底板Ejector Retainer Plate

垫板Retainer Plate

垃圾钉Stop Pin 有托顶针Shoulder Ejector Pin 顶针板导套Guided Ejection

Bushing

针板导柱Guided Ejection Leader Pin 唧嘴Sprue Bushing

三板模延伸式唧嘴Extension Nozzle Bushing 水口板导套Runner Stripper Plate Bushing 定位圈（法兰）Locating Ring

管钉（定位销）Dowel Pin

管状管钉Tubular Dowel

吊环Safety Hoist Ring

日期印Dating Insert

环保印Recycling Insert

气顶Air Poppet Valve

截水口镶件Runner Shut-Off Insert

早回Early Ejector Return

加速顶Accelerated Ejector

扁顶Blade

出模斜波Draft

手动滑块模具Hand Slide-In Type Mold 回针板Backup

合模Shutoff

空隙槽Clearance Slot

导柱及导套Leader Pin Bushing

水口拉钩Spuer Puller

模框镶件Pocket Insert

成型热固性塑胶模具Thermoset Mold

三板模3-Plat Mold

分型面Parting Line

司筒Ejector Sleeve

垫圈Washer

熔接线（夹水纹） Weld line

吸针Sucker Pin

回针板Retainer Plate 顶出板Knock -Out Plate

电动安全开关Electrical-Safety Switch 脱开Cut Of Position

预先决定Preload

缓冲器Bumper

衬垫Cushion

公差Tolerance

突然性动作Slam

销针Dowel

钩槽Gib

精磨Finished

通框Through Window

粘后模Sticking Core

粘水口Sticking Sprue

夹水纹Weld Line

变形Warpage

走水不平均Filling Uneven 走不齐Short Shot

挂成品Part Hanging

漏水Water Leakage

刮花（擦伤）Galling

漏电Ele Leakage

困气Air Trapping

温度Temperature

注塑模Injection Mold

入水Gate

试板Sampling

压力Pressure

倒圆Fillet

顶棍Ejector

顶白Stress Mark

粘前模Sticking Cav 名称块表Title Block

版本标识Revision Level

材料清单Stock List

斜导柱（斜边）Angle Pin

A板 A'plate

B板 B'plate

倒扣Undercut

披峰Flash

缩水Sink Mark

氮化Nitride

不规则四边形Trapezoid

缩水Shrinkage

连续的Consecutive

雕刻Engrave

出模角Draft

分模面Parting Surface

擦位Shut-Off(S/0)

导套Bushing

回针Return Pin

加硬Harden

唧嘴Sprue

设计筒图Design Preliminary 丝印Silkprint

不干胶Adhesive Sticker 导向针Guide Din

公差Tolerance

线切割Wire-Cut

电火花Edm 抛光Polishing

蚀纹Texture

探热针Thermocouple

三打螺丝毫（限螺丝）Stripper Bolt 盖板Cover Plate

齿轮Gear
