____________________________________________________________________________________________Transfer PumpsTransfer Gear Pumps KF | BT-Pumps | Duro Tec-Pumps | Pressure Relief Valves | Special PumpsHigh economy, optimal efficiency and silent inoperation.These are all important features which particularlycharacterize our transfer pumps.Compact design, low weight, solid construction andworkmanship anti-wear coatings, application specificmaterials, size and seal variants, as well as numerousaccessories and type of connections are additionalreasons which make KRACHT transfer gear pumps morethan interesting for every user. And this is our motto forevery type of pump: only the best is good enough.Valid for all pump construction lines is: We aren’thappy until the optimum has been achieved.1 2Transfer Gear Pump KF 4 (80)Transfer Gear Pump KF 3/100…KF6/630 HousingGearBearingConnectionDisplacementOperatingpressureSpeedApplicationsGrey cast iron (spheroidal cast iron, optional) Steel Stratified plain bearing (Plastic slide bearing, optional) KF4…25 Pipe connection or SAE-Flange connection KF32…80 SAE-Flange connection 4…80 cm 3 / r … 25 bar … 3000 l / min Pumping of lubricants in ship engines Pumping of lubricants in wind power plants Pre-lubrication and main lubrication of diesel motors Pumping of compressor lubricants Oil supply in filter systems Dosing of polyurethane components1 Housing Gear Bearing Displacement Operating pressure Speed Applications Grey cast iron Steel Stratified plain bearing 100…630 cm 3 / r … 25 bar … 2000 l / min Pumping of lubricants in ship engines Pumping of lubricants in wind power plants Pre-lubrication and main lubrication of diesel motors Pumping of compressor lubricants Oil supply in filter systems Dosing of polyurethane components 2DEWEI (HONGKONG) INDUSTRIAL CO. Tel: +852-3178 0960 Fax: +852-******** website E-mail hayes@____________________________________________________________________________________________Transfer Gear Pump KF 0HousingGearBearingDisplacementOperatingpressureSpeedApplications Grey cast iron Special steel with wear-resistant and corrosion- resistant coating Plain bearing bushes from special steel with wear-resistant and corrosion-resistant coating 0.5…4 cm 3/r … 120 bar … 2000 l/min Pumping of lubricantsDosing of polyurethane components1Transfer Gear Pump KF1/4…KF1/24 coatedHousing Gear Bearing Displacement Operating pressure SpeedApplications Grey cast ironBearing bushes made of with special steel withwear-resistant and corrosion- resistant coatingSpecial steel with wear-resistant and corrosion-resistant coating4…24 cm 3 / r… 50 bar… 2000 l / min Dosing of polyurethane components21 Transfer Gear Pump BT 0… BT 723 HousingGearBearingDisplacementOperatingpressureSpeedApplications Grey cast iron (Sizes 0…7) Bronze (Sizes 1…4) Stainless steel (Size 2) Steel (Sizes 1…7) Stainless steel (Sizes 1…4) w/o bearing bushes (Sizes 0…4) Iron bearing bushes (Sizes 1…7) Bronze bearing bushes (Sizes 1…7) 4…494 cm 3 / r … 8 bar … 700 l/min Pumping of bitumenPumping of paints/inks/varnishes, etc.Pumping of gluePumping of resin 3DEWEI (HONGKONG) INDUSTRIAL CO. Tel: +852-3178 0960 Fax: +852-******** website E-mail hayes@Transfer Gear Pump KP Duro TecHousingGearBearingDisplacementOperatingpressureSpeedApplications Spheroidal cast iron Special steel with wear-resistant and corrosion- resistant coating Special ceramic and steel goggle-type bearings 5.5…22 cm 3 / r … 150 bar … 1500 l / min Dosing of media with abrasive additives1Pressure Relief Valve SPV 10 / SPV 25 (80)Pressure Relief Valve HV / HVFHousingValve cone materialMax flow volumesOperating PressureApplications Grey cast iron Steel 40…800 l/min …160 bar System protection of lubrication systems 1222.1____________________________________________________________________________________________DEWEI (HONGKONG) INDUSTRIAL CO. Tel: +852-3178 0960 Fax: +852-******** website E-mail hayes@Flow MeasurementGear Type Flow Meter VC | Turbine Flow Meters | Evaluation Electronics | VOLUMECGear Type Flow Meter VCVC 0.025…VC 16, made of cast ironVC 0.025…VC 5, made of stainless steelMeasuring rageMeasuring ratioOperatingpressureTemperaturerangeMeasuringaccuracyElectrical outputApplications0.008…700 l / minUp to 1:300…400 bar- 30oC - + 220oC (- 22 - + 428oF)Up to + / - 0.3% deviation from measured value2 incremental signals90o out of phaseCurve tracing of hydraulic componentsFilling of gear lubricantsIndirect, volumetric cylinder stoke measurementConsumption measurement of inksRatio measurement in dosing plants for 2- andmultiple component media1Gear Type Flow Meter VCA / VCNVCA 0.04 / VCA 0.2 / VCA 2 / VCA 5, aluminiumVCN 0.04 / VCN 0.2, stainless steelFlow Measurement-that means high-dynamic,precise volume and flow measurements,evaluated according to the application-from asimple display unit to an intelligentmicrocontroller solution.The basis for all this is the KRACHT volumecounter .This flow measure product presents thesuccessful result of our long-experiencedengineers .The sophisticated tooth system geometryin connection with application-specific bearings aremade for the volume counter being an absolute”All-rounder”.The volume counter covers a wide medium range :togo from hydraulic oil to printing ink ,from gear greaseto water based lacquer.The highly-efficient KRACHT electronics takes thesignals given by the volume counter and ensuresthat processes are exactly monitored ,regulated andcontrolled .For example ;in process technology asmicro-controller for metering and mixing systems ,oras flexible measuring and recording electronics fordifferentiated applications is test bench technology.KRACHT’ s know-how warrants functional so-lutions, standardized and optimal for manyapplicationsMeasuring rageMeasuring ratioOperatingpressureMeasuringaccuracyElectrical outputApplications0.02…200 l / minUp to 1 : 200…160 barUp to + / - … 1% deviation from measured value1 incremental signalLubrication oil controlMeasuring of fuel consumptionCylinder stroke measurement21 1.12 DEWEI (HONGKONG) INDUSTRIAL CO. Tel: +852-3178 0960 Fax: +852-******** website E-mail hayes@____________________________________________________________________________________________Insertable Display Unit SD 1Local display of all KRACT flow metersWith plug connection according to DIN EN 175301-803With 4-digit LED display for flow rate or volumeMicrocontroller AS 8 Control unit in control panel housing 5-digit LED display for flow rate or volume Output Voltage supply+ / - 20 mA or 0 … 20 mA or 4 … 20mA or + / - 10 V output Or 0 … 10 B or serial interface RS 232 230 V, 50 / 60 Hz or 120 V, 50 / 60 Hz or 24 VDC or 12 VDC Power supplyDisplayTouch panelHousingDegree of protectionConnectionsOutputOption 18 VDC – 28 VDC Optional 10 – 19 VDC Principle: 7-segment LED, 7.62 mm, red Display: 0.000 … 9999 with floating point Overflow: (>9999) display 9999 Two buttons behind a screen Aluminium (DIN 40050) IP 65 Right angle plug DIN 43650 (4-pole), polarized SD1-R incremental output SD1-L analogue output 0 – 20 mA or 4 – 20 mA SD1-K 2 relay contacts 24 VDC / 1A SD1-Service with battery pack 1Special software for the following applications:- Flow control- Dosing - Cylinder stroke measurement and monitoring- Display and monitoring of added amounts- Display and monitoring of differential amounts- Display and monitoring of mixing ratio- Display and control of mixing ratio212____________________________________________________________________________________________ DEWEI (HONGKONG) INDUSTRIAL CO. Tel: +852-3178 0960 Fax: +852-******** website E-mail hayes@Mobile HydraulicsHigh Pressure Gear Pumps and Motors | Valves for Mobile ApplicationsHigh-pressure Gear Motors KMDisplacementOperating pressureSpeed range1…300 cm3 / r…350 bar…6000 l / minWhen you need to produce and control high pressures ,forces andtorques permanently for mobile applications ,then there are somepreconditions:- Robust ,service-friendly technology- Small size- Low weight- As flexible multiple use of a component as possible- Easy handling and operationThe KRACHT mobile hydraulics components meet theserequirements exemplarily. A glance at the technical data willconvince you.Pumps available in aluminium, gray cast iron, ductilegraphite, flow divider, fan drive system withthermostatic valve.1High-pressure Gear Pumps KPWith hydraulic axial clearance compensation1DisplacementOperating pressureSpeed range1…300 cm3 / r…350 bar…6000 l / minManifold pump combinations with a common suctionconnection.2Pressure, Flow and Stop Valves23- Check valves pressure regulators- Flow control valves- Hydraulic proportional remote control- One-way restrictors- Over-center valves- Pressure relief valves- Shuttle valves- Stop valves3____________________________________________________________________________________________ DEWEI (HONGKONG) INDUSTRIAL CO. Tel: +852-3178 0960 Fax: +852-******** website E-mail hayes@。
