MAX4040–MAX4044
Ordering Information
PART MAX4040EUK-T TEMP RANGE -40°C to +85°C -40°C to +85°C -40°C to +85°C -40°C to +85°C -40°C to +85°C -40°C to +85°C -40°C to +85°C -40°C to +85°C -40°C to +85°C -40°C to +85°C PINPACKAGE 5 SOT23-5 8 µMAX 8 SO 8 SO 8 µMAX 8 µMAX 8 SO 10 µMAX 14 SO 14 SO SOT TOP MARK ACGF — — — — — — — — —
元器件交易网
19-1377; Rev 1; 9/05
Single/Dual/Quad, Low-Cost, SOT23, Micropower Rail-to-Rail I/O Op Amps
________________General Description
The MAX4040–MAX4044 family of micropower op amps operates from a single +2.4V to +5.5V supply or dual ±1.2V to ±2.75V supplies and have rail-to-rail input and output capabilities. These amplifiers provide a 90kHz gain-bandwidth product while using only 10µA of supply current per amplifier. The MAX4041/MAX4043 have a low-power shutdown mode that reduces supply current to less than 1µA and forces the output into a high-impedance state. The combination of low-voltage operation, rail-to-rail inputs and outputs, and ultra-low power consumption makes these devices ideal for any portable/battery-powered system. These amplifiers have outputs that typically swing to within 10mV of the rails with a 100kΩ load. Rail-to-rail input and output characteristics allow the full powersupply voltage to be used for signal range. The combination of low input offset voltage, low input bias current, and high open-loop gain makes them suitable for lowpower/low-voltage precision applications. The MAX4040 is offered in a space-saving 5-pin SOT23 package. All specifications are guaranteed over the -40°C to +85°C extended temperature range.
ELECTRICAL CHARACTERISTICS—TA = +25°C
(VCC = +5.0V, VEE = 0V, VCM = 0V, VOUT = VCC / 2, SHDN = VCC, RL = 100kΩ tied to VCC / 2, unless otherwise noted.) PARAMETER Supply-Voltage Range Supply Current per Amplifier Shutdown Supply Current per Amplifier Input Offset Voltage Input Bias Current Input Offset Current Differential Input Resistance Input Common-Mode Voltage Range Common-Mode Rejection Ratio Power-Supply Rejection Ratio Large-Signal Voltage Gain Output Voltage Swing High Output Voltage Swing Low Output Short-Circuit Current Channel-to-Channel Isolation SYMBOL VCC ICC ICC(SHDN) VCC = 2.4V VCC = 5.0V SHDN = VEE, MAX4041 and MAX4043 only VEE ≤ VCM ≤ VCC (Note 1) (Note 1) VIN+ - VIN- < 1.0V VIN+ - VIN- > 2.5V Inferred from the CMRR test VEE ≤ VCM ≤ VCC 2.4V ≤ VCC ≤ 5.5V (VEE + 0.2V) ≤ VOUT ≤ (VCC - 0.2V) Specified as VCC - VOH Specified as VEE - VOL Sourcing Sinking Specified at DC, MAX4042/MAX4043/MAX4044 only RL = 100kΩ RL = 25kΩ RL = 100kΩ RL = 25kΩ RL = 100kΩ RL = 25kΩ 74 MAX404_EU_ All other packages VEE 65 70 75 94 94 85 94 85 10 60 10 40 0.7 2.5 80 60 90 VCC = 2.4V VCC = 5.0V MAX4044ESD VOS IB IOS RIN(DIFF) VCM CMRR PSRR AVOL VOH VOL IOUT(SC) MAX404_EU_ All other packages CONDITIONS Inferred from PSRR test MIN 2.4 10 14 1.0 2.0 ±0.20 ±0.25 ±0.20 ±2 ±0.5 45 4.4 VCC 5.0 ±2.0 ±2.5 ±1.50 ±10 ±3.0 20 TYP MAX 5.5 UNITS V µA µA mV mV nA nA MΩ kΩ V dB dB dB mV mV mA dB
____________________________Features
♦ Single-Supply Operation Down to +2.4V ♦ Ultra-Low Power Consumption: 10µA Supply Current per Amplifier 1µA Shutdown Mode (MAX4041/MAX4043) ♦ Rail-to-Rail Input Common-Mode Range ♦ Outputs Swing Rail-to-Rail ♦ No Phase Reversal for Overdriven Inputs ♦ 200µV Input Offset Voltage ♦ Unity-Gain Stable for Capacitive Loads up to 200pF ♦ 90kHz Gain-Bandwidth Product ♦ Available in Space-Saving 5-Pin SOT23 and 8-Pin µMAX® Packages
VEE 2
Pin Configurations
TOP VIEW
OUT 1 5 VCC
MAX4040
IN+ 3
4
IN-
µMAX is a registered trademark of Maxim Integrated Products, Inc.
SOT23-5 Pin Configurations continued at end of data sheet.
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
________________________________________________________________ Maxim Integrated Products
1
